Year of construction: 2025, condition: refurbished (used), functionality: fully functional, machine/vehicle number: 3649, Country of manufacture: Switzerland Voltage: 380 V / 50 Hz / 3 Phases Net weight: approx. 445 kg Dimensions: 730 x 780 x 1380 mm Customs tariff number: 8459.6130 TECHNICAL SPECIFICATIONS Maximum distance between stops: 80 mm Maximum cutting length: 50 mm Maximum cutting diameter (with 24 mm dia. cutter): 36 mm Maximum module: 1 Number of teeth cut – with 1:4 ratio: 6-100 with 1:10 ratio: 6-200 Total rapid approach and plunge travel: 8 mm Maximum axial movement travel of the cutter: 10 mm Maximum plunge cutting travel: 2.5 mm Maximum movement of counter-spindle quill: 25 mm Fjdpfx Aow Uc Tbefpsgh Maximum distance between workpiece axis and cutter axis: 30 mm Maximum cutter diameter: 32 mm Quill body diameter: 35 mm Continuously adjustable slide feed rate: 0-60 mm/min Constant rapid return feed rate of the slide: 3 m/min 8 spindle speeds: 660–5300 rpm Horizontal tilt of the cutter head: approx. 4° Cutter motor power (2 speeds): 0.37/0.59 kW Hydraulic pump motor power: 0.24 kW Coolant pump motor power: 0.07 kW Hydraulic oil tank capacity: 13 l Cutting oil tank capacity: 10 l Quill oil tank capacity: 10 l All technical data provided without guarantee and subject to errors or omissions.

Condition: ready for operation (used), Five older thread milling machines Mikron are available, 3x Hydraulic Thread Milling Machine Mikron 132.02, 1x Mikron 132-01, 1x Mikron 104-01 and 1x Short Thread Milling Machine Mikron 106.01, an on-site inspection is possible. Fsdpsw Sxyxsfx Afpsgh

Year of construction: 2007, condition: used, gear hobbing diameter - external 1200 mm gear hobbing diameter - internal 1200 mm gear hobbing width -max. 260 mm control Liebherr PC-NC max. workpiece diameter 1500 mm table diameter 900 mm table bore diameter 320 mm max. table load 95 kN power capacity 30 kW coolant pump 120 l/min Axial distance between thrust spindle - table 0-820 mm Shaping spindle diameter 125 mm tool taper SK 45 DIN weight of the machine ca. 26 t dimensions of the machine ca. 8,073 x 6,183 x 4,375 m Strokes: - Stroke length min./max. - 0 mm / 270 mm Fgedpfow Rf S Esx Afpjh - Stroke length adjustability - 270 mm - Stroke rate (double strokes) - 10 to 270 DH/min Equipment/accessories: - Chip conveyor - Cutting wheel holder SK 45 DIN - Cooler - Technical documentation

Year of construction: 2009, condition: used, gear hobbing diameter - external 1200 mm gear hobbing diameter - internal 1200 mm gear hobbing width -max. 260 mm control Liebherr PC-NC max. workpiece diameter 1500 mm table diameter 900 mm table bore diameter 320 mm max. table load 95 kN Fgjdsw Rf R Ujpfx Afpsh power capacity 30 kW coolant pump 120 l/min Axial distance between thrust spindle - table 0-820 mm Shaping spindle diameter 125 mm tool taper SK 45 DIN weight of the machine ca. 26 t dimensions of the machine ca. 8,073 x 6,183 x 4,375 m Strokes: - Stroke length min./max. - 0 mm / 270 mm - Stroke length adjustability - 270 mm - Stroke rate (double strokes) - 10 to 270 DH/min Equipment/accessories: - Chip conveyor - Cutting wheel holder SK 45 DIN - Cooler - Technical documentation

Condition: good (used), Year of construction: 1979, machine/vehicle number: 1137.05, Used tool grinding machine Manufacturer: KAPP Model: AST305B Year of manufacture: 1979 Fedpfjwzk R Nsx Afpsgh Serial number: 1137.05 With accessories

Year of construction: 2022, operating hours: 6,941 h, condition: used, machine/vehicle number: 1700846, Max. workpiece diameter: approx. 225 mm, travel distances: X-axis: max. approx. 500 mm, Z-axis: max. approx. 300 mm, control unit: REXROTH IndraControl V, 1 air filtration unit IFS E200D, year of manufacture: 2022, serial no.: 567880-3, net weight: approx. 160 kg, connected load: 400 V, 50/60 Hz, 0.85 kW, 2.5 A, 1 chiller unit RITTAL SK3334400, year of manufacture: 2022, serial no.: 2022K000051653, connected load: 3 phases, 380-415 V/50 Hz, 2.49 kW, flow rate: approx. 15 l/min, 1 coolant lubricant filtration unit FES AF2X4, 0KM/S, year of manufacture: 2022, serial no.: 38/22, tank volume: approx. 950 l, control unit: SIEMENS Simatic HMI Touch, 1 magnetic separator Fgodjwv Tiqopfx Afpeh

Year of construction: 2022, operating hours: 5,194 h, condition: used, machine/vehicle number: 4700417, Max. rolling force: approx. 400 kN, max. rolling speed: approx. 500 mm/s, max. workpiece length: approx. 300 mm, workpiece diameter: approx. 10–50 mm, control: PROFIROLL/RITTAL/SIEMENS Sinumerik 840D, 1 two-door steel cabinet, contents: various machine tools and spare parts, Note: further data to be researched Fgjdpfowv Tkbjx Afpsh

Condition: used, Technical details: z-travel: 1250 mm Fedpfx Afjv U Un Hjpsgh swing diameter over bed: 260 mm workpiece dia. over bed: 500 mm workpiece dia. over support: 250 mm center height over bed: 260 mm hobbing length: 2000 mm module max. : 8 / 12 total power requirement: 9,5 kW weight of the machine ca.: 3,8 t

Condition: used, Technical details: center height over bed: 260 mm workpiece dia. over bed: 500 mm workpiece dia. over support: 250 mm Fgjdev U T Dyopfx Afpeh hobbing length: 2000 mm number of teeth: 2 - 50 feed:: 0,023 - 5,17 / mm/min module max. : 8 / 12 spindle bore diameter: 102 mm workpiece rpm : 18 - 224 U/min tailstock quill adjustment: 100 mm total power requirement: 9,5 kW weight of the machine ca.: 5,2 t dimension machine xH: 3,6 x 2,1 x 2,0 m

Year of construction: 1999, condition: ready for operation (used), Module size: 5mm, max. workpiece diameter: 180mm, axial travel: 400mm, shank travel: 200mm, milling cutter diameter: 150mm, tool speed: 2250rpm, table speed: 250rpm, max. tool clamping length for bore milling cutter/end milling cutter: 236mm/360mm, control: Liebherr PC-NC. Documentation available. On-site inspection is possible. Fjdpevpviujfx Afpjgh
