Universal machining center

HERMLE C 600 U

Condition: good (used), Year of construction: 2004, functionality: fully functional, travel distance X-axis: 650 mm, travel distance Y-axis: 450 mm, travel distance Z-axis: 450 mm, The machine is in good technical condition and can be tested by prior arrangement. The current condition corresponds to its age, and we currently have no issues with the machine. On 16.03.2022, the tool magazine door was replaced. On 28.08.2023, the SIMODRIVE 611/18A servo converter was replaced. SK 40. Spindle hours: 18,396, machine hours: 56,040. Number of axes: 3. Machine video available upon request. Heidenhain 530. Kdjdoxyip Sepfx Acusw

Condition: reconditioned (used), Year of construction: 2004, CNC Vertical Machining Center HERMLE C 600 U Equipped with Siemens Sinumerik 840 D CNC control system Year of manufacture: 2004 Travel paths: X 600 mm, Y 450 mm, Z 450 mm Spindle speed range: 0 – 16,000 rpm, stepless (HSK 63) Including the following accessories: NC swivel rotary table Ø 320 mm Vertical tool changer with 30 magazine slots (HSK 63) 3D touch probe Renishaw BLUM tool breakage / measurement A 2 Electronic thermal compensation Electronic hand control module Manual cabin door, manual cabin roof Coolant flush gun Oil mist extraction High-pressure internal coolant supply (IKZ) 40 bar Chip conveyor Chip trolley Kdodpoxvzv Asfx Acuew Purge air for linear scales 3 height-adjustable machine feet Operating manuals

Condition: excellent (used), Year of construction: 2000, TECHNICAL DETAILS CNC Control: HEIDENHAIN TNC430 X-axis travel mm: 600 Y-axis travel mm: 450 Z-axis travel mm: 450 A-axis travel mm: +/- 110 C-axis degrees: +/- 360 Number of pallets: 1 Table dimensions mm: - Max. table load kg: - Feed rate mm/min X, Y, Z: 20,000 Max. rapid traverse m/min X, Y, Z: 35,000 Spindle speed rpm: 50 - 10,000 Spindle power kW: - Taper type: ISO-SK40 Torque Nm: - Tool changer type: Chain Tool changer positions: 30 Max. tool diameter mm: - Max. tool diameter with adjacent pockets empty: - Max. tool length mm: - Kjdpfexak A Hox Acusdw Max. tool weight kg: - Coolant tank capacity l.: - Through-spindle coolant bar.: - EQUIPMENT: Zero-point clamping system: EROWA MTS / EROWA MTS RENISHAW OMP60 probe MACHINE DIMENSIONS Length mm: 2,130 Width mm: 2,300 Height mm: 2,750 Weight kg: 6,500

Condition: ready for operation (used), Year of construction: 2001, Control Unit Brand HEIDENHAIN Model TNC 430 Main Drive Spindle speed range 15000 Number of axis 5 Kdjdpoxvfimefx Acuow Movement X-Axis Feed Force 30000 m/min Y-Axis Feed Force 30000 m/min Z-Axis Feed Force 30000 m/min Media Chip conveyor Yes Additional Equipment Oil mist extraction Electronic handwheel Chip flushing gun Machine bed flushing NC swivel table Blow-off device Closed roof 200-liter coolant tank Includes 24 pallets and MTS-Chuck S-P/A clamping device. This 5-axis HERMLE C 600-U + EROWA Robot easy automation was manufactured in 2001. It features a 24-position magazine, extended X-axis of 2010 mm, C-axis rotary table, spindle speed up to 15,000 rpm, and a 30 tool capacity. Includes a chip conveyor and a 200-liter coolant tank. If you are looking to get high-quality automation capabilities consider the HERMLE C 600-U machine we have for sale. Contact us for more information about this machine. Application Types Milling

Condition: used, Hermle C 600 U 5-axis CNC universal machining center Milling machine Spindle on : 28383 h Control on: 64298 h X-axis: 600mm Y-axis: 450mm Z-axis: 450mm Spindle holder: HSK A 63 Feed range: 1-30000mm/min Speed: 35m/min Kdjdpfouqap Rsx Acuew rotational speed: Ø turntable: 280mm Rotation range: A-axis: +20 / - 90° Rotation range C-axis: 360 Control: Heidenhain iTNC 530 Year of manufacture: 2002 Weight: approx. 6500 kg You are welcome to come by for a viewing. We will be happy to arrange a cost-effective forwarding agent for you. organize! You will receive a proper invoice. A net invoice can also be issued for foreign customers. Prerequisite is a valid VAT number. Subject to prior sale. Visit our store and have a look at our other offers. Company names and trademarks are the property of their owners and are used only to identify and describe the products. Deviations from technical data and errors in the description of the article may occur and are reserved.

Condition: excellent (used), Year of construction: 2001, x-travel 600 mm y-travel 450 mm Kdsdpjvwgm Tjfx Acujw z-travel 450 mm spindle turning speed range 16000 U/min control HEIDENHAIN TNC 430 Number of axles 5 simultan table rotating 360 ° taper ISO SK-40 table diameter 280 mm rapid traverse 30wer m/min tool change unit 30 -fach weight of the machine ca. 6,5 t dimensions of the machine ca. 3100 x 2400 x 2500 m his HERMLE C600U is in very good condition and available immediately. Hours on: - Machine ON: 65'656h - Spindle ON: 28'281h Equipment & Description: - Coolant outside with 6bar 3 nozzles - Manual canopy - Electr. heat compensation - Electr. handwheel iTNC - Measuring probe HEIDENHAIN - Blum tool breakage control - Documentation / Operating instructions - NEW air filter system CABARON type: COB-H10-2 (year of construction 2012 never in use) Option: - Div. tool holders ISO SK-40, 109 pcs.

Condition: refurbished (used), Year of construction: 2004, operating hours: 42,000 h, functionality: fully functional, machine/vehicle number: 16429, rapid traverse X-axis: 35 m/min, rapid traverse Y-axis: 35 m/min, rapid traverse Z-axis: 35 m/min, feed length X-axis: 600 mm, feed length Y-axis: 450 mm, feed length Z-axis: 480 mm, controller model: Heidenhain iTNC530, spindle speed (max.): 16,000 rpm, spindle nose: SK40, number of slots in tool magazine: 30, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, 5-axis Hermle C600U with Heidenhain iTNC530 controller The machine is very well maintained, ready to work immediately. Y-axis bed guide replaced. Geometry adjusted. Available for immediate delivery. Year of construction 2004 X-travel 600 mm Y-travel 450 mm Z-travel 480 mm Heidenhain iTNC 530 Spindle: SK40 Kdedpewtc Tysfx Acuow Speed range 16000 rpm Feed range 1-30000 mm/min Rapid traverse 35 m/min Number of tool positions 30 Diameter of rotary table 280 mm Swivel range A-axis +20 / -90° Swivel range C-axis 360° Total connected load 30 kW Weight 6500 kg With the following accessories: Table probe for tool measurement Electronic handwheel Electronic temperature compensation IKZ 40 bar Swarf conveyor Enclosed cabin roof section Coolant unit Cabinet cooling unit ( RITTAL ) 3 pcs. Height adjustable machine feet 2-circuit factory built-in hydraulics. Can be controlled with M code! Instructions for use Ballbar protocol included

Condition: used, Year of construction: 2000, travel -x axis 600 mm travel -y axis 450 mm travel -z axis 450 mm control HEIDENHAIN - TNC 430 turning speeds 10.000 U/min numbers of positions in the tool changer 30 tool taper SK 40 5-axis simultaneous machining center | HERMLE - C 600 U equipped with a 30-tool changer, a swivel axis, and an NC combination table (600 x 370mm / ø 280mm). The machine has approx. 17.754 H spindle hours. Additional equipment: - Swivel axis - NC combination table (600 x 370mm / ø 280mm) - Probe system (SK 40 - RENISHAW) - Tool breakage monitoring Kdsdpfx Aev T Nr Rocuow The machine is in well-maintained condition, has been used exclusively for educational and training purposes, and can be inspected under power at any time. For further technical details, please refer to the offer. - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - #Tags: C 600 | C600 | C-600 | C600U

Condition: excellent (used), Year of construction: 1998, Heidenhain TNC 426 control Travel X/Y/Z: 600/450/450 mm Spindle speed 10,000 rpm Tool magazine for 30 tools, SK 40 Kjdpfxjwhrfzs Acusdw

Condition: ready for operation (used), Year of construction: 2002, operating hours: 28,384 h, functionality: fully functional, machine/vehicle number: 15594, travel distance X-axis: 600 mm, travel distance Y-axis: 450 mm, travel distance Z-axis: 450 mm, swivel angle A-axis (min.): -90 °, swivel angle A-axis (max.): 20 °, TECHNICAL DETAILS Control: Heidenhain iTNC 530 X-axis: 600 mm Y-axis: 450 mm Z-axis: 450 mm A-axis rotation range: +20° / -90° C-axis rotation range: 360° Rotary table diameter: 280 mm Spindle data Kdjdpfx Acevytgfouew Spindle mount: HSK A 63 Tool changer: 30 positions Feeds and speed Feed range: 1 - 30,000 mm/min Rapid traverse speed: 35 m/min MACHINE DETAILS Machine weight: approx. 6,500 kg Control switch-on time: 64,299 h Machine switch-on time: 61,676 h Program run: 29,320 h Spindle hours: 28,384 h Drive hours: 37,893 hours
