Free bottle conveyors

Krones

Condition: used, Year of construction: 2003, functionality: fully functional, machine/vehicle number: K787016, overall weight: 41,000 kg, input voltage: 400 V, input frequency: 50 Hz, input current: 800 A, operating pressure: 40 bar, control voltage: 24 V, type of input current: three-phase, Equipment: documentation/manual, Krones Contiform S20 PET stretch blow molding machine – 20 cavities, output up to 40,000 units per hour. Used Krones Contiform S20 machine for manufacturing PET bottles. The machine is completely disassembled and prepared for loading onto a truck. Due to its disassembled condition, it is not possible to perform a test run or functional tests – it is sold as a complete set of components for reassembly by the buyer. Technical specifications: • Manufacturer: Krones • Model / Year: Contiform S20 / [2003] • Number of cavities: 20 • Nominal output (according to the manufacturer's specifications): up to 40,000 bottles/hour • Maximum container volume: up to 3 l (depending on the shape) • Oven: linear, with a 40 mm stroke • Neck size: 26/22 (PCO 1881) Scope of supply: [preform feeder, hopper/elevator and orienting device, chiller, molds, spare parts, etc.] Nedez Euubjpfx Agrsdb Inspection possible by prior arrangement – the machine can be inspected in its disassembled state, with the components laid out in Kutno. Loading at the buyer's expense. Transport to be agreed. Price on request.

Condition: excellent (used), Year of construction: 2003, PET bottle blowing machine Manufacturer: KRONES Model: CONTIFORM K781 Efficiency: 12,000 bph Includes 1.5 L and 0.5 L bottle molds Ndodpfsvddkvox Agreb Power: 150 kW Air requirement: 10 bar - 1500 m3/h, 30 bar - 1000 m3/h Set dimensions (blow mold + preform feeder): 1100 x 340 cm, h: 450 cm Blow mold dimensions: 500 x 340 cm, h: 250 cm Feeder dimensions: 600 x 250 cm, h: 450 cm Air requirement: 10 bar - 1500 m3/h, 30 bar - 1000 m3/h Year of production: 2003 Technical documentation of machine operation Very good condition

Condition: used, Year of construction: 2019, Overview This Krones VarioFlash B is a flash pasteurization system for beer and beer mix beverages, built in 2019 by Krones AG at its Steinecker plant in Freising, Germany. It pasteurizes 20 - 45 hl/h in a three-stage plate heat exchanger with energy recovery, a heat retention tube and a cooling stage. Everything is mounted on a stainless steel skid with a horizontal 2,100 l buffer tank, and a freestanding stainless steel control cabinet with touchscreen HMI completes the system. Technical data - Manufacturer: Krones AG (Werk Steinecker, Freising, Germany) - Model: VarioFlash B with cooling stage - Year of manufacture: 2019 - Machine type: flash pasteurizer with plate heat exchanger - Products: beer, beer mix beverages - Capacity: 20 - 45 hl/h - Pasteurization temperature: 71 - 85 °C - Holding time: 30 s at 45 hl/h - Max. CO₂ content: 6.5 g/l - Product inlet temperature: 5 - 15 °C; product outlet temperature: 16 °C - Energy recovery: approx. 91 % - Heating requirement at 85 °C: approx. 51 kW (approx. 90 kg/h steam at 6 bar(g), 165 °C) - Cooling requirement with water circulation at 5 °C: approx. 38 kW (5 m³/h glycol water, 2 - 10 °C) - Process water: inlet pressure 4.0 bar(g), inlet temperature 6 - 15 °C Nedpfx Aez Ekdxegrsdb - Buffer tank: 2,100 l, max. allowable pressure -1.0 / +7.0 bar, allowable temperature -4 to +98 °C, CE marked Equipment - Plate heat exchanger with 3 stages: energy recovery, pasteurization with temperature control, cooling with temperature control - Heat retention tube with fixed length; PU control depending on temperature and flow rate - Hot water circuit with separate brazed plate heat exchanger, temperature control, circulation pump and expansion vessel - Sanitary product pumps: frequency-controlled product feed pump, booster pump for a positive pressure difference towards the unpasteurized product, frequency-controlled product pump to the filler - Horizontal stainless steel buffer tank, pneumatic valves, inline instrumentation and sanitary pipework on a tubular stainless steel frame - Freestanding stainless steel control cabinet with touchscreen HMI and main switch Condition Used. The system has been removed from production and is stored indoors. It can be inspected by appointment. Availability Immediately. Location: Germany.

Condition: used, Year of construction: 2012, Overview Complete Krones PET line from 2012 for carbonated water in non-returnable PET bottles of 0.5 L, 1.0 L and 1.5 L, rated at 16,000 bottles/h on the 1.5 L format. The line runs from preform feeding through a blow moulder-filler-capper bloc in a clean room, beverage treatment and CIP, inspection, drying, coding and wrap-around labelling, to shrink-film packing with handle application, palletizing and stretch wrapping. A separate sleeve section with sleeve labeller, steam shrink tunnel, inspection and two dryers is included. Technical data - Year of manufacture: 2012 - Output: 16,000 bottles/h (1.5 L) - Product: carbonated water - Bottles: PET, 0.5 L, 1.0 L and 1.5 L - Labeller: up to 20,000 bottles/h - Packer, palletizer and stretch wrapper: up to 24,000 bottles/h - Packs: shrink-film packs with carry handle, 3x2 and 4x3 - Pallets: 800 x 1200 mm and 1000 x 1200 mm - Electrical: 380/220 V, 3/N/PE, 50 Hz Scope of Delivery - Preform feed unit | Krones | CONTIFEED | with tilting device for the preform hopper | 2012 - Preform interior cleaning | Krones | PREJET | 2012 - Stretch blow moulder | Krones | CONTIFORM S8 | 16,000 bottles/h (1.5 L) | 2012 - Filler-capper | Krones | MODULFILL VFS | 60 filling valves, 16,000 bottles/h (1.5 L) | 2012 - Clean room | Krones | for the blow moulder-filler-capper bloc | 2012 - Closure conveyor | Krones | 2012 - Beverage treatment | Krones | CARBOFLOW | 2012 - CIP system | Krones | VARIOCLEAN | 30 m³/h | 2012 - Container conveyors | Krones | SYNCO | 2012 - Inspection machine | Krones | CHECKMAT 707 | 2012 - Container dryer | Krones | LINADRY | 2012 - Container coding | Videojet | inkjet coder | 2012 - Labelling machine | Krones | CONTIROLL COMBI | wrap-around OPP labels, up to 20,000 bottles/h | 2012 - Inspection machine | Krones | CHECKMAT 731 | 2012 - Sleeve labeller | Krones | SLEEVEMATIC | 2017 - Steam shrink tunnel | Krones | SHRINKMAT - Inspection machine for the sleeve section | Krones | CHECKMAT - 2 container dryers for the sleeve section | Krones | LINADRY | 2017 - Pack conveyors | Krones | MULTICO | 2012 - Shrink-film packer | Krones | VARIOPAC PRO FS | 3x2 and 4x3 packs, up to 24,000 bottles/h | 2012 - Handle applicator | Krones | VARIOSTICK | 2012 - Palletizer | Krones | MODULPAL | 800 x 1200 and 1000 x 1200 mm pallets, up to 24,000 bottles/h | 2012 - Pallet conveyors | Krones | PALCO | 2012 - Stretch wrapper | Robopac | 2012 - Electrical power distribution for the line | Krones | 2012 Condition Dismantled and stored. Inspection on site by appointment. Availability Nedpoz Dw Uujfx Agrjdb Available immediately. Location: Georgia.

Condition: excellent (used), Year of construction: 2010, 200hl Steinecker Krones Brewhouse. Capable of 6 brews per day. Nodpfxjxb Uz Ae Agrodb Location: UK Available Immediately Including: • Steinecker Mill • Steinecker Cereal Cooker • Steinecker Mash Vessel • Steinecker Lauter Tun • Steinecker Holding Vessel • Steinecker Lauter Worth Heater • Steinecker Copper • Steinecker Whirlpool • Steinecker Wort Cooler • HLT & CLT • Hop Pellets Station • Vapour Condenser • Condensate Cooler • Spent Grain System Contact Indassol UK for Pricing and more details. We are at Drinktec - Please reply to set up a meeting to discuss further.

Condition: used, Year of construction: 2000, machine/vehicle number: 690-264, Machine: KRONES KGW-65-S-E Crate washer Ndedsz Ablwspfx Agrsb

Condition: used, Year of construction: 1987, with 2 stations photo-oriented working direction: left-right Nsdszz Rppopfx Agrjdb Capacity: 8000 bph

Condition: good (used), With top press-on rollers for levelling out staples Can be combined with a pallet brushing unit Infinitely adjustable test pressure Standard tests: Bottom boards and bottom crossboards, Lengthwise and crosswise mounted top boards Nodpfx Asd R Eqpsgrodb Indirect wedge inspection Optional tests: Dimension check, fork arm or area-clear monitoring, separate bottom board inspection of loaded pallet, direct wedge inspection If you need more information, please don't hesitate to contact us on the contact form or call us.

Condition: used, Year of construction: 2020, Overview Krones Ergomodul modular container labeller. Containers run anticlockwise after the infeed in a frontal arrangement with two discharge starwheels. Finish RAL 9018 papyrus white in the wet-line section. Two docking positions at the carrousel, both in operation, accept the four labelling stations without tools, so cold-glue and self-adhesive labelling run on the same carrousel; height adjustment of the top part and each station is motorised with container type preselection. Technical data - Manufacturer: Krones - Model: Ergomodul - Year of manufacture: 2020 - Table pitch diameter: 1,200 mm - Rotary plates: 30 - Machine pitch: 125.6 mm - Main drive: controlled servo motor; Danfoss servo motors, container table - Cold-glue stations (2x): ERGOMATIC-CL, 8-shaft glue pallet carrousel, 8-section gripper cylinder d = 350 mm, unwinding length 40-130 mm, steel glue roller, integrated glue pump, gluing height 5-215 mm, housing stainless steel, AISI 304-similar - Self-adhesive stations (2x): AUTOCOL-TS 120, web speed 120 m/min, supply tolerance +/- 0.5 mm, four-axis stand (application height, container diameter, conicity, sloping position), two-reel holder with automatic splicing and end-of-reel detection, driven carrier-film rewinder, ionisation unit, reels up to 390 mm outer diameter, carrier film up to 150 mm - Container infeed: worm with servo drive; detects damaged and fallen-over containers - Container orientation: prepared for camera orientation at the carrousel (360-degree monitoring, one camera); electrical interface prepared, mechanical adjustment unit not installed - Coding: prepared for a laser coder at the carrousel, with laser guarding, safety switch, clock pulse, oil-free air supply - Conveyors: flat-top chain, 83.8 mm wide, stainless steel (AISI 304-similar); servo-driven infeed, PM-motor discharge, centralised frequency inverter control - Machine guarding: lifting doors at the carrousel (polycarbonate), hinged doors at the front table (tempered safety glass) - Pneumatics: Festo; Bosch-Aventics, Norgren Herion, SMC, Bürkert components - Electrical: 400/230 V, AC 3/N/PE, 50 Hz, 28 A full load, 50 A back-up fuse; UPS 400/230 V, 17 A - Media: 92.4 m³/h oil-free compressed air, 0.009 m³/h process water - Weight: approx. 10,600 kg total (carrousel 3,200 kg, front table 3,000 kg, 1,100 kg per cold-glue station, control cabinet 1,000 kg) Equipment - 2x ERGOMATIC-CL cold-glue labelling stations, interchangeable - 2x AUTOCOL-TS self-adhesive labelling stations, interchangeable - Stand-alone control cabinet with Krones iPanel operator terminal - Central lubrication (Lincoln progressive distributor with motor pump) - Ecopush rejection module - Handling parts set on trolleys The inspection unit (Checkmat) and the container coding device used with this labeller are not part of this machine. Condition Used, still installed and under power in an operating line; on-site inspection possible before purchase. Availability Available now. The machine is in Belgium and will be dismantled and moved to our location in Germany; dismantling, loading and transport quoted on request. Njdpfx Ajzzz N Hsgrodb

Condition: used, Year of construction: 2023, Overview This Krones Pressant Universal 1N is a container sweep-off depalletizer that lifts each container layer off the pallet stack and sweeps it onto the discharge table, while a separate handling module removes the layer pads and the empty pallets. The machine is built in Krones enviro design for reduced energy and media consumption. Operation is from a Krones touch terminal with a production dashboard and a separate control page for the pallet conveyor. Technical data - Manufacturer / model: Krones PRESSANT UNIVERSAL 1N - Machine type: container sweep-off depalletizer - Year of manufacture: 2023 - Application: depalletizing of glass bottles, several formats - Container throughput: 14,000 containers/h (machine setting) - Pallet format: flat pallets 1,200 x 1,000 mm Njdozzz Naspfx Agrjdb - Container conveyor height: 1,300 mm - Sweep-off station: raised design for container heights above 320 mm, SEW servo drive - Discharge table: 90° connection, 3,600 mm table length, 15 steel conveyor chains, servo drive (SEW) - Lifting unit: servo drive (SEW), maintenance unit on the columns - Layer scanning: pneumatic - Layer centring: lateral and centring beam servo-motorised (SEW), pneumatic front flap - Stack fixing: lateral, motor-driven; pneumatic transfer plate - Packing material handling: 1 module with pivoted arm, suction gripper for layer pads and complete layers, vacuum ejector, pallet gripper (1 DIN size), motorised gripper frame rotation - Magazines: two magazine and stacking areas, free-standing chute for inverted trays - Central lubrication: Lincoln Quicklub, automatic pump - Pneumatics: Festo, minimum operating air pressure 5 bar, air connection G 1/2" - Power supply: 400 / 230 V, 3 Ph, 50 Hz, 57 A - Overall dimensions: depalletizer approx. 6,000 x 3,500 x H 5,620 mm; complete installation approx. 15,900 x 9,600 x H 5,620 mm - Finish: RAL 5013 cobalt blue columns, RAL 9018 papyrus white and RAL 7037 dusty grey machine parts - CE marked Scope of delivery - Krones PRESSANT UNIVERSAL 1N sweep-off depalletizer - Infeed roller conveyor, stainless steel rollers, roller width 1,350 mm, approx. 1,820 x 1,450 x 1,030 mm - Stainless steel platform with chain conveyor, approx. 5,000 x 2,500 x 1,680 mm - Krones PALCO pallet conveyor and Krones SYNCO container transport - Outfeed conveyors, stainless steel belts, belt widths 1,280 mm and 250 mm, approx. 5,200 x 1,700 x 1,420 mm and 5,700 x 500 x 1,420 mm - Krones operator terminal with production dashboard - Control cabinets with SEW servo drives, safety technology and central lubrication - Machine guarding with safety gates and locking pawl on the sweep-off station - OEM machine data sheet and dimension drawing Condition Used, technically complete. The machine is still installed and under power at its production site; the photographs show it in the installed state. Availability Immediately. The machine will be dismantled and relocated to Germany. Viewing by arrangement; dismantling, loading and transport can be quoted on request.
