Cylindrical Grinding Machine

JUNKER Jucam 1000 /11S

workpiece .
workpiece diameter 15 -70 mm
swing diameter max. 150 mm
clamping length max. 500 mm
Swing over bezel area 70 mm
dimension 150 x 300 mm
max. turning speeds 250 min/-1
longitudinal adjustment manuell über Kettenrad
Fixed tip MK 4 (Junker D75 mm)
clamping capacity ü. Hydraulik einstellbar
travel -z axis max. 1000 mm
feed z - Achse (CNC gesteuert)
dimension D 205 x 450 mm
flange diameter D 190 mm
Cjdpfx Abevdt Nuswsrh
standards association D 127 mm
drive 30 kW
speed control mit Frequenz- Umformer
max. turning speeds 4400 min/-1
type Borazon (CBN) o. Diamant mm
diameter 450 mm
bore D 127 mm
peripheral speed max. 90 m/sec
type GR-3520-NR mm
diameter range D 20 - D 35 mm
dimension D 80 x 250 mm
flange D 100
standards association D 75
drive 1,8 kW
max. turning speeds 24000 min/-1
weight of the machine ca. 7,0 t
In our opinion, the machine is in good condition
and can be inspected under power by appointment.

There are 2 identical machines available.

Accessories, tools and clamping devices shown are only part of the scope of
delivery
if this is noted in the additional information.

Changes and errors in the technical data and information as well as
Subject to prior sale!
