Cylindrical grinding machine

Junker Jumat 5340/S

Condition: good (used), Year of construction: 2000, gear diameter: 449 mm, Equipped with: Fanuc 150MB CNC Control Dry Cutting Cutter Shroud Chip Evacuation System Auto Doors Hydraulic System Lubrication System Work light Stack Light Specifications: Largest Speed Ratio: 10:01 Work Area (Continuous): Largest Depth of Teeth: 15.24 mm Largest Width of Tooth Face: 50.8 mm Work Area Axis: Horizontal Movement X Axis: -114 - 178 mm Vertical Movement Y Axis: -178 - 190 mm Movement of the Carriage Baseplate Z-Axis: -10.16 - 500 mm Workpiece Headstock Swiveling Range B-Axis: -3 - 90 Degree Maximum Distance Machine Center to Spindle Side: 165 mm Number of Teeth: 5-200 Inclusive Max. Gear Pitch Dia. of Typical 35 Deg. Spiral Angle Gear Using Max. Cutter Dia. 12" Cutter at the Following Ratios: Face Milling 1 x 1 - 13.5" - 342.9mm 2 x 1 - 16.0" - 406.4mm 5 x 1 - 17.7" - 450.0mm Face Hobbing (210mm Dia. Cutter) 1 x 1 - 10.560" - 268.22mm 2 x 1 - 10.286" - 275.00mm 5 x 1 - 11.810" - 300.00mm Milling Head Diameter: Helixact: 100,125,169,200,250,320mm Continuous Gumption Procedure, Teichloroethylene: 102 - 210 mm Workpiece Spindle: Ksdsruakgspfx Akwonb Drilling of Large Diameters: 5 3/64" Cone Upward Gradient on 304.8 mm (1 Foot): 21/32" Deep One of the Cone: 5.29" Diameter of the Whole Spindle Perforating: 3.35" Speeds: B-Axle Workpiece Headstock Drag Axis: 30 Degrees A-Axle Workpiece Spindle Number of Revolutions: 0 83 min-1 X-Axis Horizontal: 80 mm/sec Y-Axis Vertically: 80 mm/sec Z-Axis Carriage Baseplate: 80 mm/sec Space Requirement L x W x H (Approximate): 4.75 x 3.40 x 2.54m / 188" x 134" x 100" Machine Weight (Approximate): 10980 kg / 24,156#

Condition: ready for operation (used), Year of construction: 1995, functionality: fully functional, machine/vehicle number: 4304, rotary table diameter: 600 mm, grinding height: 450 mm, overall weight: 14,500 kg, Machine is equipped with 3 spindles, surface grinding, external grinding, bore grinding Turret head B-axis with 1° division Belt filter system included Kedpfx Ajvt A Rtskwenb

Condition: excellent (used), travel distance X-axis: 1,500 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 750 mm, table width: 1,500 mm, table length: 850 mm, rotational speed (max.): 2,500 rpm, quill stroke: 120 mm, SHW UF 5 Travels - X-axis (rotary table): 1,500 mm - Y-axis (vertical headstock): 1,000 mm - Z-axis (horizontal headstock): 750 mm Control system - CNC control: Heidenhain TNC 355 Automatic swivel head (change between horizontal and vertical machining) Quill 120mm Milling spindle holder SK 50 Speed 2500 rpm Partial overhaul 2014 - Year of construction 1990 - Inspection/repair 2025 Table assembly - Travel distance: X = 1,500 mm - Clamping surface: 1,500 x 800 mm Chip conveyor Splash guard cabin We have ALL spare parts for this series (SHW UF 5) in stock! About us: MBM Maschinenservice & Gebrauchtmaschinen GmbH is an independent specialist for SHW machine tools. Our main focus is in the field of tool milling machines. Our services include spare parts deliveries, on-site customer service, machine overhauls and control system modernizations. Services: - Used machines - Spare parts - Customer service - Machine service - Machine overhauls - Control modernization _____ Used machine - used milling machine - used bed type milling machine - orthogonal milling head - metalworking - tool milling machine - milling head - SHW machine - SHW spare parts - milling machine used - milling machine used - CNC milling machine used - drilling milling machine used - milling machine metal used - metal milling machine used - metal milling machine used metal milling machine used - used cnc milling machine - cnc milling machines - cnc milling machines - milling machine - large part machining - large part machining - large part machining - cnc large part machining - milling - shw - uf5 - uf 5 - Uniforce - SHW UF - SHW Uniforce - SHW Uniforce 5 - UFZ 5 - UFZ5L - UFZ 5 L - MBM Milling Machine - MBM Machine Knedpfxsvfm I Tj Akwjb

Condition: used, Year of construction: 1998, Technical details: max. module: 7 weight of the machine ca.: 5 t worm grinding diameter: 280-350 mm width of grinding worm: 84-104 mm min. number of teeth: 6 max. number of teeth: 600 max. top circle diameter: 360 mm max. workpiece weight: 60 kg with Turbo Separator, loading unit, latest-generation balancing and dressing unit and various accessories Knjdpfszgw I Nex Akwjb *

Year of construction: 2016, condition: ready for operation (used), Offered is a high-precision worm and thread grinding machine MIKROMAT 20G, used as a test and trial machine, nearly all available options included, technically flawless condition. Capabilities: external thread grinding, internal thread grinding, whirling Whirling, grinding length max. 2000mm, workpiece diameter max. 320mm, distance between centers: 2250mm NC tailstock option: 2050mm, workpiece weight max. 200kg 350kg NC tailstock, pitch range: 0-400mm, 7-axis system, feed speed: up to 15000mm/min, setting angle: +/-40°, positioning accuracy: uncertainty 0.0024mm P, upgrade to 23.5kW continuous power/45kW maximum power, grinding wheel speed: up to 50m/s, special equipment internal grinding: internal thread diameter up to 100mm, length up to 50mm, coolant system: KNOLL compact unit vacuum rotary filter, 2500l tank volume and oil cooling, installation dimensions X/Y/Z: approx. 6500mm/4000mm/3000mm, total weight: approx. 13000kg, inspection possible by arrangement. Kedpfxoylbr Do Akwenb

Condition: used, Year of construction: 2013, max. wheel diameter 260 mm gear width 320 mm max. module 4,5 min. module 0,5 Control SIN 840D max.helical angle +/- 45 ° Kjdpfx Asx R U Hgjkwjnb total power requirement 68 kW weight of the machine ca. 15,50 t dimensions of the machine ca. 3,25 x 3,25 x 3,30 m Fire extinguishing system Siemens Sinorix TM Knoll Filtering system VL1500/8000 year 2017 Wekal loading cell

Condition: used, TECHNICAL DETAILS TRAVELS - Travels on X/Y/Z axes : 600x400x310 [mm] - Travels on U/V axes : [mm] - Max. taper : [°/mm] PART - Max. part dimensions : 1050x820x300 [mm] - Max. part weight : 1000 [kg] WIRE GUIDE - Wire diameter : 0.1-0.3 [mm] - Coil weight : 16 [kg] POWER SUPPLY - Supply voltage : 380 [V] - Total installed power : 13 [kVA] WEIGHT & DIMENSIONS - Machine floor space : 2650x3050 [mm] - Machine height : 2070 [mm] - Machine weight : 3600 [kg] MACHINE HOURS - Spark erosion hours : 2000 [h] EQUIPMENT - CNC : Fanuc 31iw-model B - Cooling unit - Filtration unit Knjdpfxjyxhmio Akwjb

Condition: excellent (used), Mikron Gear Hobbing Machine A33/0 – for Module 0.5 to 2.5 – rarely used Manufacturer: Mikron Kodpfx Aox A D Izjkwsnb Model: A33/0 – Gear Hobbing Machine (vertical) Version: Base machine with standard milling head Condition: used, very good condition, machine has been rarely operated Color: green Technical Data Max. workpiece diameter: approx. 80 mm Max. hobbing length: approx. 150 mm Module range: approx. 0.5 – 2.5 Ideal for small gears in the module range 0.5 – 1.0 Main drive: 3 kW Electrical connection: 3 x 380 V AC, 50 Hz Total power consumption: approx. 9.5 kVA Dimensions & Weight L x W x H: approx. 1,450 x 1,380 x 2,080 mm Weight: approx. 2,200 kg Special Features Very well-suited for manufacturing small gears (module 0.5 – 1.0) Machine was rarely used in production, therefore minimal wear Availability / Service Detailed photos and operating video available upon request Quotation including price, delivery terms, and lead time possible Subject to prior sale and errors.

Condition: good (used), Year of construction: 2007, Height of points 150 mm Distance between points 1000 mm Grinding wheel dimensions (h x id x w) Ø400xØ127x50mm Internal head 4 pcs Center height 150mm Max. workpiece weight 80Kg X-axis travel (transverse) 350mm X axis speed 10 meters per minute Z axis travel (longitudinal) 1000mm Z-axis speed 12 meters per minute Z-axis resolution 0.00004" B-axis turning range 210° B-axis resolution 0.00004 B-axis resolution 0.0001° B-axis resolution 0.0001 Drive capacity 10 HP Grinding wheel diameter 400mm Max. width Grinding wheel width 63mm Spindle Speed Range 0-1000 RPM Spindle turning range 0° - 90° Tailstock stroke 30mm Tailstock stroke 30mm Equipped with Fanuc 21i-TB CNC Control Dimensions 3350x 2130x 2130 Weight 4535Kg Knedpfx Akerakimjwjb Accessories: Steady rests, magnetic chuck, 3-jaw chuck, balancer, sensitron 6, coolant with paper and magnetic filter, fume extractor, etc.

Condition: excellent (used), Year of construction: 2015, With a focus on optimized and energy-efficient drives in the automotive industry, significantly higher demands are placed on the components of the drive system. Higher power transmission, higher torques, and a smaller overall size are the challenges. This development has led to an increased need for cold-formed splines. With the vertical spline press (VSP), Sack & Kiesselbach provides customers with a solution that offers technological and logistical advantages compared to conventional technologies (such as rolling or broaching). The relatively small and very user-friendly press can be configured for both manual and automated operation. In addition to the spline press, the customer can also obtain the appropriate tooling system and the corresponding process technology from a single source. 1 used vertical spline press Manufacturer: Sack & Kiesselbach Type: VSP 50/30 Year of manufacture: 2015 Technical data: Press force: 500 kN Ram stroke: 450 mm Closing speed: 200 mm/s Pressing speed: 5.5 mm/s Opening speed: 120 mm/s Table dimensions: 500 x 400 mm Installation height: 1000 mm Distance between columns: 530 mm Spline cylinder speed: 3-9.5 mm/s Dimensions: Height: 2900 mm Width: 3100 mm Depth: 1400 mm Drive power: 8 kW Special equipment: Digital position measuring system Kedpfx Ajgtty Tekwjnb Spline tool for internal gearing
