Stop angle

INOX

Condition: new, For sale: High-quality steel compensating hose (Ringwellschlauch) made of stainless steel, designed for industrial applications. This component is used to compensate for vibrations, thermal expansions, and stresses in piping systems. Ideal for installations: - industrial - heating - gas - water - process/technological Lrsdpfxsz Smkkj Al Teu ⚙️ Technical data Type: SP20 Nominal diameter: DN100 Length: 1000 mm Pressure: PN10 Material: stainless steel 1.4404 (INOX) Standard: ISO 10380 / DIN 3384 Designation: BOA-MS (10/2022) Connections: pipe ends for welding Braid: reinforced stainless steel braid ✅ Advantages ✔ corrosion resistance ✔ high durability and flexibility ✔ vibration and noise damping ✔ compensation of thermal expansion ✔ industrial-grade product – robust construction

Condition: used, Used approximately 13,400 litre Inox-Maurer AG stainless steel reactor body. Unit has an approximately 770 litre external coil. Unit is rated 2.0 / -1bar internal operating at 200degC. External coil is rated 16.0bar operating at 200degC. Unit has an internal material of construction of 1.4435 and external coil of 1.4306. Ljdjy Ryrnepfx Al Teru Specifications: Capacity: 13,400 L Internal Pressure: 2 bar Internal Temperature: 200°C Jacket Pressure: 16 bar Jacket Temperature: 200°C Legs/Lugs/Mounting Ring: Mounting Ring

Condition: used, Year of construction: 2019, Overview Complete 10 hl craft brewery around a BBC INOX Essential 1000 steam-heated two-vessel brewhouse, installed in 2019. One package from milling to bottling: brewhouse, hot liquor, wort cooling, steam and water treatment, fermentation with glycol cooling, filling, labelling and capping, a walk-in cold room for bottle conditioning, plus handling and cleaning equipment. Suited to a new brewery or a brewpub moving up to 10 hl; fermentation capacity can be extended. Technical data - Brew length: 10 hl (1,000 L) per brew - Brewhouse: 2 vessels, AISI 304, steam-heated - Fermentation: 3 x 18 hl gross (approx. 15 hl working), AISI 316, atmospheric - Cellar output: approx. 700-800 hl/year with 3 fermenters on 3-week cycles - Year: 2019 Scope of Delivery - Brewhouse | BBC INOX | ESSENTIAL 1000 | mash/boil kettle 1,600 L, steam-heated, whirlpool inlet; lauter tun 1,300 L with false bottom and rake; AISI 316 wort pump, grant, platform and stairs; control panel with 15 recipes | 2019 - Hot liquor tank | 2,000 L | AISI 304, internal steam coil, CIP spray ball, manway, level gauge, pump; approx. H 3,100 x D 1,270 mm - Plate heat exchanger | Kelvion | NT 25 PH | AISI 316 plates, 2,000 L/h, wort 98 to 12.8 °C - Cylindro-conical fermenters, 3 units | BBC INOX | 18 hl | AISI 316, 60° cone, dual-zone glycol jackets, individual temperature controllers, CIP spray ball, sampling valve - Glycol chiller | outdoor monobloc, glycol down to -5 °C, buffer tank and circulation pump - Steam generator | process steam for brewhouse and hot liquor tank - Water softener | ion-exchange column with brine tank - Bottling / priming tank | BBC INOX | AISI 304/316, polished, level gauge - Linear gravity bottle filler | 6 filling spouts, 480 L/h, 33 / 50 / 75 cl, AISI 304 on trolley - Semi-automatic labeller | OMB | front and back label on round bottles, photocell, 230 V | 2019 - Crown capper | AIR-MATIC | pneumatic column capper, 26 / 29 mm crowns - Walk-in cold room | 5.30 x 3.10 x H 2.50 m, dismountable panels, +2 to +10 °C - Malt mill | two hardened-steel rollers, adjustable gap, 25 kg hopper, 1.5 kW - Digital floor scale | stainless steel low-profile platform, tare and dosing - Semi-electric stacker | Jungheinrich | HC 110 | 1,000 kg, lift height 1,600 mm, 12 V, integrated charger | 2019 - Manual hydraulic stacker | BASIC | D 1025 | 1,000 kg, fork lift 85-2,500 mm - Floor scrubber-dryer | Lindhaus | LW 38 PRO - Stainless steel workbench | AISI 304, 200 x 70 x H 85 cm Ledpfx Ajz E U Diol Tsru - Wire-mesh storage baskets | foldable, stackable, 112 x 77 x H 95 cm - Food-grade hoses and stock | hoses with DIN fittings; approx. 1,600 empty bottles, 250 cartons, 3 x 20 L kegs, 2,000 crown caps Condition Used, visually very good, clean installation, still installed and under power. The fermenters are atmospheric: carbonation by bottle conditioning or via an additional pressure tank. Chiller, cold room and steam generator must be disconnected by certified technicians. Availability Immediately. Location: Italy. Dismantling and loading by the buyer. The brewhouse, hot liquor tank and heat exchanger are also available as a separate package.

Condition: excellent (used), Thermix cook chill tanks x 18 Ledpfjzwug Rox Al Tjru

Condition: used, Year of construction: 2018, Manufacturer: Poly Concept Inox Lrodpfoz Eb Rcox Al Tou Year: 2018 Type: Vibrating conveyor Variable speed drive: yesGrate size: 22 x 20 cmMesh size: ± 4.20 mm / wire diameter: 1 mm Dimensions: 50 x 150 x 50 cm Video showing the machine in operation available on request

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, total height: 18,000 mm, outer diameter: 3,000 mm, water tank capacity: 70,000 l, Tank made of stainless steel with a capacity of 70,000 litres. Insulated body with load cells. Volume Total capacity 70,000 L Material Stainless steel Equipment configuration Insulated Load cells Transport information Length 18,000 mm Width 3,500 mm Ljdpfxsxlir Ds Al Teru

Condition: used, Used stainless steel tank Last application: Chemicals Article number: 10909 Volume: 1450 liters Type: Standing on 4 rollers Material (in contact with media): 1.4301 / AISI304 Lrjdjzxz Anjpfx Al Tou Design: Single-walled Tank dimensions: Inner diameter: 1400mm Cylindrical height: 1000mm Height of legs: 240mm Overall height: 1200mm Overall width: 1446mm Materials: Inside: 1.4301 / AISI304 Exterior parts: 1.4301 / AISI304 Features: Nameplate: yes Distance from drain to bottom: 190mm Outlet diameter: 50mm

Condition: excellent (used), Isothermal Aseptic Tank BIO-INOX 18,000 L – Stainless Steel BIO-INOX 18,000-liter aseptic tank with a double bottom and thermal insulation, designed for the storage and intermediate preservation of liquid and semi-liquid food products under controlled hygienic conditions. Its large-capacity vertical configuration and stainless-steel construction allow it to be integrated into aseptic processing industrial facilities, acting as a storage tank or buffer between thermal treatment and filling stages. The isothermal design helps limit temperature variations of the product during its stay in the tank, while its aseptic configuration is designed for processes where it is necessary to preserve the hygienic conditions of the previously treated product. MAIN FEATURES -Manufacturer: BIO-INOX -Type: Isothermal aseptic tank -Capacity: 18,000 liters -Vertical configuration -Double bottom -Stainless steel construction -Isothermal / thermally insulated design -Prepared for aseptic storage -Large storage capacity -Sanitary product connections -Stainless steel support legs -Designed for continuous industrial processes -Suitable as a buffer tank / intermediate storage -Integrable into aseptic processing and filling lines -Hygienic construction for the food industry APPLICATION Lodpfx Aszxccvel Tsru The 18,000 L BIO-INOX is designed to receive and temporarily store processed product, maintaining it under controlled conditions before its transfer to the next stage of production. It can be used as an aseptic buffer tank between a sterilizer and a filler, providing accumulation capacity and helping to partially decouple the different stages of a process line. It can be integrated with: Aseptic sterilizers UHT systems Heat exchangers Sanitary pumps Homogenizers CIP systems Aseptic piping and valve systems Aseptic fillers Complete processing lines APPLICATIONS Particularly suitable for juice and beverage industries, fruit, tomato, puree, pulp, concentrate, sauce, and other liquid or pumpable food product processors that require intermediate storage within an aseptic process. Its 18,000-liter capacity, stainless steel construction, and isothermal configuration provide a large-capacity solution for aseptic processing and storage industrial facilities. Machine available for inspection. Additional technical information, dimensions, additional photographs, or videos can be provided upon request.

Condition: used, Year of construction: 2015, Overview  This compact brewing, fermentation and packaging setup was manufactured between 2015 and 2022 by various European manufacturers The installation is designed for beer production in bottles and cans and consists of an isobaric filler, can seamer, small brewhouse, fermentation tanks, refrigeration unit, labeller and steel kegs. The equipment is already dismantled and stored und immediiately available. Technical data - Application: Beer (bottles & cans) - Filling type: Isobaric Filling & Seaming - Bottle formats: 33 cl, 50 cl, 75 cl - Bottle output: 350–400 bph (at −1°C to +1°C, 33 cl) - Can formats: 33 cl, 44 cl, 50 cl - Can output: 350–400 cph (at −1°C to +1°C, 33 cl) Brewhouse - Capacity: 650 L - Heating: Propane gas - Electrical: Single-phase Lrodoy Sccxjpfx Al Tju Fermentation & Cooling - Total fermentation capacity: 9,800 L - Stabilization capacity: 2,940 L - Dimensions (refrigeration unit): approx. 1,100 × 930 × 840 mm Scope of Delivery  - Isobaric Bottle & Can Filler | Inox CG | — | — | 350–400 bph/cph - Can Seamer | — | — | 2022 | Brand new, never used - Brewhouse | — | — | 2015 | 650 L, propane gas, agitator - Refrigeration Unit | W3/4 | — | 2020 | Multi-unit control, 4 zones - Isobaric Fermenter | CEAO Inox | — | 2018 | 650 L, cooling jacket (Unit 1) - Isobaric Fermenter | CEAO Inox | — | 2018 | 650 L, airlock (Unit 2) - Isobaric Fermenter | Construções em Aço Inox | — | 2022 | 650 L, dry-hopping port - Isobaric Fermenter | Construções em Aço Inox | — | 2022 | 320 L, dry-hopping port - Atmospheric Fermenter | — | — | 2015 | 650 L, non-insulated - Semi-Automatic Labeller | — | — | 2015 | Circular reel labels - Stainless Steel Kegs | — | — | — | 50 pcs, 30–50 L

Condition: used, Year of construction: 2016, Overview  This complete 1,500 L brewhouse system was manufactured by Spanish company Inox GC. It includes a three-vessel hot side, a 2,000 L mash/whirlpool tun, a 2,500 L lauter tun, and a 1,800 L hot water tank. The brewhouse comes with pumps, heat exchanger, CIP features, and a new AEM automatic gas burner for heating. The equipment is in good condition. Technical data - Brewhouse System – Inox GC (1,500 L) - Capacity per batch: 1,500 L - Vessels: HLT, mash/lauter tun, kettle/whirlpool - Material: AISI 304 stainless steel - Heating: Compatible with automatic gas burner - Includes: Temperature control panel, integrated pumps - Isothermal Mash & Whirlpool Tun (2,000 L) - Capacity: 2,000 L - Insulation: 50 mm rock wool - Features: Hinged lids, agitator with VFD, CIP system, PT100 probe - Isothermal Lauter Tun (2,500 L) - Capacity: 2,500 L - Features: 5° sloped bottom, 500 mm manway, German V-screen, automatic rake, CIP system - Insulated Hot Water Tank (1,800 L) Lredpfx Alsyb S D No Teu - Capacity: 1,800 L - Heating: 9 kW electric element - Features: Rock wool insulation, 50 mm inlet/outlet, CIP system - Process Equipment - Wort pumps (helical & transfer) - Tubular heat exchanger (removable) - Hop filter - Automation panel with VFDs - Automatic Gas Burner – AEM GR8 PHP (2016) - Type: Circular gas burner, automatic ignition
