Jig Grinding Machine

HAUSER S35-400

Condition: good (used), HAUSER S 35-400 is a CNC jig grinder for precision, high accuracy and reliability. Capacities: table 600×380 mm, X500 Y300, vertical slide 450 mm, spindle‑to‑table 485 mm, max grinding Ø 230 mm (360 with plate), spindle nose stroke 340 mm, taper up to 16°. Specs: spindle vertical travel 1–110 mm stepless, travel speeds 1–12 m/min, planetary C 5–250 t/min, 3×380 V 50 Hz, total power 10 CV, weight ≈4000 kg, footprint 2700×1700×2850 mm. Accessories: coolant, paper filtration, lamp, MSS, oil‑mist extractor, CBN redresser HF, toolchanger 12 EROWA. Suited for tight tolerances in automotive, watchmaking, toolmaking, aerospace and medical sectors. Iedpfx Adoxx U Uwo Dotp

Condition: excellent (used), Year of construction: 2016, operating hours: 26,678 h, functionality: fully functional, This machine is available exclusively through Montrasio GmbH and is being sold on behalf of the authorized parties. DMG DMU 100P duoBLOCK – 5-Axis CNC Machining Centre (2016) Year of manufacture: 2016 Control: SIEMENS CELOS Travel / Capacities X-axis: 1,000 mm Y-axis: 1,250 mm Z-axis: 1,000 mm Workpiece diameter: 1,100 mm Itodpfjxl Arkjx Ad Dep Workpiece height: 1,600 mm Workpiece weight: up to 2,200 kg Table / Axes Table size: 1,100 × 900 mm Table rotation speed: 35 rpm Max. table load: 2,223 kg B-axis universal milling head swiveling range: −30° to +180° Spindle / Tool Spindle speed: 0 – 12,000 rpm Spindle motor power: approx. 69 HP (≈ 51.5 kW) Spindle taper: HSK-A100 Tool magazine: 63 positions Machine Dimensions Footprint: approx. 24 m² Machine height: approx. 3,606 mm Machine weight: approx. 24,540 kg Accessories / Equipment CNC-controlled universal milling head (B-axis) Workpiece probe Tool measurement system 3D Quickset Chip conveyor

Condition: not inspected (used), Year of construction: 1998, machine/vehicle number: 2183, travel distance X-axis: 500 mm, travel distance Y-axis: 300 mm, spindle speed (max.): 60,000 rpm, spindle speed (min.): 9,000 rpm, workpiece weight (max.): 300 kg, total height: 3,250 mm, feed rate X-axis: 2,000 m/min, feed rate Y-axis: 2,000 m/min, table width: 380 mm, table length: 600 mm, table load: 300 kg, overall weight: 4,500 kg, travel distance W-axis: 450 mm, Equipment: documentation/manual, THIS MACHINE IS SOLD EXCLUSIVELY WITHIN THE EU – THANK YOU FOR YOUR UNDERSTANDING! Item type: CNC Coordinate Grinding Machine Manufacturer: HAUSER Model: S35-400 Year of manufacture: 1998 Machine number: 2183 Condition: According to the previous owner and a Hauser specialist, the machine is in good condition. Terms of delivery: Free loaded onto truck Availability: Immediately (subject to prior agreement) Location: Magdeburg Technical data: • Control: GE Fanuc Series 16-M • Tool holder: Collets EX 19 or grinding arbors E19 • Travel X / Y / W axes: 500 / 300 / 450 mm • Feed rate X & Y axes: 0 – 2000 mm/min • Feed rate W axis approx.: 900 mm/min • Table dimensions: 600 x 380 mm • Max. table load: 300 kg • Grinding spindle speed stepless: 9,000 – 60,000 rpm • Z-axis stroke speed stepless: 0.5 – 14,000 mm/min • Fire extinguishing system • Further technical data – see pictures Scope of delivery: • Grinding motor 60S (9,000 – 60,000 rpm) – see separate pictures • Extraction system • Coolant system • Dressing turbine • Available manuals • The clamping equipment visible in the pictures as well as the currently mounted grinding motor are NOT included in the scope of delivery! Dimensions & weights: • Installation dimensions (L x W x H) approx.: 4,250 x 4,000 x 3,250 mm • Weight approx.: 4,500 kg If you have any questions or would like to arrange a viewing, please feel free to contact us. Iedpfx Aowakqyed Dotp Additional notes: The tool changer is not operational – according to the previous owner, it was never needed anyway! • On request, we can arrange transport to the destination. • The offer price is net plus VAT. • The goods are sold under exclusion of any warranty! • The sale is exclusively to business customers! • Technical data subject to change and without guarantee. • Subject to prior sale.

Condition: used, Year of construction: 1990, table length 600 mm table width 380 mm control FANUC 0-M longitudinal travel 500 mm cross travel 300 mm Iodpow Eykyjfx Ad Detp largest grinding diameter 230 mm control FANUC 0-M Jig grinding machine | HAUSER - S35-400 The machine is in a well-maintained condition. Please note that the technical details were added from comparable machines. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: S35400 | S35 400 | S35CNC400 | S35 | S-35 | S 35

Condition: used, Year of construction: 2008, tip circle diameter 650/800 mm workpiece length - max. 1100 mm max. module 20 (25) mm min. module 0,5 mm control Siemens Sinumerik 840 D Ijdpfx Aew Rrbyed Dotp total connected load 62 kVA helical angle -45 / + 120 ° weight of the machine ca. 10 t

Condition: ready for operation (used), Year of construction: 1995, functionality: fully functional, travel distance X-axis: 500 mm, travel distance Y-axis: 450 mm, travel distance Z-axis: 110 mm, spindle speed (max.): 160,000 rpm, spindle speed (min.): 8,000 rpm, workpiece weight (max.): 250 kg, overall weight: 6,000 kg, travel distance W-axis: 400 mm, Hauser Coordinate Grinding Machine S35. Isdjxp Hq Eepfx Ad Dotp Fully functional. Very good motors and additional accessories available. The machine is under power and can be inspected. Grinding trials can be arranged by appointment. U-axis in excellent condition. Positioning is highly precise. C-axis for contour grinding is available and fully operational. Control: Fanuc O-M The machine is in daily use and continues to be highly accurate. Fanuc components have been replaced over the last two years. Old parts have been exchanged for new ones. Machine is being sold - > bought as seen -> "As is where is" - no manufacturer or seller warranty. Training on the machine and control system is possible at any time, either at our facility or on your premises. (We are also happy to assist with any further questions.)

Condition: excellent (used), Year of construction: 1991, functionality: fully functional, travel distance X-axis: 500 mm, travel distance Y-axis: 350 mm, travel distance Z-axis: 120 mm, travel distance W-axis: 450 mm, For sale: Hauser coordinate grinding machine, model S35-400 The machine is in excellent condition and underwent a partial overhaul in 2024 for €15,000. The machine is equipped with 6 high-quality grinding motors, a face motor, and turbines. TECHNICAL DATA Distance between column and spindle: 365 mm Clearance between table and spindle: 485 mm Main spindle diameter: 100 mm X-axis: 500 mm Y-axis: 350 mm Z-axis: 120 mm W-axis: 450 mm U-axis: 5.5 mm Maximum taper grinding: 16° Table size: 600 x 380 mm Itodpfx Aswtqthod Djp T-slots: 6 units, 10 mm width, 50 mm spacing Table load capacity: 300 kg Speeds and Tool Holders Speed 22S: 4,500 - 22,500 rpm 45S/45ST: E19 Speed 45S/45ST: 9,000 - 45,000 rpm 80S: F6 Speed 80S: 40,000 - 80,000 rpm T10/T16: Ø 3 mm Speed T10/T16: 100,000 / 160,000 rpm Slot grinding attachment: 2,900 - 34,500 rpm Planetary movement: 5 - 250 rpm C-axis: 0 - 5 rpm X/Y feed: 0 - 1,200 mm/min W-axis feed: 900 mm/min Z-axis feed: 0.5 - 12,000 mm/min MACHINE DETAILS Digital measuring accuracy: 0.001 mm Base deviation: 0.003 mm Power: 7.5 kW Compressed air requirement: 20 m³ System pressure: 5 bar Footprint: 3.5 x 4.4 m Machine height: 3.5 m Connection value: 8.3 kVA Weight: 3.1 t EQUIPMENT - Slot grinding attachment - Rotary table, 300 mm diameter - Swivel table, 200 mm diameter - Coolant system - Extraction unit - Very high-quality accessories included Transportation and loading can be arranged across Europe at extra cost upon request. Prices plus VAT. Viewing by appointment is possible. Contact us—our team is happy to assist you. Trade-in or exchange possible! MACHINE PROCUREMENT / SALES PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES AND MORE. Are you looking for a high-quality yet affordable metalworking machine for your production? Or do you want to sell yours? For more information or contact options, visit our website.

Condition: used, Year of construction: 2007, x-travel 900 mm Isdjw Rrb Hopfx Ad Dotp y-travel 300 mm z-travel 1000 mm control Siemens Sinumerik 840D max. workpiece diameter 1600 mm max. module 20 mm tip circle diameter 350 mm Milling arbour diameter 375 mm Total closing value 80 kVa weight of the machine ca. 33,5 t dimensions of the machine ca. 10,530 x 6,375 x 4,680 m Feed rate: - X-axis 1 to 3000 mm/min - Y-axis 1 to 3000 mm/min - Z-axis 1 to 4000 mm/min Spindle speeds in rpm: - Tool 26 to 265 - Workpiece table 0 to 8 Equipment/accessories: - M 2 motor milling head - Milling mandrels - Oil cooler - Technical documentation

Condition: used, Year of construction: 2001, table length 600 mm table width 380 mm control FANUC 16i-M longitudinal travel 500 mm cross travel 300 mm largest grinding diameter 230 mm Jig grinding machine | HAUSER - S35-400 The machine is in a well-maintained condition. Itjdjwmwwyjpfx Ad Djp Please note that the technical details were added from comparable machines. The machine video from the production plant will be shared on request. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: S35400 | S35 400 | S35CNC400 | S35 | S-35 | S 35

Condition: excellent (used), Year of construction: 1991, functionality: fully functional, travel distance X-axis: 500 mm, travel distance Y-axis: 350 mm, travel distance Z-axis: 120 mm, travel distance W-axis: 450 mm, The machine was recently partially overhauled at a cost of €15,000! The machine features six high-quality grinding motors, a spur motor, and turbines. TECHNICAL DETAILS Distance between column and spindle: 365 mm Clearance between table and spindle: 485 mm Main spindle diameter: 100 mm Travel paths X-axis: 500 mm Y-axis: 350 mm Z-axis: 120 mm W-axis: 450 mm U-axis: 5.5 mm Taper grinding: max. 16° Table Table size: 600 x 380 mm T-slots: 6, 10 mm wide, 50 mm spacing Table load: 300 kg Tool holder and speeds 22S: E23 Speed 22S: 4,500 - 22,500 rpm 45S/45ST: E19 Speed 45S/45ST: 9,000 - 45,000 rpm 80S: F6 80S speed: 40,000 - 80,000 rpm T10/T16: Ø 3 mm T10/T16 speed: 100,000 / 160,000 rpm Groove grinder: 2,900 - 34,500 rpm Planetary motion: 5 - 250 rpm C-axis: 0 - 5 rpm Feed rates X/Y feed: 0 - 1,200 mm/min W-axis feed: 900 mm/min Isdpfx Asv Rck Ujd Detp Z-axis feed: 0.5 - 12,000 mm/min MACHINE DETAILS Digital measurement accuracy: 0.001 mm Basic deviation: 0.003 mm Power: 7.5 kW Compressed air requirement: 20 m³ Mains pressure: 5 bar Space requirement: 3.5 x 4.4 m Machine height: 3.5 m Power consumption: 8.3 kVA Weight: 3.1 t EQUIPMENT - Groove grinder - Rotary table, 300 mm diameter - Swivel table, 200 mm diameter - Coolant system - Extraction system - High-quality accessories included

Condition: reconditioned (used), Year of construction: 1998, operating hours: 44,675 h, functionality: fully functional, travel distance X-axis: 650 mm, travel distance Y-axis: 450 mm, travel distance Z-axis: 140 mm, spindle speed (max.): 60,000 rpm, spindle speed (min.): 9,000 rpm, workpiece weight (max.): 800 kg, table width: 860 mm, table load: 1,500 kg, travel distance W-axis: 635 mm, Equipment: documentation/manual, Fully overhauled and in perfect condition as per original specifications and accuracy. 6 Axis X-Y-Z-C-U 7th axis CNC-rotary table with tailstock in option Control: Fanuc 15 MB Grinding Spindle 60S speed 9,000 to 60,000 rpm Isdpjwb Db Ujfx Ad Djtp Hi-Cut system with full enclosure CBN Form rotary dressing with Fischer spindle and Dr. Kaiser diamond wheel This machine is under power and can be seen in our facility in Gals, Switzerland Garantee of 6 months Shipment, installation and training can be provided
