MC 4 complete

KraussMaffei MC4

Condition: used, Krauss Maffei SE502 MC4 sequence controller- removed from KM 18 C3 - removed from running machine Kfjdpfx Aorr Eh Asc Hsa - fully functionalmanufacturer: Krauss Maffei type: SE502 spare part no.: 5 Dition: gebraucht

Condition: reconditioned (used), Year of construction: 2002, Used injection molding machine directly from the manufacturer! We as manufacturer KraussMaffei offer here one of our used injection molding machines. CONTROL - MC4 TECHNICAL DATA CLAMPING UNIT - injection force: kN 5000 - distance between columns (h x v): mm 900 x 800 - distance of mold opening max: mm 1170 - mold installation height min: mm 480 - opening stroke of the clamping platen: mm 1650 - Ejector stroke: mm 250 - Ejector force: kN 95 ( Backward: 48 ) SCREW UNIT - Screw diameter: mm 90 - Ratio Ls/D: 20 - Injection pressure: bar 1742 - Injection volume: cm3 1953 - Injection size for PS: g 1777 - Injection capacity: cm3/s 649 - Closing force of the nozzle: kN 115 ELECTRICAL PARAMETERS - capacity of pump motor: kW 90 - heating power: kW 44 WEIGHT AND DIMENSIONS - net weight: t 25,8 - dimensions of the machine (L x W x H): m 7,65 x 2,33 x 2,55 Basically, we deliver this machine in a functioning basic condition. In addition, we as the manufacturer of these systems can offer various add-ons depending on the individual case, such as: - Updates for energy optimization of the machine - Possible connection to digital products from KraussMaffei - Plasticizing conversions - Optional: Organization and arranging of delivery (Not included in the price) - Optional: Installation and commissioning (not included in the price) Kfodponh Rnusfx Ac Hja You will receive from us first-class service as well as the possibility to purchase immediately desired spare parts packages of wear parts in order to ensure a continuous production of your new used machine. Do not hesitate and ask us right away!

Condition: good (used), Year of construction: 1995, operating hours: 60,000 h, functionality: fully functional, screw diameter: 40 mm, clearance between the columns: 470 mm, Krauss Maffei injection moulding machine type KM110-390 C1 for sale. The machine is in very clean condition, as it was used for manufacturing medical products (see clean room in the photos). Maintenance was carried out by Krauss Maffei up to the end. Kfsdsxbar Hjpfx Ac Hja The machine is immediately ready for use and has already been dismantled. Loading by forklift. - Approx. 60,000 operating hours - Serial no. 114104 - Year of manufacture: 1995 - 40mm screw - 1,100 kN clamping force - 470x470 mm tie bar distance - Core pull connector: 1 - Dimensions: 4.5x1.5x2.2 meters - Weight: 5,800 kg If you have any questions, please feel free to contact us at any time.

Condition: used, Krauss Maffei IPC 5-133 for MC4 control system- removed from KM not testedmanufacturer: Krauss Maffei spare part no.: 5 Kfedpfx Acerr Egwj Hsa Dition: gebraucht

Condition: excellent (used), Year of construction: 2006, Clamping force: 500 t Screw diameter: 80 mm Platten dimensions: 1300 x 1200 mm Distance between tie bars V: 900 mm Distance between tie bars H: 900 mm Kodpfxova H Amo Ac Hofa Shot volume: 1779 cm3 Shot weight: 1620 g Injection pressure: 1855 bar Working hours: 46.511 Type: Horizontal Drive: Hydraulic

Condition: good (used), Year of construction: 1997, Krauss Maffei KM 650 - 3500 C2 injection molding machine Year of production - 1997 Fully hydraulic closing system. MC 3 control system SP 3500 plasticizing system complete plasticizing system for thermoplastics in the version with abrasion protection, with a screw diameter of 90 mm, with a non-return lock and an open nozzle. Closing system: complete plasticizing system for thermoplastics with a screw diameter of 90 mm, with a non-return lock and an open nozzle. TECHNICAL DATA: Closing unit: - Mold closing force: kN 6500 Kfedpfx Aovlpcgoc Hja - Mold opening force: kN 346 - Mould mounting plate movement force -- opening kN 169 -- closing kN 144 - Mounting plate dimensions (h x v): mm 1490 x 1440 - Clearance between columns (h x v): mm 1000 x 930 - Mold opening stroke: mm 1150 - Minimum mold height: mm 600 - Opening width: mm 1750 - Ejector stroke: mm 250 - Ejector force: kN 226/285 Injection unit: - Screw diameter: mm 90 - Injection pressure: bar 1742 - Injection volume: cm3 1953 - Injection weight for PS: g 1777 - Injection capacity cm3/s 649 - Increased injection capacity - Electric-hydraulic equipment: - Nominal power of the pump motor: kW 90 - Power of installed heaters: kW 44 - Number of cylinder heating zones: 7 - Oil tank capacity: l 1240 Dimensions and weight: - Net weight with control cabinet: t 39.5 - Machine dimensions (length x width x height): m 9.36 x 2.65 x 2.44

Condition: reconditioned (used), Year of construction: 2006, operating hours: 60,000 h, functionality: fully functional, clamping force: 8,000 kN, screw diameter: 85 mm, Horizontal injection moulding machine from Krauss-Maffei. 800 tons clamping force. Year of manufacture 2006. Screw diameter 85mm. MC5 control. Approximately 60,000 working hours. The machine is delivered REFURBISHED by our team of technical experts and in optimal working condition. We can offer commissioning services at our customer's premises, ensuring full functionality upon installation completion. Technical Details Screw diameter: 85mm Injection pressure: 2242 Bar Injection volume: 2695 cm3 Injection weight: 2452g (PS) Year of manufacture: 2006 Working hours: 60,000 Minimum mould thickness: 550/1100mm (Min/Max) Maximum platen distance: 2100mm Opening stroke: 1600mm Ksdpfx Aow Avafoc Hjfa Tie bar distance: 1120x1000mm Platen dimensions: 1600x1530mm Clamping force: 8000 kN

Condition: ready for operation (used), Year of construction: 2006, operating hours: 77,000 h, functionality: fully functional, clamping force: 5,000 kN, screw diameter: 100 mm, Clamping force 5000 kN Mould opening force, max. 280 kN Travel force movable platen opening 137 kN Travel force movable platen closing 136 kN Size of mould platens (h x v) 1270 x 1200 mm Distance between tie bars (h x v) 900 x 800 mm Mould opening stroke 1170 mm Mould height min 480 mm Kfjdpfewgni Hsx Ac Hoa Max. daylight 1650 mm Hydraulic ejector - stroke 250 mm Ejector force 95/48 kN Injection unit: Screw diameter 100 mm Ls/D ratio 18 Injection pressure 1411 bar Stroke volume 2411 ccm Shot weight (PS) 2194 gr. Injection rate 801 ccm/s Screw speed 189 1/min Plasticising rate max. 161 g/s Nozzle pressure 173 kN Electric and Hydraulic Equipment: Nominal capacity of pump motor 90 kW Installed heating capacity 44 kW Adjustable barrel heating zones 7 Oil Reservoir capacity 1075 ltr. Dimensions and weights: Dimensions of the machine ca. 7,50 x 2,50 x 2,50 m Total machine weight 27090 kg Max. mould weight 7900 kg Accessories: - Anti vibration pads - 2 x 8 fold water flow regulator Additional Options: - 2 x hydr. core pull on movable plate - 2 x hydr. core pull on fix plate - Robot interface according to Euromap 12 - 16 x hotrunner controller - 1 x air valve on movable plate

Condition: ready for operation (used), Year of construction: 2009, functionality: fully functional, clamping force: 6,500 kN, screw diameter: 70 mm, Clamping unit: Clamping force 6500 kN Mould opening force, max. 346 kN Travel force movable platen opening 169 kN Travel force movable platen closing 144 kN Size of mould platens (h x v) 1520 x 1470 mm Distance between tie bars (h x v) 1000 x 930 mm Mould opening stroke 1150 mm Mould height min 675 mm Max. daylight 1825 mm Hydraulic ejector - stroke 135 mm Ejector force 226 kN Injection unit: Screw diameter 70 mm Ls/D ratio 23 Injection pressure 2389 bar Stroke volume 1097 ccm Shot weight (PS) 998 gr. Injection rate 393 ccm/s Screw speed 218 1/min Plasticising rate max. 83 g/s Nozzle pressure 173 kN Electric and Hydraulic Equipment: Nominal capacity of pump motor 75 kW Installed heating capacity 36 kW Adjustable barrel heating zones 7 Dimensions and weights: Dimensions of the machine ca. 8,70 x 2,90 x 2,80 m Kedpfxov Stbmj Ac Hefa Total machine weight 44000 kg Accessories: - Anti vibration pads Additional options: - 1 x air valve - 8 x pneumatic sequentional valves - Accumulator - 2 x hydr. core pulls on movable plate - 2 x hydr. core pulls on fix plate - Robot interface according to EUROMAP 67

Condition: excellent (used), Year of construction: 2007, functionality: fully functional, KM 500-3500 C2 Year of manufacture: 2007 Operating hours in automatic mode: 60,000 h Clamping unit Clamping force: 5,000 kN Mounting plate dimensions: 1270 x 1310 mm Distance between tie bars: 900 x 800 mm Min./max. mold height: min. 480 mm Maximum opening stroke: 1,650 mm Injection unit Screw diameter: 80 mm Injection volume: 1,543 cm³ Shot weight: 1,404 g Injection pressure: 2,205 bar Electrical and hydraulic equipment Nominal pump motor power: 90 kW Kedpfxew Rflrj Ac Hefa Heating capacity: 44 kW Dimensions and weight Net weight with control cabinet: 27,090 kg Dimensions (L x W x H): 7.65 m x 2.55 m x 2.55 m
