HEDELIUS T8 - 2300

HEDELIUS T8 - 2300

This 5-axis HEDELIUS T8 - 2300 was manufactured in 2006, featuring a robust vertical machining center design. It boasts a large travel range of 2300/800/850 mm and a high spindle speed up to 12,000 rpm. The machine includes a B-axis NC swivel head, a 40-position tool magazine, and supports a maximum workpiece weight of 2500 kg. Consider the opportunity to buy this HEDELIUS T8 - 2300 vertical machining center. Contact us for more information.

• NC swivel head B-axis: +92° / -92°
• Max pendulum operation: 2 × 850 mm
• Rapid traverse: 60 m/min
• Feed force: X/Y 5000 N, Z 9000 N
• Spindle:
• Max torque: 158 Nm
• Front spindle bearing diameter: 70 mm
• Tool clamping (pull-in force): 12 kN
• Tool magazine/changing:
• Tool positions (standard): 40
• Tool positions (Magnum): 80
• Max tool diameter: 125 mm (180 mm with adjacent positions empty)
• Max tool length: 330 mm
• Tool change time (approx.): 3.5 s
• Chip-to-chip time: vertical 6.0 s / horizontal 6.5 s
• Table/capacity:
• Fixed table (L×W): 2000 × 920 mm
• T-slots: 6 × 18 H12
• Rotary table: 1 × 18 H8
• Max. workpiece weight: 2500 kg
• Machining capacities:
• Drilling in St 52 with carbide: 40 mm
• Tapping: M24
• Milling in St 52: 500 cm³/min
• Distances (reference):
• Z travel vertical (L2): 850 mm
• Spindle nose to swivel axis (L3): 300 mm
• Spindle nose to table surface (L4): 40 mm
• Z travel horizontal (L5): 1000 mm
• Spindle axis to table surface (L6): 210 mm
• Y travel (L7): 800 mm
• Table center to travel start/end (L8/L9): 400 / 400 mm
• Power/weights:
• Total connected load: 25 kVA
• Machine weight (standard): approx. 17,000–17,500 kg
Hfjdpfxox E Ebwo Ahueb
• Hours:
• Operating hours: 21,100 h
• Spindle hours: 7,647 h

Additional equipment

• Chip conveyor
• Internal coolant through spindle, 40 bar
• Paper belt filter
• Oil and emulsion mist separator
• Rotating viewing windows (2)
• Cleaning guns (2)
• Renishaw touch probe

Technical Specification
Taper Size SK 40
