Horizontal Turning Machine

Index C100

Condition: good (used), Year of construction: 2007, DESCRIPTION Control SIEMENS Main and counter spindle Ø 42 mm Max. speed main and counter spindle: 7,000 rpm C-axis 3x turret Tool holder VDI 25 Turret 1 Number of stations 10 (all driven) Travel path: X= 70, Y= 70, Z= 250 mm Bsdpfsu Rc Rrox Af Hedk Turret 2 Number of stations 10 (all driven) Travel path: X= 70, Y= 70, Z= 400 mm Turret 3 Number of stations 10 (all driven) Travel path X= 125 mm Speed of driven tools: 8,000 rpm Bar loader INDEX MBL February 2025 New chip cylinder with rotary feedthrough (draw tube etc.) Original Index spare parts, € 10,000

Condition: excellent (used), Year of construction: 2023, X/Y/Z: 360/120/750 mm Bar capacity: 82 mm 12-station driven tool turret C-axis Y-axis VDI 40 NC tailstock MK 5 with foot switch Foot switch for clamping on main spindle Bjdpfsw Nxyaex Af Hsdk Air curtain Signal light Coolant device Chip conveyor Hydraulic holding brake ShopTurn Transmit function (cylindrical machining on outer and face surfaces) iXpanel (control system operation and organization extension) Gripper tray Small tool package

Condition: used, TECHNICAL DETAILS - Number of spindles : 2 - Number of axes : 10 - Number of turrets : 3 MAIN SPINDLE - Spindle nose : A2-5 - Spindle power : 22/29 [kW] - Spindle speeds : 7.000 [rpm] - Max. bar diameter : 42 [mm] - Max. chuck diameter : 110 [mm] Bdedpfx Asu Uu H Rsf Hok - C axis indexing precision : 0,001 [°] COUNTER-SPINDLE - Spindle nose : A2-5 - Spindle power : 16,5/19 [kW] - Spindle speeds : 7.000 [rpm] - Max. bar diameter : 42 [mm] * Max. chuck diameter : 110 [mm] - C axis indexing precision : 0,001 [°] - Travel : 500 [mm] - Rapid traverse rate : 60.000 [mm/min] - Spindle / counter-spindle distance : 515 [mm] UPPER LEFT TURRET - Number of positions : 10 - Number of motorized positions : 10 - X/Z stroke : 70 / 250 [mm] - Y stroke : 70 [mm] - Tool type : VDI 25 - Live tools speed : 8.000 [rpm] - Live tools power : 4,2 [kW] UPPER RIGHT TURRET - Number of positions : 10 - Number of motorized positions : 10 - X stroke : 125 [mm] - Tool type : VDI 25 - Live tools speed : 8.000 [rpm] - Live tools power : 4,2 [kW] LOWER LEFT TURRET - Number of positions : 10 - Number of motorized positions : 10 - X/Z stroke : 70 / 400 [mm] - Y stroke : 70 [mm] - Tool type : VDI 25 - Live tools speed : 8.000 [rpm] - Live tools power : 4,2 [kW] POWER SUPPLY - Supply voltage : 400 [V] - Total installed power : 68 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 5540 x 2910 [mm] - Machine weight : 5.500 [kg] MACHINE HOURS - Number of spindle hours : 25000 [h] EQUIPMENT - CNC : INDEX C200-4D (base Siemens ) - 3 colors status lamp - Coolant tank * with high-pressure pump : 20 [bars] * with paper filtering unit * With washing gun * Coolant through spindle : principale et secondaire - Chips conveyor : DROITE - Spindle cooling unit - Parts catcher - Bar loader : IEMCA BOSS 545 E - rotary tool holders : 6 - fixed tool holders : 24

Condition: used, TECHNICAL DETAILS - Number of spindles : 6 - Number of counter-spindles : 1 SPINDLES - Max. bar diameter : 40 [mm] - Spindle speeds : 7000 [rpm] - Spindle power : 13/24 [kW] NUMERICAL AXES - Slide unit 1.1 : X and Z axes controlled by NC - Slide unit 1.2 : X and Z axes controlled by NC - Slide unit 2.1 : X and Z axes controlled by NC - Slide unit 2.2 : X and Z axes controlled by NC - Slide unit 3.1 : X and Z axes controlled by NC - Slide unit 3.2 : X and Z axes controlled by NC - Slide unit 4.1 : X and Z axes controlled by NC - Slide unit 4.2 : X and Z axes controlled by NC - Slide unit 5.1 : X and Z axes controlled by NC - Slide unit 5.2 : X and Z axes controlled by NC - Slide unit 6.1 : Z axis controlled by NC - Slide unit 6.2 : X and Z axes controlled by NC POWER SUPPLY - Supply voltage : 380 [V] - Total installed power : 77 [kW] WEIGHT & DIMENSIONS - Machine floor space : 3329 x 2032 [mm] - Machine height : 2654 [mm] - Machine weight : 7100 [kg] MACHINE HOURS - Number of working hours : 47580 [h] EQUIPMENT - CNC : Siemens 840D (Powerline) - Double NCU - 2 NC control panels - Cutting force monitoring: ARTIS - Chips conveyor - Coolant tank * with high-pressure pump : 80 [bars] - Bar loader : Index MBL 40-6 - Fire extinguisher * * NB : working order not guaranteed. To have it checked by a qualified organization of the buyer. Bdodpfx Afjxqhtkj Hek - Electric transformer

Condition: used, Year of construction: 2023, Technical details: turning diameter: 770 mm turning diameter over slide: 650 mm turning length: 750 mm max. diameter of work permitted:: 82 mm y-axis: +/- 60 mm turret (x-stations): 12 VDI 40 turning speeds: 4.000 1/min tail stock: ja total power requirement: 47 kVA weight of the machine ca.: 7,8 t dimensions of the machine ca.: 3,3 x 1,9 x 2,3 m Accerories main spindle power 16 / 24 kW CNC lathe, NC-tailstock, C-axis with brake, live tooling (10,5 kW, 5.400 rpm), 3-jaw chuck SCHUNK ROTA THW 260-81, chip conveyor, prepared for oilmist suction, parts catcher and belt (right side), coolant device 300l, 8/20bar, Bdjdpfx Afoxhd Ufe Hsk accessories (8pcs. live-toolholder...) approx. 3.000 working hours *

Condition: used, Cnc multispindle lathe INDEX MS32C Bjdext U Hpjpfx Af Hjdk
