Vertical milling machine

KLOPP FS 11

Condition: excellent (used), Deckel FP1 AKTIV (3-Axis Active) Machine no.: 2102-3240 Year of manufacture: approx. 1988 Travel paths: X: 300 mm Y: 150 mm Z: 330 mm Table size: 600 x 210 mm Spindle taper: SK 40 – S20x2 Spindle speed: 40–2,000 rpm Motor power: 1.6 and 2 kW Power supply: 380 V, 50 Hz Equipment/Accessories: - Active digital readout, 3 axes, HEIDENHAIN type TNC 113 - Infinitely variable feed in X, Y, and Z axes - Vertical milling head quill travel: 60 mm - Vertical milling head swivels and extends 100 mm horizontally - Coolant system (coolant tank in machine base) - Documentation - Central lubrication system - Machine vice - Various toolholders/collets/tools Space required (L x W x H): 1,350 x 1,100 x 1,700 mm Weight: 850 kg The machine has been visually reconditioned and technically inspected. Geometry inspection videos can be provided upon request. Backlash Y axis: 0.1 mm Backlash X axis: 0.2 mm Backlash Z axis: 0.15 mm Runout horizontal spindle: 0.001 mm Runout vertical spindle: 0.001 mm Parallelism deviation Y axis: 0.002 mm (measurement path: 150 mm) Parallelism deviation X axis: 0.01 mm (measurement path: 300 mm) Geometry inspection videos can be provided upon request. The following parts have been renewed: - Gears in horizontal head replaced and gear shaft newly mounted Cgedjyll A Tspfx Af Hsu - New guide cover for Z axis + various attached parts - Machine refurbished - New LEDs installed - Y-axis chain tensioner overhauled - Reference point programming checked - Function test carried out

Condition: reconditioned (used), Year of construction: 1976, Universal tool milling machine Make: DECKEL Model: FP 1 Year of manufacture: 1976 - overhauled, repainted, RAL7035 light gray / RAL7012 basalt gray / RAL5008 gray-blue Mach. No.: 52860/08 Milling head number: 7296/80 Guarantee: 12 months single shift from delivery on the mechanics overhauled by us. The electrics and electronics are excluded from this, as they have only been subjected to a functional test. Cgodpfxjmhfrrj Af Hou For machines located outside of our northern Bavarian sales area, the travel costs must be borne by the customer. geometric acceptance with test report Accessories: - 3-axis digital display FAGOR Innova 30i-M, new - Fixed table 600 x 210 (T-slot: 12 mm) - Vertical milling head SK 40 with tightening thread S 20 x 2 - Coolant system - Operating instructions Used as seen The machine corresponds technically to the state of the year of manufacture.

Condition: used, Year of construction: 2003, Technical details: bore capacity in steel (diameter): 25 mm Cedpju Idhyjfx Af Hegu throat: 255 mm bore stroke: 140 mm spindle taper MT: MK 3 spindle speed:: 105 - 2980 / 8step U/min Distance spindle/table max.: min.: 350 / max.: 950 mm table clamping surface:: 420 x 270 mm table rotating: 360 ° table swivable approx.: 30° links / rechts drill table adjustment: 600 manuell mm column diameter: 100 mm current- max.: 400 V / 50 Hz A total power requirement: 0,9 kW weight of the machine ca.: 180 kg dimension machine xH: 0,6 x 0,5 x 1,8 m Equipment: Röhm quick-action chuck 3 - 16mm Switchover for clockwise/anticlockwise rotation for thread cutting *

Condition: good (used), Year of construction: 1980, Table size 1300 x 355 mm Tool holder, vertical + horizontal ISO 50 Travel X-axis 1000 mm Y-axis 350 mm Cgsdpfx Afovu Dv Tj Hsu Z-axis 450 mm Vertical milling head, swiveling R + L Quill stroke 100 mm Speed range 22.4 – 1400 rpm Feed range 6.3 – 630 mm/min Rapid traverse 2.5 m/min Drive power approx. 5 kW Space requirement L x W x H 1900 x 1800 x 2100 mm Weight 3200 kg Accessories / Special features: • 3-axis digital display, make FAGOR • Swiveling vertical milling head (R-L) with quill adjustment 100 mm • Vertical and horizontal milling spindle ISO 50 • Milling spindle vertical + horizontal • Large Clamping table 1350 x 350 mm • Feed and rapid traverse in all axes • Wide, stable guideways • Central lubrication • Swiveling control panel • Coolant system • EMERGENCY STOP switch Siegfried Volz Werkzeugmaschinen Rüschebrinkstr. 151-153 DE - 44143 Dortmund - Wambel

Condition: used, Description Cedpfovkxiyex Af Hogu Turning diameter over bed: 350 mm Turning diameter over support: 200 mm Turning length: 500 mm Speed range: 34-1500 rpm Space requirement approx.: 1600 x 1000 x 1400 mm Total power requirement: 2.2 kW Machine weight approx.: 1 t SYSTEM for thread cutting needs to be overhauled, not active. 1 used COLCHESTER STUDEN center & spindle lathe

Condition: used, Technical details: table diameter: 315 mm Cgjdpou N Dz Aofx Af Hsu rotatability of the table - manual/mechanic: 360 ° weight of the machine approx.: 100 kg dimensions: 620 x 530 x 135 mm The tables were rarely used other features: -with radial scale -surface is finished -center mounting MK3 -dividing circle 19 / 27 / 31 / 41 / 49 / 59 -operation also possible by machine via coupling on both sides (switchable right-/left-hand rotation with automatic changeover) -foot clamping: support size 360 x 420mm with 1 clamping groove on the front side 16 x 200mm *

Condition: used, Year of construction: 1982, Technical details: Cjdpju Ngxdsfx Af Hogu dimensions of grinding wheel: Ø 150 x 20 mm grinding spindle speed: 3600 U/min height over floor: 900 mm current type: 220 V machine weight approx.: 27 kg dimensions L x W x H: 0,37 x 0,35 x 1,4 m Double sanding bench sitting on foot stand (foot Ø 353mm) Left side with drill grinding device (angle 90° - 180°), longitudinal adjustment 25mm incl. accessories *

Condition: used, Technical details: Codpfxeu N Einj Af Hegu table surface area: 330 x 310 geschlichtet mm weight of the machine ca.: 25 kg dimension L-W-H: 430 x 400 x 420 mm Application: Machine table adjustable clamping angle with 3 T-slots according to DIN 650: a=17; H027; b=32; c=14mm distance 100mm swivelling via tooth guide +90° rotatable 360° Base Ø 350mm with 2x clamping groove Ø 17 x 25mm *
