Kupfermuhle Four Side Planer

Kupfermuehle vuin

Condition: good (used), Code: 0046 Brand: KUPFERMUEHLE - GERMANY Model: DOIN - VUIN 605 2-shaft planing machine + multi rip saw for wood carpentry, wood beams, roofing, sawmill, coffins and various Technical data: Heavy cast iron structure Working width mm 605 Min/max working height mm 3/200 Min workpiece length mm 350 Automatic group lifting with possibility of manual adjustment Feed speed mt/min 7 - 9 - 11,5 - 14 - 18 - 23 Infeed table with 3 support guides and motorized top feed rollers Height adjustable guide saw unit - Motor Hp 2,5 - Blade diameter mm 180 - Suction port mm 120 Motorized towing roller on the table 1° shaft surface planer with 4 knives - Motor Hp 7,5 - Suction port mm 120 2° shaft thickness planer with 4 knives - Motor Hp 12 - Suction port mm 160 - Motorized towing roller on the table 3° Multiblade saw shaft - Motor Hp 40 - Blade diameter mm 230 - Cutting height mm 50 - Upper suction port mm 160 - Lower suction port mm 160 Cedpfx Aov D N Efegmorh N° 2 upper motorized towing rollers and N°1 lower roller Control panel Overall dimensions mm 3300 x 1650 x 1600 h Weight kg 4000

Condition: ready for operation (used), functionality: fully functional, working width: 850 mm, Four-side planer Manufacturer: Kupfermühle Model: VUIN Maximum working width: approx. 850 mm Cjdpfx Agjw Hr Nksmorh Maximum planing height: approx. 200 mm Planing spindle with 4 knives With electronic height adjustment 1 horizontal shaft from above, 7.5 kW 1 horizontal shaft from below, 7.5 kW 1 vertical shaft from the left, 4 kW 1 vertical shaft from the right, 4 kW Feed motor 3 kW

Condition: ready for operation (used), Wide planer Constant table Maximum planing width: 605 mm Planing height (2 sides): 200 mm Crsdpewg S Tvofx Agmsh Planing height (4 sides): 170 mm Planer blocks with 6 knives

Condition: used, Year of construction: 1988, Planing width: 860 mm, clearance height: 200 mm, minimum clearance height: 3.0 mm, bottom motor: 18.5 kW, top motor: 7.0 / 10.0 kW Credpfx Agsvvkc Ajmoh Storage location: Nattheim

Condition: used, Empty weight: 6.000 kg Dimensions (LxBxH): 340 x 210 x 190 cm Price: On request - Max. working width: 860 - Documentation available: No - Transport dimensions: 3400mm x 2100mm x 1900mm (l x w x h) - Transport weight [kg]: 6000kg - Transport packages [pcs.]: 3 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Cedpfoxbf Iasx Agmorh Glenn Smeets

Condition: excellent (used), DOIN - VUIN - DOMA - KH 30 - DK14 - DK 16 Crjdpfxjinudge Agmjh accessories for planing machine Kupfermühle from A-Z For the infeed and outfeed of the planing machine

Condition: good (used), functionality: fully functional, Kupfermühle 4-sided planer. Planing width 605 mm. Two-sided planing height 200 mm. Four-sided planing height 180 mm. Electric table adjustment. Pressure beam. Feed 4.0 kW. Lower shaft motor = 5.5 kW. Upper shaft motor = 9.0 kW. Left vertical shaft motor = 11.0 kW. Crjdpewbt H Tofx Agmeh Right vertical shaft motor = 9.0 kW. With accessories.

Condition: used, Year of construction: 1965, functionality: fully functional, machine/vehicle number: 8650, planing width: 605 mm, height adjustment type: electric, Kupfermühle 4-Sided Planer -Type VUIN -Machine number: 8650 Cedpfxov Rfpms Agmsrh -Top and bottom cutter blocks -2 milling units (left, right) -1 additional milling unit -Long table and ruler extension -Moving scale for reading the working width -Loading possible -Price ex works

Condition: used, Year of construction: 1972, Empty weight: 3.000 kg Dimensions (LxBxH): 180 x 170 x 200 cm Four-sided planer Küpfermuhle 600 planing width 600 mm planing height 190 mm Angled bottom cutterblock 9 kW Top inclined cutterblock 11 kW Vertical spindle right 4 kW Vertical spindle left 5.5 kW Dimensions approx. 1800 x 2000 x 1700 mm (LxWxH), Weight 3000. - Year: 1972 - Documentation available: No - Serial number: 9552 - Transport dimensions: 1800mm x 1700mm x 2000mm (l x w x h) - Transport weight [kg]: 3000kg Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Cedpfxswnhbxj Agmjrh Delivery and trade-in always possible for everything in the industrial sectors Glenn Smeets

Condition: excellent (used), Feed rollers for DOIN 605 VUIN 605 DK 14 and other spare parts and accessories Csdpfx Ageic T R Rjmjrh
