Vertical machining center

HURCO VMX60

Condition: used, TECHNICAL DETAILS - Number of axes : 5 MILLING SPINDLE - Tool holder type : BT40 - Spindle power : 36.5 [kW] - Spindle speeds : 12000 [rpm] - B Rotary Axis : 90 [°] (+/-) LINEAR AXES - Travels on X/Y/Z axes : 1525 / 660 / 610 [mm] - Rapid traverses rates (X/Y/Z) : 32 / 32 / 24 [mm/min] TOOL CHANGER - Auto. Tool Changer type : Bras chargeur - Tool magazine capacity : 40 TABLE - Table dimensions : 1680 x 660 [mm] Lodpfxoy Tzc Ho Akuehg - Distance table / spindle nose (min./max.) : 12.7 - 622.3 [mm] - Maximum weight upon table : 1360 [kg] - Diameter of the C-type rotary table : 600 [mm] - Travel : 360 [°] - Maximum load on the rotary table : 500 [kg] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 69 [kVA] WEIGHT & DIMENSIONS - Machine weight : 9.800 [kg] EQUIPMENT - CNC : WinMax / MAX5 - Electronic handwheel - Coolant tank * with high-pressure pump - Coolant through spindle - Chips conveyor - Spindle cooling unit - Tool probe

Condition: ready for operation (used), Number of axes: 3, connected load: 30kVA, control: Hurco Ultimax 4, weight: approx. 10.5t, equipment: chip conveyor, full enclosure cabin, electronic handwheel/control panel, coolant system, tool magazine. The machine should be overhauled, electronic components such as the mainboard and hard drive have been replaced repeatedly. An on-site inspection is possible. Ledpoy Tx Nqsfx Akushg

Condition: good (used), Year of construction: 2021, functionality: fully functional, The machine has 280 spindle hours and 2300 operating hours. Hurco VMX 60 i, Year of manufacture: 2021, Control system: Hurco Max 5, Lhodpfxoy S Tt Ie Akusg Travel range X/Y/Z: 1524/660/610 mm, SK 40, extra heavy-duty, Chip conveyor, Spindle speed up to 12,000 rpm, 30-position tool changer, Clamping area: 1680 x 660 mm, Max. table load: 2,000 kg, Network interface (1 x plain text dialog programming on the machine + 1 x for ISO code programming via external programming device or CAD/CAM system) Ethernet interface, USB interface, Trochoidal milling for higher material removal rate, Tool and material library Pocket milling with islands Synchronous thread cutting (thread cutting without a compensating chuck) ISNC extended NC mode Spindle cooler Chip guard enclosure Coolant system Ulti Motion Solid Import Tool change optimization IKZ 20 bar

Condition: good (used), Year of construction: 2011, functionality: fully functional, Travel X-axis approx.: 1,524 mm Travel Y-axis approx.: 660 mm Travel Z-axis approx.: 610 mm Table size approx.: 1,676 x 660 mm Table load approx.: 1,500 kg Tool changer: 24 positions Tool holder: SK 40 Spindle speed: 12,000 rpm ICS 20 bar 3D probe: Renishaw Lhedpey R A Swsfx Akujg Network interface Electronic handwheel Pocket milling with islands Synchronous tapping DXF software Scraper belt conveyor * Spindle hours approx. 1,937 (spindle replacement 2019) * Approx. single-shift operation

Condition: used, functionality: unexamined, Hurco VMX60T vertical machining centre Lhsdey Duv Ujpfx Akujg

Condition: good (used), Year of construction: 2011, HURCO CNC machining center VMX 60 t X-axis 1,500 mm Y-axis 660 mm Z-axis 600 mm Table size 1,680 x 660 mm Spindle speed 12,000 rpm Tool holder SK40 Tool changer, 24 positions Equipped with WinMax control Includes: Internal coolant system (IKZ) Spindle cooler Coolant spray gun Chip splash guard cabin Signal light for machine operating status Flushing system to assist with chip removal Machine lamp Set of machine leveling pads Machine manual on CD Ledpfjxvtfpox Akuohg 2 color screens (text + graphics) Simulation graphics Tool and material library Detachable electronic handwheel Pocket milling with islands Synchronous tapping (thread cutting without compensating chuck)

Condition: ready for operation (used), Year of construction: 2008, travel distance X-axis: 1,524 mm, travel distance Y-axis: 660 mm, travel distance Z-axis: 610 mm, table width: 660 mm, table length: 1,670 mm, spindle speed (max.): 10,000 rpm, number of axes: 3, This HURCO VMX 60 Vertical Machining center was manufactured in the year 2008. It is equipped with a MAX control unit and has 3 axis. The machine has a spindle speed of 10000 rpm. Machine Benefits Qualitative Machine Benefits • Good condition Lhodpfx Aoyi Ekxskujg Technical Machine Benefits • Tool turret 24 positions • Equipment various tools • Accessories chip evacuator

Condition: ready for operation (used), Year of construction: 2008, travel distance X-axis: 1,524 mm, travel distance Y-axis: 660 mm, travel distance Z-axis: 610 mm, spindle speed (max.): 10,000 rpm, number of axes: 3, This 3-axis Hurco VMX 60 was manufactured in 2008. A vertical machining center featuring a MAX Control system, it offers X-axis travel of 1,524 mm, Y-axis travel of 660 mm, and Z-axis travel of 610 mm. It includes a spindle speed of 10,000 rpm, a BT40 spindle taper, and a 24-position tool turret. Consider the opportunity to buy this Hurco VMX 60 vertical machining center. Contact us for more information about this machine. • Table size: 1,670 x 660 mm • Tool turret: 24 positions Additional equipment • Various tools Ljdpfx Ajygmtvjkushg • Chip evacuator Technical Specification Taper Size BT 40

Condition: excellent (used), Year of construction: 2016, functionality: fully functional, input voltage: 400 V, type of input current: three-phase, travel distance X-axis: 1,524 mm, travel distance Y-axis: 660 mm, travel distance Z-axis: 610 mm, number of slots in tool magazine: 40, controller manufacturer: Hurco, total height: 3,298 mm, total length: 5,662 mm, total width: 3,921 mm, overall weight: 10,900 kg, table length: 1,676 mm, table width: 660 mm, controller model: MAX5, torque: 118 Nm, distance table center to spindle nose: 622 mm, spindle motor power: 36,500 W, number of spindles: 1, rapid traverse Z-axis: 2 m/min, rapid traverse X-axis: 3 m/min, rapid traverse Y-axis: 3 m/min, rotary table diameter: 600 mm, rotational speed (max.): 100 rpm, spindle nose: BT40, spindle speed (max.): 12,000 rpm, table load: 1,360 kg, tool diameter: 75 mm, tool length: 249 mm, tool weight: 7 g, Equipment: CE marking, chip conveyor, 🔹 For Sale: 2016 Hurco VMX60SRTi 5-Axis CNC Machining Centre – Excellent Condition🔹 Make: Hurco Model: VMX60SRTi Year: 2016 Machine Type: 5-Axis CNC Machining Centre Condition: Excellent Control System: Hurco WinMax with Touchscreen Location: Ireland 📌 Machine Overview: Available now is a Hurco VMX60SRTi 5-Axis CNC Machining Centre in excellent condition, fitted with high-performance features and Hurco’s flexible swivel-head + rotary table configuration. This 2016 model delivers outstanding part accessibility, powerful milling capability, and robust software for advanced 5-axis work. The large table space supports both full 5-axis and standard 3-axis machining, offering maximum operational flexibility for tooling, mold-making, aerospace, and general precision engineering. ✅ Key Features & Included Options: Touchscreen display with shaded 3D graphics (real-time) 2GB RAM | 120GB SSD | USB ports Ultimotion high-speed software (profiling & data smoothing) S-Curve Acceleration & Look-Ahead Finish Control Coolant Through Spindle (CTS) NC4 Laser Tool Probe Renishaw RMP60 Part Probe Software Add-ons: Mould Maker Suite (3D Swept Surface, Helical Entry, Rest Machining) DXF Import, Ultipocket, Adaptipath Ultimonitor + Ultinet (Networking/Remote Diagnostics) Conversational/NC Merge Swivel B Axis & C Axis Rotary Table Conversational or G-code Programming flexibility 🔧 Technical Specifications: Table Size: 1676 x 660 mm Rotary Table Diameter: 600 mm Max Load (Flat Table): 1360 kg Max Load (Rotary Table): 500 kg X Travel: 1524 mm Y Travel: 660 mm Z Travel: 610 mm B Axis Tilt: ±92° C Axis Rotation: 360° Spindle Nose to Table: 13–622 mm Spindle Speed: 12,000 rpm Spindle Taper: BT40 Spindle Power: 36.5 kW Spindle Torque: 118 Nm - 2,900 rpm Tool Changer: 40 Tools Max Tool Diameter: 75 mm Max Tool Length: 249 mm Max Tool Weight: 7 kg Rapid Traverse Rates: X/Y: 32 m/min | Z: 24 m/min Rotary Table Speed: 100 rpm Power Requirement: 70 kVA Machine Dimensions (LxW): 5662 x 3921 mm Height: 3298 mm Machine Weight: 10,900 kg 📈 Ideal For: Aerospace & Defence Components Mould & Die Work Lsdpfx Ajuyt U Tekujhg Complex 3D Surface Milling Multi-Side Machining in One Setup High-Precision Part Manufacturing Hurco VMX60SRTi for Sale 5 Axis CNC Machining Centre Used Hurco CNC Machine Hurco 5 Axis CNC Ireland CNC Machining Centre with Rotary Table Notes: *Specifications are given in good faith but not guaranteed*
