DREMO Werkzeugmaschinen GmbH & Co. KG

Condition: good (used), Year of construction: 2018, drilling depth: 1,250 mm, total length: 8,100 mm, total width: 6,300 mm, total height: 4,300 mm, workpiece weight (max.): 7,000 kg, overall weight: 31,000 kg, travel distance X-axis: 1,600 mm, travel distance Y-axis: 1,250 mm, travel distance Z-axis: 1,100 mm, spindle speed (max.): 6,000 rpm, drill diameter: 36 mm, drill spindle length: 1,250 mm, spindle motor power: 23,000 W, table length: 1,500 mm, table width: 1,100 mm, feed length W-axis: 1,600 mm, 4 side complete machining Hfjdpfoz Ayqfjx Ac Ajl Swiveling drilling and milling unit DCM Dynamic Collison Monitoring CAM-Model QCK ( Quick Check Kinematics) Transfer bore cycle (380-382) 90 Bar IKZ Coolant system Extra ATC Tower 24 position (4 x 6) HSK 63 Double ballscrew construction Clear tank 1650 L and Waste tank 1300 L Chip conveyor Max. drill Ø steel: 36mm Drilling depth: 1250mm X - Travel: 1600mm Y - Travel: 1250mm Z - Travel: 1100mm W - Travel: 1600mm Table load: 7000 Table size L x W / or ø:1500 x 1100mm Spindle taper: HSK-63Mk Power on spindle: 23kW Speeds / ranges: 6000Rpm Length: 8100mm Width: 6300mm Height: 4300mm Weight: 31000kg Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details!

Condition: excellent (used), Year of construction: 2010, functionality: fully functional, IMSA DRILLING MACHINE Model MF1100BBLL 6P Year 2010 Control unit: SELCA 4045 X-axis travel: 2200 Y-axis travel: 1000 Hfsdpfsz An Tnsx Ac Ajl Table length: 1000 Table width: 1200 Maximum workpiece size (length x width x height): D.2100 x H.1300 Table surface: Tapped holes Maximum workpiece weight: 10000 Spindle speed: 4000 Spindle connection: ISO 40 Torque (continuous / 10 min): 1200 Nm Number of tools: 108 6-position pallet changer MACHINE EQUIPPED WITH A LANCE CHANGER AND TOOL CHANGER FOR MILLING HEAD MACHINE IN EXCELLENT CONDITION AVAILABLE FOR INSPECTION WHILE IN OPERATION

Condition: used, Technical details: x-Travel: 530 mm table cross travel (Y-axis): 5200 mm w-axis: - mm drilling depth in one stroke: ca. 4000 mm metrical thread cutting: 0,25 -560 M total power requirement: 35 kW bed width: 560 mm centre distance: 5700 mm centre height: 500 mm swing diameter over bed: 1000 mm turning diameter over support: 800 mm range of feed in x - axis: 0,0063 - 4,0 mm/U range of feed in y - axis: 0,0063 - 4,0 mm/U spindle bore: 135 mm range drill spindle revolution per minute: max.1400 U/min range drill spindle revolution per minute: min. 7,1 U/min speed steps work spindle: 24 steps tailstock taper MT: MK 6 tailstock quill stroke: 300 mm dimension machine approx.LxWxH: 12,0 x 2,5 x 2,0 m The machine was retrofitted/overhauled in 2007. Special-purpose machine suitable for deep-hole drilling and/or heavy-duty turning operations. Inch thread range: 1/16 – 80 TPI 3-jaw chuck, chuck diameter: Ø 315 mm 2 steady rests Faceplate: Ø 800 mm without jaws PARAT quick-change tool holder, Type 4 3 pices Hfjdpfjzxlv Ejx Ac Ajl Coolant system HEIDENHAIN PT 880 4-axis DRO Boring bar for deep-hole drilling Drilling head for deep-hole drilling Infinitely variable boring-bar feed Various accessories *

Condition: new, Year of construction: 2026, functionality: fully functional, drilling depth: 2,000 mm, drill diameter: 75 mm, rotational speed (min.): 250 rpm, rotational speed (max.): 10,000 rpm, The DeepFlex deep hole drilling machines from technica technology gmbh are designed for high-precision deep hole drilling applications. The machine series covers drilling diameters from Ø1.5 mm to Ø75 mm and drilling depths from 250 mm up to 2,000 mm, providing exceptional flexibility for a wide range of industrial manufacturing requirements. Whether you require small-diameter precision drilling or large deep hole machining, DeepFlex machines deliver outstanding accuracy, reliability, and consistent production quality. Hfsdpozwvzpefx Ac Ajl

Condition: excellent (used), Year of construction: 1985, Drilling depth 750 mm Solid drilling in steel approx. 30 mm Maximum spindle speed 5,700 rpm Clamping table 1280 x 420 mm Hsdpfxszwhkvj Ac Aofl Cross-slide table Coolant tank Various accessories (drills, bushings)

Condition: good (used), functionality: fully functional, drilling depth: 600 mm, workpiece weight (max.): 2,000 kg, travel distance X-axis: 750 mm, travel distance Y-axis: 630 mm, travel distance Z-axis: 300 mm, spindle speed (max.): 3,000 rpm, drill diameter: 35 mm, drill spindle length: 600 mm, spindle mount: MK 2, spindle stroke: 600 mm, number of spindles: 1, Equipment: rotational speed infinitely variable, Driling capacity: Ø 35 mm Driling depth: 600 mm Hedpszu Sp Rofx Ac Aofl X-axis: 750 mm Y-axis: 630 mm Z-axis: 300 mm Spindle speeds: 0 - 3000 rpm Tabel size: 1100 x 650 mm Load on table: 2000 kg max Turning table: 360° Controller: Degen AE30 Including: - Cabinet + pallet with drills - Coolingunit - Machine manuals Country of origin: Germany Motor power: 11,2 kVA Machine LxWxH: 350 x 120 x 175 cm Machine weight: 1300 kg

Condition: excellent (used), TBT T30 SERIES TABLE TYPE GUN DRILLING MACHINE Model T30-1000KTN Serial number 410.364.016 Year of manufacture, approx. 1980 Number of spindles 1 Drilling range in steel 4 - 30 mm (solid) Counter boring 40 mm Nominal drilling depth 1000 mm Slotted table size 850 long x 750 wide mm Table size overall 1100 long x 1000 wide mm Table cross movement 800 mm (approx.) Table vertical movement 400 mm (approx.) Drilling slide longitudinal travel 1450 mm Slideway width 250 mm Spindle speeds to approx. 9000 rpm Spindle motor 25 kW Total load 41 kW Supplied with: 2 off Whip guides. Ballscrew feed. 2 Axis DRO to table Cross and Vertical, DRO to drill slide. TS25-1000 Coolant tank. Drill bushes. For Sale with Jet Machinery Ltd Jet Machinery Stock No: #27033 Machine Serial Number: 410 364 016 Hfodpfxszuxp Re Ac Asl Cost: £17,500.00 + VAT Whilst every effort has been made to ensure that the above information is accurate it is not guaranteed. We advise prospective purchasers to check any vital details. Health and Safety At Work Act 1974: It is not reasonably practical for ourselves as suppliers to ensure that for your application the goods comply with requirements of the Act with respect to guarding etc. Prospective purchasers should ensure that a guarding specialist inspect the goods prior to use.

Condition: ready for operation (used), Year of construction: 2003, functionality: fully functional, machine/vehicle number: M01.16.21.51.02, travel distance X-axis: 1,600 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 500 mm, spindle speed (max.): 10,000 rpm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel range X-axis: 1,600 mm Travel range Y-axis: 1,200 mm Travel range Z-axis: 500 mm Travel range W-axis: 1,200 mm Travel range B-axis: 360° Spindle speed: 10,000 rpm Spindle motor power: 30 kW Feed drive: Brushless AC servo motors Feed rate: 0–20,000 mm/min Rapid traverse X-axis: 20,000 mm/min Rapid traverse Y and Z axes: 20,000 mm/min Manual mode: 20,000 mm/min Setup operation: 0–2,000 mm/min Table size: 1,500 × 1,500 mm T-slots: 5 × DIN 650-22 H12 T-slot spacing: 150 mm MACHINE DETAILS Tool clamping: Hydraulic Electrical connection: 400 V Hjdpfjznkpvex Ac Asfl Frequency: 50 Hz Compressed air operating pressure: 6 bar Nominal flow rate: 7,000 rpm

Condition: like new (used), Year of construction: 2022, functionality: fully functional, drilling depth: 1,250 mm, feed length X-axis: 1,700 mm, feed length Y-axis: 800 mm, feed length Z-axis: 600 mm, workpiece weight (max.): 6,000 kg, travel distance X-axis: 1,700 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 600 mm, spindle speed (max.): 4,200 rpm, drilling capacity: 30 mm, Equipment: rotational speed infinitely variable, - HEIDENHAIN TNC 620 control unit - Electronic handwheel Hedpfx Acszixyro Aofl - Table dimensions: 1000 x 1000 mm - Manual table changing system with ZERO POINT table - Table rotation around B-axis: 360,000 positions/revolution - Table tilt around A-axis: +/- 22.5° - Deep-hole drilling spindle: 11 kW / 6000 RPM - Milling spindle: ISO 40 / 13 kW / 6000 RPM - Tool changer: ISO 40, 24 positions - Smoke extraction system: AR FILTRAZIONI - CE marking

Condition: used, Year of construction: 1991, operating hours: 58,273 h, functionality: fully functional, machine/vehicle number: 11.05149.028, drilling depth: 6,000 mm, feed length Z-axis: 6,000 mm, total length: 35,000 mm, total width: 4,500 mm, total height: 3,000 mm, overall weight: 30,000 kg, travel distance Z-axis: 6,000 mm, spindle speed (max.): 2,000 rpm, drill diameter: 64 mm, The machine is ready for operation; however, we do not have sufficient demand to utilize it to its full capacity. Hjdpfxey Tvy He Ac Aofl

Condition: used, core drilling diameter max. 50-600 mm bore depth 6000 mm table load 6 t turning speeds 50-600 U/min clamping diameter max. 650 mm Boring (pushing) from ID = 50 to 320 Skyving and roller Burnishing from ID = 50 to 300 Honing from ID = 50 to 320 Extraction system The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale Hfjdpfsy R Ef Tjx Ac Ajl apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: good (used), functionality: fully functional, drilling depth: 1,000 mm, FOR SALE: TBT T 30 – 1000 KT Deep Hole Drilling Machine High-quality German engineering for precision drilling Overview: Available for purchase is a robust and reliable deep hole drilling machine from the renowned German manufacturer TBT Tiefbohrtechnik. As a global leader in deep hole drilling technology, TBT machines provide unmatched precision for long-hole operations. Technical Specifications: Model: T 30 – 1000 KT Year of Manufacture: 1977 Max Drilling Depth: 1000 mm Drilling Diameter: approx. 4 – 30 mm Hjdpfey Rvc Aox Ac Aofl Rated Power: approx. 20 kW Operating Voltage: 380 V / 50 Hz Machine Type: Knee-table (KT) design for flexible clamping. Key Benefits: Solid Construction: German heavy-duty build ensures superior stability and accuracy. High Performance: The 20 kW motor provides ample power for various metal alloys. Versatile Application: Ideal for drilling shafts, molds, and other long workpieces.

Condition: ready for operation (used), Year of construction: 1976, functionality: fully functional, drilling depth: 1,500 mm, feed length X-axis: 2,030 mm, feed length Y-axis: 1,800 mm, feed length Z-axis: 1,700 mm, table length: 2,200 mm, table width: 1,800 mm, table load: 12,000 kg, Deep hole drilling machine Ixion (drilling depth 1500mm, X 2030mm, Y 1800mm, Z 1700mm) The base machine is a PEGARD drilling machine AF 13 (year of manufacture 1976, machine weight approx. 32 t) 1996: Retrofit and conversion to a deep hole boring machine (the conversion was carried out by ROTTLER Maschinenbau GmbH - Mudersbach) 2024: Overhaul (spindle bearings renewed, drill bushing holder/coolant supply disassembled and cleaned, hydraulics for tool clamping repaired, coolant system and hydraulic unit cleaned and inspected, etc.) Working ranges: - X-axis (longitudinal) 2030mm - Y-axis (drilling unit vertical) 1800mm - Z-axis 1700mm - Drilling depth in one operation 1500mm - B-axis (rotary table) 0-360° Drilling unit: - Main spindle ISO40 - Spindle speed 60-6000 rpm - Drive power at 100% ED 7.5kW NC rotary table (B-axis) - Table surface 2200x1800mm - Rotary axis 0-360° - Max. table load 12,000kg - Positioning accuracy +/-15 sec Coolant system/chip conveyor - Tank size approx. 1000l - Coolant pressure max. 80 bar - Flow rate max. 46 l/min - Paper band filter - Scraper conveyor/chip conveyor Hodpfey Rhzwsx Ac Asfl CNC control - Mitsubishi M325 with 14" color screen - Integrated tool breakage monitoring by querying the torque of the main spindle - Real-time process variable visualization of torque - Deep hole drilling technology programs - Portable electronic handwheel

Condition: excellent (used), Year of construction: 2013, 4mm Dia. - 16mm Dia Range of Drilling; Up to 3,000mm Length of Component; Hfedpfxoy Ey E Re Ac Aol Double Axis; Overall Length Approx 11 Metres x 900mm Wide, (2) Sections - Headstock Bed Length Approx 5 Metres, Drilling Length Bed Approx 6 Metres; (1) 500mm Dia 4-Jaw Chuck, 120mm Bore with Troyke DL-20-B, 4th Axis, 500mm Dia. Precision Rotary Table; Pendant Control; Stand Alone Electrical Cabinet (Dimensions Approx 3,000mm x 500mm x 1,900mm High); Technidrill Coolant Filtration System consisting of LNS 'Turbo HB' Swarf Conveyor, FSI 'CBFP 11' Filter System & Oil Tank with High Pressure Delivery Pumps; Stand Alone Dimplex Koolant Koolers Chiller Unit with Controls (Dimensions Approx 700mm x 1,300mm x 1,850mm High, 2012);

Condition: excellent (used), Year of construction: 1996, general overhaul in 2005 Number of spindles: 2 Drilling capacity/spindle, steel: 1-6 mm Drilling depth: max. 350 mm Z-axis travel: 350 mm X-axis travel: 350 mm Drive power/spindle: - 100% duty cycle 3.7 kW - 50% duty cycle 5.5 kW Spindle speed: 3,000 - 27,000 1/min Hfjdpfx Ajy Eykgsc Aol Spindle mounting: Ø 10 - 60 mm Coolant pressure: max. 150 bar Coolant flow: 48 l/min Coolant volume: 1,000 l Compact band filter High-pressure pump Accessories included: - 29 drilling sleeves - Drilling sleeve holder - Taper chucks - Tapers - Drill chucks Optional accessories - € 5,500 - 137 drills - List available in PDF

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, drilling depth: 1,500 mm, feed length X-axis: 3,250 mm, feed length Y-axis: 1,500 mm, spindle speed (max.): 4,200 rpm, table load: 35,000 kg, CNC SELCA 4040 DH Maximum drilling depth in single cycle, V axis: 1,500 mm Column, longitudinal travel X axis: 3,250 mm Vertical travel Y axis: 1,500 mm Drilling slide, workpiece support movement W axis: 500 mm Maximum workpiece height: 2,400 mm Clamping table and workpiece approach movement U axis: 1,000 mm Controlled radial resolution, B axis: 360,000 divisions/rev Clamping table, rotating surface size: 1,600 x 1,800 mm Clamping table, max load with rotating workpiece: 20,000 kg Standard T-slot size: 22 mm Minimum–maximum solid drilling diameter: 5 – 50 mm Rapid feed rate, adjustable max speed: 8,000 mm/min Drilling spindle rotation speed, adjustable: 1 – 4,200 rpm Drilling spindle motor power: 15 kW Gun drill tool holders: Shank for drill Ø < 6 mm: Ø 10 x 40 mm Shank for drill 6 mm < Ø < 25 mm: Ø 25 x 70 mm Shank for drill Ø > 25 mm: Ø 40 x 70 mm Dimensions and weights Hsdpfx Asyymdisc Asfl Width x Length x Height MF 1500 BB: 5,900 x 7,600 x 3,850 mm Total weight: 42,000 kg Oil tank capacity: 600 – 1,200 liters WORK SLIDE TILTING Minimum / maximum vertical inclination – A axis: +20° / -20° Continuous controlled radial resolution: 0.001° MILLING HEAD – ISO 50 spindle connection Max horizontal working stroke – Z + W axes: 1,000 mm Column longitudinal travel – X axis: 3,250 mm Drilling slide vertical travel – Y axis: 1,500 mm Spindle rotation speed, adjustable max: 2,500 rpm Spindle power (S1 duty): 17 kW Maximum spindle torque: 680 Nm ROTO-TRANSLATING CLAMPING TABLE Max clamping surface: 2,000 x 2,000 mm Max horizontal travel – U axis: 1,000 mm Continuous controlled radial resolution: 0.001° Max rotating workpiece load: 35,000 kg Standard T-slot size: 22 mm Machine complete with: • Remote electronic handwheel • ISO 50 tool changer magazine with 10 positions • Many tools and working equipment • Rack with various drills • User manual, maintenance manual, and CE conformity declaration

Condition: excellent (used), Year of construction: 1986, machine/vehicle number: 00127634, functionality: fully functional, High-speed bench drill, Made in Germany - Clamping table: 290 x 225 mm - Travel: 150 mm with hand crank - Spindle fitting: Drill chuck included - Drilling capacity in steel Ø 1 - 6 mm - Throat depth: 180 mm - Speeds: 900 - 10,000 rpm, 8 steps - Column: diameter 75 mm - Spindle stroke: 60 mm, with fine stop - Voltage: 380 V - Dimensions: 640/330/H740 mm - Weight: 92 kg Hjdpfoyx Dzpex Ac Asfl

Condition: excellent (used), Year of construction: 2018, functionality: fully functional, drilling depth: 1,600 mm, feed length X-axis: 3,000 mm, feed length Y-axis: 2,100 mm, feed length Z-axis: 1,500 mm, overall weight: 50,000 kg, feed rate X-axis: 10,000 m/min, feed rate Y-axis: 10,000 m/min, feed rate Z-axis: 10,000 m/min, spindle speed (max.): 4,500 rpm, drill diameter: 40 mm, table length: 2,100 mm, table width: 1,900 mm, CNC Heidenhain iTNC 640 AXES OF MOVEMENT Maximum drilling depth in a single operation (V axis): mm 1,600 Hfsdpjywnr Nefx Ac Ajl Table travel, horizontal movement (X axis): mm 3,000 Vertical movement (Y axis): mm 2,100 Column approach movement (milling) (Z axis): mm 1,500 Drilling slide tilting (resolution 0.001°) (A axis): +30° / -15° Table rotation (resolution 0.001°) (B axis): 360° Max axis feed rate: mm/min 10,000 DEEP HOLE DRILLING AND MILLING SPINDLE – ISO 50 Solid drilling capacity: mm 5 – 25 Maximum drilling diameter: mm 40 Adjustable spindle speed: rpm 1 – 4,500 Spindle power S1: kW 17 Spindle torque: Nm 324 Standard drilling tool holder: mm Ø 25 x 70 Maximum internal spindle pressure: bar 120 Taper type: ISO 50 DIN 69871/A Coolant system: Yes ROTARY TABLE Rotary table dimensions: mm 1,900 x 2,100 Table rotation (resolution 0.001°) (B axis): 360° Table load capacity in rotation: kg 20,000 T-slots: mm 22 OIL SYSTEM Hydraulic pump motor power: kW 4 – 7.5 Self-regulated oil pressure: bar 15 – 120 Self-regulated oil flow rate: l/min 5 – 80 Oil tank capacity: L 800 – 1,000 Cooled oil temperature: 25 – 32 °C Filtration grade: micron 16 MACHINE DIMENSIONS AND WEIGHT Width x Length x Height: mm 7,000 x 7,900 x4,700h Machine weight: kg 50,000 DRILLING CAPABILITIES WITH GUN DRILLS Maximum depth: mm 1,600 Maximum rotation speed: rpm 4,500 Minimum drilling diameter: mm 6 Maximum drilling diameter: mm 40 THREADING HEAD “IMSASISTEM” WORKING FEATURES Max rotation speed: rpm 4,500 Maximum threading on C40 steel: M36 Machine equipped with: • Remote electronic handwheel Heidenhain • ISO 50 tool changer magazine with 40 positions • Fume extraction system 4,000 m³/hour • Through-spindle air/oil system • M24 threads on table side • Various tools and equipment • Tool rack with assorted gun drills • User and maintenance manual and CE declaration of conformity

Condition: excellent (used), Year of construction: 2017, functionality: fully functional, drilling depth: 2,250 mm, travel distance X-axis: 2,000 mm, travel distance Y-axis: 1,500 mm, travel distance Z-axis: 700 mm, spindle speed (max.): 4,500 rpm, drill diameter: 40 mm, table length: 1,600 mm, table width: 1,300 mm, table load: 20,000 kg, Deep Hole Drilling, Milling and Tapping Machine 5 linear axes X, Y, Y1, Z, W Rotary table axis B Equipped with 3D CAD simulation, WISE PLUS system, electrical cabinet cooling, and fume extraction system. Capacity Gun drilling capacity: 40 mm Table X-axis stroke: 2000 mm Ram Y-axis stroke: 1500 mm Column Z-axis stroke: 700 mm Spindle taper: ISO 50 – DIN 69871 Motor power: 22 / 33 kW Table size: 1600 × 1300 mm Hedsyuc Rtopfx Ac Asfl Technical Specifications Drilling diameter range: Ø 5 – Ø 40 mm Maximum drilling depth: 2250 mm Milling capacity with cutting tools up to: Ø 60 mm Drilling axis inclination: W -15° / +25° Milling capacity: 400 cm³/min Filtration and cooling system tank capacity: 2000 L Maximum pressure: 80 bar Direct gun drilling with guide bushings: up to Ø 20 mm Rotary table load capacity: 20,000 kg Positioning: 360,000 positions 9 T-slots 18 H12 P=140 Positioning accuracy: ± 0.2 sec Linear Axes X: 2000 mm Y: 1500 mm Z: 700 mm W: 1630 mm

Condition: used, Year of construction: 1971, core drilling diameter max. 50-355 mm bore depth 4000 mm swing diameter 1000 mm centre height 500 mm full boring 18-100 mm main spindle bore 163 mm turning speeds 56-710 U/min workpiece weight 6,3/10 t Tailstock 70-600 mm Drill pipes, guide block, drill head, rolling steady rest, support bearing drill heads, jaws 21- 240 mm, Holder, tools, shelves, cupboards Hedpfxsyt Rz Dj Ac Aefl The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: excellent (used), drilling depth: 1,000 mm, overall weight: 20,000 kg, travel distance X-axis: 1,250 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 380 mm, drill diameter: 40 mm, rotational speed (max.): 4,200 rpm, table length: 1,000 mm, table width: 800 mm, table load: 9,000 kg, feed length W-axis: 500 mm, Equipment: rotational speed infinitely variable, IMSA DEEP HOLE DRILLING MACHINE, MODEL MF 1000 BB TRAVELS: LONGITUDINAL AXIS 1250 TRANSVERSE AXIS (MILLING SPINDLE) 380 mm TRANSVERSE HEAD TRAVEL 500 mm VERTICAL TRAVEL 1000 mm MAXIMUM DRILLING DEPTH 1000 mm MAXIMUM DRILLING SPINDLE SPEED 4200 RPM MAXIMUM DRILLING DIAMETER 40 mm MAXIMUM MILLING SPINDLE SPEED 4000 RPM Hsdpfjytff Dex Ac Asfl MAXIMUM THREADING SIZE M 40 MAXIMUM MILLING DIAMETER 65 mm SPINDLE TRAVEL 380 mm ROTARY TABLE DIMENSIONS 1000x800 MAXIMUM WEIGHT WITH STATIONARY TABLE 9000 KG MAXIMUM WEIGHT WITH ROTATING TABLE 4000 KG TOTAL MACHINE WEIGHT 20,000 KG

Condition: used, Year of construction: 2006, full boring 150 mm bore depth 13000 mm full boring 150 mm workpiece weight 80 t control Siemens type S 7 workpiece dia. 1250 mm 0 2000 mm borehole diameter 450 mm weight of the machine ca. 160 t Headstock adjustment 10,000mm Headstock bed bed width 1600mm, guideway width 360 Center height of headstock 1600 mm Face plate 1750 mm Drive 60 KW Speed ??2.62-200 rpm Bed for drilling unit Bed length 27,000 mm Bed width 1320 mm Guideway width 290 mm height of the bed 670 mm Drill motor 60 KW Drilling unit Sph 920 mm The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Hodpfx Acoyqvcno Aofl Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: used, faceplate diameter 3100 mm swing diameter 3600 mm turning height 3600 mm control Fagor 8035 table load 35 t turning speeds 0,32 - 40 U/min max. ram stroke 3000 mm table load 35 t turning speeds 0,32-40 U/min total power requirement 70 kW 2x Ram head 250 x 250 mm Chip conveyor Mist extraction unit Coolant system The tech. Data are manufacturer or operator information and therefore non- binding. We reserve the right to prior sale; Our terms and conditions of sale apply exclusively. About us More than 400 of our own machines in stock Hfsdsyqt Hdjpfx Ac Ael Over 15,000 m² of storage space, 70 t crane capacity More than 10,000 items and accessories for your workshop If you are interested in selling machines, production lines, or your business, please contact us. You can find further offers on our website. Tours are possible by appointment. We look forward to your visit. Your Markus Hirsch Team

Condition: excellent (used), Year of construction: 2008, operating hours: 39,000 h, functionality: fully functional, drilling depth: 1,800 mm, drill diameter: 30 mm, Manufacturer: SFT Model: TBM 3-1500 Machine type: Deep hole drilling machine with BTA system Drilling diameter: 15 – 30 mm Drilling depth: 1800 mm Chip conveyor: included Control: SFT / PS 100 incl. control cabinet Hjdpeynui Iefx Ac Asfl Frequency inverter: included Oil sump: included Coolant tank: 2,500 liters oil Coolant pumps: 3 units, each adjustable to 40 liters, 100 bar Signal beacon: included Tailstock: rotating and adjustable according to drilling length Clamping: hydraulic clamping operation Drill spindle: speed regulation available Paintwork: light grey / blue Loading station: automatic door Machine footprint: 7,000 x 1,200 mm Filter footprint: 3,000 x 800 x 1,250 mm Commissioned: late 2007 Recurring maintenance according to manufacturer’s specifications Available: end of March 2026 Operation: 2/3-shift operation

Condition: refurbished (used), Year of construction: 1992, functionality: fully functional, WE OFFER AN NICE CONDITION DEEP HOLE DRILLING IXION WITH BRAND NEW CONTROLS Hjdpfeyk Ixbex Ac Ajfl
