Fischer Metall & Maschinenbau GmbH

Condition: excellent (used), Year of construction: 2009, functionality: fully functional, travel distance X-axis: 16,000 mm, travel distance Y-axis: 1,600 mm, travel distance Z-axis: 4,000 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 30 m/min, rapid traverse Z-axis: 30 m/min, spindle speed (max.): 5,000 rpm, CNC SIEMENS 840 D WORKING AREA Longitudinal travel X axis: mm 16.000 Cross travel Z axis: mm 1.600 Vertical travel Y axis: mm 4.000 Rapid traverse rate: m/min 30 Axis acceleration: m/s² 2 Maximum axis thrust: N 16.000 WORKING TABLES No. 2 floor plates: mm 7.792 x 3.190 Rototranslating table: mm 3.000 x 2.992 Cross travel of rototranslating table: mm 2.500 Maximum load capacity at table center: Ton 60 SPINDLE Tool taper: ISO 50 DIN 69871 Spindle speed: Rpm 5.000 Power S1: kW 37 Power S6: kW 56 Maximum torque S1: Nm 1.295 Bedozipmpspfx Acfsli Maximum torque S6: Nm 1.963 Usable low range: Rpm 0 – 1.145 Usable high range: Rpm 1.145 – 5.000 KOSMO 3 UNIVERSAL MILLING HEAD Positioning accuracy: ± 0.002° Maximum torque on rear plane: Nm 15.600 Maximum torque on front plane: Nm 11.000 Lubrication and cooling: Forced oil circulation Weight: kg 450 EQUIPMENT • Rueckle rototranslating table, size 3,000 x 2,992 mm, cross travel 2,500 mm, maximum load capacity at table center 60 tons, equipped with double preloaded pinion system; • Vertical axis designated as Y and cross axis designated as Z; • Remote electronic handwheel; • Automatic universal bi-rotary milling head “KOSMO 3 5000”, 5,000 rpm, ISO 50, indexing 0.02° on the front plane, continuous C-axis (hydraulic clamping) and 1° Hirth coupling on the rear plane, oil recirculation lubrication system; • Horizontal extension, diameter 200 mm, length 600 mm, 4,000 rpm, ISO 50 taper, continuous C-axis (hydraulic clamping) and 1° Hirth coupling; • Continuous platform (C-axis) prepared for future installation of a 2-axis continuous milling head; • Automatic head changer for the above-mentioned heads (Kosmo head, horizontal extension and preparation for continuous head); • Head storage magazine for 2 heads (Kosmo head + horizontal extension); • Air conditioning unit for electrical cabinet; • Belt-type chip conveyor along X-axis complete with transverse conveyor, coolant tank and coolant pump; • High-pressure coolant system, 40 bar through spindle, complete with tank and paper filter system, DIN 69871 type B; • Chain-type tool magazine with 80 positions “MAC80”, ISO 50, with tool change capability in both horizontal and vertical spindle positions (maximum tool length 400 mm, maximum tool weight 20 kg); • Air blast through external spindle nozzle; • Renishaw NC4 laser tool presetting system; • Renishaw RMP60 workpiece probe; • Mobile operator cabin moving along vertical and horizontal axes; • Instruction manuals and CE Declaration of Conformity.

Condition: used, Year of construction: 2011, Technical details: x-travel: 6500 mm y-travel: 2000 mm z-travel: 1500 mm rapid travel x/y/z: 25 m/min table-size: 8.000 x 1.300 mm table load: max. 2,5 t/qm Bsdpfx Acozipkhsfoli universal head: orthogonal 1° x 1° tool taper: SK 50 milling head speed: 4.000 1/min power capacity: 32 kW max. torque on the spindle: 910 Nm control: HEIDENHAIN iTNC 530 Tool changer: 40 Pos. total power requirement: 75 KW dimensions of the machine ca.: 10,7 x 5,2 x 4,6 m weight of the machine ca.: 30 t universal travelling column - universal machining center, orthogonal milling head, with 2,5° indexing, oil-air lubrication, 3D touch probe M&H 20.41, moveable operator-cabin/panel, chipconveyor, el. handwheel, LUBRIX MQL, 2pcs. clamping angle 1.000 x 400mm, approx. 29.800h "machine on", approx. 11.000h "spindle on" still under power in closed factory *

Condition: ready for operation (used), Year of construction: 1997, travel distance X-axis: 4,500 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,000 mm, rotational speed (max.): 3,000 rpm, CNC Heidenhain TNC 426 30-tool changer SA 50 spindle Maximum spindle speed: 3000 RPM Table: 6000 x 1100 mm Bsdpfezh U Hfex Acfoli Travel: 4500 x 1200 x 1000 mm Chip conveyor

Condition: used, travel distance X-axis: 12,000 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 2,000 mm, position of the milling head: AUTOMATICA, spindle speed (max.): 2,000 rpm, spindle motor power: 29 W, MECOF M 200 MOBILE OVERHEAD MILLING MACHINE Bjdpfxszhnx Io Acfsli

Condition: used, Year of construction: 1991, This Butler CNC bed milling machine will be auctioned off online as part of our industrial auction / machine auction, which includes clearing out warehouse stock – pallets, office supplies, and other items. Blsdpfezhmftsx Acfsi You can find this and many other items on our platform.

Condition: ready for operation (used), Year of construction: 2004, functionality: fully functional, travel distance X-axis: 2,700 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,050 mm, spindle speed (max.): 3,000 rpm, controller model: HEIDENHAIN iTNC530, The machine can be inspected while powered on during production! TECHNICAL DETAILS Travel range X-axis: 2,700 mm Travel range Y-axis: 1,000 mm Travel range Z-axis: 1,050 mm Bledozg Dq Dopfx Acfsi Max. feed rate X/Y/Z: 10,000 mm/min Table dimensions: 3,300 x 1,000 mm T-slots: 7 x 22 2-axis diagonal milling head: 1 x 2.5 Spindle speed: 60 - 3,000 rpm Motor power: 22/30 kW Tool holder: ISO 50 (DIN69872-B) MACHINE DETAILS Control system: HEIDENHAIN iTNC530 Coolant pressure through the spindle: 19 bar EQUIPMENT Adjustable control panel in front of the machine Enclosure with front-facing doors Machine documentation Cooling and chip disposal Chain conveyor in the longitudinal direction

Condition: used, Year of construction: 2019, travel distance X-axis: 5,500 mm, travel distance Y-axis: 1,350 mm, travel distance Z-axis: 2,000 mm, position of the milling head: 2,5° x 2.5°, rapid traverse X-axis: 25,000 m/min, rapid traverse Y-axis: 25,000 m/min, rapid traverse Z-axis: 25,000 m/min, feed rate X-axis: 10,000 m/min, feed rate Y-axis: 10,000 m/min, feed rate Z-axis: 10,000 m/min, spindle speed (max.): 4,000 rpm, torque: 1,638 Nm, coolant supply: 16 bar, Equipment: documentation/manual, rotational speed infinitely variable, On behalf of our client: Used CNC fixed-bed milling machine Manufacturer: KIHEUNG Model: D-TRAX X5500 Year of manufacture: 2019 Operating hours: • Control system on: 12,578 hours • Program run: 6,742 hours • Spindle run: 4,869 hours STANDARD EQUIPMENT: • CNC control HEIDENHAIN TNC 640 with HSCI, 19" TFT monitor, DXF converter, and swiveling control panel • SIEMENS main spindle motor 28/38 kW • 2-stage, cooled ZF reduction gearbox (1–1,000 / 1,001–4,000 rpm) • X-axis drive via TWIN-DRIVE / REDEX rack and pinion system with two servo motors Bedjzgw Dwopfx Acfoli • Y and Z-axis drive via KORTA precision ball screws • HEIDENHAIN linear scales in all three axes with compressed air system DA 400 • INA precision linear guides in all three axes • Hydraulic counterbalance of the Z-axis using nitrogen pressure cylinders • Automatic central lubrication with pressure monitoring • Telescopic guide covers for X, Y, and Z axes • HEIDENHAIN Teleservice dongle for remote diagnostics • HEIDENHAIN handwheel HR-510 • RITTAL control cabinet with air conditioning and interior lighting • CE-compliant complete enclosure with 15 mm polycarbonate safety glass and four front doors • Rear articulated chip conveyor • Coolant system up to max. 8 bar, tank volume 800 l • Ethernet interface • Paint finish in light gray RAL 7035, carmine red RAL 3002, and slate gray RAL 7015 SPECIAL ACCESSORIES: • Universal automatic milling head A4 – 2.5° x 2.5° (bi-rotating, hydraulic clamping) • Horizontal chain-type tool changer for 30 tools (servo motor with HEIDENHAIN encoder) • CTS system 16 bar – cooling through the spindle with paper band filter system • Oil skimmer HAMMA Germany • Magnetic separator • Stand extension for Z-axis travel of 2,000 mm • Preparation for pendulum machining DELIVERY SCOPE / DOCUMENTS • Machine including all existing options and accessories • Available documentation: operating manual, maintenance manual, lubrication manual, electrical wiring diagrams, CE declaration of conformity, and programming manual INSPECTION / CONTACT • Inspection possible by appointment

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, machine/vehicle number: 7853, travel distance X-axis: 4,000 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 2,000 mm, spindle speed (max.): 3,000 rpm, controller model: Heidenhain TNC 426 C, No minimum price – guaranteed sale to the highest bidder! Loading can be carried out by the seller for €750! TECHNICAL DETAILS Travel in X-axis: 4,000 mm Travel in Y-axis: 1,200 mm Travel in Z-axis: 2,000 mm Spindle type: ISO 50 Spindle power: 50 kW Spindle speed: up to 3,000 rpm Table length: 5,000 mm Tool changer: 30-position ATC MACHINE DETAILS Control system: Heidenhain TNC 426 C Headstock Swiveling: Automatic Increment: 1 degree / 2.5 degrees / stepless Dimensions & Weight Dimensions (L x W x H): 9,000 mm x 5,000 mm x 5,000 mm Weight: 35,000 kg EQUIPMENT Hydrostatic guideways in all axes Tool holders Coolant preparation/filtration system Chip conveyor Cooling system, manufacturer: Deerosdassi Blodpfx Acjzdtxfefei Control cabinet system Note: The machine has already been professionally disassembled and is in storage.

Condition: like new (used), Year of construction: 2011, Retrofitted: 2026 Numerical control: HEIDENHAIN TNC-i530 Bodpjzcz Srefx Acfjli Technical features Dimensions Table dimensions: 10000 x 2250 mmNumber of T slots: 9T slots dimensions: 22 mm Traverses of axis X axis traverse: 10000 mmY axis traverse: 1500 mmZ axis traverse: 2500 mmVertical capacity (VC): 150 - 2650 mm  (adjustable) Milling head Head type: Universal Auto-indexing UDG (2.5º)Tool clamping system: HydraulicTaper nose: ISO 50 (DIN 69871) / Pull stud: DIN 69872Speed range: 3000 rpmSpindle power: 30 kW Feedrates Rapid feedrate (X / Y,Z): 30000 mm/min Weight and dimensions Maximum weight on table: 15 Tn/m2Machine weight approximate: 56000 kgMachine dimensions approximate: 16520 x 8575 x 5290 mm Accessories Guarding: front sliding doors and new perimetral wire-mesh fenceAutomatic tool changer: ATC40Chip conveyor: 1 longitudinal rear hinge typeElectronic handwheel: HR-410Coolant: external internal high-pressure coolant through spindle Sale conditions Warranty: 6 months mechanical partsPrice and sale conditions: On request View all technical features

Condition: refurbished (used), Year of construction: 2007, functionality: fully functional, travel distance X-axis: 7,000 mm, travel distance Y-axis: 1,600 mm, travel distance Z-axis: 1,400 mm, feed length X-axis: 7,000 mm, feed length Y-axis: 1,600 mm, feed length Z-axis: 1,400 mm, Complete with all assemblies required for installation and commissioning x = 7 m y = 1.6 m z = 1.4 m (800 mm + quill = 600 mm) General overhaul in 2007, year of manufacture 1991 Rapid traverse: 12,000 mm/min; w-axis: 6,000 mm/min Bedozcm Aispfx Acfoli Fitted with new Siemens Sinumerik 840D control system, new drive motors, refurbished guideways, and new control cabinets. ECOCUT 1 was only operated for a few hours thereafter. TDV 2 rotary table, max. workpiece weight 6 t / clamping area 1,000 x 1,000 mm TDV 3 rotary table, max. workpiece weight 12 t / clamping area 1,250 x 1,600 mm Accessories: 2 right-angle milling heads / chain-type automatic tool changer / platen table / full enclosure / Knoll hopper feeding system / extraction unit / coolant system with belt filter. Supplied with all BWF fixtures required for installing the machine bed and clamping plate.

Condition: ready for operation (used), Year of construction: 2003, functionality: fully functional, travel distance X-axis: 12,000 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 2,800 mm, position of the milling head: ASSE B 1°/ASSE C 3°, rapid traverse X-axis: 20 m/min, rapid traverse Y-axis: 20 m/min, rapid traverse Z-axis: 20 m/min, spindle speed (max.): 4,000 rpm, Equipment: documentation/manual, rotational speed infinitely variable, HEIDENHAIN iTNC530 NUMERICAL CONTROL Bjdpfx Aszcfg Hecfjli TBA4 AUTOMATIC ROTARY HEAD, 1° + 3°, with HIRTH gearing Spindle head oil cooler Spindle motor power: 30 Kw Maximum spindle torque: 780 Nm Automatic tool changer with 61 positions Mobile operator platform with vertical hydraulic movement Programmable adaptive control Tool life monitoring Chain-type chip conveyor Tool cooling with supply around the spindle Work table with 2 STOLLE tables, totaling 12000 x 2500 mm 4 work table supports, dimensions 2500x1000x1200 mm CE marking and manuals TBA4 HEAD COMPLETELY OVERHAULED BY EMCO MECOF

Condition: excellent (used), Year of construction: 2002, travel distance X-axis: 5,000 mm, travel distance Y-axis: 3,100 mm, travel distance Z-axis: 1,600 mm, spindle speed (max.): 3,500 rpm, Machine parameters – see photo. Bodpjy U Ngvofx Acfoli X-axis – 5000 mm Y-axis – 3100 mm Z-axis – 1600 mm Control system: Siemens 840 D.

Condition: used, Year of construction: 2016, x-travel 4.500 mm y-travel 1.300 mm z-travel 1.800 (2.300) mm control iTNC 530 HSCI Heidenhain tool taper ISO 50 DIN 69871 AD spindle turning speed range 20 - 6.000 U/min spindle drive 43 kW Torque 900 Nm table surface area 6.000 x 1.100 mm T-slots 6x 22 H12 mm T-slots REF: 1x 22 H7 mm T-slot - distance 140 mm number of toolpositions 40 pos. tool taper ISO 50 DIN 69871 max. tool diameter 125 mm max. tool-dia with free toolbox 250 mm max. tool length 400 mm max. tool weight 20 kg tool changing time 10 sec rapid traverse ( X / Y / Z ) 35.000 mm/min Feed force ( X / Y / Z ) 16.000 N Accelaration X: 1 | Y:1,5 | Z: 2 m/s² total power requirement 57 kW CNC Fixed-Bed Milling and Boring Center SORALUCE - SLP 6000 - Automatically indexing milling head with 0.001° x 0.001° indexing in two planes - Tool clamping force: 20,000 N - "Dynamics Active Stabilizer" preparation - Dynamic Collision Monitoring Software (DCM) - Interpolation turning - INA linear roller guide system RUE55-E-L (X/Y/Z axes) - Hydromechanical damping slides (Y/Z axes) - Rack-and-pinion drive (X-axis) - Ball screws (Y/Z axes) Bljdpfx Acsy Umagofoi - Heidenhain AC drive motors with digital drive technology - Pressurized direct linear measuring system (Heidenhain) - 3D thermal expansion compensation for all milling head positions - Automatic feed control - Enhanced accuracy via Soraluce 3D milling head compensation - Preparation for NC rotary table (for 5-sided machining) - Tool changer function: loading and unloading during automatic operation - Adaptive Control - Accura Heads option - DXF converter - Heidenhain interpolation turning - Splash guard enclosure (2x front doors, 2,500 mm)

Condition: ready for operation (used), Year of construction: 1993, functionality: fully functional, machine/vehicle number: F 36905, travel distance X-axis: 7,000 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,300 mm, spindle speed (max.): 2,000 rpm, controller model: HEIDENHAIN TNC 360, TECHNICAL DETAILS Travel X-axis: 7,000 mm Travel Y-axis: 1,200 mm Travel Z-axis: 1,300 mm Rapid traverse x/y/z: 10 m/min Table size: 8,000 x 1,300 mm Table load capacity: max. 4 t/sqm Universal head: 5x90 plus manual 1 Tool holder: SK 50 Blsdpfx Acsy Rrbhjfei Milling spindle speed range: 20 – 2,000 rpm Drive power: 30 kW Spindle torque: 2-speed gearbox, 750 Nm MACHINE DETAILS Control: HEIDENHAIN TNC 360 Total power requirement: 50 kW Dimensions & Weight Space requirements approx.: 9.0 x 3.8 x 4.6 m Machine weight approx.: 25 t EQUIPMENT Orthogonal milling head, water-cooled 3D radio probe M&H 20.41 Partition wall for parallel machining/setup Internal air blast Internal coolant supply 15 bar Adapter for high-speed milling spindles with torque support Operator platform travels with machine Chip conveyor Electronic handwheel HR 410 Monitored safety fences Various optional accessories (angle milling heads, clamps, etc.)

Condition: excellent (used), Year of construction: 2010, functionality: fully functional, 5-axis traveling column milling machine MFS with 840D Siemens control. Bjdpfxjy Rgt Ej Acfoli Travel ranges: 13200 x 3000 x 1200

Condition: used, Year of construction: 2013, functionality: fully functional, travel distance X-axis: 8,900 mm, travel distance Y-axis: 7,300 mm, travel distance Z-axis: 1,500 mm, position of the milling head: 360.000°, spindle speed (max.): 2,500 rpm, table length: 4,000 mm, table width: 3,000 mm, table load: 800,000 kg, spindle motor power: 60,000 W, milling spindle length: 1,000 mm, Equipment: documentation/manual, FERMAT WRF 160 CNC HORIZONTAL BORER, CNC HEIDENHEIN iTNC 530. Built 2013. Robot ATC 90, Pickup station 4 positions. Universal Micro positioning head UHA mi 30 kW. Right Angle head 60 kW. Hand Wheel HR 520, M&H Probe. X= 8.900mm. Y= 7.300 mm. Z, Ram= 1.500 mm. W, Spindle= 1.000 mm. Rotary Table 3.000 x 4.000 mm, Travel 3.000 mm, 80 Ton. X Column travel 8.900 mm Y Headstock vertical travel 7.300 mm Z, Ram stroke 1.500 mm W, spindle stroke 1.000 mm W+Z 2.500 mm Spindle diameter 160 mm Spindle diameter ISO 50 Spindle speed 10 - 2.500 rpm Spindle motor, 2 steps, ZF 60 kW Ram square section 520 x 520 mm Automatic robot tool changer 90 Tools Coolant through spindle 50 Bars Outside Coolant 4 Bars Rotary Table size 4.000 x 3.000 mm Table load 80 ton C-axes 360 000° Table travel, V 3.000 mm Bedpfx Acey Hwwtofsli The machine is complete with all Manuals, Foundation Plan, Hydraulic Diagram, Electrical Drawings etc. These will be shipped along with the Machine

Condition: used, Year of construction: 2012, travel -x axis 8.000 mm travel -y axis 2.600 mm travel -z axis 1.500 mm control HEIDENHAIN - iTNC 530 turning speed range 20 - 5.000 U/min numbers of positions in the tool changer 60 tool taper SK50 clamping plate 10.000 x 2.500 mm CNC Milling machine | SORALUCE - FP-8000 equipped with radio measuring probe, 60-way tool changer and clamping plates. The machine is in good condition and can be inspected under power. For additional equipment information please refer to the original order confirmation which is included in the offer of this machine. The machine videos from the production plant will be shared on request. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Bjdpsy E Txkefx Acfeli #Tags: FP8000 | FP 8000

Condition: good (used), Year of construction: 2014, Table size 6000 x 1100mm, traverses X Y Z 4500 x 1600 x 1300mm, maximum workpiece weight 5000kgs, Blsdpfxjy Ey Rts Acfei spindle taper DIN 50, toolchanger capacity 40 stations, spindle speed 5,000rpm, automatic head, swarf conveyor, 4th axis rotary table

Condition: like new (used), Year of construction: 2017, Year: 2017 Control: Heidenhain iTNC 640 HSCI Location: Germany, under power Travels X Longitudinal: 14100 mm Bljdsy D Tzpjpfx Acfji Y Vertical: 5000 mm Z Ram: 1550 mm Headstock Spindle power: 51/36 (40%/100%) KW Spindle Torque: 1500 NM Spindle speed: 5000 rpm Spindle Taper: ISO 50 Ram size: 420 x 420 mm C- axis integrated: 0.001° - continuous Desh gearbox Heads and Head changer Automatic pickup station for: 3 places Head 1: Uhami 30 continuous A and C axis 180°+, 180°- Head 2: Uhami 30 continuous A and C axis 180°+, 180°- (New in 2022) Head 3: horizontal spindle extension: 400 mm Head 4: horizontal spindle extension: 800 mm Head 5: ISO 40 vertical head to be mounted on horizontal spindle extension Tables Table 1 Size: 3000 x 3000 mm V- Travel: 2400 mm Table load capacity: 50 Tonnes Table 2 Size: 2500 x 2000 mm V- Travel: 2400 mm Table load capacity: 30 Tonnes Additional information: Floor plates: 2 pcs. 4000 mm x 2000 mm, 2 pcs. 5000 mm x 2000 mm Working Area separation Tool changer Robot type Spindle through coolant Chip conveyor 3D probe Movable operator platform Wireless Handwheel CE marking Approx. 14000 programming hours Continous heads, continous tables

Condition: good (used), Year of construction: 2008, functionality: fully functional, ANAYAK HVM-11000-PC - Condition: Used machine - Year of manufacture: 2008 Control system: - HEIDENHAIN iTNC530 Linear axis travel distances: Blsdpfx Acey Dr Rijfoi - X-axis: 10,300 mm - Y-axis: 2,000 mm (cross axis) - Z-axis: 2,700 mm Machine table: - Dimensions: 11,000 x 2,000 mm - T-slots: 8 x 22 - Capacity: max. Axis speeds: - Max. feed rate X/Y/Z: 10,000 mm/min Milling head and spindle: - 2-axis diagonal milling head 1° x 2.5° - Max. spindle speed: 60 - 3,000 rpm - Max. motor power: 37/51 kW - Tool holder: ISO 50 (DIN69872-B) Coolant and chip disposal: - Chain conveyor for chips, longitudinal direction - Through-spindle coolant, 22 bar Other equipment features - Travelling operator platform - Machine documentation

Condition: used, travel distance X-axis: 4,000 mm, travel distance Y-axis: 2,000 mm, travel distance Z-axis: 1,200 mm, spindle speed (max.): 4,000 rpm, STROKE OF AXIS X: MM.4000 STROKE OF AXIS Y: MM.2000 STROKE OF AXIS Z: MM.1200 SPINDLE TAPER ISO 50 SPINDLE SPEED RPM.4000 TABLE MM.6000x1100 SPINDLE MOTOR KW. 22 CNC SELCA 4045 AUTOM.HEAD 1° x 2.5° (FRONT) INT.COOLANT SYSTEM 15bar Bljdpfx Acoyzfhvsfsi EX.COOLANT SYSTEM AUT.TOOLS CHANGER 20 POS.

Condition: excellent (used), Year of construction: 1997, functionality: fully functional, machine/vehicle number: 3431097, travel distance X-axis: 2,500 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,500 mm, mount diameter: 120 mm, feed rate X-axis: 10,000 m/min, feed rate Y-axis: 10,000 m/min, feed rate Z-axis: 10,000 m/min, spindle speed (max.): 2,000 rpm, table length: 1,600 mm, table width: 1,200 mm, spindle motor power: 24 W, TECHNICAL SPECIFICATIONS CNC: Siemens 840 C Transverse table travel (X): 2,500 mm Longitudinal column travel (W): 1,200 mm Vertical head travel (Y): 1,500 mm Table size: 1,600 x 1,250 mm Table load capacity: 4 tons Spindle stroke (Z): 600 mm Spindle diameter: 120 mm Spindle taper: ISO 50 Spindle speed: 0 ÷ 2,000 rpm Spindle motor power: 24 kW Bjdpfx Aeyyvq Eecfoli Feed rates (X; Y; W; Z): 0 ÷ 10,000 mm/min Total weight: 19 tons Year of manufacture: 1997 Complete with: Boring support Various tapers and tools Chip conveyor

Condition: excellent (used), travel distance X-axis: 6,000 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 2,000 mm, spindle speed (max.): 5,000 rpm, Equipment: documentation/manual, FPT PRAGMA M 60 CNC SELCA 4045 Automatic continuous head, 5000 rpm 2.5° automatic head with electrospindle 18 kW – 18,000 rpm Bsdpfx Acoyycibefeli Stolle table 7000 x 2000 x H 300

Condition: used, Butler Elgamill CNC Travelling Column Bed Type Mill x 5000mm T slotted Table 8,000mm x 1030mm Column travel X 6200mm TBC Ram travel Y 1250mm TBC Vertical travel of Head Z 1950mm TBC Spindle speeds Various and a Max of RPM TBC Spindle Taper 50 Spindle drive motor HP TBC Bedpfx Aeyx Hv Ajcfoli Power feeds Horizontal and Vertical 6 – 500 mm/min Rapid power traverse to all motions 2,000mm/min Complete With: Heidenhain CNC Control Manual Indexing Head Machine Data: Machine weight 20,000kg

Condition: like new (used), Year of construction: 2008, Retrofitted: 2026 Blsdpfxeyvwcho Acfoi Numerical control: SIEMENS 840D Technical features Dimensions Table dimensions: OptionalNumber of T slots: UndefinedT slots dimensions: Undefined Traverses of axis X axis traverse: 10000 mmY axis traverse: 1500 mmZ axis traverse: 2500 mmVertical capacity (VC): 0 / 2500 mm (adjustable) Milling head Head type: Universal Auto-indexing UAD (0,1º)Tool clamping system: HydraulicTaper nose: ISO 50 (DIN 69871) / Pull stud: DIN 69872Speed range: 20 - 6000 rpmSpindle power: 30 kW Feedrates Rapid feedrate (X / Y,Z): 30000 mm/min Weight and dimensions Maximum weight on table (kg/m2): OptionalMachine weight approximate: 70000 kgMachine dimensions approximate: 17560 x 12800 x 4270 mm Accessories Guarding: pendular with automatic front door and perimetral wire-mesh fenceAutomatic tool changer: ATC80 with electrical motorsChip conveyor: 1 front longitudinal and 1 transversalElectronic handwheel: 6FX2007-1AE14 SiemensCoolant: external internal high-pressure through spindleOperator’s cabinet: adjustable in vertical traverse Other technical features 2 ROTARY TABLES:Model:   DEMMELER DRLTS1800Table surface: 2400 x 1800 mmMaximum load on table: 40 TT slots number: 9T slots dimensions: 22 mmRotary axis: HydrostaticMaximun speed (S1/S6): 3.4 / 5.4 rpmClamped tangencial torque: 175000 NmW axis: 1500 imum feedrate: 20000 mm/ntity of guideway (W axis): 4 Sale conditions Warranty: 6 months mechanical partsPrice and sale conditions: On request View all technical features
