Cnc multispindle lathe

INDEX MS42C

Condition: good (used), Year of construction: 2002, CNC multi-spindle lathe Manufacturer: INDEX Machine model: MS 42C Control: Siemens SINUMERIK 840C Year of manufacture: 2002 Number of controlled axes: 12 Number of spindles: 6 Kjdpfxey Ak S Ns Afdjdk TECHNICAL DATA Spindle - Bar passage (mm): 42 - Max. speed (rpm): 5,000 EQUIPMENT FEATURES + 12 linear axes + Central coolant system + Central automatic lubrication

Condition: used, Year of construction: 1998, functionality: fully functional, machine/vehicle number: 23109, CNC 6-Spindle Lathe Index MS42C Year of manufacture: 1998, Serial number 23109 Control: Index Bar loader: Index/Hydag Maximum bar diameter: 42 mm Kjdpfx Afjyzicwedsdk Chip conveyor and fleece filtration system: Knoll CO2 extinguishing system: Kraft & Bauer ----- Attractive Offer – Flexible & Worry-Free We not only offer you a high-quality product, but also tailor-made financing solutions that suit your needs. Whether you prefer a down payment, installment plan, or custom financing model – together we will find the right solution. Upon request, we will also handle the entire transportation logistics for you. From planning to reliable delivery, we ensure a smooth and timely process so that you don’t have to worry about a thing. 📞 Please contact us for further information or a non-binding quote. We offer you professional and personalized advice.

Condition: good (used), Year of construction: 2003, functionality: fully functional, machine/vehicle number: 28102, CNC 6-Spindle Lathe Index MS42C Year of manufacture: 2003, Serial number 28102 Control: Siemens Sinumerik Bar feeder: lemca SIR-MS52 Max. bar diameter: 42 mm Chip conveyor and fleece filter system: Knoll CO2 extinguishing system: Kraft & Bauer ----- Attractive offer – flexible & worry-free We offer you not only a high-quality product but also customized financing options tailored to your needs. Whether down payment, installment purchase, or individual financing models – together we will find the right solution. On request, we can also take care of the entire transport organization. From planning to reliable delivery, we ensure a smooth and timely process, so you don’t have to worry about a thing. Kdjdpfx Ajyzickofdok 📞 Please feel free to contact us for further information or a non-binding offer. We provide you with personal and competent advice.

Condition: good (used), Year of construction: 2006, functionality: fully functional, machine/vehicle number: 31102, CNC 6-Spindle Lathe Index MS42C Year of manufacture: 2006, Serial number 31102 Control system: Siemens Sinumerik Bar feeder: lemca SIR-MS52 Max. bar diameter: 42 mm Chip conveyor and fleece filtration system: Knoll CO2 extinguishing system: Kraft & Bauer ----- Attractive offer – flexible & worry-free We offer not only a high-quality product, but also tailored financing solutions that are adapted to your needs. Whether it's a down payment, installment plan, or individual financing models – together we'll find the right solution for you. Kodjyzibyspfx Afdodk On request, we can also handle the entire transport logistics. From planning to reliable delivery, we ensure a smooth and timely process so you don’t have to worry about a thing. 📞 Contact us for further information or a non-binding offer. We provide personal and expert advice.

Condition: good (used), Year of construction: 2004, functionality: fully functional, machine/vehicle number: 29105, CNC 6-Spindle Turning Machine Index MS42C Year of manufacture: 2004, Serial number 29105 Control system: Siemens Sinumerik Bar feeder: lemca SIR-MS52 Max. bar diameter: 42mm Chip conveyor and fleece filter unit: Knoll Ksdpfx Ajyzibajfdedk CO2 fire extinguishing system: Kraft & Bauer ----- Attractive Offer – Flexible & Worry-Free We not only offer you a high-quality product, but also tailored financing options that meet your needs. Whether it’s down payment, installment plans, or customized financing models – together, we’ll find the right solution for you. Upon request, we also handle the entire transport logistics. From planning to reliable delivery, we ensure a smooth and punctual process, so you don’t have to worry about a thing. 📞 Please feel free to contact us for further information or a non-binding quotation. We provide personal and professional advice.

Condition: used, Year of construction: 2000, INDEX MS42C Maximum bar diameter: 42 mm Spindle pitch circle diameter: 320 mm Main spindle: Power clamping with INDEX spring-loaded hollow clamping cylinder and collet Maximum clamping stroke: 4 mm Clamping force: 26 kN Main spindle drive: Rated power: 5 kW Rated speed: 1,500 rpm Rated torque: 32 Nm Maximum speed: 5,000 rpm Synchronous spindle and rotary tool holder: Rated power: 5.3 kW Rated speed: 1,500 rpm Rated torque: 34 Nm Maximum speed: 5,000 rpm Cross slides: Max. number: 10 Travel (X): 70 mm Travel (Z): 140 mm Max. feed force +X: 11.4 kN Max. feed force −X: 7.9 kN Max. feed force +Z: 11.4 kN Max. feed force −Z: 7.9 kN Rapid traverse: 15 m/min Longitudinal spindles: Quantity: 6 Stroke (Z): 240 mm Max. feed force +Z: 15.1 kN Max. feed force −Z: 11.6 kN Rapid traverse: 15 m/min Longitudinal slide units: Max. number: 6 Travel (X): 70 mm Max. feed force +X: 11.4 kN Max. feed force −X: 7.9 kN Rapid traverse: 15 m/min Synchronous spindle: Chuck system: spring-loaded clamping cylinder Maximum clamping diameter: 42 mm Chuck outside diameter: 112 mm Jaw stroke: 1 mm Max. total clamping force: 13 kN Weight: approx. 11,000 kg Ksdpfxeymc S Ue Afdjdk Scope of delivery: KNOLL KTS 32-48-T hydraulic unit CUCCHI PLURIMANDRINO bar feeder, year 2000 Workshop cabinet with machine accessories KNOLL VRF 500 KNOLL 400 S-1/250 chip conveyor

Condition: ready for operation (used), Year of construction: 1998, operating hours: 39,445 h, controller manufacturer: SIEMENS, controller model: SINUMERIK 840C, number of axes: 12, This 12s Index MS42C was manufactured in 1998. It features a maximum bar diameter of 42 mm and operates with a fully automatic system, making it suitable for high-volume precision turned parts. The machine is equipped with a Siemens SINUMERIK 840C control system and AC servo drives, ensuring efficient performance. Consider the opportunity to buy this Index MS42C automation equipment. Contact us for further details. • Maximum bar diameter: 42 mm • Number of spindles: 6 • Spindle pitch circle diameter: approx. 320 mm • Maximum spindle speed: approx. 5,000 rpm • Number of CNC axes: 12 linear axes (6 × X, 6 × Z) • Axis configuration: X/Z per spindle station • Control: Siemens SINUMERIK 840C (INDEX OEM integration) • Drive system: AC servo drives with SERCOS interface • Automation level: Fully automatic • Operating mode: Continuous production (24/7 capable) • Cooling: Central coolant system • Lubrication: Central automatic lubrication • Electrical supply: 3-phase industrial power • Installed power: approx. 70–75 kW (configuration dependent) • Machine construction: Rigid cast iron base • Typical materials: Steel, stainless steel, aluminum, brass Kdjdpfxoyhf N Es Afdek • Typical applications: High-volume precision turned parts

Condition: ready for operation (used), Year of construction: 2002, operating hours: 24,971 h, spindle speed (max.): 6,000 rpm, controller manufacturer: SIEMENS, controller model: SINUMERIK 840C, number of axes: 12, This 12s Index MS42C multi-spindle turning machine was manufactured in 2002. It features a maximum bar diameter of 42 mm and a spindle speed of approximately 5,000 rpm, making it suitable for high-quality turning capabilities. Consider the opportunity to buy this Index MS42C multi-spindle turning machine. Contact us for further details. • Maximum bar diameter: 42 mm • Number of spindles: 6 Kdedpfxoyhpgus Afdek • Spindle pitch circle diameter: approx. 320 mm • Number of CNC axes: 12 linear axes (6 × X, 6 × Z) • Axis configuration: X/Z per spindle station • Control system: Siemens SINUMERIK 840C (INDEX OEM) • Drive system: AC servo drives with SERCOS interface • Automation level: Fully automatic • Cooling system: Central coolant system • Lubrication system: Central automatic lubrication • Installed power: approx. 70–75 kW • Typical materials: Steel, stainless steel, aluminum, brass

Condition: good (used), Year of construction: 2006, Year of manufacture: 1998 to 2006 Available from current location Kdsdpfxeypltgj Afdjk

Condition: used, Cnc multispindle lathe INDEX MS42C Kedpsxzu Trsfx Afdjdk
