SINGLE SIDE EDGE BANDER (Left)
HOMAG EdgeTeq S-500 (Profi KAL 370 / 10 / A20)

Name: HOMAG EdgeTeq S-500 (Profi KAL 370 / 10 / A20)
Brand: HOMAG
Availability: InStock

Condition

Used

Location

Roreto

SINGLE SIDE EDGE BANDER (Left) HOMAG EdgeTeq S-500 (Profi KAL 370 / 10 / A20)

HOMAG EdgeTeq S-500 (Profi KAL 370 / 10 / A20)

Machine data

Machine type:: SINGLE SIDE EDGE BANDER (Left)

Manufacturer:: HOMAG

Model:: EdgeTeq S-500 (Profi KAL 370 / 10 / A20)

Condition:: excellent (used)

Price & Location

Location:: Via Savigliano, 12062 Roreto CN, Italia

Call

Details about the offer

Listing ID:: A222-99532

Reference number:: 207026

Update:: 09.07.2026

Description

SINGLE SIDE EDGE BANDER (Left)
Fodpfezku Rpjx Aptjgd
Edges (band in rolls) thickness (Min/Max) mm 0,3 / 3
Edges thickness in strips / lippings (min/max) mm 0,4 / 20
Panels thickness (min/max) mm 8 / 60
Numerical Control POWER CONTROL PC23 Powertouch / WoodCommander (TAPIO Ready)
Feeding speed m/min 16-25
Top pressure system with rubber belt

Spraying unit (Anti-sticking liquid)
In-feed fence, adjustable by N.C.
Pre-milling Unit (vertical joint trimmers) 2 x Kw 3
Lamps to heat the workpieces side
Glueing Unit (Hot Melt + Quick Melt Unit) FE-MA-TECH + QA/PU + PU65
Band Pressure zone (N.C. adjustment) "C 7"
Edge coils supporting unit (No. 2 reels) with SERVO-control edge feeding

Snipping (end-cutting) unit PK 25 (2 x Kw 0,8) max 25 m/min
Rough Trimming unit BF20 (2 x Kw 1,5)
Fine Trimming unit (Multiprofile) MF21 (2 x Kw 0,55) swevelling 0°-20°
Multi Function Unit (Profile contour Trimming unit) FK 30/V20 (1 x Kw 0,7) adjustable by NC
Milling-grooving units SF 21 (1 x Kw 5) 0°-90°
Profile edge scraping unit MN 21 (Multiprofile, by N.C.)
Glue scraping Unit FA 20
Buffing unit FA06 (2 x kW 0,18) + Free Space
