Condition: used, Year of construction: 2010, turning diameter 700 mm turning length 1250 mm control Siemens 840 G Ergoline spindle passage 104 mm spindle speed: 4000 spindle motor 35/45 kW max. torque on the spindle 600/700 Nm Spindlespeed subspindle 4000 U/min milling head -swivable ° turning speed range - milling 00 U/min tool taper Capto C6 tool magazin: 36 y-axis +/- 200 mm mm weight of the machine ca. 18,5 t Ljdpjy T R Rmefx Aiiohg Used CNC- Lathe with sub- spindle and milling head - milling head full axis + 1° clamping - chipconveyor - aircondition for elextric box - new milling spindle in 2025 - absolute scale X/Y/Z1 axis - Shop Mill dialig programming - 8/20 bar coolant programmable - band filter system - Bar package (Partscatcher, prepared for ba magazin) Machine sold without jaws.

Condition: used, Year of construction: 2008, functionality: fully functional, Turning / milling center with counter spindle with 10 CNC axes (X1, X2, Z1, Z2, Y1, Y2, B1, B2, C1, C2) Control: FANUC 31:iA Main Spindle Power: 15/11 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Counter Spindle Power: 11/7,5 kW bar material dia.: 51 mm spindle revolution: 5.000 min-1 Turning and milling spindle Power: 7,5/3,7 kW Ledpfoy T I H Eox Aiijhg Turning and milling spindle speed: 12.000 min-1 max. rotation length turret bottom: 1.005 mm Slide cross X1 / X2 / Z1 / Z2 / B2: 455 / 222,5 /1.090 / 1.005 / 1.008 mm Slide cross Y1 / Y2: +/- 70 / +20, -50 mm Swivel range B1 axis: +/- 95 ° Linear rack magazine incl. support robot CNC support steady rest Coolant cyclone filter system incl. 2 pcs. coolant pumping spindle oil cooler

Condition: ready for operation (used), Year of construction: 2020, operating hours: 19,990 h, functionality: fully functional, turning length: 2,100 mm, turning diameter: 560 mm, spindle motor power: 37,000 W, spindle speed (max.): 2,000 rpm, spindle bore: 117 mm, travel distance X-axis: 320 mm, travel distance Z-axis: 2,200 mm, rapid traverse X-axis: 20 m/min, rapid traverse Z-axis: 20 m/min, overall weight: 11,000 kg, Hyundai WIA L400LMC – Heavy-Duty Long-Bed Turning Center The Hyundai WIA L400LMC is a robust and powerful turning center designed for machining large and heavy workpieces with high stability and precision. With its high torque spindle, large machining capacity, and integrated automation-ready features, this machine is ideal for demanding industrial applications. With box guide design – the most rigid solution used in turning centers. Key technical specifications: • Main spindle power: 37 kW • Maximum torque: 3,073 Nm • Maximum spindle speed: 2,000 rpm • Maximum turning length: 2,100 mm Lhsdpfjy T Ixbsx Aiijg • Chuck size: 15” • Maximum bar capacity through spindle: Ø117 mm Machine configuration: • 12-position turret with BMT75 interface • C-axis for advanced machining operations • High-pressure through-tool coolant system – 15 bar • Bar feeder interface • Automatic Q-SETTER tool measuring system • FANUC control system • Hydraulic steady rest, programmable via M-code • Large programmable tailstock, controlled via M-code • Coolant spray gun • Wide machine door opening (>2000 mm) for easy loading of large parts • Oil mist / emulsion extraction system Additional equipment included: • 4 driven tools included • SMW-Autoblok SLUB-5-ZS-050310 self-centering steady rest o Monitoring of open/closed position o Clamping range: 50–310 mm The machine was commissioned in 2020 and has been in regular industrial use. The equipment remains in good working condition and offers a powerful solution for heavy-duty turning applications requiring high torque and long part capacity.

Condition: ready for operation (used), Year of construction: 2019, operating hours: 12,055 h, functionality: fully functional, turning length: 760 mm, turning diameter: 420 mm, spindle motor power: 37,000 W, spindle speed (max.): 3,000 rpm, spindle bore: 102 mm, travel distance X-axis: 265 mm, travel distance Y-axis: 120 mm, travel distance Z-axis: 830 mm, rapid traverse X-axis: 30 m/min, rapid traverse Y-axis: 10 m/min, rapid traverse Z-axis: 30 m/min, bar passage: 102 mm, overall weight: 6,900 kg, The Hyundai WIA L3000SY represents the flagship model in Hyundai WIA’s turning center lineup, designed for high precision machining, productivity, and long-term reliability. The machine is equipped with true direct-drive spindles (without belts), ensuring excellent torque transmission, high dynamic performance, and improved machining accuracy. Key technical features include: • Main spindle: 12” chuck with 37KW Lhedpey T Iuiefx Aiijg • Sub spindle: 6” chuck • True Direct Drive spindles (belt-free design for higher precision and reliability) • BMT65 turret with 24 positions and 12 driven tool stations • Driven tools: up to 5,000 rpm with 7.5 kW power • Through-tool coolant system – 15 bar • Gun coolant system • Digital scales for improved machining precision • Pneumatic part pusher through the sub-spindle, including part flushing with M code • Part catcher on both main and sub spindle • Part extraction conveyor • Bar feeder connection • Bore-Max bar capacity: Ø102 mm • Chip conveyor • Automatic Q-Setter tool measuring system • Latest generation FANUC control • Oil mist / emulsion extraction unit with the machine • Hainbuch main spindle chuck The machine was installed at the customer site in 2020 and has been used only lightly. The current owner is changing production profile, which is why the machine has become available. This configuration offers an excellent opportunity to acquire a high-end multi-tasking turning center with very strong specifications and low operating hours. Machine has regular Maintenance done and machine is working! With box guide design – the most rigid solution used in turning centers.

Condition: excellent (used), Year of construction: 2014, operating hours: 4,688 h, functionality: fully functional, turning length: 600 mm, turning diameter: 460 mm, spindle motor power: 22 W, spindle speed (min.): 4,000 rpm, spindle bore: 66 mm, travel distance Y-axis: 140 mm, 12-position turret Motorized tool speeds: 12,000 rpm Chip conveyor Tool measuring arm Parts collector Automatic tailstock Lsdpfx Aiey T H I Ueiohg

Condition: good (used), Year of construction: 2008, functionality: fully functional, machine/vehicle number: 185273, turning diameter: 610 mm, spindle motor power: 26,000 W, spindle speed (min.): 35 rpm, spindle speed (max.): 4,000 rpm, spindle bore: 88 mm, travel distance X-axis: 740 mm, travel distance Y-axis: 410 mm, travel distance Z-axis: 1,838 mm, rotational speed (max.): 12,000 rpm, rotational speed (min.): 15 rpm, overall weight: 17,600 kg, Mazak Integrex E410H-II 2008mod Mazatrol Matrix Ledpfx Aioy T Hxgeiohg

Condition: ready for operation (used), Year of construction: 2007, Manufacturer: HAAS Year of manufacture: 2007 MODEL: SL-40 Operating hours: 6200 Control system manufacturer: HAAS X-axis travel: 800 mm Z-axis travel: 1250 mm Number of tools: 12 Spindle power: 30 kW Spindle speed: 2400 RPM Max. turning diameter: 648 mm Ledpfx Aoy Tytqoiijhg Bar capacity: 103 mm Fully programmable: Tailstock Machine weight: 9000 kg

Condition: ready for operation (used), Year of construction: 2020, operating hours: 8,977 h, functionality: fully functional, machine/vehicle number: MM0008-000192, turning length: 1,020 mm, turning diameter: 540 mm, travel distance X-axis: 565 mm, travel distance Y-axis: 170 mm, travel distance Z-axis: 1,050 mm, controller model: FANUC Series 31i-MODEL B, TECHNICAL DETAILS Turning length: 1,020 mm Turning diameter: 540 mm Swinging diameter over the machine bed: 750 mm Swinging diameter over the top slide: 540 mm Swinging diameter over the cross slide: 270 mm Travel range X-axis: 565 mm Travel range Y-axis: 170 mm Travel range Z-axis: 1,050 mm Rapid traverse rate X-axis: 36 m/min Rapid traverse rate Y-axis: 26 m/min Rapid traverse rate Z-axis: 36 m/min Power of the spindle motor: 22 W Spindle speed main spindle (max.): 5,000 rpm Spindle bore: 76 mm Spindle speed milling spindle (max.): 12,000 rpm Bar passage: 76 mm Bar diameter (max.): 65 mm Spindle nose: A2#6 Spindle diameter: 110 mm MACHINE DETAILS Control system: FANUC Series 31i-MODEL B Chuck outer diameter: 210 mm Type of input current: Three-phase Dimensions & Weight Dimensions (L x W x H): 4,850 x 2,525 x 2,805 mm Total weight: 12,000 kg Operating hours: 8,977 h Lodpsy Tw Ulefx Aiiohg EQUIPMENT Documentation/Manual

Condition: excellent (used), Year of construction: 2020, functionality: fully functional, Technical details turning diameter 760 mm turning length 1540 mm control Fanuc 31i-B dimensions of machine 5500 x 2700 x 3110 mm chip conveyor 6900 x 2400 mm total power requirement 94,42 kW weight of the machine ca. 15,5 t Additional information Ledpfxsy Tv Ukj Aiishg Turning center with infinitely variable swiveling milling head and Y-axis, motorized lower turret and subspindle. Condition: Very well preserved, machine comes from a company liquidation. Time recording: Control unit on: 13127 hours Runtime: 3833 hours Processing time: 2835 hours The upper head is fed by a tool magazine and can turn or mill at various angles. Even highly complex components can be completely machined without further repositioning. Fanuc 31i-B CNC control Swing diameter over bed: 1000 mm Maximum turning diameter: 760 mm Maximum turning length: 1540 mm Maximum bar diameter (manual/continuous): 76/76 mm Y-axis travel: 230 mm (±115 mm) Clamp (counter spindle) ASA interface: A2-8 Spindle speed: 4000 rpm AC motor power (cont./30 min.) 22/26 kW Turning/milling head B-axis rotation / indexing 240 deg. (±120 deg.) Tool holder Capto C6 Speed in revolutions per minute 12000 rpm AC motor power 30 min. 15/18.5 kW 40-station ATC Tool turret Number of driven tools 12 (12) Number of driven tools 7.8 kW/30 min.

Condition: used, Year of construction: 2007, functionality: fully functional, Technical details turning diameter 100 mm turning length 320 / 345 mm control Siemens 840 D swing diameter 145 mm spindle distance 580 mm slide I - cross travel (X1) 220 mm slide I - longitudial travel (Z1) 320 mm y-axis +/- 30 mm rapid traverse (X/Y/Z) 30/15/30 m/min slide II - cross travel (X2) 120 mm slide II - longitudial travel (Z2) 345 mm rapid traverse (X/Z) 30 m/min Ljdpoy Tvn Rjfx Aiishg Travel subspindle (Z3) 380 mm vertical stroke (X3) 145 mm bar material dia. max. 36 mm rapid traverse (X/Z) 20/30 m/min power capacity (40/100 % ED) 26/21 kW spindle turning speed range 40 - 7200 U/min total power requirement 42 kVA weight of the machine ca. 5,3 t Additional information CNC turning and milling centre with Y-axis, 2 turrets, subspindle and bar feeder. A total of over 44,000 EUR has been invested in necessary repairs and maintenance over the last 5 years by DMG MORI (replacement of the main spindle S4, ball-screws, etc.). Equipment: - SIEMENS 840 D powerline CNC control - Number of controlled axes: 9 - 2 x C-axis - Y-axis in upper turret - Pick-up device with gripper - 2 SAUTER turrets with 12 tool positions (driven), VDI 25 - Tool drive with a speed range of 30 to 6000 rpm - Coolant system with paper band filter - Chip conveyor - Collet chuck on main and subspindle - Bar loading magazine, make: IEMCA BOSS 332 E 32 L, max. bar length 3180 mm

Condition: good (used), Year of construction: 2022, functionality: fully functional, Technical details turning diameter 820 mm turning length 4500 mm control Siemens Si 840 D sl Additional information New purchase price in the year 2022 EUR 1.2 million Time recording from Feb. 2025 Operating hours = 16085 h Main spindle = 616 h Milling spindle = 369 h CNC control Siemens Sinumerik Si 840D sl Max. center distance 4500 mm Working height 1375 mm X-axis travel -15 +725 mm Lhjdpfxoy Tu U Ns Aiiog Y-axis travel -245 + 4756 mm Swing diameter over cross slide 780 mm Swing diameter over bed 820 mm C-axis, smallest increment +/-0.001° Main spindle A15 with BVG; 3135 N;/2000 rpm Spindle head DIN 55026 Form A 15 Max. speed 3000 rpm Max. torque 3135 Nm Drilling/milling unit Milling power (40/100% duty cycle) 36.5/29.8 kW Torque up to 1110 rpm (40/100% duty cycle) 328/261 Nm Max. spindle speed 5000 rpm Swivel range (B-axis) -105 +95° Vertical travel (Y-axis) -250 +250 mm SR5 steady rest with eccentric fine adjustment 45–310 mm C8 tool system Tool magazine (2 magazines) 144 Tailstock Quad diameter MK6 180 mm Quad stroke 170 mm Quad force (adjustable) 5–28 kN Quad fine adjustment +/- 0.15 mm Optional equipment Coolant tank capacity 990 l Workpiece measurement MC (Reinshaw) Software Gear hobbing &more

Condition: good (used), Year of construction: 2006, functionality: fully functional, Technical details turning diameter 660/275 mm turning length 1498 mm control Fanuc/Mori Seiki MSX 701 total power requirement 90 kVA weight of the machine ca. 26,6 t dimensions of the machine ca. 5301 x 2997 x 2788 mm Additional information Lhsdpsy Tu Tfjfx Aiijg 9-axis CNC turning and milling centre * Fanuc MSX-701 CNC control * Milling spindle at top (B axis), as full 4th axis, positioning 0.0001 deg. * 40-position tool magazine * 10-position turret at bottom, all positions driven * 2 x 3-jaw quick-change chuck KNCS-N 315/91 * KNOLL high-pressure coolant system, pressure setting 12/25/35/45/55/62 and 72 bar, with maintenance-free rotary filter system * Chip conveyor * Drain system for main spindle chuck (controlled via M function) * Drain system for tool cutting edge (controlled via M function) * Coolant gun incl. accessories * Oil mist extraction * Direct measuring system X1, X2, Y-axis * Bar loader interface * Double foot switch for both spindles * Islands and pocket programming for MAPPS * High-speed fixed cycle for MAPPS * Programm memory extension to 8 MB * Programm restart * 3-stage signal lamp * 512 MB memory card (CF card) Swing diameter over cross slide (tool spindle 1): 750 mm Swing diameter over cross slide (turret 2): 400 mm Max. turning diameter (tool spindle 1): 660 mm Max. turning diameter (turret 2): 275 mm Max. machined workpiece length: 1498 mm Max. bar material: 90 mm Travels: X1 axis (tool spindle): 750 mm Y axis (tool spindle): 420 (+/- 210) mm Z1 axis (tool spindle): 1635 + 100 mm for tool change B axis (tool spindle): +/- 120 deg., full B-axis 1 deg. indexed and 0.0001 deg. braked X2 axis (turret): 195 mm Z2 axis (turret): 1525 mm SZ axis (subspindle): 1610 mm Rapid traverse: (X1,Z1) 50 m/min. / (Y,X2,Z2,SZ) 30 m/min. Main and subspindle: Spindle speeds infinitely variable (spindle 1 + 2): 30-3000 rpm. C axis (spindle 1 + 2): 0.001 deg. Main spindle motor: 22/18.5 kW Subspindle motor: 22/18.5 kW Torque (spindle 1 + 2): 1000 Nm Disc turret: Number of tool positions: 10 Speed of driven tools: 6000 rpm. Drive power: 5.5/3.7 kW Milling spindle head: Tool holder: HSK A63 Max. speed: 12,000 rpm Drive power: 18.5/11 kW Torque: 120/44 Nm Tool changer: 40-stations Tool diameter 70/140 mm Tool length 400 mm Tool weight 8/10 kg Total power requirement 90 kVA Main dimensions Length x width x height 5301 x 2997 x 2788 mm Machine weight 26.6 t Accessories: Measuring arm (picture) tool measurement in machine Tool holder + box, reduction sleeves, driven tools Clamping jaws package Collets package

Condition: good (used), Year of construction: 2000, functionality: fully functional, Technical details turning diameter 420 mm turning length 650 mm control Okuma OSP-U100L spindle bore 95 mm spindle turning speed range 2800 U/min travel -x axis 300 mm travel -z axis 675 mm main drive motor 22/30 kW weight of the machine ca. 5,5 t dimensions of the machine ca. 2700 x 1900 x 1885 mm Additional information First put into operation 2001. - 12-station turret (VDI 40) with driven tool stations, 3,000 rpm, 5.5 kW Lsdpfxoy Tuu Ae Aiishg - Internal extraction system by Hengst Filtration (year of manufacture 2023) - Touchsetter, tool measurement - C-axis (main spindle) - Tool breakage and wear monitoring - 3-jaw chuck, Kitagawa B210, Ø250 - Tailstock - Coolant supply, also through the tool - IGF dialog programming - Chip conveyor

Condition: used, Year of construction: 2007, turning diameter 300 mm turning length 600 mm control FANUC, 18i-TB turning diameter over bed slide 230 mm travel x1 165 mm travel z1 700 mm travel x2 190 mm travel z2 720 mm travel -y axis +/- 50 mm main spindle bore 76 mm main spindle speed 5.000 U/min main spindle drive 22 kW max. torque on the spindle 208 Nm sub spindle bore 76 mm sub spindle speed 5.000 U/min sub spindle drive 22 kW max. torque on the spindle 208 Nm tool turret 2 x 12 Stat. number of driven tool stations 2 x 12 speed of driven tools 5.000 U/min Ljdoy Tplispfx Aiiehg max. torque 47 Nm work piece power 5,5 kW C-axis resolution 0,001 ° rapid traverse x + z axis 20 / 40 m/min rapid traverse y-axis 7,5 m/min total power requirement 68,4 kVA Accessories: collet fixture make KITAGAWA, CRS 66, on main spindle, hydr. 3-jaw chuck make KITAGAWA, BB 208, 210 mmø, on sub spindle, various tool holders for turret, bar loader make HYDRAFEED, model MULTIFEED MX-1B for bar dia. 3 - 80 mm and bar length up to 1650 mm, chip conveyor, coolant with belt filter device

Condition: good (used), Year of construction: 2016, functionality: fully functional, HAAS ST-40L CNC lathe, year of manufacture 2016, C-axis, driven tools, tailstock, steady rest, extended bed The machine is equipped with a C-axis, driven tools, programmable tailstock, Kitagawa hydraulic steady rest, chip conveyor, and accessories. The machine is powered on and available for testing by appointment. Machine basic specifications: Manufacturer: HAAS Automation, Inc. Model: ST-40L Year of manufacture: 01/2016 Serial number: 3104909 Control system: HAAS CNC Power supply: 3 × 400 V / 50 Hz Machine weight: approx. 14,062 kg Design: extended bed ST-40L Technical parameters: Max. swing diameter over bed: 876 mm Max. turning diameter: 648 mm Max. turning length: 2,032 mm X-axis travel: 432 mm Z-axis travel: 2,032 mm Work travel X/Z: 18 / 8.1 m/min Rapid traverse X/Z: 18 / 8.1 m/min Positioning accuracy: 0.005 mm Repeatability: 0.003 mm Spindle Spindle: A2-8 Spindle bore: 102 mm Spindle bore diameter: 117 mm Max. spindle speed: 2,400 rpm Spindle power: 30 kW / 40 HP Torque: 1,898 Nm at 150 rpm Chuck: hydraulic 3-jaw Kitagawa B15, diameter 381 mm Turret and driven tools Turret: 12-position combined turret Tool clamping: 6× VDI 40 / 6× BOT Driven positions: every other position in the turret Tool drive: yes Lsdpfxjy Tnwwj Aiijhg C-axis in the spindle: yes Max. speed of driven tools: 0–6,000 rpm Power of driven tools: 9.3 kW C-axis positioning: 0.001° Continuously controlled C-axis in the spindle: yes Tailstock and steady rest Programmable tailstock: yes, servo-controlled Tailstock taper: MK5 Tailstock clamping force: 1,334–6,672 N Hydraulic steady rest: Kitagawa 1131 Steady rest range: 110–310 mm Separate oil lubrication for the steady rest: yes Max. steady rest speed: 650 rpm Max. clamping force of the steady rest roller: 20 kN Machine equipment The machine is equipped with: HAAS CNC control system, C-axis, driven tools, 12-position turret with 6× VDI / 6× BOT, programmable tailstock, Kitagawa 1131 hydraulic steady rest, Kitagawa B15 hydraulic chuck, chip conveyor, cooling unit, automatic central lubrication, manual spray gun for coolant, manual air blow gun, remote jog handle, USB port, work area lighting, set of tool holders and accessories. Accessories The machine comes with accessories as shown in the photos, including: ER32 driven tool holders, VDI/BOT tool holders, set of hard jaws for Kitagawa B15 chuck, additional jaws, sleeves and clamping elements. Operating hours According to the display on the control system: Cycle start time: approx. 7,208 h Cutting time with feed: approx. 5,989 h Machine condition The machine is currently in operation and powered on. Inspection and testing are possible by appointment. The technical condition corresponds to the normal operation of a used machine.

Condition: not inspected (used), Year of construction: 2006, ● Availability: Immediately, by arrangement ● Payment terms: Advance payment – by bank transfer ● Internal No.: KA1 ● Can be inspected while powered on: Yes Technical data: Turning diameter: 760 mm Turning length: 1,524 mm Control system: Mazak Matrix CNC Spindle speeds: 3,300 / 12,000 / 3,300 Spindle diameter: 78 / 78 mm Tool magazine slots: 80 Tool holder: Capto Max. tool length: 400 mm Max. tool diameter: 125 / 90 mm Machine times: Total time: 72,894 h Automatic operation: 42,535 h Cutting time: 33,294 h Effective cutting: 15,281 h Scope of delivery: Available manuals (completeness not guaranteed) Main and counter spindle Milling unit (mill spindle) Two-force chuck Kitagawa QJ-312 Pallet pool with robot Coolant system available Extraction system not included Dimensions & weights: ● Installation dimensions L x W x H approx.: 5200 x 2500 x 2750 mm ● Weight approx.: 7800 kg Additional notes: ►Upon request, we can offer transport to the desired location. ►The quoted price is net plus VAT. Ljdpfey Tm I Uex Aiiohg ►The goods are sold with exclusion of any warranty. ►Technical data without guarantee. ►Subject to prior sale. ❗The sale of the goods is exclusively to business customers❗

Condition: excellent (used), Year of construction: 2009, operating hours: 29,000 h, functionality: fully functional, Equipment: documentation/manual, The INDEX C200 – manufactured in 2009 – is a powerful CNC production turning center with a FANUC 31i control, main and counter spindle, and a 65 mm bar capacity. The machine features a high-quality 3-turret design, with turrets 1 and 2 each equipped with X, Z, and Y axes, and turret 3 used for machining on the counter spindle. All three disc turrets are equipped with 10 stations and, with driven tools up to 6,000 rpm, enable highly flexible complete machining. With a portal parts handler, conveyor belt, C-axes on the main and counter spindles, and powerful spindle drives, the machine is particularly suitable for productive series production of complex turned/milled parts. Control: FANUC 31i Design: Machine with 3 tool holders / 3 disc turrets Bar capacity: 65 mm Machine bed: Vertically arranged gray cast iron machine bed Main spindle: Spindle 4 Counter spindle: Spindle 5 with Z-axis Spindles Main spindle Bar capacity: 65 mm Spindle diameter at front bearing: 110 mm Spindle nose: ISO 702/1, Size 140 Cyl. Chuck diameter: 160 mm Power: 25 kW at 100% ED / 33 kW at 40% ED Torque: 112 Nm at 100% ED / 150 Nm at 40% ED Speed: 5,000 rpm C-axis: Resolution 0.001° Counter spindle Bar capacity: 65 mm Spindle diameter at front bearing: 110 mm Spindle nose: ISO 702/1, Size 140 Cyl. Chuck diameter: 160 mm Power: 25 kW at 100% ED / 33 kW at 40% ED Torque: 112 Nm at 100% ED / 150 Nm at 40% ED Speed: 5,000 rpm C-axis: Resolution 0.001° Counter spindle Z-axis: 700 mm travel Rapid traverse Z-axis: 50 m/min Tool holder / Turret Design with 3 disc turrets, each with 10 stations. Tool system with 10 stations: Cylindrical shank DIN 69880 – Ø30 x 55 mm. Tool holder 1 X, Z, Y axes 10 stations X-axis: 110 mm Z-axis: 320 / 550 mm (according to documentation) Y-axis: 100 mm, ±50 mm Driven tools: 6.5 kW / 16 Nm / 6,000 rpm Tool holder 2 X, Z, Y axes 10 stations X-axis: 110 mm Z-axis: 550 mm Y-axis: 100 mm, ±50 mm Driven tools: 6.5 kW / 16 Nm / 6,000 rpm Tool holder 3 X-axis 10 stations Used exclusively for machining on the counter spindle X-axis: 180 mm Driven tools: 6.5 kW / 16 Nm / 6,000 rpm Further technical equipment according to documentation Portal parts handling system with numerically controlled Z-axis Workpiece removal from main or counter spindle to conveyor belt Removal of scrap material from the main spindle into a scrap container Portal parts handler: Traverse speed: 100 m/min Traverse range: 70 mm Workpiece diameter max.: 90 mm Workpiece length max.: 250 mm Scrap length max.: 250 mm Workpiece weight max.: 3.5 kg Hydraulic system: Flow rate: 19 l/min System pressure: 90 bar Hydraulic tank: 40 l Coolant circuit: Flow rate: 19 l/min Coolant unit power: 13 kW Coolant system: Pump output: 80 l/min / 8 bar Tank capacity: 300 l Chip conveyor: Chip discharge height: 1,250 mm Lodpfxoy Tmhze Aiijhg

Condition: used, Year of construction: 2006, functionality: fully functional, Machine dimensions: 2.9m x 2.8m x 2.9m Machine weight: approx. 7 tons Ljdpfx Aijy Tlu Toijhg Year of manufacture: 2006 Travel ranges: X 1050 Y 530 Z 510 (150 above table) Spindle speed: max. 12,000 rpm Motor spindle: SK40 Measuring probe: Renishaw OMP 60 Measuring head: Mazak Internal cooling pressure: 25 bar External cooling Tool magazine: 30 positions Articulated belt conveyor Machine control: MAZATROL M640 • One machine each in left-hand and right-hand configuration (chip conveyor on the left or right) • Various tool holders can be purchased separately. • NO clamping devices (vices) included! • NO dust extraction system The stated price is for one machine only.

Condition: good (used), Year of construction: 2005, EMCOMILL FB 6 (with digital scales X, Y, Z) Tool milling machine with 18 spindle speeds from 63-3150 rpm, 18 feeds in the X, Y, Z axes, toolmaker accuracy according to DIN 8615, slide travels X/Y/Z 700/500/500 mm, Lodpfxsy Tkghs Aiijhg power 5.5 kW (100% duty cycle), hydraulic tool clamping, tool holder DIN 69871 SK 40, electrical connection 400/50/3, incl. Heidenhain scales in X/Y/Z, machine complies with CE, without counter support, with work area protection Manufactured according to ISO 9001: 1994 Year of manufacture 2005 F4UT3901

Condition: good (used), Year of construction: 2021, functionality: fully functional, Machine has 920 spindle hours. Mori Seiki NLX 2000 turning/milling center, year of manufacture 2021, Celos 730 UM / Mapps control system, X/Z travel 260 / 590 mm, Y-axis +/- 50 mm, bar diameter up to 65 mm, main spindle with C-axis, spindle speed up to 5,000 rpm, 12-station BMT turret, driven tools, Lhjdjy Ti Uwepfx Aiiog NC steady rest, tailstock, tailstock spindle speed up to 6,000 rpm, chip conveyor, high-pressure cooling system, oil mist separator, manually adjustable tool pre-setter, swiveling inside the machine, part catcher for main and tailstock spindles, Irco short bar loader ILS, gear hobbing, gear skiving.

Condition: good (used), Year of construction: 2023, Spinner TC 600, Year of manufacture 2023, Fanuc 32 i TB control system, Travel range X/Z 275/700 mm, Chip conveyor, Tailstock, 16-position turret, VDI 40, C-axis, Powered tool holders, 3-jaw chuck Ø 250 mm. Lhedpfxey Thmlj Aiiog

Condition: good (used), Year of construction: 2006, functionality: fully functional, machine/vehicle number: 187859, turning diameter: 380 mm, spindle speed (max.): 5,000 rpm, rotational speed (max.): 4,500 rpm, bar passage: 65 mm, overall weight: 4,900 kg, Mazak QTN-200MS CNC turning and milling center, manufactured in 2006 with subspindle and driven tools Main spindle with Kitagawa chuck and Hainbuch collet chuck, 35-5000 rpm. Subspindle with Kitagawa chuck, 35-6000 rpm. All 19 tool holders, including 5 driven tools Jaws, collet chucks, wrenches and accessories shown in the photo are included. 12-position turret Ledpfx Aisy Tb D Djiohg Parts catcher, chip conveyor >>Bar feeder FMB SL80 V (year 2020) >>Conveyor belt The machine has been very well maintained. Hydraulic oil, lubricants, and operating fluids have been recently changed. The machine can be inspected while in operation. Model: QTN-200MS Serial number: 187859 Weight: 4900 kg Weight: 10780 lbs Year of manufacture: 2006 If you have any questions or require further information, please send us a message or call us.

Condition: excellent (used), Year of construction: 1999, 1. CNC turning center with dual spindle and dual turret, WT 250 NAKAMURA, manufactured in 1999, including: * 4 axes Ljdsy Ta Iuspfx Aiijhg * 1 parts loader

Condition: excellent (used), Year of construction: 1998, 1. CNC turning center with twin spindle and twin turret, WT 250 NAKAMURA, manufactured in 1998, including: * 4 axes Lhsdpfxey Ta Ihs Aiieg * 1 MASTER 880 IEMCA bar feeder

Condition: good (used), Year of construction: 2005, 1. 5-axis CNC turning center, TOME NTJ NAKAMURA model, year 2005. Lhsdpfsy Ta Hqjx Aiijg 2. LNS bar feeder.
