Document finishing system

Horizon spf

Condition: good (used), Horizon VAC-100a + VAC-100c + SPF-20A + FC-20A Booklet Maker Dedpfx Adsyrz Tbjgoup Machine setup is via the control panel. Made in Japan. The line consists of: – Horizon VAC-100A / VAC-100M Max size: 350x500mm Min size: 120x148mm Vacuum feeding 10 shelves Stack height: 55mm Basic weight: 40-270g 230V power supply Weight: 310kg/piece Touchscreen control Jam, double-feed, and no-feed sensors Ability to save 9 preset jobs to the machine’s memory Horizon SPF-20A Max size: 500x350mm Min size: 120x180mm Wire stitching Folding Two Hohner heads Horizon FC-20 Cutting thickness: 88 sheets 230V power supply Weight: 240kg Touchscreen control panel for quick format changes. With a single click, you can retool the machine for a different format. 230V power supply Weight: 490kg The machine includes: delivery, PJ-77R jogging machine, operating tools, additional components, and documentation.

Condition: used, Year of construction: 2002, Horizon VAC-100a SPF-20A FC-20A Booklet Making System, Used This Horizon booklet making system is a powerful solution for professional booklet production, combining collating, stitching, folding, and front trimming in an efficient process. It offers high productivity, versatile applications, and easy operation for efficient booklet production. Key Features: - Collator: VAC-100a with 10 stations - Versatile stitching options: Saddle, corner, and side stitching possible - Touch & Work: Intuitive operation thanks to user-friendly technology - 9 programmable memory locations for repeat jobs - Precise error control: Prevention of miss-feed, double-feed, and jam problems - Expandable configuration: Possibility to add more VAC-100 towers Technical Specifications: - Paper format: max. 350 x 500 mm; min. 148 x 120 mm - Booklet format: max. 250 x 350 mm; min. 85 x 120 mm - Paper weight: 40-300 g/m² - Processing thickness: 2-22 sheets (80 g/m²) - Trimming thickness: 4-50 sheets (80 g/m²) - Front trim: max. 25 mm - Production speed: max. 3,600 booklets/h - Collating performance: up to 9,900 sets/h - Loading capacity per station: 55 mm - Power supply: 230V; 50/60Hz - Total power consumption: approx. 2.3 kW All-Inclusive Service Package Dsdsymmfrspfx Adgjup We take care of everything: from secure packaging and transportation to customs clearance. Upon request, we can also provide a customized leasing offer. Sustainable and Economical Choose a used machine and benefit twice: Save the environment and your budget. Despite possible signs of use, you receive a quality product at an attractive price.

Condition: used, Year of construction: 2005, Horizon booklet maker SPF-20 A FC-20 A offer consists of: - stitching and folding SPF-20A - frontcutter FC-20A Horizon SPF-20A stitcher and folder: - format adjustment: fully automatic - DIN-size and standard fold types: preassigned - saveable jobs: 12 memories for special sheet sizes + all DIN sheet sizes - stitching heads: 2 - expandable up to 4 stitching heads - stapling options: top-, side-, cornerstitiching - ring eylete stitiching: with ring eyelet stitching heads possible - inlet format: max. 500x350mm; min. 180x120mm - processing strength: min. 2 pages; max. 22 pages (80g/sqm) - clip distance: min. 73mm - stitching wire: 26 - 28 Dsdpfxjxyhngo Adgsup - production speed: max. 3.600 cycles/h - power: 230V/50Hz - 0,45kW - dimensions: 2.710x810x1.070mm - weight: 490kg Horizon FC-20A fore-edge trimmer: - counter - faulty set ejection - booklet size: max. 250x20mm; min. 85mm - size front cut: max. 20mm - trimming thickness: min. 4 pages / max. 88 pages (80g/sqm) - production speed: max. 3.400 cycles/h - power: 230V/50Hz - 0,2kW - dimensions: 610x810x1.070mm - weight: 240kg We can also organize the following for you: packaging, loading, transport ( by ship or plane) including customs

Condition: refurbished (used), Year of construction: 2002, Horizon VAC 100 A+C brochure line Staple-fold station SPF 20A, trimmer FC 20A Jogger PJ 77R Dusdpfx Aeyl Aiwsdgjp

Condition: used, Year of construction: 2001, Horizon VAC-100a VAC-100m SPF-20A FC-20A Booklet Making System, Used This Horizon booklet making system is a powerful solution for professional booklet production, combining collating, stitching, folding, and front trimming in an efficient process. It offers high productivity, versatile applications, and easy operation for efficient booklet production. Key Features: - Two collating towers: VAC-100a and VAC-100m with 10 stations each - Versatile stitching options: Saddle, corner, and side stitching possible - Touch & Work: Intuitive operation thanks to user-friendly technology - 9 programmable memory locations for repeat jobs - Precise error control: Prevention of miss-feed, double-feed, and jam problems - Expandable configuration: Possibility to add more VAC-100 towers Dujdpfeyiz T Aox Adgep Technical Specifications: - Paper format: max. 350 x 500 mm; min. 148 x 120 mm - Booklet format: max. 250 x 350 mm; min. 85 x 120 mm - Paper weight: 40-300 g/m² - Processing thickness: 2-22 sheets (80 g/m²) - Trimming thickness: 4-50 sheets (80 g/m²) - Front trim: max. 25 mm - Production speed: max. 3,600 booklets/h - Collating performance: up to 9,900 sets/h - Loading capacity per station: 55 mm - Power supply: 230V; 50/60Hz - Total power consumption: approx. 2.3 kW All-Inclusive Service Package We take care of everything: from secure packaging and transportation to customs clearance. Upon request, we can also provide a customized leasing offer. Sustainable and Economical Choose a used machine and benefit twice: Save the environment and your budget. Despite possible signs of use, you receive a quality product at an attractive price.

Condition: excellent (used), functionality: fully functional, Horizon SPF-200A + FC-200A – High-Production Automatic Saddle Stitching Line We are offering a Horizon SPF-200A saddle stitching line with FC-200A three-side trimmer—an automatic system for producing stapled booklets—ideal for digital and offset printing environments demanding high quality and productivity. This is a robust, reliable, and easy-to-adjust machine, designed for continuous production of magazines, catalogues, and brochures. 🔧 Included Configuration SPF-200A: Automatic stitching and folding unit FC-200A: Front trimming guillotine Central stapling with two heads Integrated automatic folding Delivery via conveyor belt 🚀 Key Features Stable, high-speed production Quick setup and adjustments via control panel Double-sheet and misfeed detection Fast format changeover Designed for continuous operation High folding and squaring accuracy 📐 Approximate Technical Specifications Maximum input format: up to 350 x 500 mm (depending on configuration) Minimum format: approx. 120 x 180 mm Supported paper weight: 50–200 gsm (depending on combination and paper type) Maximum stitching thickness: approx. 4 mm Production speed: Up to 4,500–5,000 cycles/hour (depending on format and paper) 📚 Ideal Applications Magazines Catalogues Dedpfx Ajyitwasdgoup Programs Promotional brochures Digital production of short and medium print runs 💡 System Advantages High mechanical reliability Reduced maintenance cost Ideal for supplementing digital finishing lines Expandable modular system 📍 Machine available for inspection 🔧 Checked by specialized technicians 📸 Photos and video available on request

Condition: used, offer consists of: Dsdpou Sr A Tofx Adgeup SPF-20 - gear / equipment for smaller sizes used We can also organize the following for you: packaging, loading, transport ( by ship or plane) including customs

Condition: excellent (used), Year of construction: 2009, Horizon Brochure System Collating Machine Horizon VAC 100a, VAC 100c Number of Stations: 2 x 10 Max. Format: 500 x 350 mm Min. Format: 148 x 120 mm Loading Capacity: 55 mm per station Speed: up to 9,500 cycles/h Weight: 320 kg per tower Machine Dimensions: 810 x 652 x 1,961 mm Power Supply: 230 V, 10.6 A, 2.3 kW Staple-Fold Station SPF 200A Feed Format (4-page sheets): min. 180 x 105 mm, max. 508 x 356 mm Final Brochure Format: min. 85 x 105 mm, max. 250 x 356 mm Brochure Thickness: up to 25 sheets, 100 pages Speed: up to 4,800 cycles/h Weight: 782 kg (with front trimmer FC-200A) Machine Dimensions: 3,450 x 810 x 1,250 mm (L x W x H) Power Supply: 230 V, 5.3 A, 1.0 kW Dodpfjyhzubex Adgeup Trimmer FC 200A

Condition: used, Year of construction: 2003, Horizon VAC-100a VAC-100m SPF-20A FC-20A Booklet Making System, Used This Horizon booklet making system is a powerful solution for professional booklet production, combining collating, stitching, folding, and front trimming in an efficient process. It offers high productivity, versatile applications, and easy operation for efficient booklet production. Key Features: - Two collating towers: VAC-100a and VAC-100m with 10 stations each - Versatile stitching options: Saddle, corner, and side stitching possible - Touch & Work: Intuitive operation thanks to user-friendly technology - 9 programmable memory locations for repeat jobs - Precise error control: Prevention of miss-feed, double-feed, and jam problems - Expandable configuration: Possibility to add more VAC-100 towers Technical Specifications: Dedpfx Adsx D Urgsgoup - Paper format: max. 350 x 500 mm; min. 148 x 120 mm - Booklet format: max. 250 x 350 mm; min. 85 x 120 mm - Paper weight: 40-300 g/m² - Processing thickness: 2-22 sheets (80 g/m²) - Trimming thickness: 4-50 sheets (80 g/m²) - Front trim: max. 25 mm - Production speed: max. 3,600 booklets/h - Collating performance: up to 9,900 sets/h - Loading capacity per station: 55 mm - Power supply: 230V; 50/60Hz - Total power consumption: approx. 2.3 kW All-Inclusive Service Package We take care of everything: from secure packaging and transportation to customs clearance. Upon request, we can also provide a customized leasing offer. Sustainable and Economical Choose a used machine and benefit twice: Save the environment and your budget. Despite possible signs of use, you receive a quality product at an attractive price.

Condition: used, Year of construction: 1998, machine/vehicle number: 42016, Zusammentragmaschine / Broschürenfertigung MC-80a MC-80m SPF-11 FC-11 Booklet Maker / Brochure Finishing MC-80a MC-80m SPF-11 FC-11Anlage besteht aus / Booklet Maker consist of:Zusammentragmaschine / Air Suction Collator MC-80a MC-80m - 2 x 8 Stations Feeder Baujahr / Year 1998 - Serial-No. 042016 Format / Size min. 110 x 160mm - max. 318 x 470mm Grammatur / Paper weight 50-260g/qm Stapelhöhe / Infeed height Station 50mm Geschwindigkeit / Speed 5.100 Product/hBroschürenfertigung / Booklet Maker SPF-11 - FC-11 Dsdpjibuq Dofx Adgeup Baujahr / Year 1998 - Serial-No. 128032 Heften-Falzen-Schneiden / Stitching-Folding-Trimmer Unit 2 Universalheftköpfen / 2 Stitching heads Hohner 48/5S Kompressor / Compressor Rietschle Auslage / Delivery - Rüttler / Jogger PJ-77 Geschwindigkeit / Speed 1.500 - 3600 Sets/h Online-Video-Inspection by Skype-Video We would be very pleased with your visit - more machines on Stock Available Immediately - Can be inspect On Stock Emskirchen / Nürnberg - Can be test
