Königswieser forestry winch KGD 30 M

Königswieser

Condition: new, The Königswieser KGD 85 SA is a hydraulically controlled professional forestry winch with an 8.5-ton pulling force and hydraulic rope payout. It is designed for demanding forestry operations and is particularly suitable for heavy timber extraction. The robust design, the Hardox blade edge, and the durable duplex chain ensure high load-bearing capacity and reliable operation. The hydraulic rope payout, the radio remote control, and the end limit switch provide high operating comfort and additional safety during professional use. Rope: 80 m / 13 mm HV Mounting category: II + III Lower rope inlet: fixed Blade edge: Hardox Nwedps Adhc Njfx Ai Tjn Radio remote control: SBS Funk Blade width: 2.00 m Pulling force: 8.5 t Hydraulic rope payout: standard End limit switch: standard Weight without rope: approx. 711 kg Self-contained oil supply: yes Rope speed: 0.6 m/s Control: hydraulic

Condition: new, The Königswieser KGD 80 SA is a hydraulically controlled, professional forestry winch with a pulling force of 8.0 t. It is designed for large tractors with approximately 80 hp and is suitable for demanding forestry applications. The KGD 80 SA is equipped as standard with hydraulic cable payout and a continuously adjustable cable infeed brake. The robust design, the high-quality powder coating, and the reinforced drive chain ensure reliable operation and high power transmission, even with heavy loads. Cable: 80 m / 12 mm HV Band brake / dead man's switch: standard Nedj Adhc Aspfx Ai Tjwn Cable payout control: continuously adjustable Weight without cable: approx. 756 kg Remote control: SBS radio Infeed brake: standard End stop: standard Folding protective grille: standard Suitable for tractors from: approx. 80 hp Hydraulic cable payout: standard Attachment device: standard Lower idler pulley: standard Shield width: 1.80 m Drive power: from 59 kW Pulling force: 8.0 t Control: hydraulic

Condition: new, The Königswieser KGD 65 SA - 1900 is a hydraulically controlled forestry winch with a pulling force of 6.5 tons and hydraulic cable payout. Its shield width of 1.90 m provides particularly wide support and makes it suitable for demanding forestry operations. The hydraulic cable payout with adjustable speed supports comfortable and controlled cable extension. The robust design, high-quality powder coating, and reinforced drive components ensure reliable operation even with heavy loads and long cable lengths. Weight without cable: approx. 500 kg Shield width: 1.90 m Drive power: from 45 kW End stop: standard Folding protective grille: standard Pulling force: 6.5 t Cable payout regulation: stepless Nedpfx Ae Adhcvoi Town Attachment device: standard Gearbox: standard Lower deflection pulley: standard Infeed brake: standard Radio remote control: SBS radio Hydraulic cable payout: standard Cable: 80 m / 11 mm HV Band brake / dead man's switch: standard Control: hydraulic

Condition: new, The Königswieser KGD 65 SA is a hydraulically controlled forestry winch with a 6.5-ton pulling force and hydraulic rope payout. It is designed for tractors with approximately 55 hp and is particularly suitable for demanding operations and handling heavy timber. The hydraulic rope payout with adjustable speed provides comfortable and controlled rope extension. The robust design, high-quality powder coating, and reinforced drive components ensure reliable operation even with heavy loads and long rope lengths. Folding protective grille: standard Drive power: from 40 kW Rope payout regulation: infinitely adjustable Hydraulic rope payout: standard Nsdpfxs Adhcpo Ai Town Pulling force: 6.5 t Control: hydraulic Lower deflection sheave: standard Gearbox: standard Remote control: SBS radio Rope: 80 m / 11 mm HV End stop: standard Infeed brake: standard Hitch: standard Band brake / dead man switch: standard Suitable for tractors with: approx. 55 hp Weight without rope: approx. 485 kg Width: 1.70 m

Condition: new, The Königswieser KGD 65 EH Terra S1 is a hydraulically controlled forestry winch with a pulling force of 6.5 tons. It is designed for tractors with approximately 55 horsepower and is particularly suitable for demanding tasks and heavy timber. The Terra S1 radio control system allows for comfortable control of important winch functions. The robust design, high-quality powder coating, and reinforced drive components ensure reliable operation in forestry applications. Radio control: Terra S1 Control: hydraulic Gear ratio: standard Weight without cable: approx. 473 kg Cable: 80 m / 11 mm HV Nsdpfxo Adhcij Ai Town Attachment device: standard Pulling force: 6.5 t Cable payout adjustment: continuously variable Band brake / dead man's switch: standard Folding protective grille: standard Suitable for tractors with: approx. 55 HP Drive power: from 40 kW Shield width: 1.70 m Lower deflection pulley: standard

Condition: new, The Königswieser KGD 65 EH is a hydraulically controlled forest winch with a pulling force of 6.5 tons. It is designed for tractors with approximately 55 hp and is particularly suitable for demanding applications and handling heavy timber. The robust design, high-quality powder coating, and reinforced drive components ensure reliable operation in forestry work. Thanks to the electro-hydraulic operation and hydraulic self-supply, the KGD 65 EH offers a high level of operating comfort while providing powerful performance. Hitch: Standard Weight without rope: approx. 473 kg Suitable for tractors from: approx. 55 hp Gearbox: Standard Lower sheave: Standard Pulling force: 6.5 t Drive power: from 40 kW Band brake / dead man's switch: Standard Nwjde Adhccepfx Ai Ten Folding protective grille: Standard Control: hydraulic Rope payout regulation: stepless Rope: 80 m / 11 mm HV Shield width: 1.70 m

Condition: new, The Königswieser KGD 55 SA - 1700 is a hydraulically controlled forestry winch with a pulling force of 5.5 tons and hydraulic cable payout. Its 1.70 m shield width provides a wider support base, making it suitable for professional use in timber extraction. The hydraulic cable payout with adjustable speed facilitates comfortable and controlled cable extension. The robust all-steel construction, high-quality powder coating, and reinforced drive components ensure reliable operation even under demanding conditions. Radio remote control: SBS radio Control: hydraulic Pulling force: 5.5 t Suitable for tractors from: approx. 50 hp Shield width: 1.70 m Cable: 70 m / 10 mm HV Nwsdo Adhb Sepfx Ai Ton Cable payout regulation: infinitely variable Drive power: from 37 kW End stop: standard Infeed brake: standard Hydraulic cable payout: standard Hitch: standard Folding protective grid: standard Weight without cable: approx. 443 kg Lower deflection pulley: standard Band brake / dead man's switch: standard Reduction gear: standard

Condition: new, The Königswieser KGD 55 SA is a hydraulically controlled forestry winch with a 5.5-ton pulling force and hydraulic rope payout. It is designed for tractors with approximately 50 hp and offers a high level of operating comfort when working in the forest, thanks to the rope payout function. The hydraulic rope payout with adjustable speed facilitates comfortable and controlled rope extension. The robust all-steel construction, high-quality powder coating, and reinforced drive components ensure reliable operation even under demanding conditions. Nwjdpfx Ao Adhb Esi Ton Weight without rope: approx. 443 kg Band brake / dead man’s switch: standard Lower pulley: standard Attachment device: standard Rope: 70 m / 10 mm HV Pulling force: 5.5 t Folding protective grid: standard End stop: standard Control: hydraulic Hydraulic rope payout: standard Remote control: SBS radio Shield width: 1.50 m Drive power: from 37 kW Suitable for tractors from: approx. 50 hp Reduction gear: standard Infeed brake: standard Rope payout regulation: stepless

Condition: new, The Königswieser KGD 55 Q - 1700 is a hydraulically controlled forestry winch with a 5.5-tonne pulling force and SBS radio remote control. Its shield width of 1.70 m provides a wide support base and makes it suitable for professional use in timber extraction. Nodpfx Aie Adhbxe Tjwn The robust all-steel construction, high-quality powder coating, and reinforced drive components ensure reliable operation even under demanding conditions. The KGD 55 Q - 1700 is a comfortable solution for users looking for a powerful 5.5-tonne winch with a wider shield and radio remote control. Folding protective grid: standard Radio remote control: SBS radio Suitable for tractors from: approx. 50 hp Cable payout regulation: stepless Shield width: 1.70 m Cable: 70 m / 10 mm HV Weight without cable: approx. 530 kg Pulling force: 5.5 t Attachment device: standard Control: hydraulic Gearbox: standard Drive power: from 37 kW Band brake / dead man's switch: standard Lower pulley: standard

Condition: new, The Königswieser KGD 55 M is a mechanically controlled forestry winch with a pulling force of 5.5 tons. It is suitable for more professional use in timber extraction and is designed for tractors with approximately 45 hp or more. The robust all-steel construction, high-quality powder coating, and low-maintenance chain drive ensure a long service life and reliable operation in forestry applications. Hardened chain sprockets, a reinforced drive chain, the standard reduction gear, and massive steel struts provide the KGD 55 M with additional stability and strength. Control: mechanical Njdj Adhbrepfx Ai Tswn Drive power: from 33 kW Weight without cable: approx. 406 kg Reduction gear: standard Cable: 70 m / 10 mm HV Shield width: 1.50 m Cable payout adjustment: continuously variable Band brake / dead man's switch: standard Suitable for tractors from: approx. 45 hp Lower idler pulley: standard Pulling force: 5.5 t
