Vertical splines press

Sack & Kiesselbach VSP 50/30

Condition: good (used), Year of construction: 2000, gear diameter: 449 mm, Equipped with: Fanuc 150MB CNC Control Dry Cutting Cutter Shroud Chip Evacuation System Auto Doors Hydraulic System Lubrication System Work light Stack Light Specifications: Largest Speed Ratio: 10:01 Work Area (Continuous): Largest Depth of Teeth: 15.24 mm Largest Width of Tooth Face: 50.8 mm Work Area Axis: Horizontal Movement X Axis: -114 - 178 mm Vertical Movement Y Axis: -178 - 190 mm Movement of the Carriage Baseplate Z-Axis: -10.16 - 500 mm Workpiece Headstock Swiveling Range B-Axis: -3 - 90 Degree Maximum Distance Machine Center to Spindle Side: 165 mm Number of Teeth: 5-200 Inclusive Max. Gear Pitch Dia. of Typical 35 Deg. Spiral Angle Gear Using Max. Cutter Dia. 12" Cutter at the Following Ratios: Face Milling 1 x 1 - 13.5" - 342.9mm 2 x 1 - 16.0" - 406.4mm 5 x 1 - 17.7" - 450.0mm Face Hobbing (210mm Dia. Cutter) 1 x 1 - 10.560" - 268.22mm 2 x 1 - 10.286" - 275.00mm 5 x 1 - 11.810" - 300.00mm Milling Head Diameter: Helixact: 100,125,169,200,250,320mm Continuous Gumption Procedure, Teichloroethylene: 102 - 210 mm Workpiece Spindle: Drilling of Large Diameters: 5 3/64" Hfodpfx Aoruakgsc Noh Cone Upward Gradient on 304.8 mm (1 Foot): 21/32" Deep One of the Cone: 5.29" Diameter of the Whole Spindle Perforating: 3.35" Speeds: B-Axle Workpiece Headstock Drag Axis: 30 Degrees A-Axle Workpiece Spindle Number of Revolutions: 0 83 min-1 X-Axis Horizontal: 80 mm/sec Y-Axis Vertically: 80 mm/sec Z-Axis Carriage Baseplate: 80 mm/sec Space Requirement L x W x H (Approximate): 4.75 x 3.40 x 2.54m / 188" x 134" x 100" Machine Weight (Approximate): 10980 kg / 24,156#

Condition: good (used), 1 used single-sided press Make: SACK & KIESSELBACH, year of construction: 1962,74 serial number 31900 Pressing force 630 t, stroke 310 mm Hjdeul U Svjpfx Ac Njfh Installation height 320 mm Working height 1200 mm Drive power 10 KW

Condition: good (used), Year of construction: 2005, Machine type: cylindrical grinding machine Hfjdpfx Aekyrqijc Nsh Manufacturer: Junker Model: Jumat 5340/s Serial number: 2328 Year of manufacture: 2005 Available immediately Ex site for self dismantling Optionally we can offer dismantling and loading

Condition: used, Year of construction: 2006, Technical details: grinding diameter: 5-55 mm grinding length: 500 mm Hodpfxjvg Thie Ac Nefh total power requirement: 44 kW -- Intended use and general information -- Fully automated external and surface grinding of synchronous rings Centre height: 200 mm Grinding length: 500 mm Grinding wheel arrangement: right, 30° angled Grinding wheel dimensions: 600 x 30 x 203.2 mm Drive power: 7 kW X/Z axis drive: ball screw Travel speed: 0.01 - 10,000 mm/min. Resolution: 1 µm Concentricity of workpiece spindle: < 1 µm Workpiece changing system: Fanuc robot Control: Siemens Sinumerik 840-D Machine weight: 7,000 kg Centre height: 200 mm Grinding length: 500 mm *

Condition: excellent (used), Mikron Gear Hobbing Machine A33/0 – for Module 0.5 to 2.5 – rarely used Manufacturer: Mikron Model: A33/0 – Gear Hobbing Machine (vertical) Version: Base machine with standard milling head Condition: used, very good condition, machine has been rarely operated Color: green Hjdpfx Acox A D Ize Nsfh Technical Data Max. workpiece diameter: approx. 80 mm Max. hobbing length: approx. 150 mm Module range: approx. 0.5 – 2.5 Ideal for small gears in the module range 0.5 – 1.0 Main drive: 3 kW Electrical connection: 3 x 380 V AC, 50 Hz Total power consumption: approx. 9.5 kVA Dimensions & Weight L x W x H: approx. 1,450 x 1,380 x 2,080 mm Weight: approx. 2,200 kg Special Features Very well-suited for manufacturing small gears (module 0.5 – 1.0) Machine was rarely used in production, therefore minimal wear Availability / Service Detailed photos and operating video available upon request Quotation including price, delivery terms, and lead time possible Subject to prior sale and errors.

Condition: used, Year of construction: 2000, Technical details: max. wheel diameter: 180 mm gear width: * mm max. module: 4 total power requirement: 14 kW weight of the machine ca.: 8 t Hsdpfx Aceyk Ur Uo Nsfh slide travel axial ( Z-axis ): 300 mm work piece - max.: 490-640 mm

Condition: used, TECHNICAL DETAILS - part holder spindle speed : 1500 [Rpm] - tool holder spindle speed : 3000 [Rpm] - max part Ø : 50 [mm] - dimensions : 2820 x 2400 x 2500 [mm] - weight : 4200 [kg] EQUIPMENT - CN SIEMENS 840D - STAUBLI robot 6 axes TX60 with CS8C control - deburring device Hfjdsuhbp Eepfx Ac Nsh

Condition: used, Year of construction: 2005, ratio of transmission 10:1 min. number of teeth 3 max. number of teeth 200 range of tooth size 20 mm tooth width max. 58 mm diameter of tools min 69,85 mm diameter of tools max. 230 mm x-axis 325 mm y-axis 350 mm z-axis 470 mm Hsdpfx Aceynmm Es Nefh work piece table - Ø 212,71 mm b-axis + 90,1 / - 1 ° Control SIN 840 D SIEMENS total power requirement 75 kW weight of the machine ca. 10.000 Kg dimensions of the machine ca. 6,10 x 4,40 x 3,30 m WAGURI with EWAB load cell built in 2012 (Linear loader) no coolant filter system available

Condition: excellent (used), Year of construction: 2014, functionality: fully functional, turning length: 800 mm, bar diameter (max.): 104 mm, 1 DMG Mori CTX 800 TC, year 2014 Control unit: Siemens 840 D SL with Shop-Turn 3 G Turning length: 800 mm Main spindle as integrated spindle motor ISM 76 with 5,000 rpm Hydraulically actuated collet chuck 104 mm Draw tube inner diameter: 104 mm C-axis with spindle brake Upper cross slide with turning/milling spindle HSK 63 Hfodpfsy Svvrjx Ac Njh As motor spindle with hydraulic clamping during turning Y-axis ±100 mm, B-axis ±110° Tailstock automatic/programmable Absolute linear measuring systems in X and Y axes 5-axis simultaneous machining Technology cycles Tool magazine with 48 stations HSK 63 Differential pressure clamping Chip conveyor, ICS (internal coolant supply) Automatic positionable steady rest slide Z-axis slide for steady rest carrier Steady rest incl. quick-change system Tropical package Infrared measuring probe Renishaw Oil mist separator

Condition: like new (used), Year of construction: 2015, machine/vehicle number: IntNr231595, WICKI CG12GE – Centerless Grinding Machine Year of manufacture: 05/2015 The WICKI CG12GE is a high-precision centerless grinding machine for efficient series production of cylindrical parts with small to medium diameters. The machine operates without clamping between centers. The workpiece is continuously guided between the grinding wheel, regulating wheel, and support blade, ensuring extremely high dimensional stability and surface quality while maintaining high productivity. Grinding processes - Through-feed grinding for continuous series production - In-feed (plunge) grinding (centerless) for short precision parts and shoulders Technical data (approx.): - Grinding range: Ø 1 – 30 mm - Workpiece length: up to approx. 140 mm (depending on process) - Grinding wheel: Ø 305 × 150 × 127 mm - Regulating wheel: Ø 205 × 150 × 90 mm - Grinding wheel speed: approx. 1,900 rpm - Grinding speed: approx. 30 m/s Hfedpfx Acsy U Hgts Njh - Grinding wheel drive power: approx. 5.5 kW - Regulating wheel drive power: approx. 1.3 kW - Total connected load: approx. 10 kW / 400 V Features & advantages - Very high roundness and dimensional accuracy - Ideal for series and mass production - Short cycle times due to continuous material flow - Robust industrial design suitable for continuous operation - Minimal setup and operating requirements - Excellent surface finish quality Fields of application - Automotive supply industry - Hydraulic and pneumatic components - Precision shafts, pins, and bolts - Mechanical engineering and series production - Metalworking and contract manufacturing Gross weight: approx. 1,750 kg Dimensions: approx. 2250 x 1100 x 1700 mm The machine can be inspected under power by appointment. We reserve the right to make changes and correct errors in the technical data and information. Subject to prior sale!
