Cylindrical Grinding Machine

KNUTH RSM 1000 C

Condition: new, The RSM 1000 C is a precision cylindrical grinder in the Conventional Cylindrical Grinders category, designed by KNUTH for processing long and heavy workpieces. This exceptional machine features a robust design with a large, heavy machine bed that accommodates workpieces up to 2000 mm in length and 320 mm in diameter, ensuring maximum accuracy and supporting high weights. Equipped with wide, precision-ground guideways, this grinder delivers outstanding surface quality thanks to its hydrostatic bearings, while the powerful grinding spindle motor is optimally designed for continuous operation. The RSM 1000 C includes an internal grinding device and a swiveling headstock which allows for conical grinding of short parts, enhancing its versatility for both individual and small series production. Its extensive standard equipment package, such as a 3-axis position indicator and a coolant system, adds to its appeal. For any needs in the Conventional Cylindrical Grinders category, request a quote today to explore how the RSM 1000 C can enhance your grinding operations. Nedpfx Ahsuy Ia Rs Dsli

Condition: good (used), Year of construction: 2004, TBT ML 200-2-800 deep hole drilling machine TECHNICAL DATA Type: ML 200-2-800 Year of construction: 2004 Control: Simatic OP17 Number of spindles: 2 Spindle distance: 12 mm Drilling slide stroke: 800 mm Drilling range: 1 - 10 mm Process: Single-lip drill Drilling depth: Immersion spindle: 110 mm Seal housing: 430 mm Nodpfjvcbg Sox Ah Deli Sealing housing with steady rest: 400 mm Spindle drive: Power: 1.7 / 2.9 / 1.3 Voltage: 240 / 350 / 350 V Frequency: 100 - 800 Hz Weight: Approx. 2.6 T We assume no liability for the accuracy, completeness and up-to-dateness of the information provided

Condition: excellent (used), Year of construction: 1970, Model: AR 1000 - Year of manufacture: 1970 – 1991, geometrically overhauled - Condition: good to very good - Grinding diameter: max. 350 mm - Grinding length: 1000 mm - Plunge grinding length: 100 mm - Centre height: 180 mm Nljdpsxfvyzsfx Ah Dji - Centre taper: 60 MK4 - Grinding wheel dimensions: max. 500 Ø x 300 Ø x 80 mm - Swivelling grinding head: +/- 45° - Dimensions: 3.2 x 1.7 x 1.6 m (LxWxH) - Space requirement: 4.13 x 2.02 x 1.6 m (LxWxH) - Weight: approx. 4,300 kg - Operating voltage: 380 V - Power: 7.5 kW (total 11.6 kW)

Condition: new, Year of construction: 2025, CNC centers have been designed based on proven components that guarantee reliability for a long time of use. The massive machine body ensures efficient and precise machining. Hermetic chamber ensures safety and cleanliness at the workplace. The table with a hardened surface can accept workpieces without loading the mechanical elements of the structure. Each machine in this series is equipped with an efficient cooling system to ensure optimal cutting conditions. Description Linear guides Top quality guides for all axes Massive machine body Good accessibility of the work table Hermetic working chamber ensuring work safety CNC control (SIEMENS SINUMERIK 808D) Technical parameters Nsdperh Ewksfx Ah Dsli Spindle taper BT40 Table dimensions 1000 x 500 mm The distance between the spindle and the table surface 620 mm The distance between the spindle and the column 530 mm Table travel 800 x 500 mm Z axis movement range 500 mm Spindle speed range up to 10 000 rpm Number / width / spacing of T-slots 4 / 18 mm / 120 mm Working feed 2000 mm/min Rapid feed X,Y,Z 15 m/min Number of tools in the magazine 24 Power (torque) of feed drives 1,75 / 1,75 / 3,5 kW Spindle motor power 5,5 kW Power supply, total power 400V / 18 kW Max. table load 500 kg Weight 5000 kg Dimensions (L x W x H) 2800 x 2300 x 2700 mm
