Injection molding machine

KraussMaffei KM 800-6100 MX

Condition: ready for operation (used), Year of construction: 2007, clamping force: 8,000 kN, screw diameter: 85 mm, injection weight: 2,452 g, This Krauss Maffei KM 800-6100MX was manufactured in 2007. It features a clamping force of 8000 kN and an injection volume of 2695 cm³, making it suitable for various materials such as PA, PP, PE, and ABS. The machine is equipped with a Wittmann Robot System for enhanced handling capabilities. If you are looking to get high-quality injection moulding capabilities, consider the Krauss Maffei KM 800-6100MX hydraulic injection moulding machine we have for sale. Contact us for further details. • Injection unit: 6100 • Injection volume: 2695 cm³ • Injection pressure: 2242 bar • Materials processed: PA, PP, PE, ABS, etc. • Cylinder temperature: up to 450°C • Availability: Early 2027 Additional equipment Rsdpfoyyxc Dox Amgocb • Handling: Wittmann robot system • Model: W743 • Power: 400 V, 18 A / 12.5 kVA • Axes travel: X 1200 mm, Y 2000 mm, Z 4000 mm

Condition: new, Year of construction: 2023, functionality: fully functional, machine/vehicle number: 61036721, clamping force: 6,500 kN, screw diameter: 70 mm, clearance between the columns: 1,110 mm, displacement volume: 1,078 cm³, injection pressure: 1,877 bar, injection weight: 981 g, opening stroke: 3,200 mm, plate height: 1,540 mm, drive type: Hydraulisch, clear span: 3,200 mm, tool weight: 2,200,000 g, Injection Moulding Machines Directly from the Manufacturer! As the manufacturer KraussMaffei, we offer you our certified and flexible stock machines: The hydromechanical two-platen clamping unit of the GXW machine sets new standards in terms of quality and productivity. With the sophisticated GuideX sliding shoe, forces are ideally absorbed and the service life of the moulds is extended. The innovative GearX locking system engages instantly and reliably. Powerful, user-friendly and value-retaining. TECHNICAL DATA: KM 650 / 2000 / 2000 GXW G06 (Order 38618339) CONTROL SYSTEM - MC 6 with 24'' TFT color screen with multitouch functions CLAMPING UNIT - Clamping force: 6500 kN - Max. mould opening force: 455 kN - Daylight opening (h x v): 1110 x 960 mm - Platen size (h x v): 1540 x 1440 mm - Mould installation height min. - max.: 1550 mm (without centre platen) - Opening stroke: 3200 mm - Max. mould opening distance: 1650 mm - Max. mould weight: 22,000 kg INJECTION UNIT 1 SP2000 - Screw diameter / type: 60 mm / thermoplastics - Effective L/D ratio: 23.3 - Injection pressure: 2420 bar - Shot volume: 792 cm³ - Shot weight at max. stroke for PS: 720 g - Injection speed: 140 mm/s - Injection throughput: 396 cm³/s - Screw drive speed: 285 rpm - Plasticizing throughput: 72.2 g/s - Nozzle contact force: 82 kN INJECTION UNIT 2 SP2000 - Screw diameter / type: 70 mm / thermoplastics - Effective L/D ratio: 20 - Injection pressure: 1877 bar - Shot volume: 1078 cm³ - Shot weight at max. stroke for PS: 981 g - Injection speed: 140 mm/s - Injection throughput: 539 cm³/s - Screw drive speed: 285 rpm - Plasticizing throughput: 98.3 g/s - Nozzle contact force: 82 kN ELECTRICAL PARAMETERS - Connected load: 341 kW - Power supply: 400 V / 50 Hz, 3 phases with neutral conductor WEIGHT & DIMENSIONS - Net weight: 43.5 t - L x W x H: 11.89 x 3.22 x 2.77 m ADDITIONAL EQUIPMENT - Wear-resistant plasticizing unit - BluePower full insulation for plasticizing cylinder - Open nozzle - BluePower ServoDrive - Pneumatic valve: 1-fold (BWAP), 1-fold (FWAP) Rcedpfjw U N Ixsx Amgsb - Pneumatic cascade valves: 6-fold (BWAP), 6-fold (FWAP) - Hydraulic core pull: 2-fold (BWAP), 2-fold (FWAP) - Mould heating: 96 zones (3.5 kW each) - Euromap interface for handling: E18 - Euromap central computer interfaces: E67, E77, E78, E63, E82.1 - Adaptive Process Control (APC+) - Graphic analysis package - Sliding table with turning unit, servo-driven - Vertical centre platen - Parallel clamping & opening during injection process with bar parallelism control between FWAP and centre platen or BWAP and centre platen - ColorForm interface signal interface for connecting an RPM unit - Electrical interface for HRS-Flexflow system - Electrical interface and hydraulic valves for "1-K dummy operation" - Interface for connecting a CoMo-Kistler Injection Basic System with good/bad part separation The machine is located at our plant in Parsdorf and is available at short notice. Further additional options can be offered on request. We look forward to your enquiry.

Condition: ready for operation (used), Year of construction: 2006, operating hours: 30,000 h, functionality: fully functional, clamping force: 8,000 kN, screw diameter: 95 mm, displacement volume: 3,367 cm³, Clamping force 8000 kN Mould opening force, max. 560 kN Travel force movable platen opening 89 kN Travel force movable platen closing 92 kN Size of mould platens (h x v) 1600 x 1550 mm Distance between tie bars (h x v) 1120 x 1000 mm Mould opening stroke 1600 mm Mould height min/max 500/1100 mm Max. daylight 2100 mm Hydraulic ejector - stroke 300 mm Ejector force 200/100 kN Injection unit: Screw diameter 95 mm Ls/D ratio 23 Injection pressure 1795 bar Stroke volume 3367 ccm Shot weight (PS) 3064 gr. Injection rate 690 ccm/s Screw speed 116 1/min Redpfjymn Rvox Amgjcb Plasticising rate max. 104 g/s Nozzle pressure 166 kN Electric and Hydraulic Equipment: Nominal capacity of pump motor 90 kW Installed heating capacity 53 kW Adjustable barrel heating zones 7 Oil Reservoir capacity 1500 ltr. Dimensions and weights: Dimensions of the machine ca. 11,00 x 3,00 x 2,60 m Total machine weight 44500 kg Max. mould weight 12200 kg Accessories: - Anti vibration pads Additional Options: - 1 x air valve - tiebar pull system - 3 x core pulls on movable plate - 2 x core pulls on fix plate - 20 x hot runner controller - Robot interface according to Euromap 67

Condition: ready for operation (used), Year of construction: 2006, operating hours: 50,000 h, functionality: fully functional, clamping force: 8,000 kN, screw diameter: 95 mm, displacement volume: 3,367 cm³, Clamping force 8000 kN Mould opening force, max. 560 kN Travel force movable platen opening 89 kN Travel force movable platen closing 92 kN Size of mould platens (h x v) 1600 x 1550 mm Distance between tie bars (h x v) 1120 x 1000 mm Mould opening stroke 1600 mm Mould height min/max 500/1100 mm Max. daylight 2100 mm Hydraulic ejector - stroke 300 mm Ejector force 200/100 kN Injection unit: Screw diameter 95 mm Ls/D ratio 23 Injection pressure 1795 bar Stroke volume 3367 ccm Shot weight (PS) 3064 gr. Injection rate 690 ccm/s Screw speed 116 1/min Plasticising rate max. 104 g/s Nozzle pressure 166 kN Electric and Hydraulic Equipment: Nominal capacity of pump motor 90 kW Installed heating capacity 53 kW Adjustable barrel heating zones 7 Oil Reservoir capacity 1500 ltr. Dimensions and weights: Dimensions of the machine ca. 11,00 x 3,00 x 2,60 m Rcedeymn Nfjpfx Amgsb Total machine weight 44500 kg Max. mould weight 12200 kg Accessories: - Anti vibration pads Additional Options: - 1 x air valve - tiebar pull system - 3 x core pulls on movable plate - 2 x core pulls on fix plate - 20 x hot runner controller - Robot interface according to Euromap 67

Condition: like new (used), Year of construction: 2003, For sale complet MC 4 control for Krauss-Maffei machines, tested and full in function ! Rjdoikfmhspfx Amgocb

Condition: ready for operation (used), Year of construction: 2006, operating hours: 50,000 h, functionality: fully functional, clamping force: 8,000 kN, screw diameter: 95 mm, displacement volume: 3,367 cm³, injection pressure: 1,795 bar, opening stroke: 2,100 mm, No reserve price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Clamping force: 8,000 kN Max. mold opening force: 560 kN Moving platen opening force: 89 kN Moving platen closing force: 92 kN Mounting platen (h x v): 1,600 x 1,550 mm Clear daylight (h x v): 1,120 x 1,000 mm Mold opening stroke: 1,600 mm Min./max. mold installation height: 500 / 1,100 mm Max. mold weight: 12,200 kg Max. opening width: 2,100 mm Ejector stroke: 300 mm Ejector force forward/back: 200/100 kN Screw diameter: 95 mm L/D ratio: 23 Injection pressure: 1,795 bar Shot volume: 3,367 cm³ Shot weight (PS): 3,064 g Injection flow rate: 690 cm³/s Screw speed: 116 rpm Plasticizing rate: 104 g/s Nozzle contact force: 166 kN MACHINE DETAILS Rcsdpfjyv Acmsx Amgsb Dimensions & Weight Space requirements (approx.): 11.00 x 3.00 x 2.60 m Total weight: 44,500 kg Pump motor rated power: 90 kW Installed heating power: 53 kW Barrel heating control zones: 7 Oil fill volume: 1,500 l Operating hours: 50,000 h EQUIPMENT Oscillating elements 1 x air valve Tie-bar pulling device 3 x hydraulic core pulls on moving side 2 x hydraulic core pulls on fixed side 20 x hot runner controllers Robot interface as per Euromap 67

Condition: used, Year of construction: 2015, Technical details: closing pressure: 6600 kN weight of the machine ca.: 45,5 t Rsdpfx Amsw I E R Njgjcb

Condition: used, Year of construction: 2005, Injection molding machine Manufacturer: Krauss Maffei Type: KM350 /1900 C2 Year of manufacture: 2005 Clamping force: 3,500 kN Mold opening force: 220 kN Drive force of moving platen: opening: 105 kN closing: 95 kN Platen size (h x v): 1,060 x 1,095 mm Mold opening (h x v): 710 x 710 mm Mold opening stroke: 920 mm Redjxu Uvaspfx Amgscb Minimum mold height: 380 mm Opening width: 1,300 mm Ejector stroke: 250 mm Ejector force forward/backward: 95 / 48 kN Pump motor: 75 kW Installed heating capacity: 30 kW Control zones for cylinder heating: 6 Dry cycle rate: 1,550 1/h Oil capacity: 720 liters Dimensions and weights: Net weight with control cabinet: approx. 16.0 tons L/W/H: 6,510 x 2,040 x 2,380 mm Maximum mold weight: 4,780 kg Injection unit: Working capacity: 1900 Screw diameter: 70 mm Injection pressure: 1,778 bar Displacement volume: 1,047 cm3 Shot weight for PS: 953 g Injection flow rate: 527 cm3/s Screw speed Standard / Option: 1/min. 285/349 Screw speed Standard or Stage 1: 95 PS Screw speed Option or Stage 2: 117 PS Nozzle clamping force: 82 kN Fully hydraulic 2-platen clamping system PV control for injection unit MC4 32-bit microprocessor control Integrated control panel with TFT color display and Floppy disk drive (3.5 inches) for data backup Plasticizing: 1 complete thermoplastic plasticizing unit in wear-resistant design, screw diameter 70 mm with backflow valve and open nozzle Nozzle radius: 15.00 mm Nozzle bore: 6.00 mm 19526ä

Condition: excellent (used), Year of construction: 2010, Krauss Maffei KM 80-380 CX Injection Moulding Machine Year of manufacture: 2010 Clamping unit Clamping force: 800 kN Mounting plate dimensions (H × V): 670 × 670 mm Space between tie bars (H × V): 420 × 420 mm Mould height (min./max.): 250 mm Maximum opening: 750 mm Injection unit Screw diameter: 40 mm Injection volume: 201 cm³ Shot weight (PS): 183 g Injection pressure: 1860 bar Rodpfsxw Upfsx Amgjcb Electro-hydraulic equipment Pump motor power: 15 kW Heater power: 10.9 kW Dimensions and weight Machine dimensions (L × W × H): 4.09 × 1.48 × 2.02 m Weight (with control cabinet): 3.55 t

Condition: ready for operation (used), Year of construction: 2009, functionality: fully functional, clamping force: 6,500 kN, screw diameter: 70 mm, Clamping unit: Clamping force 6500 kN Mould opening force, max. 346 kN Travel force movable platen opening 169 kN Travel force movable platen closing 144 kN Size of mould platens (h x v) 1520 x 1470 mm Distance between tie bars (h x v) 1000 x 930 mm Mould opening stroke 1150 mm Mould height min 675 mm Max. daylight 1825 mm Hydraulic ejector - stroke 135 mm Ejector force 226 kN Injection unit: Screw diameter 70 mm Rcodpjv Stbmsfx Amgeb Ls/D ratio 23 Injection pressure 2389 bar Stroke volume 1097 ccm Shot weight (PS) 998 gr. Injection rate 393 ccm/s Screw speed 218 1/min Plasticising rate max. 83 g/s Nozzle pressure 173 kN Electric and Hydraulic Equipment: Nominal capacity of pump motor 75 kW Installed heating capacity 36 kW Adjustable barrel heating zones 7 Dimensions and weights: Dimensions of the machine ca. 8,70 x 2,90 x 2,80 m Total machine weight 44000 kg Accessories: - Anti vibration pads Additional options: - 1 x air valve - 8 x pneumatic sequentional valves - Accumulator - 2 x hydr. core pulls on movable plate - 2 x hydr. core pulls on fix plate - Robot interface according to EUROMAP 67
