Wide belt sander

Heesemann FGA8

Condition: like new (used), Working width 1350 mm The machine is in excellent, new condition as shown in the pictures. Dodpeuuitgefx Akqokp

Condition: used, Year of construction: 2008, machine/vehicle number: 0-411-49-1873, Technical data: - Manufacturer: Bütfering - Type: Optimat SGO 211/RC - Number of grinding units: 2 - Year of manufacture: 2008 - Working width: 1.100 mm - Grinding belt width: 1.120 mm - Grinding belt length: 1.900 mm - Workpiece thickness: 3-160 mm - Feed speed: 2,5-13 m/min. - Table height adjustment Standard equipment: - Automatic workpiece thickness adjustment - Stepless feed speed via requency converter. - 125 grinding programs can be stored - Wear-free braking system 1. Grinding unit (R) - Calibration roller - Profiled steel contact roller - Diameter 160 mm - Drive motor: 15 kW 2nd grinding unit (C) - Combination unit with roller and grinding shoe - Rubberized contact roller 65 Shore - Contact roller diameter 160 mm - Electronic link pressure bar with segment width 35 mm. - Belt speed: 12 and 21 m/s - Tolerance compensation up to 1 mm - Suitable for veneered surfaces and solid wood. - Drive motor: 11 kW - Total connected load: approx. 28 kW - Operating voltage: 400 V / 50 Hz. - Compressed air consumption at 6 bar, 20 L/min. - Belt blow-off device per pressure surge 440 L/min. - Extraction volume: approx. 2,880 m3/h/ at 20 m/s - Extraction connection: Dedusting: 1 x Ø 160 mm (grinding unit, roller) 1 x Ø 160 mm (grinding unit, shoe) Dimensions: Dedpfsyh Hwusx Akqekp - Length: 1,700 mm - Width: 1,850 mm - Height: 2,100 mm - Location: not in stock - Available from April 2026

Condition: excellent (used), Year of construction: 2008, Working width: 1100 mm Workpiece thickness: 3 – 160 mm Abrasive belt dimensions: 1,120 x 1,900 mm Variable feed speed: 2.6 - 13 m/min Feed motor output: 1.10 kW, 400 V, 50 Hz Extraction port diameter: 2 x 160 mm Compressed air supply: 6 bar Dimensions (L x W x H): 1705 x 1545 x 1905 mm 1st unit: Steel contact roller, diameter 160 mm Motor output: 15 kW, 400 V, 50 Hz 2nd unit: Combination unit with rubber-coated contact roller (Sh 65), rigid sanding shoe Motor output: 11 kW, 400 V, 50 Hz Abrasive belt cleaning via compressed air Dksdpfx Akoychqzeqjp 3rd unit: Cleaning brush Multi-function display Multi-function lever (conveyor belt, workpiece thickness adjustment) Electronic belt oscillation Pneumatic conveyor carpet oscillation Motorized workpiece thickness adjustment with LED display in 0.1 mm increments Units with emergency braking system Emergency stop button at infeed & outfeed Motor protection switch Roller table extension at infeed with 2 loose rollers Automatic star/delta start Complete documentation Note for used machines: • Specifications and prior sale subject to change. • Stated prices are ex works – loaded free of charge! • The machine has been cleaned and functionally tested. • All machines are sold as seen, without any warranty or guarantee. Buyers are welcome to inspect the machine on site. • Special agreements are only possible in written form. (We only respond to inquiries providing your address and telephone number!)

Condition: like new (used), Year of construction: 2013, operating hours: 250 h, Wide-belt sanding machine Bütfering Type: SWT 315/C Optimat Year of manufacture: 2013 Working width: 1350 mm Feed rate: 2.5 – 13 m/min, adjustable via frequency converter 1 combination unit with steel contact roller, with three options: - infinitely variable, frequency-controlled cutting speed 2-18 m/s, - calibration sanding with profiled contact roller - veneer and lacquer sanding - one electro-pneumatic segmented pressure bar with 25 mm segmentation - protected storage area on the machine for storing additional sanding pads - adjustable sanding belt blowing device, 5-stage adjustable, application-optimized cleaning results with low compressed air consumption Technical data: Working width: 1350 mm Sanding belt width: 1350 mm – 1380 mm Belt change side: left Workpiece thickness: 3 – 160 mm Operating voltage: 400 V / 50 Hz Drive motors: Unit: 20 kW Total connected load: approx. 23 kW Extraction nozzle: 1 x Dm 180 mm (unit) Extraction volume: approx. 1,830 m³/h BL 1 (1350 MM) BELT LENGTH 2150 MM Sanding belt length: 2150 mm UPGRADE TO MPS 1 Design of the segmented pressure bar as an electromagnetic segmented pressure bar MPS with program-controlled, current-controlled adjustment of the sanding pressure of each individual sanding segment, with 2 buttons per actuator in a 25 mm grid Dsdpfjzb Ikxox Akqjkp VAKIX 1/2 (1350 MM) VACUUM INTEGRATED (T3) High-performance fan for connection to a prepared vacuum clamping device with a 3 kW fan, nozzle diameter: 160 mm Extraction volume: 940 m³/h FBM (1350 MM) FINISHING BRUSH Driven finishing brush on the outfeed side of the machine Nozzle diameter: 140 mm Extraction volume: 1100 m³/h ATA 2 (1350 MM) SUPPORT TABLE, FOLDABLE Support table approx. 900 mm long with an integrated roller at the outfeed (foldable) Machine weight: 2800 kg

Condition: used, Year of construction: 2000, Working width .- mm Dodjvwfl Uepfx Akqokp With 1 sanding unit consisting of:- combination unit with electronic shoe for lacquer sanding- lacquer sanding- dust brush- roller table at infeed 270 mm- program control electronic f. 50 programswith brand-new feed carpetusedmake Bütferingtype Classic 111 Cyear of construction 2000machineNo. 63608Working width 1100 mmPassage height 160 mmCE type-testedGS wood dust testedBelt dimensions 1120 mm x 1900 mmFeed speed 4 8 m/min.1 piece combi unit 3.7/7.5 15 kW , 3 belt speeds with autom. steel rollerdiameter 130 mmbelt speed approx. 4,5 9 18 m/selectronic link shoesegment pitch 50 mmfor lacquer sanding workpiece controlledstorage location 97447 Gerolzhofen, free loaded, unpackeddelivery as seen,without guarantee and warranty

Condition: used, Year of construction: 2002, Grinding width: 1350 mm Grinding belt width: 1370 mm Grinding belt length: 1900 mm Workpiece thickness: 3 - 150 mm Feed speed: 2.5 - 13 m/min (infinitely adjustable) Drives: Grinding unit: 15 kW Total connected load: 17 kW Weight: approx. 2400 kg Dimensions: 2000 x 1850 x 2100 mm Storage location: Nattheim Dkodpfx Aoytrfkjkqsp

Condition: used, Year of construction: 1984, functionality: fully functional, machine/vehicle number: 8315, grinding width: 1,100 mm, grinding height: 150 mm, power: 15 kW (20.39 HP), grinding belt length: 2,500 mm, workpiece height (max.): 150 mm, Working width 1100 mm 1. Contact roller drive 15 kW 2. Sanding pad drive 11 kW 3. Brush roller for cleaning the workpiece Belt length 2500 mm – prevents heating of the glue joint and avoids it becoming "smudgy" Workpiece thickness max. 150 mm – min. 4 mm Continuously variable feed Digital table height display Year of manufacture: 1984 Can be tested under power – fully connected Robust, heavy-duty design for solid wood panels (also suitable for heavy stock removal) Dksdsw Hplcopfx Akqep Existing extraction pipes can be included in the auction Connection cable, length 25 m, is also included Suitable sanding belts available, grits 80 + 120 Complete documentation available Can be loaded with a forklift – transport securing and shipping are the responsibility of the buyer
