Condition: used, Year of construction: 1988, functionality: unexamined, Equipment: documentation/manual, Good morning, I have for sale a Fellows gear shaping machine, Tos OHA 32A. Complete technical and electrical documentation available. Price: 11,000 EUR Technical specifications: Machine type: OHA 32 A Manufacturer: TOS Čelákovice Year of manufacture: 1987/1988 Workpiece diameter for external gearing: 30 – 320 mm Maximum basic diameter for internal gearing: 300 mm Maximum outside diameter for internal gearing: 400 mm Maximum gear module: 6 Maximum width of shaped gear: 70 mm Number of gear teeth: 12–300 Maximum workpiece weight with clamp: 150 kg Distance from tool support surface on the slide to table surface: min. 30 mm, max. 310 mm Motor power: As per technical data sheet Nsdpfx Asxwp Ngogmjdd Machine dimensions (L x W): 2150 x 1420 mm, machine height: 1980 mm Machine weight: 4300 kg Electrical equipment: Total connected power 15 kVA

Condition: good (used), Year of construction: 2002, Ref. -No.: 10442 Manufacturer: LIEBHERR Type: LC 122 Year of construction: 2002 Type of control: CNC Control: LIEBHERR PC NC Storage location: Halberstadt Njdsxmd Shspfx Agmodd Country of origin: Germany Hob diameter max.: 90 mm Table Diameter: 145 mm Max. Module: 3 mm Smallest number of millable teeth: 4 Milling head swivel angle: +/- 45 ° Resolution accuracy: 0,1 Degree Workpiece table load: 17 kN Milling speed: 450 - 4.500 1 / min Operating voltage: 400 V control voltage: 24 V frequency: 50 Hz Max. rated current: 55 A Fuse in the supply line: 63 A Max. milling diameter spur gears/helical gears: 125 mm Max. milling width spur gears/helical gears: 250 (axial) mm Spindle stroke: 180 mm Max. cutter width: 200 mm Further information: Ambient temperature: +12°.....+40° Operating noise: 78 dB (A) Milling head designation: motor milling head Workpiece axis: vertical Stand: movable Table: fixed Milling method: axial hobbing in the same or opposite direction The machine can be inspected under power by arrangement.

Condition: good (used), Condition: Used Stock number: 968859 State: Good Maximum diameter: 100 mm (4") Maximum length: 100 mm (4") Number of teeth: 6-400 Maximum pitch in steel: 15 D.P. 12 indexing tables Geometrically calibrated between 200 and 2,400 rpm Feed: Horizontal cut or plunge cut Main motor: 1.5 HP Coolant pump motor: 0.1 HP Ndedpfx Agexlabijmed Hydraulic system motor: 0.1 HP Dimensions: 1120x1120x1680 mm Machine weight: 500 kg

Condition: good (used), ⚙️ Mikron Gear Hobbing Machine Type 132-02 (M23) – Now available at our facility in Ireland: Mikron Gear Hobbing Machine Type 132-02 (M23) in very good condition. This precision Swiss-made machine is ideal for the production of small gears, toolrooms, and manufacturers seeking reliable, high-precision gear cutting capabilities. Mikron is renowned for its robust construction and long-lasting performance in gear hobbing applications, making it an outstanding solution for hobbing spur gears, helical gears, and splines with consistent accuracy. Condition: Used Stock number: 968859 State: Good Maximum diameter: 100mm (4") Maximum length: 100mm (4") Number of teeth: 6–400 Maximum pitch in steel: 15 D.P. 12 table revolutions Geometrically calibrated between 200 and 2,400 rpm Feed: Horizontal or plunge cutting Main motor: 1.5 HP Coolant pump motor: 0.1 HP Hydraulic system motor: 0.1 HP Dimensions: 1120 x 1120 x 1680 mm Machine weight: 500 kg Ndodpoxlabcefx Agmed

Condition: excellent (used), Specifications Manufacturer LIEBHERR Model LC 282 CNC Condition Used Stock Number Factory Max working diameter 280 mm Module 7 Worktable diameter 250 mm Worktable revolutions 100/200 rpm Min-max distance btw workpiece and hob 30 - 300 mm Hob head inclination angle 45° Ndodexgpqcjpfx Agmod Max hob diameter 160 mm Machine weight 12500 Kg

Condition: used, Year of construction: 2004, Technical details: Nedpexc E H Sjfx Agmsdd max. wheel diameter: 200 mm gear width: 60 mm max. module: 7 weight of the machine ca.: 15 t table diameter: 180 mm table turning speeds: 100 U/min hob turning speeds: 750 U/min Machine in good condition, without feed, without automation Available 24.08.2024 *

Condition: ready for operation (used), Year of construction: 2001, functionality: fully functional, machine/vehicle number: 1719, wheel diameter: 280 mm, TECHNICAL DETAILS Max. wheel diameter: 280 mm Max. module: 7 Njdpjw T R Auofx Agmedd MACHINE DETAILS Machine weight: 13 t Operating voltage: 400 V Control voltage: 24 V DC

Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, machine/vehicle number: 1130, table diameter: 250 mm, wheel diameter: 280 mm, spindle speed (max.): 1,500 rpm, TECHNICAL DETAILS Max. wheel diameter: 280 mm Max. module: 7 Table speed range: 100 rpm Table diameter: 250 mm Centre distance: 15 - 285 mm Max. axial travel: 350 mm Milling Head Drive power: 16 kW Min. number of teeth: 4 Cutter speeds: 1,500 rpm Max. cutter diameter: 160 mm Nsdpew T R Ahefx Agmjdd Max. cutter length: 230 mm Tangential travel: 200 mm Tangential speed: 3,000 mm/min Swivel angle: ± 45° MACHINE DETAILS Approx. machine weight: 13,000 kg Supply voltage: 400 V Mains frequency: 50 Hz Connected load: 35 kVA

Condition: ready for operation (used), Year of construction: 2000, functionality: fully functional, gear diameter: 180 mm, travel distance Z-axis: 300 mm, shaft length: 640 mm, TECHNICAL DETAILS Wheel diameter - max.: 180 mm Module - max.: 4 Carriage travel axial (Z-axis): 300 mm Shaft length - max.: 490-640 mm Y-axis travel: 33 - 193 mm MACHINE DETAILS Total power requirement: 14 kW Machine weight: 8 t Ndsdpjw T R Abjfx Agmod Workpiece counter: 886,067 pieces

Condition: ready for operation (used), Year of construction: 2005, functionality: fully functional, machine/vehicle number: 1443, table diameter: 180 mm, gear diameter: 200 mm, milling spindle length: 230 mm, spindle speed (max.): 750 rpm, swivel angle A-axis (min.): -45 °, swivel angle A-axis (max.): 45 °, TECHNICAL DETAILS Max. workpiece diameter: 200 mm Table diameter: 180 mm Max. table speed: 100 rpm Center distance: 15 - 400 mm Machine column Ndsdpfxew T Ry Tj Agmjd Max. axial travel: 600 mm Milling head swivel device Milling head swivel angle: ± 45 degrees Milling head Drive power: 27 kW Max. module: 7 mm Max. cutter speed: 750 rpm Max. cutter diameter: 160 mm Max. cutter length: 230 mm Max. tangential travel: 200 mm Max. tangential speed: 3,000 mm/min Counter column Max. counter support travel: 540 mm Max. counter support rapid traverse: 15,000 mm/min Max. counter support arm force: 13 kN MACHINE DETAILS Approximate total weight: 15,000 kg Ambient temperature: 15 - 38 °C Operating voltage (tolerance +/- 10%): 400 V Operating frequency (tolerance +/- 2%): 50 Hz Control voltage: 24 V DC Hydraulics Hydraulic oil: HLP 46 Max. operating pressure: 70 bar Pump flow rate: 24 l/min Hydraulic volume in hydraulic reservoir approx.: 7 l Max. average noise level: 82 dB(A)

Condition: used, Year of construction: 2003, Technical details: max. wheel diameter: 80 mm max. module: 3 total power requirement: 25-35 kW weight of the machine ca.: 10 t workpiece weight: 15 kg workpiece length - max.: -50....+450 mm Ndjdpfx Agewwlunsmsd table diameter: 145 mm diameter of hob: 90 mm cutter length max.: 220 mm hob turning speeds: 1.000 U/min

Condition: used, Year of construction: 2000, functionality: fully functional, table diameter: 132 mm, wheel diameter: 130 mm, spindle speed (max.): 3,500 rpm, tool diameter: 80 mm, swivel angle A-axis (min.): -40 °, swivel angle A-axis (max.): 40 °, Gear Hobbing Machine - Vertical SAMPUTENSILI S130 CNC Module Well-maintained CNC vertical gear hobbing machine for shafts and gears with tailstock Also suitable for hard milling (good for steering pinions) TECHNICAL DETAILS Control type: CNC Control name: Sinumeric 840C Gear diameter: max. 130 mm Ndedpfx Agswmb Nyemjd Module: max. 3 Total power requirement: 15 kW Machine weight: approx. 6 t Space required: approx. 2.3 m x 2.5 m x 2.17 m Rapid traverse radial, axial: 10,000 mm/min Rapid traverse tangential: 7,500 mm/min Max. gear diameter: 130 mm Max. module: 3 mm Tangential slide travel: 200 mm Radial Sliding travel: 10/100 mm Axial slide travel: 300/200 mm Milling head speed: 250-3500 rpm Milling head: Tiltable up to ± 40° Tool diameter: 80 mm Tool length: max. 240 mm Table speeds: 5-1000 rpm Milling spindle drive: 15 kW Feed range: 0.1-2000 mm/min Table diameter: 132 mm MACHINE DETAILS Control: Sinumerik 840 C Connected load: 40 kVA Motor power: 15 kW Weight: 6 t Dimensions: 2300 x 2500 x 2170 mm EQUIPMENT - Hydraulic workpiece clamping - Automatic loading system - Magnetic Chip conveyor

Condition: ready for operation (used), Year of construction: 2003, functionality: fully functional, machine/vehicle number: 0315, workpiece weight (max.): 15 kg, wheel diameter: 80 mm, milling length: 220 mm, workpiece length (max.): 450 mm, TECHNICAL DETAILS Max. workpiece diameter: 80 mm Workpiece weight: 15 kg Workpiece length: -50 mm - 450 mm Machining Max. nominal module for steel: 3 mm Max. milling stroke: 250 mm Max. shift travel: 180 mm Table diameter: 145 mm Table speed: 150 rpm Nsdpfx Aowmbnpegmsdd Milling head swivel angle: ±45 degrees Cutter-workpiece center distance: 10 mm - 200 mm Milling unit Cutter diameter: 90 mm Cutter length: max. 220 mm Cutter speeds: 1,000 rpm Milling spindle drive power: 15 / 23 kW Table drive power: 5.8 / 19.0 kW MACHINE DETAILS Weight of the machine with counterweight: 10,000 kg Total connected load: 25–35 kVA

Condition: reconditioned (used), Year of construction: 1991, functionality: fully functional, machine/vehicle number: 27604, feed length Y-axis: 170 mm, feed length Z-axis: 200 mm, table diameter: 160 mm, spindle speed (max.): 600 rpm, TECHNICAL DETAILS X-axis: 150 mm Y-axis: 170 mm Z-axis: 200 mm Swivel angle: -150/30° Milling unit Max. hob diameter: 130 mm Max. hob length (shaft mill): 220 mm Max. module: 3 Cutter length: max. 220 mm Cutter speeds: continuously variable up to 600 rpm Milling arbor diameter: 32 mm Table Table diameter: 160 mm Table bore diameter: 63 mm Control & Retrofit Control: SINUMERIK 840 D SIEMENS Retrofit: Sinumerik 840 D / Windows XP Pro in 2010 MACHINE DETAILS Total power requirement: approx. 20 kW Machine weight: approx. 10,500 kg Ndodpov Rdwijfx Agmod Space required: approx. 6.8 x 3.7 x 2.85 m

Condition: used, Year of construction: 2002, functionality: fully functional, wheel diameter: 130 mm, workpiece height (max.): 170 mm, TECHNICAL DETAILS Control: Sinumerik 840D Tip diameter: 80 mm Toothed length: 170 mm Overall length of hob cutter: 245 mm Collet diameter: 32 mm Tool speed: 300 - 3000 rpm Gear diameter: max. 130 mm Ndedpev I Tmusfx Agmod Gear width: 170 mm Module: 0.5 - 3 Slide travel radial / tangential / axial: 200 / 170 / 250 mm Milling head swivel angle: ± 45° Workpiece table: Ø 168.14 mm Bore: 65.532 mm Table speed: 0 - 1000 rpm Table bore: 65.532 mm Feed X/Z: 1 - 6000 mm/min Rapid traverse X, Z / Y: 6 / 5 m/min MACHINE DETAILS Total power requirement: 48 kVA Operating voltage: 3 x 400 V, 50 Hz Machine weight: approx. 9 t Space requirement: approx. 7.64 x 3.14 x 3.25 m

Condition: ready for operation (used), max. wheel diameter 150 mm gear width 1 - 200 mm max. module 4 Njdpfx Aevzhg Njgmsdd min. module 1 control Sinumerik 840 D table diameter 140 mm maximum axial offset 200 mm milling tool taper ISO 40 diameter of hob max. 130 mm cutter length max. 220 mm milling spindle speeds (infinitely variable) 300 - 1200 U/min shifting max. 170 mm milling head -swivable +/- 45 ° feed speeds 1 - 1500 mm/min rapid travel speed 3000 m/min max. workpiece diameter im Magazin: 150 mm total power requirement 50 kW weight of the machine ca. 8,5 t dimensions of the machine ca. 4,7 x 3,6 x 2,6 m Used gear hobbing machine, Pfauter, new in 1992 completely overhauled in 2023 by the specialist company SerWeMa, with Siemens Sinumerik 840 D control system and workpiece magazine.

Condition: new, Delivery program Eifco hobbing machines Nsdpfx Agju Egdlemodd

Condition: like new (used), Year of construction: 2004, More Photos coming soon hob cutter: -Largest permissible tip circle diameter: 80 mm Largest toothed length: 70 mm Largest total length: 240 mm Taper for trimming with counter bearing steep taper 1:3, 4286 Mounting diameter of the collet: 32 mm Sliding paths: Radial (X-axis): 100 mm Tangential (Y-axis): 160 mm Axial (Z-axis): 300 mm Tailstock (Z4 axis): 350 mm Loading gantry (X5 axis) 3800 mm Largest milling head swivel angle: Direction +A: 40 degrees Direction A: 40 degrees Workpiece spindle: Outer diameter: 160 mm Bore: 63 mm Overall dimensions of the machine: Length: 9130 mm Width: 3895 mm Height: 3200 mm Gain of the machine: 8400 kg Feed rates: X and Z axes: 1 to 10000 mm/min Y axis: 1 to 5000 mm/min Rapid traverse: X, Z and Z4 axes: 10000 mm/min Y axis: 5000 mm/min X5 axis: 150 mm/min Speeds: Tool: 300 to 4000 min^-1 Workpiece spindle: 0 to 1000 min^-1 Operating voltage: 400 V Supply voltage: 230 V Control voltage: 24 V Frequency: 50 Hz Connected load of the machine: 48 kVA Cable cross-section: 35 mm2 Fuse protection: 70A wälzfräser: -Großter zulassiger Kopfkreissdurchmesser: 80 mm Groste verzanne Lange: 70 mm Größte Gesamtange: 240 mm Kegel zum Abstutzen m Gegenlager Steilkegel 1:3, 4286 Aufnahmedurchmesser der Spannzange: 32 mm Schlitterwege: Radial (X-Achse): 100 mm Tangential (Y-Achse): 160 mm Axial (Z-Achse): 300 mm Reitstock (Z4-Achse): 350 mm Ladeportal (X5-Achse) 3800 mm Größter Fräskopfschwenkwinkel: Richung +A: 40 Grad Richtung-A: 40 Grad Werkstückspindel: Außendurchmesser: 160 mm Bohrung: 63 mm Gesamtabmessungen der Maschine: Lange: 9130 mm Breite: 3895 mm Höhe: 3200 mm Gewinnt der Maschine: 8400 Kg Vorschübe: Achsen X und Z: 1 bis 10000 mm/min Achse Y: 1 bis 5000 mm/min Eilgänge: Achsen X, Z und Z4: 10000 mm/min Njdpfx Aeqpf Ifsgmsdd Y.Achse: 5000 mm/min X5-Achse: 150 mm/min Drehzahlen: Werkzeug: 300 bis 4000 min^-1 Werkstückspindel: 0 bis 1000 min^-1 Betriebsspannung: 400 V Versorgungspannung: 230 V Steuerspannung: 24 V Frequenz: 50 Hz Anschlußwert der Maschine: 48 kVA Kabelquerschnitt: 35 mm2 Absicherung: 70A
