Prelle

Condition: ready for operation (used), Year of construction: 2005, functionality: fully functional, machine/vehicle number: 1500050285, travel distance X-axis: 7,800 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 630 mm, spindle speed (max.): 24,000 rpm, number of slots in tool magazine: 14, Submitting a bid obligates the buyer to collect the item on time on 23.12.2025! TECHNICAL DETAILS Travel X-axis: 7,800 mm Travel Y-axis: 1,000 mm Travel Z-axis: 630 mm Rapid traverse X-axis: 70 m/min Rapid traverse Y-axis: 40 m/min Rapid traverse Z-axis: 40 m/min Max. workpiece length: 7,300 mm Max. spindle speed: 24,000 rpm Spindle motor power: 15,000 W Number of spindles: 1 Number of tool magazine slots: 14 Tool diameter: 100 mm MACHINE DETAILS Input voltage: 400 V Type of input current: Alternating current (AC) EQUIPMENT Documentation/manual included Magazine can be equipped with nine standard tools, five special tools, and one saw blade Ten clamping devices Nwsdpfx Aoxx Uf Noh Rep Two separate work areas for pendulum operation 15" color display Floppy disk drive DOS operating system

Condition: used, Year of construction: 2009, functionality: limited functionality, machine/vehicle number: B-8023, Technical characteristics: # Machining Workspace: X 800 mm; Y 400 mm; Height from table surface to floor: 850 mm (max load 450 kg) # Number of T-slots: 3 / Distance between T-slots: 125 mm / Width of T-slots: 18 mm # Axis configuration: 3 LINEAR AXES (X, Y, Z) + 2 twin horizontal spindles + 4th Axis # Rapid traverse speed: X, Y, Z – 30 m/min # Travel: Longitudinal (X-axis) 600 mm, Cross (Y-axis) 400 mm, Vertical (Z-axis) 510 mm Headstock features: # Spindle distance: 200 mm # Maximum distance from spindle to table: 650 mm Nsdpfjxxi Skex Ah Rjwp # Spindle nose: ISO7388 (with internal cooling), Tool Holder (Size 40) # Speed range (standard): 100/8,000 rpm, Max torque: 85 Nm at 330 rpm, 7.5 kW Automatic tool changer: # Number of tools: 20, Selection system: Sequential/random, Max. diameter (adjacent tool): 85 mm, Max. diameter (non-adjacent tool): 135 mm, Max. tool length: 250 mm, Max. tool weight: 6.5 kg, Tool change time: 6 s. Tool change time (fastest): 3 s. Electrical connection: # Voltage: 3x400V/50Hz # Installed power: approx. 30 kVA Dimensions: # Required floor space: approx. L 2.1 x W 3.5 x H 3 m # Weight: approx. 4,200 kg Equipment includes: # CNC control: GE Fanuc Series 31i MODEL A # 4th axis: Nikken CNC180 FA (2012) # Broken tool detection system: Blum Novotechnik # Chip extractor # Lubrication system # Electrical panel cooling system # Spindle cooling system: HARBOR Model HBO-750PTSB2 # Documentation: Electronic and hard copy available Machine condition: OPERATIONAL — with 1 spindle / 2nd spindle defective — can be repaired.

Condition: repair required (used), Year of construction: 2009, functionality: not functional, machine/vehicle number: B-8024, Technical characteristics: # Machining Workspace: X 800 mm; Y 400 mm; Height from table surface to floor: 850 mm (max load 450 kg) # Number of T-slots: 3 / Distance between T-slots: 125 mm / Width of T-slots: 18 mm # Axis configuration: 3 LINEAR AXES (X, Y, Z) + 2 twin horizontal spindles + 4th axis # Rapid traverse rates: X, Y, Z – 30 m/min # Travel paths: Longitudinal (X-axis) 600 mm, Transverse (Y-axis) 400 mm, Vertical (Z-axis) 510 mm Nwodpjxxi Ewsfx Ah Rsp Headstock: # Spindle distance: 200 mm # Max. distance from spindle center to table: 650 mm # Spindle interface: ISO 7388 (with internal coolant), Tool holder size: 40 # Speed range (standard): 100 – 8000 rpm, Maximum torque at 330 rpm: 85 Nm, 7.5 kW Automatic tool changer: # Number of tools: 20, Selection system: sequential/random, Max. tool diameter (adjacent): 85 mm, Max. tool diameter (non-adjacent): 135 mm, Max. tool length: 250 mm, Max. tool weight: 6.5 kg, Tool change time: 3 seconds Electrical connection: # Voltage: 3x400V / 50Hz # Installed power: approx. 30 kVA Dimensions: # Required floor space: approx. L 2.1 x W 3.5 x H 3 m # Weight: approx. 4200 kg Equipment included: # CNC control – GE Fanuc Series 31i MODEL A # Chip conveyor # Lubrication system # Cooling system # Electrical cabinet # Spindle chiller: HARBOR Model: HBO-750PTSB2 # Documentation: Digital and hard copy available Machine condition: NOT OPERATIONAL # Y axis motor defective – requires replacement (not repairable) # 2 tool changer units defective – require replacement (not repairable) # Spindles defective – require replacement (not repairable) # Hydraulic unit defective – needs replacement or repair

Condition: repair required (used), Year of construction: 2010, functionality: not functional, machine/vehicle number: B-8029, Technical Characteristics: # Machining Workspace: X 800 mm; Y 400 mm; Table surface to floor height: 850 mm (maximum load 450 kg) Nwjdpfxjxxiy Is Ah Rsp # Number of T-slots: 3 / Distance between T-slots: 125 mm / T-slot width: 18 mm # Axis description: 3 linear axes (X, Y, Z) + 2 twin horizontal spindles + 4th axis # Rapid traverse rate: X, Y, Z – 30 m/min # Travel: Longitudinal (X-axis) 600 mm, Cross (Y-axis) 400 mm, Vertical (Z-axis) 510 mm Headstock Capabilities: # Spindle distance: 200 mm # Max. distance from spindle to table: 650 mm # Spindle nose: ISO7388 (with through-spindle coolant), Tool holder: Size 40 # Speed range (standard): 100–8000 rpm, Maximum torque / at 330 rpm: 85 Nm, 7.5 kW Automatic Tool Changer: # Number of tools: 20, Selection system: Sequential / random, # Max. diameter (adjacent tool): 85 mm, Max. diameter (non-adjacent tool): 135 mm, # Max. tool length: 250 mm, Max. tool weight: 6.5 kg, Tool change time: 6 s. # Tool change time: 3 s. Electrical connection: # Supply voltage: 3x400V/50Hz # Installed power: approx. 30 kVA Dimensions: # Required floor space: approx. L 2.1 x W 3.5 x H 3 m # Weight: approx. 4,200 kg Equipment includes: # CNC control: GE Fanuc Series 31i MODEL A # Chip extractor # Lubrication system # Cooling system # Electrical panel # Spindle cooling system: HARBOR Model: HBO-750PTSB2 # Documentation: Electronic and hard copy available Machine Condition: NOT WORKING # Tool changer: 1 unit broken – needs replacement (not repairable) # Spindles: broken – need replacement (not repairable) # Hydraulic unit: broken – needs replacement or repair

Condition: repair required (used), Year of construction: 2007, functionality: not functional, machine/vehicle number: 1830108, Technical specifications: # Machining workspace: X 300 mm; Y 650 mm; Z 400 mm # Axis configuration: 3 linear axes (X, Y, Z) + 1 rotary table axis (A-axis), 360° indexable dividing head (resolution 0.001°) # Number of pallets: 2; Maximum table load: 400 kg # Maximum clamping/part size: Ø 575 x 830 mm; maximum weight: 360 kg # Rapid traverse rate: X/Y/Z 75/75/75 m/min; Positioning accuracy Tp: 0.008 mm # Number of spindles: 2 / spindle spacing: 300 mm # Spindle speed: 1–10,000 rpm # Spindle interface: DIN69893-HSK-A63 (with internal coolant supply) # Automatic tool changer: 2 x 32 tools / chip-to-chip time approx. 2.5 s # Tool max. Ø75 mm / length max. 275 mm / max. weight 7.5 kg Nwsdpsxw Ukvefx Ah Rsp Electrical connection: # Voltage: 3x400V/50Hz # Installed power: approx. 70 kVA / 125A Dimensions: # Installation footprint: approx. 3.9 x 3.2 x 3.1 m # Weight: approx. 10,500 kg Scope of supply: # CNC control: Fanuc 30i-Model A # Linear axis measuring system: Heidenhain linear scales # Chip conveyor: Knoll Type 550 K-1 # Oil cooling unit # High-pressure oil filtration system max. 40 bar: Knoll AE 1060 # Cooling system for spindle, guides, and switch cabinet # 2 oil lubrication units # Part present sensing (P/Y): with low-pressure air sensors # Broken tool detection: Blum Novotec Laser Light Probe # Tool support detection system in working spindle Machine condition: NOT OPERATIONAL # Magazine chain broken — REQUIRES REPLACEMENT

Condition: used, Year of construction: 2010, functionality: fully functional, machine/vehicle number: B-8044, Technical characteristics: # Machining workspace: X 800 mm; Y 400 mm; Height from table surface to floor: 850 mm (maximum load 450 kg) # Number of T-slots: 3 / Distance between T-slots: 125 mm / Width of T-slots: 18 mm # Axis configuration: 3 LINEAR AXES (X, Y, Z) + 4th axis # Rapid traverse: X, Y, Z - 30 m/min # Travel: Longitudinal (X-axis): 600 mm, Cross (Y-axis): 400 mm, Vertical (Z-axis): 510 mm Headstock specifications: # Maximum distance spindle to table: 650 mm # Spindle taper: ISO 7388 (with internal cooling), Tool holder: Size 40 # Spindle speed range (standard): 100/14,000 rpm, Max. torque: 63.7/89.4 Nm at 330 rpm Automatic tool changer: # Number of tools: 20 # Tool selection system: sequential/random # Max. tool diameter (adjacent): 85 mm, Max. tool diameter (non-adjacent): 135 mm # Max. tool length: 300 mm # Max. tool weight: 6.5 kg # Tool change time: 6 seconds (standard), 3 seconds (fast) Electrical connection: # Voltage: 3x400V/50Hz # Installed power: approx. 30 kVA Dimensions: # Floor space required: approx. L 2.1 x W 3.5 x H 3 m # Weight: approx. 4,200 kg Equipment included: # CNC Control: GE Fanuc Series 31i MODEL A # Chip conveyor # Lubrication system # Emulsion paper filtration system: Filber S.L. Model FTH5/10 – 200 l/min # Electrical cabinet cooling system # Spindle cooling system: HARBOR Model HBO-750PTSB2 # Documentation: Electronic and hard copy available Machine status: Nodoxw Tqzjpfx Ah Rowp IN OPERATION

Condition: repair required (used), Year of construction: 2009, functionality: not functional, machine/vehicle number: 281-09, Technical Characteristics: # Machining Workspace: X 550 mm; Y 400 mm; Z 360 mm # Axis Description: 3 linear axes (X, Y, Z) + rotary table axis A and 2 rotary axes B, equipped with an index divider head with direct angular measuring system, max. rotation speed 50 min⁻¹, accuracy +/- 5" # Axis A swivel: +/-110˚ # Max. clamping/part dimensions: Ø 247 x 830 mm; max. weight 360 kg # Rapid traverse: X/Y/Z 40/40/40 m/min # Distance between divider heads B1/B2: 250 mm # Spindle speed: 1-10,000 rpm # Spindle interface: DIN69893-HSK-A63 (with internal coolant supply) # Automatic tool changer: 1x48 tools / chip-to-chip time approx. 2.5 sec # Max. tool diameter: Ø 82 mm / max. length 250 mm / max. weight 5 kg Electrical Connection: # Voltage: 3x400V/50Hz # Total installed power: approx. 45 kVA / 80A Dimensions: # Installation footprint: approx. 4.4 x 2.3 x 3.1 m # Weight: approx. 8,500 kg Equipment Includes: # CNC control: Siemens 840D Power Line # Chip extractor: Spring Knoll # Oil cooling system # High-pressure oil filtration system, up to 80 Bar: Knoll HL 450/1200 # Cooling system for spindle, linear guides, and control cabinet # 2 independent oil lubrication systems # Oil vapor extraction/recovery system: LTA AC3002 # Fire suppression system: Kraft & Bauer # Part presence detection: with low-pressure air sensors # In-process measurement: Marposs T25 # Tool breakage detection: Blum Novotech # Tool holder detection system in spindle # Documentation: incomplete Nwsdexwmvkjpfx Ah Rop Machine Condition: NOT OPERATIONAL # Hydraulic oil leakage at Peiseler rotary table # New hydraulic pump available in stock

Condition: excellent (used), Year of construction: 2012, operating hours: 3,060 h, functionality: fully functional, Longitudinal travel: 2000 mm Cross travel: 520 mm Vertical travel: 540 mm Table: 2500x520 mm Table load: 2000 kg Spindle speed: 60-12000 rpm Operating hours: 3060 h Fixed table design Spindle taper: BBT40 ATC: 30 positions Power supply: 53 kVA Year of manufacture: 2012.09 Length: 4650 mm Width: 3235 mm Height: 2845 mm Weight: 13300 kg Nwjdpfx Aoxwlu Esh Rep Fixed table design 2-zone machining (2x650 mm)

Condition: new, Model A-12, With Standard Accessories: - Travel: X 1200mm/ Y700mm/Z 700mm - FANUC-0iMF Plus (10.4") with Manual Guide I, AICCII-200 and Smooth Tolerance Control (which including Nano Smoothing) - Spindle Taper:BT-40 - Tool Magazine: 24 ARM TYPE ATC - Spindle Motor:β12/10,000(11/15KW) - Spindle Speed: 8,000 RPM (Pulley Drive) - X/Y/Z SERVO MOTORS: β22/3,000 (3KW)*2+β 30B/2,000(4KW)*1 - Cutting Coolant Equipment - Oil Circulating Coolant System for Spindle - Three-color Indicator Light - Fluorescent Light*2PCS - Automatic Lubrication Equipment - Heat Exchanger for Electric Cabinet - Fully Enclosed Splash Guard - Tool Box W/Leveling Bolts & Pads - Auto Power Off - Cutting Air Blast - Rigid Tapping - Spindle Coolant - Operation Manual - Part Program Storage Length: 2 Mbyte - Electrical Cabinet - Y Axis 2 PCS Chip Augers - X/Y/Z Ball Screw ψ45/P12/C3 with pretensioned - X/Y/Z Roller Rail 45mm with 2 tracks/ 4 tracks/ 2 tracks - Machine Weight around 9500 kgs - CE specification - CE TRANSFORMER 35KVA - Chip Conveyor+Cart (steel belt type) Njdpfx Aoxvcapoh Rewp -Delivery time 6 weeks -Transport, Installation and training price on request and depend on end user location. -Full warranty -Free on truck Holland. Netherlands.

Condition: new, travel distance X-axis: 1,600 mm, travel distance Y-axis: 800 mm, travel distance Z-axis: 700 mm, -Travel: X1600mm/Y 800mm/Z700mm; Table Size: 1800*800mm -CONTROLLER: FANUC-0iMF Plus (10.4") with Manual Guide I, AICCII-200 and Smooth Tolerance Control (which including Nano Smoothing) -Spindle Taper: BT 50 -Tool Magazine: ARM TYPE 24ATC -Spindle Motor: α15/8Ki 15/18.5KW (20/25HP) -X/Y/Z AXES MOTOR:α22i/3000(4KW) *2+ α22iB/3000(4KW) * -Spindle Speed: Max. 6,000 RPM (Gear Driven) -Spindle Air Blast -Oil Circulating Cooling System For Spindle 10. Cutting Coolant Equipment -CE TRANSFORMER (35 KVA) -CE SPECIFICATION (CE security door + CE security module) -Cutting Air Blast -Rigid Tapping -Spindle Coolant -Part Program Storage Length: 2Mbyte Nwodpfjxva Anox Ah Rep -Remote Manual Pulse Generator (M.P.G.) -Operation Manual -X AXIS (1 PC IN FRONT)+Y AXIS (2 PCS) SCREW TYPE CHIP AUGER

Condition: ready for operation (used), travel distance Z-axis: 508 mm, feed length X-axis: 1,500 mm, feed length Y-axis: 760 mm, controller manufacturer: Mazatrol M2, total height: 2,990 mm, total length: 3,105 mm, Mazak VQC 30/50B X:1500 - Y:760 - Z:508 mm Table dimensions: 1600 x 800 x 500 mm Max weight on the table: 1500 kg Admission in spindle (ISO): ISO 50 Nwedpoxuwyzjfx Ah Rep Power on the spindle: 11 kW Toolchanger: 24 positions Number of rotations: 30 -> 3150 rpm

Condition: good (used), Year of construction: 2004, This 3 axis vertical machining center is in good working condition with ca 18000 spindle hours. Equipped with chip conveyor, removable turntable and tool measuring probe. Viewing possible upon appointment. Availability: 03/2026 More information on request. Control Heidenhain iTNC530 Max spindle speed 10000 rpm Spindle taper SK40 Table dimensions 3100 x 900 mm Max table load 3100 kg Travel X-axis 2500 mm Travel Y-axis 920 mm Travel Z-axis 820 mm Capacity tool magazine 30 positions Max. tool diameter ∅ 100 mm Max. tool length 300 mm Max. tool weight 12kg Machine dimensions (LxWxH) 6000 x 3800 x 2950 mm Nwsdpjxutbzofx Ah Rsp Please note: The information on this page has been obtained to the best of our ability and belief. This information is provided in good faith, but its accuracy is not guaranteed. Accordingly, this information is not binding and does not constitute a contractual condition. We recommend that you check all essential details during an inspection of the machine. To save unnecessary travel costs for our customers, in most cases we recommend organizing a live video inspection.

Condition: used, Year of construction: 2005, Mazak VC Nexus 510C Mazatrol 640M Nexus Year of manufacture: 2005 Table: 1300 x 550 mm X: 1050 mm Y: 510 mm Nedpfx Ajxqltzjh Rewp Z: 510 mm 12,000 RPM/18.5 kW spindle: ISO-40 ATC: 30 positions tool measure, CTS 15 bar Performance CNC optional package YOM: 2005 Table: 1300 x 550 mm Y: 510 mm X: 1050 mm Spindle: ISO-40 Z: 510 mm ATC: 30 positions

Condition: ready for operation (used), travel distance Z-axis: 610 mm, feed length X-axis: 1,230 mm, feed length Y-axis: 610 mm, nominal power (apparent): 25 kVA, controller manufacturer: Fanuc, total height: 2,800 mm, total length: 3,800 mm, total width: 2,800 mm, empty load weight: 9,700 kg, Hartford VMC1230A X: 1230 - Y: 610 - Z: 610mm Nwedpfxoxp Slus Ah Rjp Table dimensions: 1270 x 630 mm Max weight on the table: 1200 kg Depth of throat (uprights-spindlecenter): 610 mm Admission in spindle (ISO): ISO 50 Power on the spindle: 15 kW / 20 hp Number of axes: 3 Toolchanger: yes Number of toolholders: 20 tools Number of rotations: 50 - 6000 rpm

Condition: ready for operation (used), travel distance Z-axis: 508 mm, feed length X-axis: 1,016 mm, feed length Y-axis: 610 mm, controller manufacturer: Heidenhain TNC 410, total height: 2,600 mm, total length: 2,260 mm, total width: 3,280 mm, empty load weight: 6,000 kg, rotational speed of tool magazine (max.): 8,000 rpm, Tos -Mas MC100V X:1016 - Y:610 - Z: 508mm Table dimensions: 1080 x 580 mm Admission in spindle (ISO): ISO 40 Power on the spindle: 16 kW Nwedsxp Slnjpfx Ah Rsp Toolchanger: yes Number of toolholders: 40x

Condition: ready for operation (used), travel distance Z-axis: 500 mm, feed length X-axis: 1,020 mm, feed length Y-axis: 510 mm, controller manufacturer: Heidenhain TNC 410, total height: 2,600 mm, total length: 3,000 mm, total width: 2,200 mm, empty load weight: 3,600 kg, rotational speed of tool magazine (max.): 6,000 rpm, Chipconveyor Table dimensions: 1150 x 490 mm Admission in spindle (ISO): BT 40 Power on the spindle: 11 kW Nedpfx Ahoxp Slhj Rowp Toolchanger: yes Number of toolholders: 22 tools

Condition: ready for operation (used), controller manufacturer: Fanuc, Freesrobot Staubli RX170HM Deze robot is voorzien van gaten om te frezen in mallen van banden, maar ook in andere zaken is dit mogelijk. Koeling door de spindel en de koelmelk is luchtgekoeld. Smering Gebeurde met vet. spindelopname: HSK E 32 Actieradius: 1835 mm Werd gebruikt in Tire Mold fabriek Mecamold Herstal. Max weight on the table: 300 kg Admission in spindle (ISO): HSK E 32 Power on the spindle: 8 kW Nedpfx Ahexppngs Rewp Drilling-capacity: 80 mm Tapping-capacity: 80 mm Number of axes: 6 Toolchanger: yes Number of rotations: 500 - 20 000 rpm Power principal motor: 5 kW

Condition: used, Year of construction: 2016, functionality: fully functional, travel distance X-axis: 450 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 330 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 30 m/min, rapid traverse Z-axis: 30 m/min, controller manufacturer: Siemens, controller model: 840D, workpiece height (max.): 370 mm, table width: 320 mm, table length: 320 mm, table load: 300 kg, rotational speed (min.): 80 rpm, rotational speed (max.): 80 rpm, overall weight: 9,000 kg, spindle speed (min.): 15,000 rpm, spindle speed (max.): 15,000 rpm, spindle motor power: 31 W, spindle nose: HSK 63A, tool length: 250 mm, tool diameter: 125 mm, tool weight: 8 g, control type: CNC control, Equipment: chip conveyor, Hermle C22U 5 Axis Machining Centre Siemens 840D Control Nwjdpsxpil Sefx Ah Rjp 5 Axis Simultaneous XYZ: 450 x 600 x 330mm 320mm diameter table Maximum workpiece diameter 320mm maximum workpiece height 265mm Maximum table load 300Kg A axis -/+ 135 degrees spindle speed 15,000rpm 55 station tool changer Swarf Conveyor Coolant Tool Setter Spindle Probe

Condition: ready for operation (used), travel distance Z-axis: 820 mm, feed length X-axis: 2,060 mm, feed length Y-axis: 1,016 mm, nominal power (apparent): 46 kVA, controller manufacturer: Meldas 500, total height: 3,200 mm, total length: 5,600 mm, total width: 3,750 mm, empty load weight: 23,000 kg, Hartford HV-80S X: 2060 - Y: 1016 - Z: 820 mm CNC Table dimensions: 2100 x 1050 mm Njdpfx Ahjxpghdj Rowp Depth of throat (uprights-spindlecenter): 1050 mm Admission in spindle (ISO): BT 50 Power on the spindle: 18/14 kW Toolchanger: yes Number of toolholders: 20 positions Number of rotations: 40 > 3000 rpm

Condition: used, Year of construction: 2021, X Axis 24.0 in (610 mm) Y Axis 16.0 in (406 mm) Z Axis 16.0 in (406 mm) 10+1 pallet pool, UMC Max Speed 15,000 rpm Taper BT40 Magazine Capacity 50+1 Programmable coolant nozzle Nedpfx Ahsxl D Erj Rowp Air through spindle Coolant through spindle Renishaw probe WIFI camera Extra coolant filter B Axis – Tilt (S.A.E / Metric) Travel 120° to -35° Max Torque 1854 ft-lbf (2514 Nm) Brake Torque 900 ft-lbf (1220 Nm) C Axis – Rotation (S.A.E / Metric) Travel 360° / 360° Max Torque 1854 ft-lbf (2514 Nm) Max Part Swing 18.0 in (457 mm) Brake Torque 900 ft-lbf (1220 Nm) Platter Diameter 15.70 in (400 mm) Max Weight on Platter 500 lb (226.8 kg) Max Weight on Platter w/Pallet Pool 200 lb (90.7 kg) T-Slot Width 0.626 in to 0.630 in (15.90 mm to 16.00 mm) Number of Std T-Slots 5 T-Slot Center Distance 2.48 in (63 mm) Max Tool Diameter (full) 2.5 in (64 mm) Max Tool Diameter (adjacent empty) 5.0 in (127 mm) Max Tool Length (from gauge line) 12 in (305 mm) Max Tool Weight 12 lb (5.4 kg) Coolant Capacity 55 gal (208 L)

Condition: ready for operation (used), Year of construction: 2015, functionality: fully functional, travel distance X-axis: 760 mm, travel distance Y-axis: 530 mm, travel distance Z-axis: 560 mm, spindle speed (max.): 12,000 rpm, number of slots in tool magazine: 30, TECHNICAL DETAILS Travels X-axis: 760 mm Y-axis: 530 mm Z-axis: 560 mm Speeds Rapid traverse: 40 m/min Spindle Speed: max. 12,000 rpm Power: max. 25 kW Tool magazine and table Tool magazine positions: 30 Table size (L × W): 900 × 500 mm Njdpfx Ajxlf D Njh Rewp EQUIPMENT Including chip conveyor Including slant bed filtration system Including zero-point clamping system Including 4th axis Rotamatik 120 New Däublin

Condition: excellent (used), Year of construction: 2014, High-Performance Machining Center Spinner VC1200-HS / Siemens 840-SolutionLine Nedpfx Aoxcwgwjh Rjwp Technology: In-line direct drive, spindle speed 12,000 rpm, power 28 kW, torque 178 Nm, tool holder SK40. Equipped with Siemens 840D Solutionline control system and 15" color screen, featuring a graphical user interface for shop floor programming (Siemens "ShopMill") and software version "Operate". Milling spindle up to 12,000 rpm with in-line direct drive. Travel distances: X-1200 mm, Y-730 mm, Z-650 mm; rapid traverse 48 m/min. Tool taper size 40 according to DIN 69871-A, drawbar bolt according to DIN 69872-A. General Features: - Air blast system for spindle taper - High-speed automatic tool changer with dual-arm changer for 32 tools - Linear guides on all three axes - Full enclosure with splash guard and work area lighting Technology: In-line direct drive, spindle speed 12,000 rpm, power 28 kW, torque 178 Nm, tool holder SK40 Tool magazine: 32 tool positions, dual-arm changer. Clamping surface 1,400 x 710 mm. Maximum table load 1,000 kg. Rapid traverse X/Y/Z 48 m/min. Chip management: scraper belt chip conveyor. Coolant supply: internal coolant supply (IKZ system) with filter, 22 bar, and additional 350-liter tank. Direct position measuring system in X/Y/Z (glass scales). Workpiece measurement with probe, BLUM TC52. Tool magazine: dual-arm tool changer for 32 tools. Pneumatics: compressed air connection at the spindle head. Control options: Siemens MyDynamics, 5-axis milling package.

Condition: excellent (used), Year of construction: 2015, High-Performance Machining Center Spinner VC1200-HS / Siemens 840 SolutionLine Technology: In-line direct drive Spindle speed: 12,000 rpm Power: 28 kW Torque: 178 Nm Tool holder: SK 40 General: - Equipped with Siemens 840DE-SolutionLine control system and 15" color screen - Features graphical user interface for shop-floor programming (Siemens "Shop-Mill") and software version "Operate" - Milling spindle up to 12,000 rpm with in-line direct drive - Travels: X-1200 mm, Y-730 mm, Z-650 mm - Rapid traverse: 48 m/min - Tool taper size 40 according to DIN 69871-A, pull studs according to DIN 69872-A - Air blast unit for spindle taper Nodpfxexcwf He Ah Rowp - High-speed automatic tool changer (double-arm) for 32 tools Tool Magazine: - 32 magazine positions, double-arm tool changer - Clamping surface: 1,400 x 710 mm - Max. table load: 1,000 kg - Rapid traverse in X/Y/Z: 48 m/min - Linear guides in all 3 axes - Full enclosure with work area lighting - 4th axis with Siemens motor and direct measuring system (Heidenhain encoder) Further Equipment: - Chip disposal via scraper belt chip conveyor - Coolant supply with internal coolant system (IKZ), filter, 22 bar, and additional 350-liter tank - Direct path measuring systems in X/Y/Z (glass scales) - Workpiece measurement with touch probe, BLUM TC52 - Tool magazine: double-arm tool changer, 32 tools - Compressed air: connection at the spindle head - Control options: Siemens MyDynamics, milling package, 4 axes - 4th-axis rotary table MRNC-320N with Siemens motor and direct measuring system (Heidenhain encoder) - Tailstock NTTS-320, height-adjustable for rotary table

Condition: good (used), Year of construction: 2006, A Heidenhain iTNC530 system is installed. Axes: X 3000 mm, Y 900 mm, Z 900 mm Table: 3000 x 900 mm Table load: 6000 kg Working speed: 3000 rpm Rapid traverse: 20000 mm/min Tools: 24 Motor: 22/27 kW Milling head – semi-automatic (see photo) Nwodoxbzrnjpfx Ah Rsp Indexing range: A-2.5° B-2.5° The machine is not equipped with through-spindle coolant supply.

Condition: ready for operation (used), travel distance Z-axis: 635 mm, feed length X-axis: 1,060 mm, feed length Y-axis: 510 mm, controller manufacturer: Fanuc, total height: 2,800 mm, total length: 3,000 mm, total width: 2,400 mm, empty load weight: 7,000 kg, rotational speed of tool magazine (max.): 10,000 rpm, met koeling door spindel met spaantransportband met Kitagawa 4e as Table dimensions: 1200 x 500 mm Nodpfexadmrsx Ah Rswp Admission in spindle (ISO): BT 40 Power on the spindle: 15 kW Toolchanger: yes Number of toolholders: 30 positions
