National Europe

Condition: ready for operation (used), Year of construction: 2000, Line for the production of round tubes and closed profiles from black and stainless steel, with diameters ranging from 20.0 mm to 70.0 mm and wall thicknesses from 0.5 mm to 3.5 mm. Different diameter ranges are possible by manufacturing a suitable set of rollers. The tube or closed profile is formed by rolling the appropriately sized and thick steel strip using a roller set, then joined together by TIG welding. During production, the following processing steps are performed: a) grinding the weld seam b) calibration c) straightening d) and cutting to length The finished product, the 'raw tube', can be further processed to achieve the desired surface structure. Two main finishing processes are used: a) wet grinding using abrasive belts b) and/or dry polishing using polishing wheels and compounds. CONSTRUCTION The tube/profiling line features automatic TIG welding by SAF: a) Tricathode NERTAMATIC 300 TR TIG inverter, 2 units b) Tricathode NETRINOX TH 500 TIG inverter, 1 unit c) Welding of 0.5 – 1.5 mm wall thickness products using E16 torch d) Welding of 1.5 – 3.5 mm wall thickness products using E25 torch e) RETRISAF cooling system 1.1 Steel strip coil support and decoiler 1.2 Roll forming stations a) entry station b) preliminary forming station c) main forming station 1.3 Welding segment – triple-electrode TIG welding heads with inert gas (argon) shielding 1.4 Weld seam cleaning station 1.5 Calibration station 1.6 Straightening station Fgsdpfxjxmiirj Afpeh 1.7 Flying saw – product cutting to specified length Additional line components: 1.8 Bossi 4-head tube grinder Type: CPS 400x3000/4 Belt: 3000x150 mm 1.9 Bossi 2-head tube polisher Type: CP 400-2U

Condition: excellent (used), Year of construction: 2005, functionality: fully functional, overall weight: 2,900 kg, input voltage: 400 V, power: 4 kW (5.44 HP), type of input current: three-phase, Eccentric press PRESSIX 40T Model 40CNV4 Serial No 40/2/88/03 MAchine weight _ 2900 kg Inverter for speed change. Variable speed 60/180 rpm High number of strokes per minute Slider with 4 bronze guides Automatic and centralized lubrication Hydraulic release Pneumatic clutch-brake group Adjustable stroke length using a toothed ring Balancing cylinders Slider adjustment mm 70 Closing height mm 240 Table surface mm 480 x 650x53 Table opening mm 120 Slider surface mm 300 x 370 Hole in the slider mm 50 Power kW 4 User manual and electrical installation in English. Machine in excellent condition. Used for small batches of automatic production. Fjdjxlpurepfx Afpjgh Total: 6,500,000 strokes Programs: tool adjustment, semi-automatic work, auto, automatic work, two-handed work, work with a pedal, turning the mortar in the opposite direction Dismantling and loading are charged additionally

Condition: good (used), Year of construction: 1987, functionality: fully functional, center width: 825 mm, center height: 350 mm, spindle motor power: 7,500 W, total length: 2,800 mm, spindle speed (min.): 300 rpm, spindle speed (max.): 2,500 rpm, quill diameter: 60 mm, quill stroke: 500 mm, total height: 2,200 mm, total width: 2,000 mm, overall weight: 3,500 kg, product height (max.): 3 mm, feed force X-axis: 2,800 N, feed force Z-axis: 2,800 N, feed length X-axis: 250 mm, feed length Z-axis: 450 mm, feed rate X-axis: 6 m/min, feed rate Z-axis: 6 m/min, The machine is located in our warehouse. It is connected and can be tested at any time. Fgjdpfxoxfiq Ho Afpeh

Condition: ready for operation (used), Year of construction: 2010, functionality: fully functional, BUD-MASZ roof tile sheet machine, manufactured in 2010, 3,510 km mileage, 1250 mm strip, without decoiler. Fgodsxbgl Tepfx Afpsh

Condition: used, Year of construction: 1989, functionality: fully functional, machine/vehicle number: 2035, input voltage: 380 V, power: 4 kW (5.44 HP), Transfer punching machine SCHOREDER & BAUER HB 20 Power 20T per workstation (2x20 T) Number of strokes from 20-100 rpm Year: 1989 Serial number: 2035 Kw 4 Weight approx. 3500 kg Complete documentation comes with the machine. Fgedpfx Ajw Tcglsfpsh The machine is in working condition.

Condition: like new (used), Year of construction: 2011, functionality: fully functional, overall weight: 30,000 kg, LEIFELD spinning machine, max diameter 900 mm, weight 30 tons. Fgedpfow Ix Izsx Afpjh

Condition: excellent (used), Year of construction: 2008, operating hours: 500 h, functionality: unexamined, machine/vehicle number: CV0604, pipe diameter (max.): 1,400 mm, Equipment: CE marking, Incremental HOT Pipe Induction Bending Machine – Cojafex (Netherlands) | 2008 Make: Cojafex (OEM, Netherlands) Model: Incremental HOT Pipe Induction Bending Machine Year of Manufacture: 2008 Condition: Almost unused – only 198 pipes bent Location: India (Currently dismantled & ready for transport) Availability: Immediate Price: Euro 1.5 Million Key Features: Original OEM Make – Cojafex, Netherlands, global leader in pipe induction bending technology Fsdpfxsw Igr Is Afpegh Incremental hot pipe bending for high-precision industrial applications Suitable for bending large-diameter and 100 MM thick-walled pipes of Dia 1400 MM Machine is almost unused – only 198 pipes bent Ideal for oil & gas, energy, heavy engineering, and infrastructure sectors Condition & Readiness: Machine is dismantled, stored securely in India Can be inspected upon request OEM (Cojafex) ready to commission and install the machine on-site under a separate contract Logistics: Can be shipped internationally Crating and loading support available All original documentation available Serious Buyers Only: Inquiries welcome. Please contact us for detailed specifications, photos, and pricing.

Condition: ready for operation (used), Injection mold for plastics. K60/156x196x9/1.1730II92 12 06 Fgjdpfovi Ialsx Afpjh

Condition: ready for operation (used), Year of construction: 1980, functionality: fully functional, center width: 1,400 mm, center height: 400 mm, spindle motor power: 3,000 W, total length: 2,400 mm, spindle speed (min.): 100 rpm, spindle speed (max.): 1,200 rpm, Manual spinning machine make Leifeld Type Plb 300 License plate - Powerful, solid machine - Very good technical machine condition - All functions checked - Electrical controls and operating buttons new - Motor and belt drive new - New paint finish - green Technical data Center height mm 400 Center width mm 1400 Machine bed with offset + bridge mm 200 deep / 350 wide Machine length mm 2400 Spindle motor kW 3 4-speed gearbox Speeds - infinitely variable approx. 1/min 100 - 1200 Spindle holder M 64 Manual steel support - length mm 450 Tailstock - stroke mm 280 Quill - fine adjustment Morse taper MK 3 Machine weight approx. kg 1200 Special equipment built into the machine - Center height mm 400 - Center width mm 1400 - M-bed with crank + bridge mm 200 deep / 350 wide - Morse taper MK 3 - Stepless spindle speeds in the indexing steps due to frequency-controlled drive motor - Multi-plate clutch and brake - Hollow bored main spindle - Electrical switching Fgsdpfxevcfhme Afpjh Additional equipment - on request - Manual cross support PS 30 / 300 - Cut-off device

Condition: refurbished (used), The PNC 90 - 3A is equipped with three additional PNC/CNC controlled auxiliary axes. That allows now a working area of ​​approx. 900x1,1100mm and this means extremely economical production of large printed parts. - Blank Centering Unit - Blank counter holder - Shaping Unit BAE I (on headstock) - Shaping Unit KA (in front of machine) - 4-fold tool turret Technical specifications: Blank diameter (max.): 900 mm Distance between centers: 1.100 mm Tool holder DIN 55027: Gr. 11 Force axis (transverse) (max.): 45 kN Force axis (longitudinal) (max.): 45 kN Stroke (transverse): 305 mm Stroke (longitudinal): 650 mm Feed axis speed (transverse) (max.): 7.0 m/min Fgjdpfx Afjupmx Nepjh Feed axis speed (longitudinal) (max.): 7.0 m/min Ejector stroke: 300 mm Tailstock stroke: 450 mm Spindle speeds (stepless): 100-2.300 rpm Main drive: 28 kW Hydraulic drive: 15 kW Operating Voltage: 400V Frequency: 50Hz Connected load approx. 20 kVA Weight: approx. 7.500 kg Further services, machine accessories and spare parts that you can obtain from us: - installation of the machines + commissioning and training - control upgrades (PLC + PNC/CNC) on existing machines - machine components - electrical, hydraulic and mechanical spare parts (PNC, PLB and APED machines) Should you have any further questions, please do not hesitate to contact us at any time!

Condition: refurbished (used), LEIFELD - PNC/CNC 350 - Blank Centering Unit - Blank counter holder - Shaping Unit BAE I (on headstock) optional 2. BAE - Shaping Unit KA (in front of machine) - Double-Roller Unit (optional) Fgodpfx Aeupaa Hsfpeh Technical specifications: Blank diameter (max.): 700 mm Distance between centers: 1200 mm Tool holder DIN 55027: Gr. 6 Force axis (transverse) (max.): 22 kN Force axis (longitudinal) (max.): 20 kN Stroke (transverse): 250 mm Stroke (longitudinal): 400 mm Feed axis speed (transverse) (max.): 6.0 m/min Feed axis speed (longitudinal) (max.): 6.0 m/min Spindle speeds (stepless): 100-2.800 rpm Main drive: 11 kW Hydraulic drive: 5.5 kW Operating Voltage: 400V Frequency: 50Hz Weight: approx. 3.500 kg Further services, machine accessories and spare parts that you can obtain from us: - installation of the machines + commissioning and training - control upgrades (PLC + PNC/CNC) on existing machines - machine components - electrical, hydraulic and mechanical spare parts (PNC, PLB and APED machines) Should you have any further questions, please do not hesitate to contact us at any time!

Condition: good (used), Year of construction: 1980, center width: 2,350 mm, center height: 1,200 mm, product height (max.): 6 mm, Manufacturer: LEIFELD Type: PLB 1200 Year of construction: 1980 Specifications: Metric Metric US Standard Max. Product over bed 1200 Max. Product in the pit 2260 Ø Center height above the bed 600 mm Distance between the centers 2350 mm Length of the gap 400 mm Max. Sheet thickness 6 mm Stroke X-Axis 1200 mm Stroke Y-axis 300 mm rotational speed 6 - 675 rpm Power output 40 kW Tailstock quill 750 mm Dimensions (estimate) length 4500 mm width 3200 mm height 2500 mm weight 10200 kg Please note: The information on this page is given in good faith and to the best of our knowledge and belief, and where possible obtained from the manufacturer, but accuracy cannot be guaranteed. Accordingly, it does not constitute a representation or contract and we recommend that you check all relevant details. Fedpfxeq Dqdio Afpsgh

Year of construction: 2008, condition: good (used), Make: OMERA Type: R 1600 Year: 2008 Specifications Metric US Standard Max. blank / workpiece over bed 1800 Dimensions (Estimate) Length 2800 mm Width 2000 mm Height 2600 mm Weight 4100 kg Fjdokvnuuspfx Afpjgh Please Note: The information on this page has been obtained to the best of our ability and belief, and from the manufacturers where possible. It is given in good faith, but its accuracy can not be guaranteed. Accordingly, it will not form a representation or constitute contractual terms. We advise you to check any vital details! Share on Downloads Max. blank / workpiece over bed:1800 Length: 2800mm Width: 2000mm Height: 2600mm Weight: 4100kg Table length 2500 mm Table width 1450 mm Spindle diameter 250 mm Spindle Rpm 3 - 20 Gr/1Gr Stroke pinole arm 400 mm Column arm 250 mm Troath arm 900 Height arm 1400 mm Max. blank / workpiece over bed:1800 Length: 110.236inch Width: 78.74inch Height: 102.362inch Weight: 9043lbs Table length 2500 mm Table width 1450 mm Spindle diameter 250 mm Spindle Rpm 3 - 20 Gr/1Gr Stroke pinole arm 400 mm Column arm 250 mm Troath arm 900 Height arm 1400 mm Table length 2500 mm Table width 1450 mm Spindle diameter 250 mm Spindle Rpm 3 - 20 Gr/1Gr Stroke pinole arm 400 mm Column arm 250 mm Troath arm 900 Height arm 1400 mm

Condition: refurbished (used), machine/vehicle number: Leifeld, LEIFELD - PNC/CNC 750 - Gearbox with circulating oil lubrication - Hydraulic blank centering device - Blank counter holder - Shaping unit BAE 1 (on the headstock) optional 2nd BAE - Shaping unit KA (in front of the machine) - optional with double roller holder Technical specifications: Blank diameter (max.): 1.500 mm Distance between centers: 1.225 mm Tool holder DIN 55027: Gr. 11 Force axis (transverse) (max.): 65 kN Force axis (longitudinal) (max.): 65 kN Stroke (transverse): 310 mm Stroke (longitudinal): 800 mm Feed axis speed (transverse) (max.): 5.0 m/min Feed axis speed (longitudinal) (max.): 5.0 m/min Ejector stroke: 300 mm Tailstock stroke: 600 mm Fedpsiqpr Refx Afpjgh Spindle speeds (3 steps): 10-1.000 rpm Main drive (DC motor): 22 kW Hydraulic drive: 18.5 kW Operating Voltage: 400V Frequency: 50Hz Connected load approx. 45 kVA Weight: approx. 7.000 kg Further services, machine accessories and spare parts that you can obtain from us: - installation of the machines + commissioning and training - control upgrades (PLC + PNC/CNC) on existing machines - machine components - electrical, hydraulic and mechanical spare parts (PNC, PLB and APED machines) Should you have any further questions, please do not hesitate to contact us at any time!
