CNC Universal Cylindrical Grinding Machine

Karstens K11 1000

Condition: refurbished (used), Year of construction: 2026, Karstens K11 1000, Fully Equipped This cylindrical grinding machine has been completely overhauled at PS-Karstens. The machine has been inspected and is in very good condition. Since we specialize in Karstens cylindrical grinding machines, we can offer you a complete service (electrical and mechanical) for the machine after purchase. Technical Data: Center distance: 1000 mm Center height: 180 mm Workpiece weight: 100 kg (overhanging), 250 kg (between centers) Grinding wheel diameter: 400 mm Workpiece spindle: MK 4, stepless speed adjustment 30-450 rpm, swivel range 0 - 90 ° Tailstock: MK4, quill stroke 45 mm, fine adjustment with cylinder Lhodpsh Riwdofx Aiqol Quill force: 200-600 N, hydraulically operated via foot pedal Table inclination: 10 degrees Adjustment travel of the feed spindle: 80 mm Rapid traverse: 50 mm Coarse adjustment with air cushion: 280 mm Grinding spindle motor (external): 4 KW Grinding spindle motor (internal): 2.2 KW Workpiece spindle motor: 0.55 KW Machine weight: Net 3800 kg Feed drive via DC motor Air cushion-assisted rapid adjustment of the grinding spindle head for quick and safe approach to the grinding position. Separate drive for the spindles for external and internal grinding. Fully automatic operating sequence, feed movement via a wind rose switch: Rapid traverse forward, rapid traverse backward, grinding operation, feed stop, incremental feed. Automatic longitudinal grinding cycle Central coolant supply for all grinding points Workpiece spindle head with steplessly adjustable drive with a rotating and lockable spindle. Feed control for longitudinal grinding and plunge grinding, input for retraction, feed amounts, feeds, dwell times, rapid traverse Digital displays for grinding spindle B-axis, workpiece spindle, X-axis, Z-axis from HEIDENHAIN Paper band filter system, approx. 250 L Similar to Weiss/EMAG/GP cylindrical grinding machines/Studer/Kellenberger/Schaudt/Tschudin/Tacchella/Dannobat /Bahmüller/Fortuna

Condition: used, Year of construction: 1991, bore capacity in steel (diameter) 50 mm arm length 1100 mm workpiece height max. ca. 1000 mm bore capacity in cast iron 60 mm spindle taper MK 5 spindle turning speed range 28 - 2500 U/min Ljdpfx Aiju Sblwsqjhl feeds 0,05 - 2 mm/U quill stroke 300 mm distance basic plate - spindle nose 630 - 1380 mm crossrail adjustment vertical 750 mm total power requirement 6 kW weight of the machine ca. 4 t dimensions of machine L x W x H 2,74 x 1,14 x 2,59 mm - with thread cutting attachment - Accessories: box table 550 x 550 x 550 mm, vice, coolant

Condition: as good as new (ex-display), Year of construction: 2026, Karstens K11 1000 Premium Retrofit Cylindrical Grinding Machine Manufacturer: Karstens Technical Data: Center distance: 1100 mm Center height: 180 mm / (250 mm = Option) Workpiece weight: 100 kg unsupported, 300 kg between centers Grinding wheel diameter: 400 mm or 500 mm (external grinding wheel) Workpiece spindle: MK 4, infinitely variable speed adjustment 30-450 rpm, swivel range 0 - 90° Tailstock: MK4, quill stroke 45 mm Quill force: 200-600 N manually, (up to 2500 N possible, adjustable = Option) Table tilt: 10 degrees Adjustment travel of feed spindle: 80 mm Rapid traverse: 50 mm Rough adjustment with air cushion: 280 mm Grinding spindle motor (external): 4 KW / (5.5 KW = Option) Infinitely variable speed adjustment of the grinding wheel with potentiometer Grinding spindle motor (internal): 2.2 KW Workpiece spindle motor: 1.1 KW Hydraulic motor: 1.5 KW Lubrication motor: 0.1 KW Hydraulic tank: 80 liters Machine weight: Net 3800 kg Feed drive via DC motor Air cushion-assisted rapid adjustment of the grinding spindle stock for quick and safe approach to the grinding position. Separate drive for the spindles for external and internal grinding. Fully automatic operating sequence, feed movement via wind rose switch: Rapid traverse forward, rapid traverse backward, grinding operation, feed stop, incremental feed. Automatic longitudinal grinding cycle Central coolant supply for all grinding points Workpiece spindle stock with infinitely variable drive with a rotating and lockable Lhedpfx Aoiv Au Esiqjl spindle. New digital feed control with Siemens panel and Siemens PLC for longitudinal grinding and plunge grinding, input for retraction, feed amounts, feeds, dwell times, rapid traverse distances, compatible with the old Karstens feed control, with a color Siemens touch panel, scale in X and Z axis, manufacturer HEIDENHAIN. Similar to Weiss/EMAG/GP cylindrical grinding machines/Studer/Kellenberger/Schaudt/Tschudin/Tacchella/Dannobat /Bahmüller/Fortuna

Condition: as good as new (ex-display), Year of construction: 2026, Karstens K11 1000 Premium Retrofit Cylindrical Grinding Machine Manufacturer: Karstens Technical Data: Distance between centers: 1100 mm Center height: 180 mm / (250 mm = Option) Lsdpfx Aioh Rimmeqohl Workpiece weight: 100 kg cantilevered, 300 kg between centers Grinding wheel diameter: 400 mm or 500 mm (external grinding wheel) Workpiece spindle: MK 4, stepless speed control 30-450 rpm, swivel range 0 - 90° Tailstock: MK4, quill travel 45 mm Quill force: 200-600 N manual, (up to 2500 N possible, adjustable = Option) Table inclination: 10 degrees Travel of the infeed spindle: 80 mm Rapid traverse: 50 mm Rough adjustment with air cushion: 280 mm Grinding spindle motor external: 4 kW / (5.5 kW = Option) Stepless speed adjustment of the grinding wheel with potentiometer Grinding spindle motor internal: 2.2 kW Workpiece spindle motor: 1.1 kW Hydraulic motor 1.5 kW Lubrication motor 0.1 kW Hydraulic tank 80 liters Machine weight: Net 3800 kg Infeed drive via DC motor Air cushion-assisted rapid adjustment of the grinding spindle head for quick and safe positioning of the grinding position. Separate drive for the spindles for external and internal grinding. Fully automatic operating sequence, infeed movement via a wind rose switch: Rapid traverse forward, rapid traverse backward, grinding operation, infeed stop, incremental infeed. Automatic longitudinal grinding cycle Central coolant supply for all grinding points Workpiece spindle head with steplessly adjustable drive with a rotating and lockable spindle. New digital infeed control with Siemens panel and Siemens PLC for longitudinal grinding and plunge grinding, input for retraction, infeed increments, feeds, dwell times, clearance strokes, compatible with the old Karstens infeed control, with a color Siemens touch panel similar to Weiss/EMAG/GP cylindrical grinding machines/Studer/Kellenberger/Schaudt/Tschudin/Tacchella/Dannobat /Bahmüller/Fortuna

Condition: used, Year of construction: 1983, Bohrleistung in Stahl (-Ø 50 mm throat 1500 mm workpiece height max. 1380 mm Bohrleistung in Guß (-Ø 60 mm Abstand Spindelmitte bis Säule 320 - 1250 mm swival range +/- 180 ° base plate surface area 2640 x 1000 mm max. torque on the spindle 310 Nm Lhsdpetv Ikljfx Aiqol Bohrspindel-Ø/ Aufnahme 75 mm /MK 5 bore spindle stroke 310 mm spindle turning speed range 28 - 2500 U/min feed: 0,05 - 2 mm/U power capacity 4 kW weight of the machine ca. 4,3 t dimensions of the machine ca. 3,2 x 1 x 2,75 m cube table 500 x 500 x 500 mm

Condition: used, BROACHING MACHINE Lhjdpot Hr Dfsfx Aiqel

Condition: excellent (used), 1. Permanent-magnet chuck, D = 315 mm, with mounting flange according to DIN 55027, size 6. Ljdsd Eaauepfx Aiqohl

Condition: excellent (used), workpiece diameter 60 mm grinding depth 30 mm Ledpfx Asunt Egeiqjhl clamping length 1000 mm weight of the machine ca. 0,6 t dimensions of the machine ca. 0,5 x 0,5 x 2,1 m

Condition: used, Year of construction: 1964, Technical details: Lhedeu Ngr Djpfx Aiqol shaft diameter: max. 120 mm work piece - max.: 800 mm height of profile: Tiefe: max. 90 mm grinding spindle speed: nicht bekannt U/min Table dimensions: Ø 150 mm voltage: 380 V total power requirement: 1,1 kW weight of the machine ca.: 0,675 t dimension machine xH: 0,75 x 0,70 x 2,0 m Application: vertical internal cylindrical grinding of shafts face, and center grinding with shaft grinder. Spindle head technical details: -equipment shank grinder Ø 13mm 60°; clamping element Ø 6mm shank clamping head. -travel=vertical 950mm by handwheel and transversal 80mm by crank handle -abrasive device with diamond, adjustment crosswise= 80mm. Table other specifications: -with fixed tip holder 60°. -speed 63 / 125 rpm. -adjustment vertical 600mm, in height 1.100mm, operation manual. centering block: -prismatic guide accessories: -fixed tip L=180mm -fixed tip L=300mm -div. shank grinder -div. clamping and auxiliary tools *

Condition: refurbished (used), Year of construction: 2005, functionality: fully functional, machine/vehicle number: 019.3790, Machine undergoing repair/overhaul = estimated delivery time approximately 8-10 weeks. Lhodpfozbqzaex Aiqjl Technical data + accessories, see separate PDF.
