Z.p.h.u.elektrotech

Condition: excellent (used), Year of construction: 2006, x-travel 750 mm y-travel 210 mm z-travel 1150 + 100 mm control Fanuc MSX-701III Maximum turning diameter 660 mm Max. turning length 1498 mm Diameter over cross slide max. 400 mm number of spindle speeds 3000 U/min tool piece magazine with 40 Plätzen turret 10 Fach total power requirement 90 kVA weight of the machine ca. 26,6 t dimensions of the machine ca. 5301 x 2997 x 2788 mm Guedpey Spuujfx Alxob

Condition: used, Year of construction: 2008, functionality: fully functional, Turning / milling center with counter spindle with 10 CNC axes (X1, X2, Z1, Z2, Y1, Y2, B1, B2, C1, C2) Control: FANUC 31:iA Main Spindle Power: 15/11 kW Gsdpfxjy Snkus Alxoub bar material dia.: 51 mm spindle revolution: 5.000 min-1 Counter Spindle Power: 11/7,5 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Turning and milling spindle Power: 7,5/3,7 kW Turning and milling spindle speed: 12.000 min-1 max. rotation length turret bottom: 1.005 mm Slide cross X1 / X2 / Z1 / Z2 / B2: 455 / 222,5 /1.090 / 1.005 / 1.008 mm Slide cross Y1 / Y2: +/- 70 / +20, -50 mm Swivel range B1 axis: +/- 95 ° Linear rack magazine incl. support robot CNC support steady rest Coolant cyclone filter system incl. 2 pcs. coolant pumping spindle oil cooler

Condition: used, Year of construction: 1991, spindle bore: 51 mm, bar passage: 51 mm, Mazak SQT-15MS CNC gantry Specifications * Manufacturer: Mazak * Model: SQT-15MS * Year: 1991 * Control: Mazatrol T-32 * 12-position turret * Live tooling * Sub spindle * Machine weight: approx. 5,500 kg Condition The machine has been used in production and is sold in working condition unless otherwise agreed. Inspection under power can be arranged upon request. Gsdpoy Snhmefx Alxsub Additional Information * Loading assistance can be arranged at additional cost. * More photos and videos available upon request.

Condition: good (used), Year of construction: 2001, turning length: 1,020 mm, turning diameter: 540 mm, spindle speed (max.): 4,500 rpm, travel distance X-axis: 565 mm, travel distance Y-axis: 160 mm, travel distance Z-axis: 1,077 mm, overall weight: 12,500 kg, 🛠️ Description For sale is a powerful CNC turning and milling center, MORI SEIKI MT 2000SZ, equipped with sub-spindle and Y-axis. ⚙️ Technical Data Travel X / Y / Z: approx. 565 / 160 / 1,077 mm Max. turning diameter: approx. 540 mm Max. turning length: approx. 1,020 mm Main spindle: up to approx. 4,500 rpm Tool spindle: up to approx. 8,000 rpm Tool holder: Capto C6 Tool stations: depending on configuration Axes: X, Y, Z, C + sub-spindle ⏱️ Operating Hours Spindle: Operating hours: approx. 33,600 h Machining time: approx. 14,200 h Sub-spindle: Operating hours: approx. 18,100 h Machining time: approx. 11,500 h (For additional specifications, see images) 📦 Features Sub-spindle (SZ version) Driven tools Guodpfx Ajy Sm U Sslxeb Y-axis Chip conveyor Coolant system Multitasking capability (turning & milling) 📌 Condition The machine is in used, fully functional condition. Tool holders (turning tools and Capto) are included in the delivery. Cutting inserts are not included. 🚛 Delivery & Terms Sale ex location / loaded free on truck Dismantling and loading can be arranged on request Sale without guarantee or warranty 📞 Contact If interested or for further information, please do not hesitate to contact us.

Condition: ready for operation (used), Year of construction: 2017, operating hours: 67 h, spindle motor power: 22,000 W, spindle speed (max.): 3,300 rpm, travel distance X-axis: 615 mm, travel distance Y-axis: 260 mm, travel distance Z-axis: 1,585 mm, overall weight: 16,600 kg, controller manufacturer: MAZATROL, number of axes: 5, This 5-axis Mazak INTEGREX i-200 S was manufactured in 2017. It features full 5-axis simultaneous machining, a maximum machining diameter of Ø658 mm, and a maximum machining length of 1519 mm. The machine includes a robust tool magazine capacity of 72 positions and is equipped with both main and second spindles for enhanced capabilities. If you are looking to get high-quality turning and milling capabilities, consider the Mazak INTEGREX i-200 S turn-mill centre. Contact us for further details. Gsdpoy Sltgofx Alxeub • Operating time: Approx. 68 hours • Availability: Immediate • Key capabilities: • Full 5‑axis simultaneous machining • Main spindle + second spindle • Milling spindle with automatic tool changer • Complete turning and milling in one setup • Capacity and working range • Max swing: Ø658 mm • Swing over cross slide: Ø658 mm • Max machining diameter: Ø658 mm • Max machining length: 1519 mm • Bar capacity (main spindle): Ø102 mm • Bar capacity (second spindle): Ø65 mm • Max support mass (main spindle): 650 kg • Max support mass (second spindle): 300 kg • Main spindle (HD1) • Chuck size: 12" • Spindle bore: Ø112 mm • Motor output: 22 / 18.5 kW • Torque: 883.3 / 716.2 Nm • Acceleration time: 4.9 s • Air blow system: Included • Additional configuration: Heavy‑duty HD1 spindle; removal of standard spindle cylinder and chuck • Second spindle (HD2) • Chuck size: 8" • Max speed: 5,000 rpm • Spindle bore: Ø76 mm • Motor output: 18.5 / 15 kW • Torque: 325 / 238 Nm • Acceleration time: 4.5 s • Factory option: HD2 spindle synchronization function • Milling spindle • Max speed: 12,000 rpm • Motor output: 24 kW • Cooling: Oil & air • Tool interface: HSK‑A63 (T63) • 90° indexing time: 0.5 s • Acceleration: 1.27 s • Lubrication: Oil & air • Tool capacity: • O.D. turning tools: □25 mm • I.D. turning tools: Ø40 mm • Milling tools: Max Ø125 × 400 mm • Axis travels • W: 1574 mm • Rapid traverse: X/Z 50 m/min; Y 40 m/min; W 30 m/min • Tool system and magazine • Tool system: CAPTO C6 • Tool magazine capacity: 72 positions • Automatic tool changer: Included • Functions: Tool breakage detection in magazine; Overload detection • CNC functions and software • 5‑axis machining function package • Tool radius compensation for 5‑axis • Cylindrical interpolation • Polar coordinate interpolation • Synchronous tapping with milling spindle • Cooling and preparation • Through‑tool coolant: 7 MPa • Preparation for oil mist extraction system • Highlights • Practically new condition with only ~68 operating hours • Very rich factory configuration • Full 5‑axis simultaneous machining • Main and sub‑spindle configuration • 72‑tool CAPTO magazine • Production‑ready with significant savings vs. new Additional equipment • Chip and parts handling • Side chip conveyor – Consep type • Belt‑type parts conveyor • Bar feeding and workpiece handling • LNS QLS II bar feeder • Bar feeder interface kit • Automatic parts catcher • Filtration • SEI FILTRATION unit • Series: JT040 • Model: 40/70‑V‑I‑R‑FM • Year: 2018 • Other accessories • Machine mounting anchors • 3‑color machine status signal lamp Technical Specification Counter Spindle Yes Driven Tools No

Condition: ready for operation (used), Year of construction: 2006, functionality: fully functional, machine/vehicle number: 190433, turning length: 1,050 mm, turning diameter: 660 mm, travel distance X-axis: 580 mm, travel distance Y-axis: 150 mm, travel distance Z-axis: 1,050 mm, controller model: Mazatrol Matrix, TECHNICAL DETAILS Max. turning diameter: 660 mm Swing over bed: 760 mm Turning length: 1,050 mm X-axis: 580 mm Y-axis: 150–160 mm (?) Z-axis: 1,050 mm Main spindle speed: 5,000 rpm Counter spindle speed: 5,000 rpm Milling spindle: 12,000 rpm MACHINE DETAILS Weight: 11,800 kg Godey Slqfopfx Alxjub Main power circuit: 3-phase AC Main power circuit voltage: 400 V Frequency: 50/60 Hz Control circuit AC: 100 V Control circuit DC: 24 V Main motor current draw: max. 84 A Main motor voltage: 400 V Rated power: 91.8 kVA EQUIPMENT

Condition: excellent (used), Year of construction: 1990, Type: CNC Lathe Manufacturer: Mori Seiki Model: SL 25 Year of manufacture: 1990 Serial number: 3592 Control: CNC Fanuc 15-T Origin: Japan Condition: Unknown, consistent with age and operating hours 2 axes Swing diameter over bed: 520 mm X-axis travel: 130 mm Z-axis travel: 590 mm Turning diameter: 260 mm Max. turning diameter: 260 mm Turning length: 500 mm Main spindle: Main spindle speed range: 35 - 3,000 rpm Number of tool stations: 10 positions Tailstock quill travel: 491 mm Gsdpfx Aloy Sk Rdjxeub Accessories: Chip conveyor, transformer, tool holders, three-jaw chuck, several jaws & documentation

Condition: ready for operation (used), Year of construction: 2001, spindle motor power: 15,000 W, spindle speed (max.): 3,500 rpm, travel distance X-axis: 230 mm, travel distance Z-axis: 250 mm, overall weight: 10,800 kg, number of axes: 8, This 8-axis Muratec MT 25 MY was manufactured in 2001. It features a maximum machining diameter of 370 mm and a maximum machining length of 920 mm. The machine is equipped with twin spindles and twin turrets, offering 15 live tooling stations per turret. If you are looking to get high-quality turning capabilities, consider the Muratec MT 25 MY turn-mill centre we have for sale. Contact us for further details. • Configuration: Twin spindle / twin turret / twin Y-axis (9 controlled axes) • Control unit: Fanuc CNC (motors, servos, electronics) • Condition: Currently in operation; immediate delivery • Travels: • X1: 230 mm • X2: 230 mm Godoy Shwhopfx Alxsub • Z1: 250 mm • Z2: 700 mm • Y: 100 mm (±50 mm) • Z3 (sub-spindle): 750 mm • Capacity & envelope: • Max machining diameter: 370 mm • Max machining length: 920 mm • Bar capacity: 67 mm • Rapid traverse (X/Z): 20 / 25 m/min • Spindles (twin, identical): • Spindle nose: A2-6 • Torque: 420 N·m • Workpiece transfer: Automatic transfer between spindles with torque control • Turrets & tooling capability: • Turrets: 2 (both with Y-axis & C-axis) • Stations: 15 per turret (all live/driven) • Live tooling speed: 3,000 rpm • Live tooling motor: 4 kW • Indexing time: 0.2 s • Build & features: • Guideways: Solid box ways (prismatic) on all axes • Cleaning: Automatic air/coolant blast for sub-spindle cleaning • Monitoring: Load control system and tool wear monitor Additional equipment • Gantry loader: High-speed 3-axis gantry robot, 8 kg capacity (automatic loading/unloading) • Bar feeder: 1.5 m CNC bar loader • Parts catcher: Automatic swing-arm for small finished parts • Parts conveyor: Integrated conveyor belt for finished components • Sampling compartment: Independent area for in-process inspection • Chip conveyor: Rear-exit hinge-type chip conveyor • Workholding: 2 × Kitagawa 250 mm hydraulic chucks • Tooling included: Complete set of static holders (OD/ID) and live holders (axial/radial) Technical Specification Counter Spindle No Driven Tools No

Condition: used, Year of construction: 2016, Mazak Variaxis i-500 5 Axis CNC Machining Centre. S/No. 276584 (2016) with Mazatrol Smooth X CNC Control, 500mm Diameter Work Table, Spindle Speeds Max 18,000rpm, Max Workpiece Size 500mm Diameter x 350mm x 300kg, 40 Tool ATC, CAT40 Spindle Taper, Mazak Spindle Chiller Unit, Absolent A Mist 10 Oil Mist Filter Extractor, Cromer Swarf Management and Filtration System, Renishaw RMI-Q Tooleye, Machine Weight 8000kg. Country of Origin: Japan Gedpfx Alsy Shk Usxoub Please Note: Erowa Machining Fixture Not Included Location: These lots are located in Gateshead, UK. Unfortunately there are no loading facilities on-site, dismantling and loading will be at the cost of the purchaser. All/Any tooling is being offered as specifically described.

Condition: used, Year of construction: 2016, Mazak Variaxis i-700 5 Axis CNC Machining Centre with Mazatrol Smooth X CNC Control. S/No. 276585 (2016), 700mm Diameter Work Table, Spindle Speeds Max 18,000rpm, Max Workpiece Size 850mm Diameter x 500mm x 700kg, 40 Tool ATC, CAT40 Spindle Taper, Absolent A Mist 10 Oil Mist Filter Extractor, Mazak Spindle Chiller Unit, Cromar Swarf Management & Filtration System, Machine Weight 15000kg. Country of Origin: Japan Please Note: Erowa Machining Fixture Not Included Gsdpfx Aley Shiwoxoub Location: These lots are located in Gateshead, UK. Unfortunately there are no loading facilities on-site, dismantling and loading will be at the cost of the purchaser. All/Any tooling is being offered as specifically described.

Condition: used, Year of construction: 2008, MAZAK INTEGREX 300 IV ST Max. machining diameter: 760 mm Max. machining length: 1,542 mm Max. milling speed: 12,000 rpm Max. main spindle speed: 4,000 rpm Max. sub-spindle speed: 4,000 rpm Machine is equipped with: - CNC control Mazatrol Matrix MT Guodpfxjy Sgd He Alxjb - Tool magazine for 120 tools (CAPTO C6) - Tool Eye - C-axis input accuracy 0.0001° - Y-axis - B-axis 0.0001° - Sub-spindle with C-axis 0.0001° - Parts conveyor with parts gripper - Interface for bar feeder magazine - MAYFRAN Consep 2000 system

Condition: excellent (used), Year of construction: 2023, functionality: fully functional, We offer you the following: Manufacturer: DMG MORI Model: NTX 3000/1500 Year of manufacture: 2023 Control: DMG Mori Celos with Fanuc F31iB5 Technical specifications: Max. turning diameter: 670 mm Turning length: 1,519 mm Bar capacity: max. 102 mm Travels: x1-axis: 675 mm y-axis: +/- 150 mm z1-axis: 1,562 + 164 mm b-axis: +/- 120° a-axis: 1,542 mm x2-axis: 200 mm y2-axis: +/- 40 mm z2-axis: 1,542 mm Main spindle: Max. speed: 3,000 rpm Drive power: 30/25 kW Torque: 1,194/995 Nm Spindle nose: JIS A2-8 Spindle bore: Ø 111 mm Counter spindle: Max. speed: 4,000 rpm Drive power: 18.5/18.5/15 kW Torque: 599/505/409 Nm Spindle nose: JIS A2-8 Spindle bore: Ø 91 mm Milling spindle: Speed range: 0 – 12,000 rpm Drive power: 28/23 kW Torque: 132/95.3 Nm Tool holder: Capto C6 Number of tool stations: 76 positions Max. tool diameter: Ø 70/Ø 130 mm Max. tool length: 400 mm Max. tool weight: 8 kg Turret: Number of tool holders: 12 positions Speed of driven tools: 12,000 rpm Tool holder: BMT40 Torque: 16.9 Nm Rapid traverse speeds: x-axis: 50 m/min y-axis: 40 m/min z-axis: 50 m/min a-axis: 36 m/min x2-axis: 25 m/min y2-axis: 18 m/min z2-axis: 40 m/min b-axis: 100 rpm Operating hours: approx. 4,500 h Spindle hours: approx. 2,200 h Technical features & accessories: − Hydraulic 3-jaw chuck, manuf. SMW KNCS-N-400-128 incl. hollow clamping cylinder for main spindle − Hydraulic 3-jaw chuck, manuf. SMW KNCS-N-260-78-3Z incl. hollow clamping cylinder for counter spindle − Foot switch for chuck operation − Automatic clamping stroke monitoring of the clamping cylinder for main and counter spindle − Tailstock function for counter spindle − Magazine-side control panel for the tool magazine − Coolant: water-soluble coolant − Chip conveyor (right discharge) − Coolant temperature control/coolant chiller − Coolant spray gun − Float switch for coolant − Coolant shower at main and counter spindle chucks − Compressed air blow-off system for chuck (counter spindle) Gusdoy Sfx Nspfx Alxob − Oil mist separator zeroGOF #2 − Oil separator − ICS 70 bar, TMF300 band filter system, 980 l tank − Manual tool presetting device for main and counter spindle − Direct measuring system in x1, x2, y, z1, z2 axes − Spindle sensor measuring system with wireless signal transmission, manuf. Renishaw RMP600 − Universal filter − 3D quickSET − Cycle Alternating Spindle Speed − Cycle "Tailstock Tip at Turret" − Cycle MPC – Machine Protection Control − Cycle MVC – Machine Vibration Control − Synchronous thread cutting without compensating chuck − Increased input resolution to 0.0001 mm − Cs control for tool spindle − Program restart Accessories, illustrated tools, and clamping devices are only included if specified in the additional information. Technical data and details subject to change, errors and prior sale excepted!

Condition: used, Year of construction: 2023, machine/vehicle number: IntNr231583, CNC Short-Turn Lathe – Citizen Miyano BNE-65 MYY Condition: Very good, ready for operation Availability: Short notice Technical Overview Manufacturer: Miyano Model: BNE 65 MYY Year of manufacture: 2023 Control: Mitsubishi M800 Equipment: Godsy Sakgjpfx Alxsub - Main and counter spindle - 2 Y-axes - Driven tools - Multi-channel control - Chip conveyor - Bar feeder Travel paths: - X-axis: approx. 260 mm - Y-axis: approx. ±50 mm - Z-axis: approx. 800 mm Spindle speeds & power: - Main spindle: up to approx. 5,000 rpm, approx. 15–18 kW - Counter spindle: up to approx. 5,000 rpm, approx. 11–15 kW - Driven tools: up to approx. 6,000 rpm, approx. 3–5 kW The machine is fully operational both mechanically and electrically. Complete technical documentation is available. The machine can be inspected under power by prior appointment. Technical data and information subject to change, error, and prior sale.

Condition: excellent (used), Year of construction: 2019, CNC lathe DOOSAN Puma 2600SY II with Siemens control system; Thermal sensors for maximum precision; Y-axis; Subspindle with collet chuck; Spindle bore 80 mm (main spindle); All axes with box ways – suitable for heavy-duty machining; Chip conveyor, tool setter, parts catcher with belt, coolant gun, extraction system; 70 bar high-pressure coolant system; Various fixed and driven tool holders included; Robot loading by Halter available upon request! Photo attached. An automatic door can be retrofitted for this purpose. In Germany, complete commissioning upon request. Godpfoy R S Uzsx Alxeub All at additional cost!

Condition: used, Year of construction: 2007, SPINNER TC110L-MCY Powerful, used CNC turning and milling center with C/Y-axis for complex machining operations with driven tools. Year of manufacture: 2007 Control: SIEMENS 840DE sl ShopTurn X – 350 mm Y – 230 mm (-115/+115 mm) Z – 1,840 mm C-axis Swing diameter up to 690 mm Spindle 26 kW with 2-speed gearbox Speeds up to 3,200 rpm Spindle bore 110 mm Equipment: Turret make BARUFFALDI type TBMR250-12 with 12 stations, completely overhauled in 2024 Driven tools up to 4,000 rpm VDI 50 tool holders Hydraulic steady rest by SMW Hydraulic three-jaw chuck by SMW with 315 mm diameter Oil mist extraction system by IFS model M1600, year 2012 Hinged belt chip conveyor by KNOLL, model S-1/50 Paper belt filter system by KNOLL, model KF150/700 High-pressure coolant pump Electronic handwheel Foot switch Including: Operating manual/documentation Technical Data & Transport – see PDF. All technical data, images, and contents are non-binding and without guarantee. Subject to change and error. All other accessories visible in the photos and videos are not included in the scope of delivery, and are therefore not part of this sale. The scope of delivery only includes accessories explicitly stated here, in the order confirmation, or invoice. FCA (Free Carrier, loaded on truck) D-Traunstein Packaging only Delivery time: immediately Subject to prior sale / Payment due upon conclusion of purchase Godpfx Aley R Sxasxsub

Condition: not inspected (used), Year of construction: 2003, ● Delivery terms: Free on truck (FOT) ● Location: 42855 Remscheid ● Availability: By arrangement ● Payment terms: Advance payment by bank transfer ● Internal number: KL3 ● Collection: Collection of the machine is scheduled for calendar week 22. The exact pickup date will be coordinated and specified by us. Technical specifications: Working area / axes: Table working area (X): 2,000 mm Table working area (Y): 760 mm X-axis travel: 1,740 mm Y-axis travel: 760 mm (+250 mm for ATC) Z-axis travel: 660 mm Distance spindle nose to table surface: min. 180 / max. 840 mm Distance spindle center to column front: 808 mm Table: Table size: 2,000 x 760 mm Max. table load: 9,810 N (1,000 kg) T-slots: 5 pcs T-slot width: 18 mm T-slot spacing: 125 mm Distance machine base to table surface: 825 mm Max. table capacity: 13,730 N (1,400 kg) Spindle: Speed range: 40 – 12,000 rpm Feed: Rapid traverse: 36,000 mm/min Cutting feedrate: 1 – 8,000 mm/min Scope of delivery: ● Existing manuals (completeness not guaranteed) Note: The clamping devices and vises visible on the machine are not included in the scope of delivery. The tool in the spindle is also not included. Any external machine accessories shown around the machine are also not part of the delivery. Dimensions & weights: ● Installation dimensions L x W x H (approx.): 5,500 x 3,450 x 3,005 mm ● Weight (approx.): 11,500 kg Additional notes: ► Transport to the destination can be offered upon request ► The quoted price is net, plus VAT ► The item is sold excluding any warranty ► Technical data not guaranteed Gujdsy R Swpspfx Alxeb ► Subject to prior sale ❗ Sale exclusively to business customers ❗

Condition: not inspected (used), Year of construction: 2006, machine/vehicle number: 182926, ● Delivery terms: Free loaded on truck ● Location: 42855 Remscheid ● Availability: By arrangement ● Payment terms: Advance payment by bank transfer ● Internal No.: KL2 ● Collection: The collection of the machine is scheduled for calendar week 22. The exact collection date will be coordinated and specified by us. Technical Data: Working Range / Axes: Table working area (right/left): 2,000 mm Table working area (front/back): 760 mm X-axis (saddle travel): 1,740 mm Y-axis (column travel): 760 mm (+250 mm for ATC) Z-axis (spindle head): 660 mm Distance spindle end to table surface: 180 – 840 mm Distance spindle center to column front: 808 mm Table: Table size: 2,000 x 760 mm T-slots: 5 units T-slot width: 18 mm T-slot spacing: 125 mm Max. table load: 1,400 kg Distance machine base to table surface: 825 mm Spindle: Spindle mount: 7/24 taper, No. 40 Speed range: 40 – 12,000 rpm Feed: Rapid traverse: 36,000 mm/min Cutting feed: 1 – 8,000 mm/min Tool Magazine: Tool positions: 30 Scope of supply: ● Existing manuals (completeness not guaranteed) Dimensions & Weights: ● Installation dimensions L x W x H approx.: 5000 x 3450 x 3300 mm ● Weight approx.: 11,500 kg Additional Information: ►Transport to the destination can be offered upon request ►Offer price is net plus VAT ►The goods are sold excluding any warranty Guedpey R Suzsfx Alxob ►Technical data subject to change ►Subject to prior sale ❗The sale is exclusively to business customers❗

Condition: excellent (used), Year of construction: 2019, functionality: fully functional, Chip conveyor, Bar feeder interface, Detachable handwheel, Parts catcher, Milling spindle, Y-axis, Tool setter, Collet chuck, Tooling Gedpfx Aljy R Az Eexeub

Condition: excellent (used), Year of construction: 2014, operating hours: 20,980 h, turning length: 800 mm, turning diameter over cross slide: 340 mm, turning diameter: 500 mm, spindle motor power: 25,000 W, spindle speed (min.): 1 rpm, spindle speed (max.): 6,000 rpm, spindle bore: 76 mm, travel distance X-axis: 300 mm, travel distance Z-axis: 800 mm, mount diameter: 250 mm, rapid traverse X-axis: 30 m/min, rapid traverse Z-axis: 30 m/min, rotational speed (max.): 6,000 rpm, rotational speed (min.): 1 rpm, overall weight: 6,800 kg, DMG MORI CTX beta 800 – CNC Lathe Manufacturer: DMG MORI Model: CTX beta 800 Year of manufacture: 2014 Control: Siemens ErgoLine Guodpfxjy R Agbj Alxjb Technical Data Max. turning diameter: approx. 500 mm Turning diameter over cross slide: approx. 340 mm Turning length: approx. 800 mm Chuck diameter: 250 mm Bar capacity: approx. 76 mm X-axis travel: approx. 300 mm Z-axis travel: approx. 800 mm Tool turret: 12-position Spindle speed: max. 4,000 / 6,000 rpm Spindle power: approx. 25 kW Voltage: 400 V Frequency: 50 Hz Connected load: approx. 65 kVA Machine weight: approx. 6,800 kg Equipment Siemens ErgoLine operator panel Hydraulic chuck C-axis Chip conveyor Coolant system Precision CNC slant bed lathe Condition Machine can be inspected under power Subject to prior sale Offered without tooling Ex-works location Technical data without guarantee Service Disassembly, loading, and transport possible Europe-wide processing available 📍 Location: Germany 📩 Further information, photos, and videos available upon request

Condition: excellent (used), Year of construction: 2017, operating hours: 13,240 h, turning length: 500 mm, turning diameter over cross slide: 290 mm, turning diameter: 500 mm, spindle motor power: 13,000 W, spindle speed (min.): 1 rpm, spindle speed (max.): 6,000 rpm, spindle bore: 73 mm, travel distance X-axis: 210 mm, travel distance Z-axis: 525 mm, rapid traverse X-axis: 30 m/min, rapid traverse Z-axis: 30 m/min, bar passage: 65 mm, overall weight: 4,300 kg, ## DMG MORI CTX alpha 500 – CNC Lathe Manufacturer: DMG MORI Model: CTX alpha 500 Year of manufacture: 2017 Guedpjy Rzggjfx Alxob Control: Siemens 840D sl / ErgoLine ### Technical Specifications * Max. turning diameter: approx. 500 mm * Turning diameter over cross slide: approx. 290 mm * Turning length: approx. 500 mm * Chuck diameter: 210 mm * Bar capacity: approx. 65–73 mm * X-axis travel: approx. 190–210 mm * Z-axis travel: approx. 525 mm * Y-axis: optional / approx. ±40 mm * Tool turret: 12 positions * Spindle speed: max. 5,500 / 6,000 rpm * Spindle power: approx. 13–20 kW * Voltage: 400 V * Frequency: 50–60 Hz * Connected load: approx. 30 kVA * Machine weight: approx. 4,300–4,650 kg ### Equipment * Siemens ErgoLine operating panel * Hydraulic chuck * C-axis * Chip conveyor * Coolant system * Precision slant-bed CNC lathe ### Condition * Machine can be inspected under power * Subject to prior sale * Sold without tooling * Ex works * Technical data subject to confirmation ### Service * Dismantling, loading, and transport available * Europe-wide handling possible 📍 Location: Germany 📩 Further information, pictures, and videos available on request

Condition: ready for operation (used), Year of construction: 2019, operating hours: 2,809 h, functionality: fully functional, machine/vehicle number: 7023000520B, turning length: 705 mm, travel distance X-axis: 260 mm, travel distance Y-axis: 50 mm, travel distance Z-axis: 795 mm, swing diameter over cross slide: 742 mm, swing diameter over bed slide: 920 mm, Attention – Images of milling accessories belonging to other machines were mistakenly included in this auction listing and have now been removed. Please refer to the updated scope of delivery as per the current images – approximately half of the accessories shown pertain to this machine. TECHNICAL DETAILS Working Area Swing diameter over bed max.: 920 mm Swing diameter over cross slide max.: 742 mm Max. turning length: 705 mm Bar capacity: 80 mm Travel X-axis: 260 mm Travel Y-axis: 50 mm Travel Z-axis: 795 mm Main Spindle Power: 18.5/15 kW Max. speed: 4,000 rpm Chuck size: 10 inch Spindle bore: 91 mm Front bearing diameter: 140 mm Gusdpfjy Rxtwex Alxeb Counter Spindle Power: 11/7.5 kW Max. speed: 4,000 rpm Chuck size: 6 inch Spindle bore: 45 mm Front bearing diameter: 85 mm Turret and Axes Tool stations: 12 Shank cross-section: 25 mm Max. speed of driven tools: 10,000 rpm Rapid traverse X-axis: 30,000 mm/min Rapid traverse Y-axis: 10,000 mm/min Rapid traverse Z-axis: 30,000 mm/min Rapid traverse B-axis: 30,000 mm/min MACHINE DETAILS Control: M730UM with CELOS Operating hours: 2,770 h Power-on hours: 10,820 h Dimensions & Weight Machine height: 2,000 mm Installation footprint: 3,347 x 2,106 mm Weight: 5,820 kg EQUIPMENT Y-axis Counter spindle Main spindle with 10-inch chuck Counter spindle with 6-inch chuck Chip conveyor High-pressure coolant system Tool measuring device Parts catcher Workpiece ejector Interface for bar loader

Condition: ready for operation (used), Year of construction: 2006, operating hours: 19,067 h, functionality: fully functional, machine/vehicle number: 122616, travel distance X-axis: 500 mm, travel distance Y-axis: 95 mm, travel distance Z-axis: 1,650 mm, controller model: OKUMA OSP P200L, center width: 1,500 mm, TECHNICAL DETAILS Travel X-axis: 500 mm Travel Y-axis: 95 mm Travel Z-axis: 1,650 mm Gsdsy Rxprepfx Alxsub Turning diameter over bed: 550 mm Power: 22.0 kW Distance between centers: 1,500 mm Spindle bore: 80 mm Counter spindle speed: 4,500 rpm Tool magazine: 44 positions Tool holder: HSK-F63 MACHINE DETAILS Control: OKUMA OSP P200L Dimensions & Weight Dimensions (L x W x H): 5,100 x 2,800 x 2,900 mm Transport weight: 13,700 kg Shipping packages: 7 units Operating hours: 19,067 h EQUIPMENT Automatic workpiece feeder with controlled arm by Pneumotec Automatic bar feeder by LNS Quick Load Servo III Counter spindle VAC-MB11 Milling head with automatic tool changer Turning turret: 12-position tool changer Chip conveyor Turret head Driven tools Bar loader Three-jaw chuck Tool magazine C-axis Documentation CE marking

Condition: like new (used), Year of construction: 2010, operating hours: 76,482 h, turning length: 800 mm, turning diameter: 430 mm, spindle speed (max.): 6,000 rpm, travel distance X-axis: 455 mm, travel distance Z-axis: 800 mm, rotational speed (max.): 6,000 rpm, feed length X-axis: 455 mm, feed length Z-axis: 430 mm, workpiece weight (max.): 5 kg, total height: 8,500 mm, total length: 2,500 mm, total width: 2,495 mm, overall weight: 8,500 kg, CNC controller: Fanuc FS31IA5 (MAPPS 4) Capacity Turning length mm: 800 Max. turning diameter mm: ø: Ø430 Turn-mill spindle X-axis travel mm: 455 Z-axis travel mm: 800 B-axis degree: ±120 (0.001º) Speed spindle rpm: 12000 Drive power kW: 9/5.5 Y-axis travel mm: ±105 Tool magazine Magazine places: 76 Tool holder: Capto C5 Tool length max. mm: 250 Tool diameter max. mm: 70/130 Tool weight max kg: 5 Lower turret X-axis travel mm: 160 Z-axis travel mm: 730 Number of tool slots St .: 10 Gedpoy Rpq Tjfx Alxsub Main spindle Speed spindle rpm: 6000 Spindle bore mm: 73 Chuck type: Hollow Chuck (8") Manufacturer: KITAGAWA Counter spindle Speed spindle rpm: 6.000 Drive power spindle kW: 7.5/5.5 Chuck type: Solid Chuck (8") Manufacturer: KITAGAWA Equipment Chip conveyor Signal lamp High pressure pump Chuck foot switch (double) for main and counter spindle Coolant gun Working time hours Under power: 76482 Spindle 1: 14010 Spindle 2: 4306 Potencial nominal kVA: 48 Basic machine dimensions / weight Length mm: 2500 Width mm: 2495 Height mm: 8500 Weight kg: 8500

Condition: used, Year of construction: 2023, machine/vehicle number: IntNr231501, CNC Lathe – DN Solutions (Doosan) LEO 1600 Year of manufacture: 2023 Equipment / Highlights - Horizontal CNC lathe Gujdpey Rftwjfx Alxob - High-performance main spindle - Robust machine construction for precise dimensional accuracy - Tool turret with rapid indexing - Compact design, minimal footprint - User-friendly CNC control - High reliability and low maintenance requirements Technical Data - Max. turning diameter: approx. 300 mm - Max. turning length: approx. 300 mm - Spindle bore: approx. Ø 52 mm - Main spindle speed: up to approx. 4,500 rpm - Tool turret: 12 stations - Control: FANUC CNC - Machine weight: approx. 2,200 kg The machine is fully operational, both electrically and mechanically. Comprehensive technical documentation available. The machine can be inspected under power by appointment. Subject to prior sale. Technical specifications and details are subject to change or error.

Condition: excellent (used), Year of construction: 2022, operating hours: 1,450 h, machine/vehicle number: 0031001080A, This 3-axis DMG MORI CLX 450 V3 was manufactured in 2022, i have been the only owner since new, I am not a dealer! It features a maximum turning diameter of 400 mm and a Z-axis travel of 600 mm. The machine is equipped with a powerful spindle capable of 4000 rpm and includes 12 driven tool stations for enhanced versatility. If you are looking to get high-quality turning capabilities, consider the DMG MORI CLX 450 V3 horizontal turning machine we have for sale. Contact us for further details. • Version: V3 (no Y-axis); configured for turning + milling (C-axis) • Working area: • Swing over bed: 650 mm • Swing over cross slide: 465 mm • Max. turning diameter: 400 / 315 mm • Rapid traverse X/Z: 30 / 30 m/min • Axes: X, Z, C; C-axis positioning accuracy: 20 arcsec • Main spindle: • Spindle nose: A2-8 • Bar capacity: 80 mm • Front bearing diameter: 130 mm • Chuck diameter options: 210 / 250 / 315 mm • Spindle power (40% / 100%): 25.5 / 17 kW • Max. torque (40% / 100%): 426 / 283 Nm • Turret (VDI 40): • 12 stations (12 driven) • Tool station diameter: 40 mm • Driven tool power: 5.44 kW • Driven tool torque: 20 Nm • Driven tool max speed: 4000 rpm • Tailstock: • Travel: 500 mm • Center interface: MK5 • Max. force: 8 kN • Guideways / Ballscrews: X/Z 40 × 10 mm • Accuracy: Positioning accuracy X/Z: 5 / 10 µm • Capacity / Workholding: • Max. bar capacity: 80 mm • Hydraulic chuck: Ø 254 mm (installed) • Chuck bore: 82 mm • Coolant & chip handling: Coolant gun 5 bar; Chip tank • Control: Siemens SLIMline multi-touch (19") Gujdpfey Rfbzsx Alxsb • Dimensions & weight: • Weight without chip conveyor: approx. 4950 – 5050 kg • Weight with chip conveyor: approx. 5500 kg • Notes: Full 12 driven tool stations Additional equipment • Chip conveyor (right-side discharge) • Hydraulic tailstock (M-function controlled) • Direct measuring system (X-axis) • External electronic handwheel • DMG MORI IoTconnector • Marposs tool probe • Signal tower (4-color) Dkec Tccdvjyzq T Ro Uel • Set of static tool holders VDI 40 • Set of driven tools WTO (QuickFlex, ER32) Technical Specification Counter Spindle No Driven Tools Yes
