Extraction system with press

Höcker Polytechnik

Condition: excellent (used), Year of construction: 1999, Höcker Polytechnik Clean Air Dust Extractor – Clean Air Unit Inlet nozzle: right Control cabinet Diameter of inlet nozzle: 300 mm Rated air flow: 5,320 m³/h Minimum air flow: 4,433 m³/h Filter area: 28 m² Filter cleaning: motorized shaking 3 collection bins, total capacity: 495 liters Filter material: polyester needle felt Negative pressure at Vmax: 2,700 Pa Design: mobile Overall length: 3,210 mm Motor power: 7.5 kW Electrical connection: approx. 400 Volt/50 Hz Klodpfx Ahsyb T Uceuel Location: ex stock 54634 Bitburg - immediately available -

Condition: excellent (used), Year of construction: 2011, Extraction system Manufacturer: Höcker-Polytechnik Model: EA 160 Year of manufacture: 2011 Nominal air flow: 1,500 m³/h Max. air flow: 2,750 m³/h Pressure loss: 2,800 Pa Power: 3 kW Kedpfjyb Rq Uex Ahusll Filter cleaning: Mechanical – Electric Extraction connection: 160 mm Weight: approx. 270 kg

Condition: used, Year of construction: 2018, machine/vehicle number: 519553, Central extraction system Höcker Polytechnik with rotary valve and/or dust bins.(Option: rotary valve instead of dust bins) Manufacturer: Höcker Polytechnik Type: Multistar JQ6/5 131/20717A Year of manufacture: 11/2018 Dust properties: Dust and chips Material throughput: Unknown Jet cleaning of filters Volume flow: Approx. 22,000 m³/h Disposal type: Open Clean air duct: Air recirculation Residual dust content: 0.1 mg/m³ based on dust. 1 piece Kljdpfxjya Idvo Ahuol Filter system, galvanized - Year of manufacture 11/2018 - Multistar JQ6/5 131/20717A - Filter area: approx. 131m² - Filter bags: 120 - Filter bag diameter: 170mm - Filter bag length: 2,070mm - Filter cleaning Air Jet, compressed air - Filter housing made of galvanized sheet steel - Inspection door, access ladder, standing platform - Tested pressure relief areas - Raw gas section as large expansion chamber - Exhaust air connection according to local requirements - Filter base frame in welded steel construction, hot-dip galvanized. - Includes dry extinguishing line, C connection - *Optionally with 6 chip bins or large rotary valve*2 pieces Clean air fans DER 404/400/18.5-2 - Volume flow: 11,000 m³/h per fan - Directly driven fans - Galvanized sheet steel - Installed horizontally in Multistar series - Electrical power of each fan 18.5 kW - Total volume flow 22,000 m³/h - Total pressure increase: 4,600 Pa 1 piece Pipe components Air recirculation - Including galvanized ducts - Must be supplemented for a new location . 1 piece Control cabinet With PLC Siemens S7-1200 Dustproof sheet steel standard housing control cabinet as wall cabinet, built and completely wired, in accordance with VDE regulations 0100, 0113, and DIN 57113. The scope of delivery includes all components required for control components and the circuit igned for: · Jet cleaning control · Control of 2 fans · 6 automatic start-up of the fans when the machine starts · Pressure monitoring indicator light · 3 control butterfly valves · Rotary valve controlDimensions: - Length: 3,960 mm - Width: 3,380 mm - Height: 5,900 mm (may vary depending on equipment) Electrical connection value: - approx. 38 kW - 400 V/50 Hz - Control voltage 230 V AC/24 V DC Location at warehouse

Condition: used, Year of construction: 2010, Suction nozzle diameter: 200 mm Rated airflow: 2262 m³/h Max. airflow: 3500 m³/h Filter area: 12.65 m² Cleaning system: vibration motor Chip disposal: 2 collection containers Collection volume: 330 liters Filter material: polyester needle felt Negative pressure at nominal flow: 2750 Pa Installation: mobile Approx. weight: 450 kg Motor power: 4 kW Power connection approx.: 400 Volt/50Hz Kjdpfox U Egxox Ahusll Storage location: with customer

Condition: used, Year of construction: 2025, Filter system, immediately available! NEW in original packaging! 1.1. STfp-rFan DER4 450/550/18.5-2 | incl. backdraft damperExtraction fan, "DER4" series for clean air-side installation, single-sided suction, direct drive. Main design features: Spiral housing made of galvanized steel, pre-configured for horizontal installation in MultiStar series filters IEC standard motor High-performance impeller with backward-curved blades, designed for clean-air extraction operation Suction nozzle with spark protection Impeller made of welded steel, statically and dynamically balanced For explosion protection reasons, the fan is not suitable for conveying explosive dust/air mixtures! Technical data and performance:Volume flow (max. permitted): 15,000 m3/hTotal pressure increase: 3,000 PaInlet nozzle: 450 mm diameterOutlet nozzle: 450 mm x 355 mmDrive motor: 18.50 kW, 3000 rpm at 50 Hz | 3600 rpm at 60 HzVoltage / Frequency: 400 V, 50 HzMotor efficiency class: IE3, Premium EfficiencyWeight, approx.: 330 kgRotation direction: RD 0 1.1.1. STcold conductor 18.5 kW 1.2. STMultiStar VR 6.6-195.25317AMultiStar modular filter system, with vibration cleaning, for installation outside explosion hazard zones. Design features:Galvanized, self-supporting sheet steel constructionPressure surge resistance 200 mbar (type tested, Dekra-Exam 342863200a-23ExA-Sip)Housing negative pressure resistance max. 5500 Pa (avoid fluctuating stress)EU type-tested rupture discsWeather protection cladding of the filter section with inspection door(s) and required number of exhaust nozzles (depending on air volume) Fire resistance EW 90ef, MPA-tested Clean-air nozzle, as per project drawing BG-tested needle felt filter material, suitable for wood and paper dust and many other types of dust Filter bags, externally pressurized, with reusable internal support elements Filter cleaning occurs during operation breaks Expansion chamber for pre-separation The permissible fill level of the expansion chamber strongly depends on the material properties (bulk density, grain size, tendency to form bridges, etc.) and is approximately 400...700mm. Inspection door with viewing window and limit switch Connection shaft for rotary valve, or similar. Technical data and dimensions:Filter area: 195 m²Filter bags: 144 pcsFilter bag length: 2530 mmBag diameter: 170 mmShake-off: 0.18 kW, 400 V, 50 Hz - 1 unitAgitator drive: 1.50 kW, 400 V, 50 HzFootprint, L x W: 2880 mm x 2880 mmSpace requirement, L x W: Space requirement as per system drawingHeight: 9110 mm Additionally included in delivery: Dry fire-extinguishing line, consisting of: o C-hose connection with blind coupling * o Riser pipe from filter base o Distributor pipe system with sprinkler nozzles o Notice sign Note: According to DIN EN 12779:2016 sec. 5.4.2.3, the water connection must be arranged 0.4 m to 0.8 m above the floor and, in the event of a fire, be safe and easily accessible for connecting a fire-fighting hose. The BGHM additionally recommends installing a dirt trap in the riser. The components, installation materials, and labor required for this are not included in the basic price of the dry extinguishing line. These can optionally be provided by the customer or as a custom-built stand = 3000 mm special height. The base frame is not included in the scope of delivery and will be designed and specified separately.1.2.3. Additional S Kljdpfxsx U Egrs Ahujl

Condition: new, Year of construction: 2022, Negative pressure deduster Hoecker-Polytechnik. LIKE NEW !! Technical data Normal volume flow rate 5100 m3/h Max volume flow rate 6000 m3/h Negative pressure at rated V 2700 Pa Kljdexr Rk Ujpfx Ahujl Motor power 11 kW Rated speed 3000 min-1

Condition: ready for operation (used), Year of construction: 2012, functionality: fully functional, power: 30 kW (40.79 HP), Extraction system Hocker Polytechnik type MultiStar JP5, year 2012, volume 20,000 m³, motor 30 kW, with briquetting press BrikStar c-3 18, with control system, with heated channels, with accessories, with negative pressure. Kodpfjx Tqd Tjx Ahuoll

Condition: used, Year of construction: 2011, Extraction system Kledex Tg Iuepfx Ahusl Manufacturer: Höcker-Polytechnik Model: EA 200 Year of manufacture: 2011 Control only possible externally The machine was used for extracting cocoa powder. The filters are dirty. Airflow: 2,252 m³/h Max. airflow: 3,500 m³/h Vacuum: 2,750 Pa Extraction nozzle diameter: 200 mm Power: 4 kW Fire extinguishing system: Yes

Year of construction: 1998, condition: good (used), Material separator, material selector, filter system, material separator, metering rotary valve, rotary valve, metering valve, rotary valve, conveying technology -Manufacturer: Höcker Polytechnik, material separators for paper, cardboard, corrugated board ... -Type:PMA-U -Drive: 0.75 kW -Inlet: 590 x 610 mm -Injection air volume: max. 12000 m³/h -Technical data: see photo of the nameplate Kledpox Td Ilofx Ahuel -Transport dimensions: 2020/1340/H2000 mm -Weight: 878 kg

Condition: excellent (used), Mobile extraction unit Kledpfx Ahjx Srmajujl - 160 mm diameter nozzle - 2.2 kW with adapter and 5 m hose to 140 mm diameter
