Aggregate

HOMAG

Condition: ready for operation (used), Year of construction: 2008, machine/vehicle number: 0-205-11-7632, functionality: fully functional, working width: 1,600 mm, milling spindle speed (max.): 30,000 rpm, working height: 535 mm, working length: 5,800 mm, TECHNICAL DETAILS Working area X-axis: 5,800 mm Working area Y-axis: 1,600 mm Working area Z-axis: 535 mm Number of milling spindles: 2 pcs. Milling spindle 1 Controlled axes: 4 pcs. Max. spindle speed: 30,000 rpm C-axis: Yes Milling spindle 2 Controlled axes: 4 pcs. Max. spindle speed: 30,000 rpm C-axis: Yes Table type: Beam table Table length: 2,500 mm Table width: 1,500 mm Tool clamping system: HSK-F63 Tool changer slots: 36 pcs. Material clamping system: Pneumatic MACHINE DETAILS Software: WoodWOP Dimensions & Weight Installation dimensions (L x W x H): 12,200 x 9,000 x 3,500 mm Overall length: 26,000 mm Empty weight: 9,000 kg Transport packages: 8 pcs. Vacuum system Number of vacuum pumps: 2 pcs. Vacuum pumps: Elmo Rietschle 2BL2141 Connection diameter: 50 mm Voltage: 400 V Current consumption: 91 A EQUIPMENT Infeed and outfeed system Loading system Unloading system Labeling machine Hand control Chip conveyor Vacuum pumps Tools USB stick with CNC documentation CE marking Documentation Dedpjzrmnpsfx Akhskr Safety fence Door interlock switch Safety light curtain

Condition: used, machine/vehicle number: 008698, X axis working area: 4200 mm Y axis working area: 1600 mm Working Table: Pod and Rail Main Electrospindle power: 12 KW Number of controlled axes: 4 axes Maximum edge height: 65 mm Total number of drilling spindles: 18 Total number of tool changer positions: 22 Dsdpfxjztka Es Akhskr

Condition: like new (used), 1 milling unit 8 vertical drills 6 side drills Dsdpfey Ukzzjx Akhekr 1 saw 12 kW Year of manufacture: 2011

Condition: ready for operation (used), Year of construction: 2016, functionality: fully functional, workpiece height (max.): 60 mm, roll diameter: 830 mm, The dismantling is scheduled for calendar week 35. Until then, the buyer can inspect the system while it is in operation in Lithuania. Fully automatic edge banding line with the following machines: HOMAG PROFI KAL330/9/A3/WZ (year of manufacture 2013) HOMAG PROFI KAL370/8/A3/WZ (year of manufacture 2016) HOMAG PROFI TBL100/20/30/F infeed table (year of manufacture 2013) HOMAG POWER TWL410/25/LQ transfer system cross conveyor (year of manufacture 2016) TECHNICAL DETAILS Edge banding machines HOMAG PROFI KAL330/9/A3/WZ & PROFI KAL370/8/A3/WZ Workpiece width without edge, with workpiece thickness of 12–22 mm: min. 60 mm (depending on workpiece length) Workpiece width without edge, with workpiece thickness of 23–60 mm: min. 100 mm (depending on workpiece length) Workpiece overhang: 30 mm Workpiece thickness: 12–60 mm Edge height: max. workpiece thickness + 4 mm Edge material on roll: 0.3–3 mm Edge material height PVC: max. 135 mm Edge material height veneer: max. 100 mm Roll diameter: max. 830 mm HOMAG PROFI TBL100/20/30/F infeed table Roller diameter: 54 mm Roller spacing: approx. 60 mm Panel length: 240–2,500 mm Panel width: 120–3,000 mm HOMAG POWER TWL410/25/LQ transfer system cross conveyor Roller diameter: 64 mm Roller spacing: 110 mm Panel length: 240–2,500 mm Panel width: min. 240 mm Panel thickness: 8–60 mm Panel weight: max. 80 kg EQUIPMENT Gap-free joining-cutting unit on both edge banding machines A3 basic gluing unit on both edge banding machines Gap-free processing units on both edge banding machines FA11 finishing unit on the HOMAG PROFI KAL330 FA21 finishing unit on the HOMAG PROFI KAL370 Fixed stop on the left side of the infeed table Transport rollers on the infeed table Lateral conveyor belt on the infeed table Electropneumatically controlled transverse safety device on the infeed table Manually adjustable infeed safety device Set for small parts Integrated air cushion table Fixed stop on the left side at the infeed and outfeed of the transfer system cross conveyor Infeed roller track with conveyor belt and cross conveying Controlled cross conveyor at the infeed Outfeed roller track Controlled cross conveyor at the outfeed Electropneumatically controlled stop protection device Dkedpfsztazfex Akhor Lateral transport belt Manually adjustable panel overhang

Condition: used, Year of construction: 2005, functionality: fully functional, Equipment: CE marking, HOMAG OPTIMAT BAZ211 VENTURE 20 (Router No. 5) Year of manufacture: 2005 Basic structure and drives • Machine bed: Heavy-duty, stable design with compact linear guides. • X and Y axis drives: Digital AC servo motors and rack and pinion gears with pre-tensioning for backlash-free operation. • Z axis drive: Digital AC servo motor with ball screw; travel range is 535 mm. • Lubrication: Manual central lubrication for all drives and linear guides. Main spindle and C axis • Power: 11 kW in S6 mode (7.5 kW in S1). • Cooling: Liquid-cooled, vector-controlled asynchronous motor. • Speed range: Continuously programmable from 0 to 18,000 rpm. • Tool holder: HSK F63 according to DIN 69893. • C axis: Equipped with an aggregate interface, pneumatic interface, and 3-point support. Clamping system (Cantilever table) • Cantilevers: 6 pieces with a tubeless, dual-circuit vacuum system. • Stops: 6 longitudinal stops in the cantilevers (stroke 140 mm) and 2 adjustable lateral stops. • Suction cup equipment: • 10x dual-action vacuum suction cups (160x115x100 mm), 4 with integrated lift. • 2x dual-action vacuum suction cups (125x75 mm). • Pneumatics: 4 connections with a single-circuit system for mechanical clamps. Dedpfxszr N H Ue Akhskr Workpiece dimensions • Length (X): Max. 3050 mm (individual setup) or 900 mm (shuttle mode). • Width (Y): Max. 1220 mm for milling; max. 1150 mm for all aggregates. • Thickness (Z): Max. 60 mm with standard suction cups; up to 300 mm including fixtures for top-side milling. • Minimum thickness: 12 mm for chamfering, 16 mm for radius milling. Tool changer and accessories • Type: Disc-type tool changer (12 positions) for HSK F63 tools and aggregates. • Diameter capacity: 12x max. 135 mm, or a combination of 6x 180 mm and 6x 85 mm. • Vacuum system: Liquid ring pump with a capacity of 66 m³/h (equivalent to 100 m³/h for vane pumps). Control system (Power Control PC85) • Hardware: Industrial PC (2 GHz) with 512 MB RAM, a hard drive for data and a second for backup (cloning). • Software: • woodWOP: Graphical interface for CNC programming. • woodDesign: 3D interface for furniture design. • woodScout (optional): Graphical diagnostic system. • Communication: Ethernet card and modem for remote diagnostics.

Condition: used, Year of construction: 2001, functionality: fully functional, Equipment: CE marking, HOMAG Optimat BOF 31/40/K Manufacturer: HOMAG Group (Germany) Type of machine: CNC machining center with a cantilever table Year of manufacture: 2001 Design: Stable gantry design (movement in the X-axis is provided by the gantry) Dsdpozr N E Dofx Akhekr Working ranges (X, Y, Z axes) • X-axis (length): 4,000 mm (working area for one large part or shuttle operation) • Y-axis (width): 1,200 mm (tool reach during milling) • Z-axis (stroke): 400 mm (max. workpiece passage including clamps approx. 100 mm) Working table (Version K – Cantilever) • Number of cantilevers: 8 sliding beams (cantilevers). • Clamping elements: Two-circuit vacuum system. Suction cups can be freely positioned on the cantilevers. • Positioning aids: Pneumatically controlled stops (rear and front row) for easy and precise positioning of parts. Aggregates and equipment • Main spindle: Power 11 kW, HSK F63 clamping, liquid-cooled. • Tool changer: 12-position disc tool changer, which moves together with the gantry in the X-axis. Control and Software • Control system: HOMAG PC85 (industrial PC based on Windows). • Programming: woodWOP 5.0 / 6.0 (graphical interface for creating macros and drilling patterns). • Vacuum pump: Typically Busch with a capacity of 100 m³/h (standard for cantilever machines).

Condition: used, Year of construction: 2000, functionality: fully functional, HOMAG Optimat BOF 31/40/G Manufacturer: HOMAG Group (Germany) Machine type: CNC machining center (stationary machine) Dsdpfxozr Nuro Akhjkr Year of manufacture: 2000 Design: Gantry design for maximum stability Working ranges (X, Y, Z axes) • X-axis (length): 4,000 mm • Y-axis (width): 1,200 mm • Z-axis (travel): approx. 400 mm (workpiece passage approx. 60–100 mm depending on clamping) Equipment and units • Main spindle: Liquid-cooled electrospindle (power 11 kW) • Tool clamping: HSK F63 • Tool changer: Disc tool changer with 12 positions, located on the gantry for quick tool changes. Clamping system • Table type: Full table • Vacuum pump: 2 pcs - Siemens Elmo water-type 2BL1 with a capacity of up to 60 m³/h Control and Software • Control system: HOMAG PC85 (based on Windows) • Software: woodWOP (one of the most widespread and intuitive systems for CNC machining)

Condition: ready for operation (used), Year of construction: 2016, This 4-axis HOMAG OPTIMAT BHX 200 was manufactured in 2016. It features a rigid steel frame construction and dust-protected linear guideways, ensuring durability and precision. The machine is equipped with digital servo drives and offers rapid traverse speeds of up to 50 m/min on the X/Y axes. If you are looking to get high-quality CNC processing capabilities, consider the HOMAG OPTIMAT BHX 200 machine we have for sale. Contact us for further details. • Measurements width: 50-1,250 mm • Rapid Traverse: X/Y axes: up to 50 m/min; Z-axis: up to 15 m/min • Main electronic connection: 400 V / 50 Hz Dksdezr Ndgopfx Akhor • Used Vertical CNC Machining Center • Year of manufacture: 2016 • Rigid steel frame construction • Dust-protected linear guideways • Digital servo drives on X, Y, and Z axes • X-axis driven by rack and pinion • Y- and Z-axes driven by ball screws • Maintenance-free servo motors with high-resolution encoders • Integrated dust extraction system for machining units • Additional dust extraction connections • Manual loading and unloading of workpieces • Pneumatic positioning stop • Workpiece length: 200-3,050 mm (with roller conveyor) • Workpiece thickness: 8-80 mm • Air-conditioned electrical cabinet for operation above 35°C • ECO Plus energy-saving mode with automatic standby, drive shutdown, and control system shutdown • The technical data and descriptions are copies of the order confirmation at the time • The information is for informational purposes only and is not binding

Condition: used, machine/vehicle number: 008519, Type of edging: Thin edge, Thick edge Gluing System: PUR, Laser Premilling Unit: yes Corner Rounding Unit: yes Grooving Unit: yes Max feed speed: 40 m/min Maximum panel thickness: 60 mm Dkedezruytepfx Akhor Operating Units: 12 nr

Condition: used, machine/vehicle number: 008696, X axis working area: 7400 mm Y axis working area: 2250 mm Working Table: Flat table Main Electrospindle power: 15 KW Dedpjzrux Njfx Akhekr Number of controlled axes: 5 axes Total number of tool changer positions: 30
