ATS Pressenservice und Vertriebs GmbH

Condition: good (used), Year of construction: 1994, Pressure: 315 t Stroke: 20-150 mm Adjustable ram stroke min./max.: 20 - 150 mm Table size: 1780 x 1250 mm Ram area: 1500 x 1000 mm Hfsdpsz Ai Igsfx Ac Aol Total power requirement: 75 kW Machine weight approx.: 46 t Additional information: - Installation height with max. stroke, adjustment at the bottom, installation at the top: 00 mm - Table opening: 1200 x 300 mm - Recess in the table: 1300 x 400 x 80 mm - Stroke rate continuously adjustable: 20-120 strokes/min.

Condition: ready for operation (used), Year of construction: 2002, functionality: fully functional, pressing force: 315 t, Equipment: documentation/manual, Bed size (x-y/mm) 2150 x 1200 Hfjdpjzzw N Nofx Ac Aol Ram dimensions X-Y (mm) 2000 x 1200 Stroke (mm) 300 Slide adjustment (mm) 200 Strokes per minute 5 - 50 Side window dimensions (x-y/mm) 800 Motor power (kW) 34.5

Condition: used, Year of construction: 1987, Kapasite : 300 ton Hava Tüketimi: 30 m³/saat Güç: 38 kW Kapladığı Alan: 13,20 m² Üst Tabla Ebatları : 1800 x 900 mm Hjdpfx Acozxra Ro Asfl Alt Tabla Ebatları : 1300 x 1200 mm Pres Yükseklik : 4.000 mm Pres En : 2.200 mm Pres Genişlik: 1500 mm Dakikadaki Vuruş Sayısı : 40 spm used

Condition: used, Year of construction: 1998, machine/vehicle number: 098211, KP09 Üretim Markası: OMERA H TİPİ EKZANTRİK PRES Makinenin Üretim Yılı: 1998 Kapasite : 500 TON Hava Tüketimi (m3/saat) : 30 Güç (KW) : 70 Kapladığı Alan (m2) : 44,12 Hfodpfezxq Uysx Ac Aol Lokasyon: KOCAELİ/ÇAYIROVA Üst Tabla Ebatları : 268 cm x 135 cm Alt Tabla Ebatları : 270 cm x 135 cm Pres Yükseklik : 5,25 m Pres En : 4,10 m Pres Genişlik: 2,05 m Dakikadaki Vuruş Sayısı : 55 spm Sac sürücü, Sac açıcı ve Sac doğrultucu Markası : Dimeco

Condition: used, Year of construction: 2017, machine/vehicle number: H 28 16 0401, KP13 Üretim Markası: ALES PRES H TİPİ EKZANTRİK PRES Makinenin Üretim Yılı: 2017 Kapasite : 500 TON Hava Tüketimi (m3/saat) : 30 Güç (KW) : 75 Hfedpezxq Tcsfx Ac Asl Kapladığı Alan (m2) : 108,16 Lokasyon: KOCAELİ/ÇAYIROVA Üst Tabla Ebatları : 377 cm x 160 cm Alt Tabla Ebatları : 350 cm x 160 cm Pres Yükseklik : 6,5 m Pres En : 5,2 m Pres Genişlik: 3,2 m Dakikadaki Vuruş Sayısı : 70 spm Sac sürücü, Sac açıcı ve Sac doğrultucu Markası : Coiltech used

Condition: used, Year of construction: 1997, KP03 Üretim Markası: OMERA H TİPİ EKZANTRİK PRES Makinenin Üretim Yılı: 1997 Kapasite : 500 TON Hava Tüketimi (m3/saat) : 30 Güç (KW) : 70 Hfedpfxozxq N Dj Ac Ajl Kapladığı Alan (m2) : 44,12 Lokasyon: KOCAELİ/ÇAYIROVA Üst Tabla Ebatları : 268 cm x 135 cm Alt Tabla Ebatları : 270 cm x 135 cm Pres Yükseklik : 5,25 m Pres En : 4,10 m Pres Genişlik: 2,05 m Dakikadaki Vuruş Sayısı : 55 spm Sac sürücü, Sac açıcı ve Sac doğrultucu Markası : Dimeco used

Condition: excellent (used), Year of construction: 1973, Description to follow! Hjdpfx Acozxh S Ns Ajfl

Condition: used, Year of construction: 1998, machine/vehicle number: SN: 5-2067, functionality: unexamined, power: 45 kW (61.18 HP), pressing force: 255 t, overall weight: 24,800 kg, PME Erfurt, Type: ZH 2500 / 1600, Serial No.: 5-2067, Year: 1998, 2500 kN, in operation until December 2025 Technical data of the press according to the nameplate: Press force: 2,500 kN Stroke rate: 25-75 strokes/min Rated stroke rate: 40 strokes/min Stroke: 20-200 mm Hedpfozvcxlox Ac Asfl Ram adjustment: 140 mm Total power: 45 kW Operating voltage: 400 V Frequency: 50 Hz Machine weight: 24,800 kg Strip feeding system consisting of: PBK, Type: Roller feeder WV-120/DSM 500P, Serial No.: BA00482, Year: 1998, PBK, Type: Straightening machine, Year: unknown, PBK, Type: Unwinding reel SCi 530 M, Serial No.: BA00482, Year: 1998 including enclosure and roller conveyor with peripherals: - Conveyor system Functionality and technical data have not been verified. without additional items/without further accessories, unless explicitly stated as part of the item. If interested, please contact us by email.

Condition: ready for operation (used), functionality: fully functional, pressing force: 70 t, table width: 495 mm, table length: 650 mm, TECHNICAL DETAILS Pressing force: 70 t Stroke, min.: 10 mm Stroke, max.: 90 mm Hfsdpozrmm Sjfx Ac Aol Table length: 650 mm Table width: 495 mm Column width: 400 mm MACHINE DETAILS Control system: CNC Dimensions & Weight Dimensions (L x W x H): 2,650 x 1,600 x 3,350 mm Dry weight: 9,000 kg Shipping packages: 4 pcs. EQUIPMENT Documentation

Condition: excellent (used), Year of construction: 1999, functionality: fully functional, KYORI Hfodpfozrkvkox Ac Ajl BEAT-40N Capacity: 40ton SPM: 300~1000 Stroke Length: 25mm Die Height: 197mm Stroke Adjustment: 20mm Maximum Material Width: 100mm Including its original feeder Fully working condition

Condition: excellent (used), functionality: fully functional, power: 37 kW (50.31 HP), pressing force: 300 t, stroke length: 30 mm, AIDA HMX-300 High-Speed Press Slide Stroke: 30mm SPM: 100~300 Die Height: 420mm Slide Adjustment: 60mm Slide Area: 2000 x 750mm Hsdezrkiwopfx Ac Ajfl Bolster Area: 2000 x 1000mm Main Motor: 37kW [Feeder Spec] Manufacturer: AIDA (Original) Type: Roll Feeder Model Number: RCF-35F Feed Length: 36~350 Height of Feeding Line: 190~220 Material Thickness: 0.5~0.6mm Material Width: 50~350mm Including S-LOOP and Uncoiler

Condition: excellent (used), Year of construction: 1997, machine/vehicle number: 30ESS024, functionality: fully functional, power: 5.5 kW (7.48 HP), pressing force: 30 t, stroke length: 25 mm, ISIS 30-Ton High-Speed Precision Press – Operating Video This video shows the ISIS 30-ton high-speed press in operation. The machine is equipped with an original ISIS NC feeder and is suitable for high-speed precision stamping applications. Press Specifications Manufacturer: ISIS, Japan Model: 8400 Frame No.: 30ESS024 Capacity: 30 tons Slide Stroke: 25 mm Speed: 150–800 SPM Slide Adjustment: 30 mm Die Height: 252 mm (220 mm) Bed Size: 500 × 500 × 100 mm Bed Opening: 360 × 80 mm Main Motor: 5.5 kW Year of Manufacture: October 1997 NC Feeder Specifications Manufacturer: ISIS Model: 610NH Feed Length: 0.5–150 mm Feed Level: 70–110 mm Maximum Material Width: 60 mm Maximum Material Thickness: 1.6 mm Motor: 1.5 kW The machine is available for sale. For pricing, machine condition, additional photos, specifications, and export inquiries, please contact us directly. Follow our Instagram account for newly available machines, operating videos, and regular equipment updates. Hfodpfszrkbysx Ac Ajl

Condition: excellent (used), Year of construction: 2008, Mossini press Drive: Servo Pressing force: 2,000 kN Stroke adjustment: 20 - 100 mm Stroke rate: 30 - 90 strokes/min Ram adjustment: 100 mm Tool installation height: 455 mm Hfjdpfezl R Hvsx Ac Ael Year of manufacture: 2008

Condition: ready for operation (used), Year of construction: 1998, machine/vehicle number: 8900, functionality: fully functional, pressing force: 20 t, stroke length: 60 mm, throat depth: 176 mm, ram adjustment: 55 mm, stroke rate (max.): 155 1/min, TECHNICAL DETAILS Press force: 20 t Stroke rate: 155 strokes/min Hedpfx Aezb Du Hsc Ajfl Ram stroke: 6 - 60 mm Ram adjustment: 55 mm Ram contact area: 130 x 248 mm Pin hole in ram: 25 x 65 mm Inclination: 28° Overhang: 176 mm Distance from table to ram: 270 mm Passage width: 470 mm Table dimensions: 300 x 450 mm Through hole in table: 90 mm Table height above floor: 775 mm Air pressure (required): 5.5 - 6 bar MACHINE DETAILS Total power consumption: 3.5 kW Control type: conventional Dimensions & Weight Machine dimensions (L x W x H): 1,300 x 1,100 x 1,950 m Machine weight: 1 t EQUIPMENT High-performance press Central lubrication with light curtain (monitored) Linuflex Stroke counter Steel plate (dimensions: 315 x 400 x 50 mm) with center hole (diameter: 63 mm)

Condition: used, Year of construction: 1977, Pressure total: 800 ton Ram stroke: 700 mm Slide adjustment: 600 mm Shut height (stroke down, adjustment up): 1500 mm Free frontal opening L-R: 3800 mm Free lateral opening F-B: 1450 x 1100 mm Table surface area : 3500 x 1900 mm Slide area: 3500 x 1900 mm Hedpfx Asyxmulec Aofl Die cushion capacity in table: 150 ton Die cushion stroke: 250 mm Die cushion pad area: 2780 x 1570 mm Number of strokes: 7 - 18 s.p.m. Required power: 120 kW Height over floor approx.: 9510 mm Weight of machine approx.: 260 ton

Condition: excellent (used), Year of construction: 2016, Specifications Manufacturer: IMV Model: DM125 Year: 2016 Condition: Used Stock number: 0396 Ram force: 1,250 t Number of press points: 2 Drive: Eccentric with stroke adjustment Ram stroke: 250–400 mm Strokes/min: 5–35 Vertical daylight below bolster, CBRA: 1,150 mm Table dimensions: 4,500 x 2,000 mm Hjdpeyw Uf Asfx Ac Ajfl Ram dimensions: 4,500 x 2,000 mm Side column window: 2,600 mm Max. front column window: 4,900 mm Transfer cart: 2 units present Main motor power: 290 kW Press weight: 310,000 kg

Condition: used, Year of construction: 1998, machine/vehicle number: 1 / 2000, Pressure total: 2000 ton Ram stroke: 900 mm Slide adjustment: 800 mm Shut height (stroke down, adjustment up): 1800 mm Free frontal opening L-R: 5040 mm Distance between oil tray: 4840 mm Distance between the columns F - B: 2600 x 2400 mm Table surface area : 5000 x 2700 mm Slide area: 5000 x 2700 mm Die cushion capacity in table: 400 ton Die cushion stroke: 350 mm Die cushion pad area: 4200 x 2100 mm Cushion pressure in ram: 200 ton Ejector stroke in ram: 200 mm Hfsdpfx Asyvz U Iec Aol Number of strokes: 8 - 14 s.p.m. Required power: 350 kW Height over floor approx.: 11350 mm Die weight at the ram max.: 40000 kg Die Weight total: 80000 kg Weight of machine approx.: 580 ton Standard configuration Moving bolster front sidePin diameter 52 mmForce in microinches = 400 tA SIEMENS control system is installed The documentation is available.A packing list would be available, as an identical press has already been dismantled.

Condition: used, Year of construction: 1985, Pressure total: 250 ton Ram stroke: 70 / 250 mm Slide adjustment: 160 mm Ejector in ram: 20 ton Ejector stroke in ram: 10 mm Shut height (stroke down, adjustment up): 520 mm Free lateral opening F-B: 1.300 mm Table surface area : 1.600 x 1.600 mm Slide area: 1.600 x 1.600 mm Number of strokes: 0 - 50 s.p.m. Required power: 33 kW Height over floor approx.: 5.500 mm Hfjdpoyvkuksfx Ac Asl Weight of machine approx.: 58 ton Roll feeder Material width: 1250 mm Material thickness: 0,3 - 1,6 mm Control: Siemens S7

Condition: used, Year of construction: 1950, pressure 500 t distance between columns 1600 mm stroke 60 mm max. ram stroke 60 1 / min ram adjustment 100 mm dayligth 700 mm Table area 1600x1400 mm Hfedeyutvyopfx Ac Ael ram surface 1400x1150 mm weight of the machine ca. 40 t The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, Year of construction: 2008, pressing force: 300 t, table width: 1,000 mm, table length: 2,000 mm, total length: 4,000 mm, total width: 3,000 mm, total height: 4,000 mm, stroke adjustment: 200 mm, Equipment: safety light barrier, We offer this used AIDA 300 Ton ULX eccentric press double column, year of construction 2008. Manufacturer: AIDA Model: 300 Ton ULX Pressing force: 300 ton Year of construction: 2008 Condition: used Category ID: 1329 Type ID: 871 Machine type: eccentric press double column From the first owner company Machine is in great condition and in operation Hfedpfx Acjytcwwo Ael Used always under its capacity Used only in 1 shift from the purchase time untill now Made in Aida Japan First ULX press in Europe Delivery Terms: EXW ESKISEHIR TURKEY Payment Terms: Cash Or Letter Of Credit If you have any questions or need more information, feel free to send us a message or give us a call.

Condition: excellent (used), Year of construction: 2001, Manufacturer: ROVETTA Model: S4-800 Year: 2001 Condition: Used Stock number: 0392 Builder: Rovetta Slide force: 800 tons Number of driving points: 4 Slide stroke: 700 mm Slide adjustment: 350 mm Strokes per minute: 10-24 Hfedpfx Acsyq Tdps Ajl Die height (low stroke, high slide adjustment): 1,100 mm Usable distance between front posts: 4,200 mm Bolster table size: 4,000 x 2,000 mm Slide dimensions: 4,000 x 2,000 mm Movable table height: 600 mm Side window size: 3,400 x 1,900 mm Number of cushions: 1 Blankholder cushion - total force: 150 tons Lower blankholder cushion stroke: 250 mm Lower blankholder working area: 1,500 x 1,000 mm.

Condition: excellent (used), Year of construction: 2001, Manufacturer: ROVETTA Model: S4-1500 Link Drive Year: 2001 Condition: Used Stock number: 0391 Manufacturer: Rovetta Number of strokes: 4 Ram force: 1500 tons Ram stroke: 763 mm Ram adjustment: 400 mm Daylight (bottom dead center, ram up): 1,200 mm Distance between front uprights: 5,700 mm Die bed dimensions: 5,500 x 2,500 mm Ram dimensions: 5,500 x 2,500 mm Moving table height: 600 mm Side window size: 3,400 x 1,900 mm Main motor power: 319 kW Blankholder (total force): 150 tons Blankholder stroke: 250 mm Hfodpfeyq Tdiex Ac Ajl Blankholder working area: 2,000 x 1,200 mm Strokes per minute: 8-24

Condition: used, Year of construction: 2000, pressing force: 260 t, stroke length: 250 mm, table width: 840 mm, table length: 1,500 mm, air pressure: 9.807 bar, compressed air connection: 9.807 bar, ram adjustment: 120 mm, We are offering this used Chin Fong OCP-260N eccentric press with double column, year of construction 2000. Model: OCP-260N Factory number: A00373 Year of construction: 2000-11 Hedpfeykbcmex Ac Aofl Capacity: 260 tons Stroke frequency: 20–40 strokes/min Stroke: 250 mm Maximum die height: 500 mm Upper bolster clearance: 7 mm Slide adjustment (range): 120 mm Upper platen surface (L × W): 1130 × 700 mm Lower platen surface (L × W): 1500 × 840 mm Main motor power: 22 kW Poles: 4 Machine weight: 31.8 tons Compressed air pressure: 9.807 bar Oil temperature max.: +100 °C Oil temperature min.: -10 °C Oil volume: 180 liters If you have any questions or need more information, please feel free to send us a message or call us.

Condition: used, Year of construction: 1988, functionality: fully functional, Press capacity 5,000 kN Table area 2,400 mm x 1,700 mm Ram area 2,400 mm x 1,400 mm Adjustable stroke 25 mm - 200 mm Ram adjustment max. 200 mm Hjdpfsyg Emzox Ac Aofl Stroke rate 20 - 100 spm Drive power 84 kW Machine weight approx. 62,500 kg with roller feeder/straightener combination + decoiler Further data and photos available on request

Condition: used, Year of construction: 1971, pressure 100 t distance between columns 400 mm Hfsdpfjxuv Htex Ac Aol stroke 20 - 140 mm table surface area 900 x 710 mm ram surface 560 x 450 mm ram adjustment 80 mm dayligth 470 mm no. of strokes 70 Hub/min total power requirement 10,5 kW weight of the machine ca. 9 t dimensions of machine L x W x H 1,98 x 1,60 x 3,10 m
