Veneer press

Italpresse

Condition: good (used), Code: 0419 Brand: ITALPRESSE Model: V/2 Electric press for cold gluing of doors, furniture, panels, composite materials, technical materials, plastics, aluminum, various materials Equipped with a motor that is operated by a switch with automatic return. This switch controls the movements of the mobile platen towards or away from the panels, while the required pressure and the release are controlled by a handwheel, which is on the side of the press. This system allows for maximum pressure with minimum effort Platen dimension mm 2500 x 1200 Opening mm 650 Pressure screw n°2 Installed power Hp 0,75 Overall dimensions: mm 2850 x 1200 x 1650 h Weight kg 880 Dedpfx Adjzcfdferjcn

Condition: good (used), Code: 0478 Brand: ITALPRESSE Model: V/2 Mechanical press for cold gluing Dodpfx Adezz Szasrscn Equipped with a motor that is operated by a switch with automatic return. This switch controls the movements of the mobile platen towards or away from the panels, while the required pressure and the release are controlled by a handwheel, which is on the side of the press. This system allows for maximum pressure with minimum effort Platen dimension mm 2200 x 1000 Opening mm 650 Pressure screw n°2 Installed power Hp 0,75 Overall dimensions: mm 2550 x 1000 x 1650 h Weight kg 750

Condition: good (used), Code: 0283 Brand: ITALPRESSE Model: 25/13 Dcsdpfxoyazdio Adrsn Fabricated platen for diathermic oil press Technical data: Platen dimensions: mm 2500 x 1300 Max temperature up to 120° Max working pressure: 3/5 kg/cm2 Heating medium pressure 0,5 ate Composition: Aluminium - Flat gauged steel sheet - Coil of piping for fluid circulation - Reinforcement piping - Flat gauged steel sheet - Insulating material

Condition: good (used), Code: 0158 Brand: ITALPRESSE Model: LOCK FORM SYSTEM AIR - CE Standard Hydraulic air membrane press with loading and unloading - CE Standard Dsdpspvk Disfx Adrscn 3-D coated on one face lamination of veneer to panels shaped or profiled on one face and flat on the other to produce cabinet door raised panels, drawer fronts, desk tops, table tops, kitchen tops, etc. 3-D lamination of plastic foils (PVC, PPE, ABS, Transfer foil ) to panels sheped or profiled on one face to produce: cabinet doors, drawer fronts, desk tops, table tops, kitchen tops, store fixture components, room doors, etc. Platen dimensions mm 2650 x 1250 Piece height mm 55 Pressure control manometer Automatic pressure reset Opening timer

Condition: good (used), Code: 0374 Brand: ITALPRESSE Model: V/4 Mechanical cold press for wood, panels, doors, furniture, composite materials, technical materials, plastics, aluminium and various other materials Working dimensions 2200 x 1000 mm Platen dimensions: n° 2 platens 1100 x 1000 mm NEW aluminium sheets Option to work on a single table or on separate tables Opening 650 mm Dcsdpfx Adsy If Rweren N° 4 pressure screws N°2 motors 0,75 Hp each Overall dimensions mm 2550 x 1000 x 1650 h Weight kg 870

Condition: good (used), Code: 0397 Dodszbmxujpfx Adrecn Brand: ITALPRESSE Model: R4/130 - CE Standard Automatic 4 rollers glue spreader for vinyl glue (PVAC), urea glue (UF) and polyurethane glue, for various types of materials like MDF, chipboard, plywood, parquet, composite materials, plasterboards, furniture, panels, doors and various, building sector, sponges, mattresses, papermaking - CE Standard Technical specifications: Working width mm 1300 Max working passage mm 100 Power 0,75 Kw Spreading rollers diameter mm 210 Variable roller feed speed Automatic rollers cleaning Motorised outfeeding discs Overall dimensions mm 2150 x 1100 x 1600 h Weight kg 750

Condition: good (used), Code: 0223 Brand: ITALPRESSE Model: PHF Hydraulic press for curved veneers for processing seats, chair backs, benches, tables and other curved items Technical data: Dcedpexmhcdefx Adren Platen dimensions mm 2600 x 1600 Opening between platens mm 1500 Thrust ton 100 Movement from bottom to top Motor power Hp 4

Condition: good (used), Code: 0136 Brand: ITALPRESSE Model: FORMATIC 20.9 Hydraulic fluid membrane press Dcjdepbvqvepfx Adrjn Two sided lamination of veneer to panels shaped or profiled on one face and flat on the other to produce cabinet door raised panels, drawer fronts, desk tops, table tops, kitchen tops, etc. 3-D lamination of plastic foils (PVC, PPE, ABS, Transfer foil ) to panels sheped or profiled on one face to produce: cabinet doors, drawer fronts, desk tops, table tops, kitchen tops, store fixture components, room doors, etc. Platen dimensions mm 2000 x 900 Daylight mm 325 Cylinder stroke mm 325 Heating electric boiler Kw 27 Thrust ton 300 ton N° 3 thrust cylinders Hydraulic unit power Kw 5,5 Pressure control manometer Automatic pressure reset Opening timer Overall dimensions mm 3300 x 1400 x 2400 h Weight kg 8100

Condition: excellent (used), Year of construction: 2013, We sell the Mambrane press for kitchen doors, doors, or door frames, etc. Producer ITALPRESSE, Spa Model: ESTREMA 14,5 - 28 Year 2013 Area 2800 x 1450mm. / 2 Table PIN system for edge binding. Magazine for foils in rolls included Possible to see at work. Documentation included Dodpfx Aez Ikxbedrecn

Condition: good (used), Year of construction: 2011, Condition: used, in working condition The robust frame construction and press beams ensure precise frame assembly and gluing. The press guarantees accurate squareness while preventing frame distortion or warping. Thanks to the long stroke of the hydraulic cylinders, the lower beam and the clamping jaws require less frequent adjustment. The lower beam features automatic lifting and locking. Technical Specifications • Maximum frame size: 3000 × 2000 mm • Minimum frame size: 250 × 340 mm • Hydraulic pump power: 3 kW • Maximum total pressing force on the horizontal and vertical beams: 19 tonnes • Vertical hydraulic cylinder stroke: 1100 mm • Horizontal hydraulic cylinder stroke: 1200 mm • Lower beam adjustable to three heights: 380, 680 and 980 mm • Adjustable vertical and horizontal pressing pressure • Two horizontal fences with quick-adjustment system • Horizontal and vertical movements are controlled by lever-operated valves mounted on the machine frame • CE-compliant design • Pendant push-button control unit Dedjzlyv Tspfx Adrjcn Specifications are provided for information only. This machine is offered for sale on behalf of a customer. Viewing is available by prior arrangement. Please contact us through the platform's messaging system for further information and the relevant technical contact details.
