Spindle moulders Hofmann TFS 1200 2001

Hofmann TFS 1200

Condition: ready for operation (used), Year of construction: 1991, Hofmann TFS 1200 tilting table milling machine Year of manufacture: 1991 Machine no.: P127-91-194-695 Motor: 54.7 / 5.7 - 11 / 13.5 Tilting range: -5° to +45° Njdpfjzmcz Iex Agrjdb Motor brake Motor: 2 speeds / pole-reversing 6 speed stages: 3 / 4 / 5 / 6 / 8 / 10,000 rpm Right-hand and left-hand rotation Table size: 2000 x 830 mm Milling arbor diameter: 30 mm Milling fence with fine adjustment Height adjustment: manual, with handwheel Tilting adjustment: manual, with handwheel Lateral sliding table for slot and tenon machining Feed device: 3-roller Elu, infinitely adjustable Dust extraction connection: D 2 x 120 mm Space requirement: approx. 2000 x 1600 x 1400 mm Weight: approx. 1000 kg

Condition: used, Year of construction: 2005, power: 7.5 kW (10.20 HP), cutting height (max.): 170 mm, cutting width (max.): 1,100 mm, saw blade diameter: 500 mm, tilt adjustment saw blade: 46 °, height adjustment type: hydraulic, saw blade bore: 30 mm, rotational speed (max.): 5,500 rpm, rotational speed (min.): 2,800 rpm, total length: 3,300 mm, total width: 2,000 mm, total height: 1,800 mm, overall weight: 1,500 kg, Equipment: CE marking, No. 04528 Sliding table saw Martin T 73 BASIC Used, year of construction 2005 Ndodjyymtdspfx Agreb Sliding table 3000 mm Maximum cutting height 170 mm Maximum saw blade diameter 500 mm Saw blade bore 30 mm Cutting width 1100 mm Motor 7.5 kW Speeds 2800 / 4000 / 5500 rpm Hydraulic saw blade tilt 0° - 46° Hydraulic cutting height adjustment Circular saw ruler can be lowered Pneumatic saw shaft lock Cross table with fixed angle adjustment Length stop extendable up to 3300 mm Sliding table with stepless locking Integrated contact for controlling the dust extraction system Central lubrication point Transport dimensions approx. 3300 x 2000 x 1800 mm LWH Weight approx. 1500 kg To avoid possible misunderstandings, an on-site inspection is possible and recommended by appointment Sold as is Technical specifications, condition description, year of construction and scope of delivery according to manufacturer's brochure or previous owner, without guarantee Subject to prior sale For used machines, any warranty is excluded, the following applies: “sold as seen” Terms of payment: Prices plus VAT, payment before collection or shipping Terms of delivery: ex warehouse

Condition: used, Year of construction: 1992, Machine cleaned, function tested, partially overhauled. Spindle runout extremely precise, maximum 1/100 mm. Pneumatic hoses, filter pressure regulator, and mist lubricator replaced. Test run carried out. Used machine, excellent condition, premium features with plunge spindle. With this milling machine, both entry and exit milling operations can be performed. This means the milling spindle can be pneumatically controlled to plunge in and out via a table operated by adjustable limit switches. Manufacturer: Hofmann Model: TFS 1200 Year of manufacture: 1992 Machine no.: P127-92-222-723 Nedpfxey Ay Dzo Agrsdb Motor: 5.0 / 6.2 kW (reinforced) Swivelling range: -5° to +45° Motor brake Motor: 2 speeds, pole-changeable 6 speed levels: 3 / 4 / 5 / 6 / 8 / 10,000 rpm Forward/reverse rotation Table size: 2,000 x 830 mm Milling arbor diameter: 30 mm Milling fence with fine adjustment Digital displays for milling fence, diameter, and cutting depth Electric height adjustment Electric swivel adjustment Digital displays for swivel angle and spindle height Extraction connection: 2 x 120 mm diameter Required space: approx. 2,000 x 1,600 x 1,400 mm Weight: approx. 1,000 kg Location: 97447 Gerolzhofen, loaded free on truck, unpacked Delivery in as-inspected condition, function tested without overhaul, without warranty or guarantee

Condition: ready for operation (used), Year of construction: 2001, machine/vehicle number: 127-01204, functionality: fully functional, power: 7.8 kW (10.61 HP), spindle diameter: 40 mm, pivoting range: 45 °, table width: 450 mm, table length: 2,680 mm, TECHNICAL DETAILS Table length: 2,680 mm Table width: 450 mm Tilting spindle: Automatic Maximum spindle tilt: 45° Spindle diameter: 40 mm Minimum spindle speed: 3,000 rpm Ndsdey Tniyopfx Agrjb Spindle speed control: Stepped MACHINE DETAILS Main motor power: 7.8 kW Connection voltage: 400 V Connection current: 16 A Dimensions & Weight Transport dimensions (L x W x H): 2,680 x 1,200 x 2,200 mm Transport weight: 950 kg Feeding device Manufacturer: Masterwood Model: Euromeo Number of wheels: 4 Number of speeds: 2 Guide manufacturer: Aigner

Condition: excellent (used), Steton PF 530 E. Nsdoipx Uqepfx Agrjdb Electric adjustment of the planing height -working width 53 cm -Ters knife shaft - length of the tops 275 cm -motor power 4kW / 380V -resistance set at an angle -electric brake The machine is in very good condition, runs quietly.

Condition: used, Year of construction: 2001, saw blade diameter min. 200 / max. 500 mm Njdszczf Ejpfx Agrodb Speed 2800 / 4000 / 5500 U/min.

Year of construction: 2003, condition: reconditioned (used), longitudinal saw for cutting boards 4 meters main engine 400V, 7.5kW - blade feed motor 400V, 2.2 kW - extending the pneumatic saw - working pressure 6bar - cutting length 4020 mm - cutting height approx. 170mm - machine length 5.5 m - machine width 1.6 m Nsdpfxohbp T Ss Agrjdb

Condition: used, Year of construction: 2022, Slider length: 3300 mm Cutting width at the rip fence: 1100 mm Cutting width at the crosscut fence: 3200 mm Cutting depth: 200 mm Scoring saw: yes Nodpfx Aez Ekp Usgrodb Saw blade height adjustment: electric / position control Saw blade swivel adjustment: electric / position control Rip fence adjustment: electric / position control Saw blade angle display: digital display Cutting height display: digital display Rip fence display: digital display Crosscut fence display: digital Miter cutting system: RadioCompens miter cutting system Saw blade diameter: 550 mm Speeds: 4000 / 4800 / 6000 rpm Motor power: 5.5 kW Operating hours: 98 Dust extraction connection: 80 and 120 mm Machine length: 3500 mm Machine width: 2200 mm Weight: 1200 kg

Condition: used, Year of construction: 2022, Used machine Year of manufacture: 2022 Equipment and technical data: - Professional sliding table saw in heavy-duty design - with scoring unit; externally adjustable with separate drive motor - format sliding carriage made of anodised aluminium with a proven and permanently smooth-running ball contact system on hardened guideways (10-year manufacturer's warranty from date of first commissioning) - saw rip fence with round-bar guide; foldable for large panels, with quick clamping and integrated fine adjustment - table extension - table widening - with integrated on/off switch on the sliding carriage - with motorised height and tilt adjustment of the saw unit, digital display for tilt - programmed control of the saw blade height and tilt and the position of the rip fence - swivelling control panel at eye level - Made in Italy quality - Trimming length: 3200 mm - Cutting height 90°/45° with scorer max.: 136.5/97 mm - Cutting-to-length width to the left of the saw blade max.: 3260 mm - Cutting width with rip fence: 1270 mm - Tilt of the saw blade: 90 - 45° - Saw blade diameter with scorer max.: 400 mm - Scoring saw blade: 120 mm - Speed main saw blade: 3500/5000 rpm - Speed scoring saw blade: 9200 rpm - Dimensions format sliding carriage: 360 x 142 x 3200 mm - Extraction ports: 120 + 80 mm - Motor power: 7.0 kW, 400 V - Motor power scorer: 0.55 kW Dimensions: approx. 3200 x 950 mm Weight: approx. 745 kg Ndsdszlbq Sjpfx Agrob Availability: at short notice Storage location: Röllbach

Condition: used, Year of construction: 1999, Second-hand machine Year of manufacture: 1999 Features and technical specifications: - with electric height and swivel adjustment for the Main saw blade, dimensions entered via keyboard - digital display of the swivel angle and cutting height - CE-compliant version - Cutting length 3000 mm - with centre and end-position locking - Cutting width 1000 mm - with digital display and fine adjustment - Cutting height up to 175 mm with a saw blade diameter of 500 mm (the scoring unit must be removed for this) - 5.5 kW motor with 4 speed settings: 3/45/6000 rpm, manually adjustable - with automatic brake and digital speed display - 2-axis scoring unit with electric height and lateral adjustment Availability: at short notice Ndjdezk N Ngepfx Agreb Storage location: 63934 Röllbach
