Felling grapple GRA-F 500, ICM - 1 unit
ICM

Fixed price plus VAT

€21,050

Condition

New

Location

Titisee-Neustadt Germany

Felling grapple GRA-F 500, ICM - 1 unit ICM

Basic data

Machine type:: Felling grapple GRA-F 500, ICM - 1 unit

Manufacturer:: ICM

Condition:: new

Price & Location

Fixed price plus VAT

€21,050

Seller location:: Feldbergstraße 37, 79822 Titisee-Neustadt, Germany

Call

Details about the offer

Listing ID:: A231-72701

Reference number:: GRA-F500

Update:: 21.10.2026

Description

The GRA-F chainsaw grapple from ICM was developed for cutting and moving tree trunks of small to large diameter with excavators (8–12 t) and truck cranes (20–60 t/m).
The grapple offers a fully adjustable tilt and a precisely adjustable cut, allowing work processes to be adapted flexibly. The robust construction made of Strenx 700 steel eliminates the need for electrical components and guarantees low maintenance and a long service life.
The chainsaw grapple is ideal for reducing labor costs, as no conventional maintenance is required for the chainsaw basket. At the same time, it increases work safety and can reduce tree felling time by up to 80%.

- Felling grapple GRA-F 500 – swivel version
- A modern and safe method for felling and maintaining trees – efficient, energy-saving and reducing the need for personnel.
- Made of high-strength Strenx® 700 steel
- Lightweight, yet extremely stable construction for maximum performance
- No electrical components – operation is purely hydraulic with only two hose connections
- Swivel installation for flexible and precise work processes

Min. cutting diameter mm: 110
Area m²: 0.22
Working machines: 8-12 t
A mm: 1405
Max. cutting diameter mm: 500
Gripping force daN: 1275
B mm: 635
Ndedpfxo Adgw Se Ahbjc
C mm: 843
Required oil flow rate l/min: 50–100
H3 mm: 1124
Max. pressure bar: 250
Blade length mm: 600
H1 mm: 1377
H2 mm: 1259

The listing was translated automatically. Translation errors are possible.
