Bench drill

Juaristi MDR 110

Condition: used, Year of construction: 2004, Technical details: x-travel: 1500 mm y-travel: 1000 mm z-travel: 1000 mm control for program: TNC 530 spindle hours: noch nicht bekannt h milling head speed: 1: 30 bis 930 und 2: 930 bis 4000 / steples U/min tool taper: horiz./vertical: SK 50 (DIN 69871/Din 69872 Form A) max. torque on the spindle: 1000 Nm spindle head swivable left - right: 90 ° feed: 1 - 6000 mm/min feed power: 30 kN kN rapid traverse: 15 m/min Number of tools: 1 St. table clamping surface LxW: 1600 x 800 mm table load: 40 kN kN voltage: 400 V / 50 HZ V total power requirement: 42 kW Weight approx.: 15,2 t compressed air: 6,3 bar dimension machine xH: 3,1 x 4,7 x 2,6 m dimensions: Kühlfilter: 1,9 x 1,6 x 1,4 mm space requirements approx. LxWxH: ca. 38,5 m² m² Hsdpfsu Nc Riox Altjnt Applications: Milling, drilling; tapping, boring. with direct coded length measuring systems the guideways of the 3 axes are on flat guideways CTS and external cooling Milling head position controlled +/-90° milling spindle nominal drive power 22 kW with integrated hydraulic power unit up to 100bar operating pressure with coolant unit with filtration, with high pressure pump 60 bar (internal cooling), nominal delivery 20 l/min. and low pressure pump 4 bar (external cooling) as well as spray gun Hinged belt chip conveyor DGS, type SSF 600 P50 Accessories: Measuring probe SK40 Reference tool SK40 Milling head SEMPUCO *

Condition: used, Technical details: spindle diameter: 120 mm x-travel: 1250 mm y-travel: 1250 mm z-travel: 800 mm W-axis (spindle longitudinal): 600 mm Speed of boring spindles: 1- 2000 U/min. spindle taper ISO: 50 table surface area: 1000 x 1000 mm total power requirement: 55 kW Hsdpfoxt El Aox Altjnt weight of the machine ca.: 18 t with CNC HEIDENHAIN TNC 426 autom. toolchnager 40-pockets coolant attachment *

Condition: excellent (used), Year of construction: 2011, TECHNICAL DETAILS CNC control: MSX-501III X axis mm: 560 Y axis mm: 560 Z axis mm: 660 B axis deg.: 360.000 Table load capacity kg: 400 Cutting feed rate mm/min X,Y,Z: 60,000 Max. rapid traverse m/min X,Y,Z: 50 Spindle speed rpm: 12,000 Spindle power kW: 15 Taper type: ISO-40 Torque Nm: 120 Tool changer type: Chain Tool changer positions: 60 Max. tool diameter mm: 70 Max. tool diameter with adjacent positions empty mm: 170 Max. tool length mm: 450 Max. tool weight kg: 8 Coolant tank capacity l: 500 Through-spindle coolant (high-pressure): Yes EQUIPMENT Double chip conveyor ISO-40 taper High-pressure through-spindle coolant with pump Hnodpfx Aexfka Noltet Tool breakage detection probe Part measuring probe RENISHAW MACHINE DIMENSIONS Length mm: 3,755 Width mm: 2,300 Height mm: 2,610 Weight kg: 7,600

Condition: good (used), Year of construction: 1983, Machine number: 316204/22 Type / Model: FSS 315/E Travel ranges x-y-z: 850 – 280 – 355 mm Table: 1,200 x 370 mm Clamping area: 1,060 x 260 mm Speed range: 28 to 1,400 rpm Spindle mount: SK 50 Quill stroke: 80 mm Feeds for x and y axes: 16 to 800 mm/min Feed for z axis: 5 to 250 mm/min Power: 8 kW Accessories/Equipment: Head swivels Hodpfx Ajfli Afjltent Condition: good Weight: 4 t Dimensions: 2,000 x 2,000 x 2,400 mm

Condition: used, Year of construction: 2014, Technical details: x-travel: 760 mm y-travel: 760 mm Hsdpfx Alexrwpdotont z-travel: 760 mm total power requirement: 43 kW weight of the machine ca.: 11,5 t dimensions of the machine ca.: 2,7 x 4,73 x 2,87 m max. table loading capacity: 500 kg

Year of construction: 2007, condition: excellent (used), X AXIS: 762 MM Y AXIS: 560 MM Z AXIS: 460 MM SPINDLE SPEED: 15,000 RPM Hnsdjpyg Rkjpfx Altst SPINDLE CONE: BT 40 TABLE DIMENSION: 460 X 760 MM MAXIMUM LOAD: 400 KG RAPID FEEDS X/Y AXIS: 40,000 MM/MIN Z AXIS RAPID FEEDS: 32,000 MM/MIN WORKING FEED: 32,000 MM/MIN TOOL WAREHOUSE: 20 PLACES TOOL CHANGE TIME: 1.2 SEC – 3.8 SEC MAXIMUM TOOL WEIGHT: 8 KG MAXIMUM TOOL LENGTH: 300 MM CONTROL: OSP-P200M

Year of construction: 1989, condition: ready for operation (used), A Maho CNC 4-axis universal bed-type milling machine is available. Travel X/Y/Z: 1600mm/800mm/800mm, table dimensions X/Y: 1250mm/800mm, max. table load: 3000kg, spindle mount: SK50, main spindle speed: 4000rpm, power: 22kW. Tool positions: 36, max. tool diameter: 160mm/210mm, max. tool length: 315mm/400mm, max. tool weight: 15kg, feed rate: 4m/min, rapid traverse: 10m/min. Machine dimensions X/Y/Z: approx. 5000mm/3700mm/3000mm, weight: approx. 16000kg, control: Philips CNC 232. An on-site inspection is possible. Hnodpfx Aev Ubqnsltjt

Condition: ready for operation (used), Year of construction: 2007, travel distance X-axis: 2,000 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 1,250 mm, table load: 2,500 kg, rotational speed (max.): 3,000 rpm, overall weight: 10,000 kg, CNC Heidenhain TNC 530 Maximum spindle speed: 3000 RPM Hnjdpjy Nnunjfx Altet SA 50 tool holder Power: 22 kW Tool changer Travel: 2000 x 1000 x 1250 mm Chip conveyor Machine weight: 12500 kg

Condition: excellent (used), Year of construction: 2011, operating hours: 11,000 h, functionality: fully functional, travel distance X-axis: 600 mm, travel distance Y-axis: 560 mm, travel distance Z-axis: 565 mm, rapid traverse X-axis: 40 m/min, rapid traverse Y-axis: 40 m/min, rapid traverse Z-axis: 40 m/min, total height: 2,700 mm, total length: 4,000 mm, total width: 2,400 mm, table width: 400 mm, table length: 400 mm, spindle speed (max.): 8,000 rpm, operating hours of spindle: 6,383 h, Equipment: chip conveyor, documentation/manual, rotational speed infinitely variable, Offered here is a horizontal machining center from the manufacturer Doosan. Hedpsyl Iu Eefx Altsnt Operating hours: 11,320 h Spindle hours: 6,383 h The machine is in very good condition and can be inspected under power in our facility. Both clamping towers are included in the scope of delivery. Manufacturer: Doosan Model: HC 400 Year of manufacture: 2011 Control: Fanuc Series 32i-MODEL A Technical data: Travel X-Y-Z: 600x560x565 mm B-axis: 1° increment (indexing table) Rapid traverse X-Y-Z: 40 m/min Feed rates: 20,000 mm/min Pallet size: 400x400 mm Spindle speed: 8,000 rpm Tool holder: SK40 Machine weight: 11,000 kg

Condition: used, Year of construction: 2001, travel distance X-axis: 2,300 mm, travel distance Y-axis: 2,300 mm, travel distance Z-axis: 1,000 mm, table width: 1,250 mm, table length: 2,500 mm, rotational speed (max.): 18,000 rpm, overall weight: 35,000 kg, CNC Siemens 840D universal head, HSK63 spindle maximum spindle speed 18,000 rpm 100-position tool changer table 2500x1250 mm Hnodjy H Av Ispfx Altst travels 2300x2300x1000 mm chip conveyor tool set
