Injection molding machine

KraussMaffei

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, clamping force: 9,500 kN, screw diameter: 120 mm, ejector stroke: 300 mm, opening stroke: 1,900 mm, TECHNICAL DETAILS Clamping force: 9,500 kN Opening force: 665 kN Tie bar distance: 1,400 x 1,150 mm Clamping plates: 1,960 x 1,710 mm Opening stroke: 1,900 mm Min. mould height: 500 mm Max. mould height: 1,200 mm Max. opening width: 2,400 mm Ejector stroke: 300 mm High-performance screw HPS-UN, diameter: 120 mm Nozzle radius: 30 mm Nozzle opening: 12 mm Screw diameter: 120 mm Shot weight (HDPE): 5,420 g Shot volume: 7,634 cm³ Specific injection pressure: 2,257 bar MACHINE DETAILS Dsdey T H A Eopfx Aktjkn Dimensions & Weight Dimensions (L x W x H): 12,770 x 3,420 x 2,750 mm Machine weight: 61.5 t

Condition: ready for operation (used), Year of construction: 2002, functionality: fully functional, machine/vehicle number: 424227, clamping force: 4,200 kN, screw diameter: 80 mm, injection pressure: 1,829 bar, injection weight: 1,304 g, opening stroke: 1,400 mm, TECHNICAL DETAILS Clamping force: 4,200 kN Platen size (H x W): 1,270 x 1,200 mm Tie bar spacing (H x W): 800 x 800 mm Minimum mold height: 380 mm Maximum mold height: 1,020 mm Max. opening stroke: 1,400 mm Screw diameter: 80 mm Injection volume: 1,433 cm³ Shot weight: 1,304 g (PS) Max. injection pressure: 1,829 bar Max. temperature: 375 °C MACHINE DETAILS Supply voltage: 400 V Phases: 3~ Frequency: 50 Hz Total current consumption: 237 A Fuse rating: 250 A Pump power: 75 kW Heating power: 36 kW Dimensions & Weight Dimensions (L x W x H): 7.06 x 2.33 x 2.51 m Machine weight: approx. 22,000 kg Dkodsy T Hwiepfx Aktjn

Condition: ready for operation (used), Year of construction: 2011, functionality: fully functional, clamping force: 8,500 kN, screw diameter: 135 mm, clearance between the columns: 1,140 mm, ejector stroke: 300 mm, TECHNICAL DETAILS Mold closing force: 8,500 kN Mold opening force: 560 kN Dimensions of the mounting plate (h x w): 1,600 mm x 1,600 mm Distance between columns (h x w): 1,140 mm x 1,140 mm Mold opening distance: 1,600 mm Mold height (min-max.): 500 mm - 1,100 mm Opening width: 2,100 mm Ejector stroke: 300 mm Ejector force: 200 kN / 100 kN Screw diameter: 135 mm Injection pressure: 1,389 bar Injection volume: 8,588 cm³ Injection weight per part: 6,098 g Injection rate: 1,414 cm³/s MACHINE DETAILS Electro-hydraulic system Motor rated power of the pump: 132 kW Dry cycle time according to Euromap 6: 965 1/h Dsdpfx Aey T Hmksktskn Oil tank capacity: 2,440 l Open nozzle with nozzle radius: 25 mm Nozzle opening: 9 mm Dimensions & Weight Installation space dimensions (L x W x H): 11.72 m x 2.92 m x 2.71 m Net weight with control unit: 49 t EQUIPMENT Krauss Maffei robot LRX 500 MC 5 control system with color monitor Integrated control panel and USB data storage Complete plasticizing unit for thermoplastics Check valve

Condition: ready for operation (used), Year of construction: 2008, functionality: fully functional, clamping force: 11,000 kN, screw diameter: 120 mm, injection pressure: 1,758 bar, injection weight: 6,175 g, opening stroke: 2,000 mm, KraussMaffei KM 1100–12000 MX including WITTMANN robot! TECHNICAL DETAILS Clamping force: 11,000 kN Opening force: 770 kN Platen size (H × V): 2,210 × 1,910 mm Tie bar distance (H × V): 1,550 × 1,250 mm Opening stroke: 2,000 mm Tool height (min. - max.): 600 - 1,200 mm Platen stroke: 2,600 mm Ejector stroke: 300 mm Ejector force: 220 / 110 kN Screw diameter: 120 mm Injection pressure: 1,758 bar Shot volume: 6,786 cm³ Shot weight (PS): 6,175 g Screw speed (Standard / Option): 103 / 145 rpm Injection rate (Standard): 1,118 cm³/s Injection rate (Accumulator): 1,696 cm³/s MACHINE DETAILS Djdpoy T Hd Nefx Aktjkn Electro-hydraulic system Rated power of pump motors: 132 kW Installed heating capacity: 82 kW Number of heating circuits on the cylinder: 7 Cycle time (Euromap): 802 1/h Oil tank volume: 2,440 l Dimensions & Weight Machine dimensions (L × W × H): 12.47 × 3.65 × 2.82 m Net weight with control cabinet: 73 t EQUIPMENT Robot: Wittmann MC5 control system with color monitor, integrated control panel and three USB ports

Condition: ready for operation (used), Year of construction: 2001, functionality: fully functional, clamping force: 8,000 kN, screw diameter: 95 mm, clearance between the columns: 1,120 mm, injection pressure: 1,795 bar, ejector stroke: 250 mm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Clamping Unit Injection force: 8,000 kN Distance between columns (h x v): 1,120 mm x 1,000 mm Maximum mold opening distance: 1,400 mm Minimum/maximum tool mounting height: 600 mm / 1,100 mm Opening stroke of the clamping plate: 2,000 mm Ejector stroke: 250 mm Ejector force: 226 kN (rearward: 59 kN) Dkodpfx Akoy Ulhcotsn Injection Unit Screw diameter: 95 mm L/D ratio: 23 Injection pressure: 1,795 bar Injection volume: 3,367 cm³ Injection size for PS: 3,064 g Injection rate: 690 cm³/s Nozzle clamping force: 166 kN MACHINE DETAILS Control model: MC4 Connected power of pumps: 90 kW Heating capacity: 61 kW Dimensions & Weight Machine dimensions (L x W x H): 10.4 m x 2.86 m x 2.39 m Net weight: 45 t

Condition: used, Year of construction: 1998, operating hours: 99,161 h, clamping force: 32,000 kN, screw diameter: 130 mm, injection weight: 8,100 g, total length: 4,900 mm, total height: 4,200 mm, overall weight: 230,000 kg, # Sales Description A high-performance injection molding machine from the German manufacturer KraussMaffei is available for sale. This is the KM 3200-19000 MC model, specifically designed for the production of large-sized plastic components and industrial series manufacturing. The machine offers very high clamping force and is particularly suitable for applications involving technical plastic parts or large-scale items. The machine features a clamping force of 32,000 kN, a screw diameter of 130 mm, and a maximum shot weight of 8,100 g. This allows for the efficient production of large parts with high material requirements. In addition, the system is equipped with extensive peripheral equipment, including a robot interface for KUKA KRC4, a S.I.S.E. IS’Tech sequential injection controller, GWK temperature control units, and a Motan Colormetric dosing and mixing system. A belt conveyor is also included in the package. Technical Data * Manufacturer: KraussMaffei * Model: KM 3200-19000 MC * Machine No.: IMM MC3F No.12 * Year of manufacture: 1998 * Operating hours: approx. 99,161 h Performance * Clamping force: 32,000 kN * Screw diameter: 130 mm * Max. shot weight: 8,100 g Dimensions and Weight * Machine weight: approx. 230,000 kg * Machine depth: approx. 4,900 mm * Machine height: approx. 4,200 mm The machine represents a robust and proven solution for industrial plastics processing and is especially suitable for manufacturers requiring large-format injection molding capacity. Dkedpfxoyt H Dhe Akton Further information, photos, or inspection appointments are available upon request.

Condition: used, Year of construction: 1998, operating hours: 98,806 h, clamping force: 40,000 kN, screw diameter: 130 mm, injection weight: 8,100 g, total length: 4,900 mm, total height: 4,200 mm, overall weight: 255,000 kg, 2x KraussMaffei KM 4000-19000 MC – Injection Moulding Machines – Year 1998 For sale are two identical injection moulding machines manufactured by KraussMaffei, model KM 4000-19000 MC equipped with MC3F control system. These machines are particularly suitable for producing large plastic components that require very high clamping force. The systems are fully equipped and include several peripheral devices for material feeding and process control. Dkjdpfxsyt Hy Nj Akton ## Technical Data * Manufacturer: KraussMaffei * Model: KM 4000-19000 MC * Control: MC3F * Year of manufacture: 1998 * Operating hours: approx. 98,806 h * Clamping force: 40,000 kN * Maximum shot weight: 8,100 g * Screw diameter: 130 mm ## Dimensions & Weight * Machine depth: 4,900 mm * Machine height: 4,200 mm * Machine weight: approx. 255,000 kg ## Equipment * Robot interface: KUKA KRC4 * Sequential injection controller: S.I.S.E. IS-Tech * Temperature control units: GWK * Dosing and mixing system: Motan Colormetric * Belt conveyor ## Available Machines * Machine No. 14 * Machine No. 15 The machines can be purchased individually or as a package. Inspection by appointment is possible.

Condition: used, Year of construction: 1998, operating hours: 101,215 h, machine/vehicle number: 23J01415, clamping force: 23,000 kN, injection weight: 6,100 g, total length: 4,500 mm, total height: 3,800 mm, overall weight: 205,000 kg, # Sales Description Dodpjyt Hidofx Aktjkn Two high-performance injection molding machines from the renowned manufacturer KraussMaffei are available for sale. These are KM 2300-14700 MC models, specifically designed for the production of large-volume plastic parts and industrial series manufacturing. Each machine offers a clamping force of 23,000 kN, equipped with a screw diameter of 105 mm and a maximum shot weight of 6,100 g—ideal for applications involving large components and high material throughput. Both units are provided with extensive peripheral equipment, including a robot interface for KUKA KRC4, a S.I.S.E. IS’Tech sequential injection controller, GWK temperature control units, and a Motan Colormetric dosing and mixing system. A belt conveyor is also part of the package. The machines originate from the years 1997 and 1998 and have been operated in an industrial production setting. Technical Overview: Machine 1 - Model: KraussMaffei KM 2300-14700 MC (IMM MC3F No. 6) - Year of manufacture: 1998 - Operating hours: approx. 101,215 h Machine 2 - Model: KraussMaffei KM 2300-14700 MC (IMM MC3F No. 9) - Year of manufacture: 1997 - Operating hours: approx. 99,030 h Shared technical data: - Clamping force: 23,000 kN - Screw diameter: 105 mm - Max. shot weight: 6,100 g - Machine weight: approx. 205,000 kg - Machine dimensions: - Depth: approx. 4,500 mm - Height: approx. 3,800 mm These machines deliver a reliable and field-proven solution for industrial plastics processing, making them especially attractive to companies seeking large-format injection molding capability.

Condition: good (used), Year of construction: 2006, operating hours: 65,000 h, clamping force: 2,000 kN, screw diameter: 55 mm, Hydraulic core pull 2x Hot Runner 4x Air valves Dedstqifnspfx Aktjkn

Condition: good (used), Year of construction: 2011, Ref. no.: 18586 Manufacturer: KRAUSS MAFFEI Type: KM180-750 AX All Electric Year of construction: 2011 Clamping unit Clamping force: 180 ton Opening stroke: 1050 mm Distance between tie bars: 560 × 510 mm Mould height min.: 200 mm Mould height max.: 600 mm Platen size (h x v): 790 × 740 mm Injection unit Screw diameter: 50 mm Injection volume: 393 cm³ Shot weight: 357 g Injection pressure: 1892 bar Measurements and weight Dimensions: 6,07 x 1,92 x 2,01 m Machine weight: 6500 kg Further information: 👉 Fully electric machine offering maximum precision, lowest energy consumption and highest process stability his machine belongs to the proven AX series from KraussMaffei, known for its robust design, high performance, and reliability in industrial production. With a clamping force of 180 tons, the machine is ideally suited for a wide range of technical plastic applications, including automotive, packaging, and general industrial parts. Key features: * Solid and durable construction for long-term operation * High injection performance and process stability * Reliable KraussMaffei MC5 control system * Suitable for continuous industrial use * Good availability of spare parts Dkodpfxow E E Eve Akten The machine is equipped with a KraussMaffei linear robot (LRX-S100), which allows efficient and automated part handling, increasing productivity and reducing cycle times. Thanks to its well-balanced performance and flexibility, this machine represents a very attractive solution for both technical parts and series production. The machine was manufactured in 2011 and appears to be in good working condition, as shown in the pictures.
