Throughfeed machining center

Homag Drillteq V-200

Condition: excellent (used), Year of construction: 2023, I sell the throughfeed CNC drilling machine HOMAG Weeke Drillteq V-200 (BHX 055), Year 2023. Configuration: 1pc. milling head with tool change 4 positions HSK63 13 + 4 + 2 pcs. drilling units Pgsdpfxsy Hfp Rs Ag Dok 1pc. grooving saw Backfeeding system to return the elements to the operator or move forwards as a throughfeed machine. With full documentation and CE. Very good condition. Available immediately.

Year of construction: 2022, condition: new, Angle: 0° - 90° Pgsdoi Ezr Nspfx Ag Dek Maximum cutting length: 1370 mm

Condition: used, Year of construction: 2021, input frequency: 50 Hz, input current: 21 A, We offer this used HOMAG DRILLTEQ V-200 through-feed drilling machine, year of manufacture 2021. The machine has been regularly serviced by HOMAG. The package includes a KOGI 2.2 kW/1650 Pa two-bag extraction unit and various tools. Type: DRILLTEQ V-200 OPTIMAT BHX050 Serial number: 0-250-73-6562 Year of manufacture: 2021 Power supply: 400Y/230 V Number of phases: 3 Podoy Extmspfx Ag Dsgk Frequency: 50 Hz Rated current at full load: 21 A Fuse: 25 A Control voltage: 24 V If you have any questions or need further information, please send us a message or contact us by phone.

Condition: excellent (used), Year of construction: 2019, functionality: fully functional, operating hours: 5,383 h, The HOMAG DRILLTEQ V-200 is a compact and highly efficient CNC vertical machining center designed for precise drilling, grooving and routing operations in furniture and cabinet production. Thanks to vertical processing, the machine requires minimal floor space while offering high flexibility and productivity. It is ideal for batch size 1 production as well as serial manufacturing. Pgjdpfx Agoym Ny Sj Dok The machine is in very good technical condition and can be inspected under power.

Condition: used, machine/vehicle number: 006622, Max. panel width: 2100 mm Max. panel length: 2850 mm Psdju T Tt Tspfx Ag Degk Max. panel stack height from the ground: 2100 mm Lifting capacity: 250 Kg Movement system: suction cups.

Condition: new, Year of construction: 2022, functionality: fully functional, machine/vehicle number: 0-250-87-6869, Drilling head with 8 spindles (V8 SW/32) Horizontal drilling head with 4 spindles on X Horizontal drilling head with 2 spindles on Y Grooving saw D=100 mm Stopping cylinder for workpiece positioning Workpiece clamping system Pgodpfx Aevtyc Hsg Djk Workpiece length 2500 mm Workpiece thickness 12-60 mm WOODWOP for machine WOODWOP IMPORT DXF BASIC (1 license)

Condition: good (used), Code: 0190 Brand: MASTERWOOD Model: PROJECT TF 100 - CE Standard CNC point to point throughfeed boring machine for panels, furniture, custom-made furniture, kitchens, bathroom furniture, carpentries and various - CE Standard Features: Robust clamping device for panel translation running on linear guides with preloaded ball bearings and moving by means of ball screw with high precision and stiffness. Brushless motor Working table: table with idle rubber wheels for panels in and outfeed . Panel movement on air film to avoid any scratching of panels with delicate surfaces . Panel pusher for smooth and accurate movement. Longitudinal sinking reference stop. Automatic reading of panel length Operating unit: boring head with vertical and horizontal spindles plus grooving saw unit. Centralised chips suction outlet Numeric control with PC: Windows operating system - network connection MASTERWORK software: Masterwood system for automatic drawing and programming - Boring, cutting programming with boring cycle optimisation Technical data: X-Y-Z axis strokes mm 1670-1330-87 Max displacement speed of X-Y-Z axis mt/min 25-50-25 Working range: width min/max mm 80/1000 - Length min mm 250 - Lenght max unlimited - Thickness min/max mm 10/60 Drilling head: n° 5 X axis independent vertical spindles - n° 5 Y axis independent vertical spindles - n° 2 X axis double horizontal spindles - n° 1 Y axis double horizontal spindle Spindles pitch 32 mm Motor power 1,7 Kw Psdpfew Emgbjx Ag Dogk Spindles revolution speed 4000 rpm Sawing unit - Motore Kw 1,7 - Blade diameter mm 125 - 4000 rpm Working air pressure 7/8 bar Overall dimensions mm 2400 x 1990 x 1600 h Weight kg 1300

Condition: used, Year of construction: 2000, Number of spindles in row: 11 Number of horizontal spindles: 3 Pedpfsxc Hi Uox Ag Djgk Cup hinge boring head: yes, Blum Drill pitch: 32mm Power consumption: 2.2kW Drilling unit: swiveling

Condition: used, machine/vehicle number: 008321, X axis working area: 4200 mm Y axis working area: 1350 mm Working Table: Pod and Rail Main Electrospindle power: 12 KW Number of controlled axes: 4 axes Pgjdpfx Asx A Tdljg Djk Maximum edge height: 60 mm Total number of drilling spindles: 18 Total number of tool changer positions: 22

Condition: excellent (used), LINE (half line) of Double-side Sizing-Milling & Edge Banding, with max working width mm 2500, with automatic fast handling system. Composed of the following machines: O02006A) PANEL INFEED roller table "HOMAG" PROFI TBL100/30/12 O02006B) TURNING DEVICE FOR PANELS (LENGTHWISE TO CROSSWISE) "HOMAG" PROFI TDL /310 /25 /12 O02006C) Double-side SIZING and EDGE BANDING machine Pgsdpfev D U Urox Ag Dok "HOMAG" Mod. PROFI KFL 526/10/A3/25 O02006D) TURNING DEVICE FOR PANELS (CROSSWISE TO LENGTHWISE) "HOMAG" PROFI TDL 510/25/12
