Condition: ready for operation (used), Year of construction: 1999, functionality: fully functional, machine/vehicle number: 142967, turning diameter over cross slide: 300 mm, spindle speed (max.): 5,000 rpm, rapid traverse X-axis: 30 m/min, feed rate X-axis: 5 m/min, controller model: Mazatrol PC Fusion CNC 640T, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Working area Maximum turning diameter: 300 mm Maximum swing diameter: 525 mm Maximum swing diameter over the slide: 350 mm Maximum bar diameter: 51 mm Main spindle Speed range: 35 – 4,000 rpm Drive power: 15 kW Maximum torque: 350 Nm Spindle nose: A2-6 Spindle bore: 61 mm C-axis positioning: 0–360° / 0.001° Counter spindle Speed range: 35 – 5,000 rpm Drive power: 7.5 kW Maximum torque: 57 Nm Indexing: 72 positions / 5° Tool turret Number of tool stations: 12 Equipment: Stationary and driven tools Turret indexing time to station 1: approx. 0.2 s Driven tools Drive power: 3.7 kW Maximum torque: 35 Nm Speed range: 25–4,500 rpm Travel ranges X-axis travel: 190 mm Z-axis travel: 575 mm B-axis travel: 585 mm Rapid traverse rates Rapid traverse X-axis: 30 m/min Credpozpxgxefx Acmjf Rapid traverse Z-axis: 30 m/min Rapid traverse B-axis: 18 m/min Feed ranges Feed X-/Z-axis: 0–5,000 mm/min Feed C-axis: 1–2,000 rpm MACHINE DETAILS Control system: Mazatrol PC Fusion CNC 640T EQUIPMENT Counter spindle Bar feeder

Condition: ready for operation (used), Year of construction: 2022, machine/vehicle number: 30B.11.040.22, functionality: fully functional, TECHNICAL DETAILS Working area, X-axis: 3,300 mm Working area, Y-axis: 1,280 mm Working area, Z-axis: 250 mm Travel, X-axis: 4,000 mm Travel, Y-axis: 1,670 mm Travel, Z-axis: 500 mm Credszrmuvspfx Acmef Milling spindle Number of milling spindles: 1 Max. spindle speed: 24,000 rpm Main motor power: 11 kW Tool clamping system: HSK-F63 Table design: Cantilever table Table length: 3,300 mm Table width: 1,280 mm Material clamping: Pneumatic Drilling unit Drilling tools available Horizontal drilling spindles: 4 Vertical drilling spindles: 12 Tool changer positions: 12 MACHINE DETAILS Controlled axes: 4 Software: WoodFlash Voltage: 400 V Current consumption: 40 A Connected load: 18 kW Dimensions & Weight Dimensions (L x W x H): 6,250 x 3,494 x 2,300 mm Shipping dimensions (L x W x H): 5,300 x 2,350 x 2,400 mm Shipping weight: 4,000 kg Shipping packages: 2 EQUIPMENT Sawing unit Vacuum pump Becker PICCHIO 2200, year of manufacture 2022 Safety light curtain Manual control panel Tools CNC documentation with user keys/licenses and USB stick Documentation CE marking

Condition: used, Year of construction: 1997, Engel ES 1050/200 HL (1997) Cedpfoztafdsx Acmerf

Condition: used, Year of construction: 1997, Engel ES 1050/200 HL (1997) Cedpfx Asztadgecmsrf

Condition: used, Year of construction: 2002, Engel ES 750/200 HL (2002) Machine type: Horizontal Drive / Clamping: Hydraulic Manufacturer: ENGEL Model: ES 750/200 HL Year: 2002 Control: CC100 Clamping force (uzatváracia sila) : 2 000 kN = 200 ton Distance between tie bars H = 533 mm Cjdpszr U Hmsfx Acmsrf Distance between tie bars V = 457 mm Shot size cca 340g

Condition: ready for operation (used), Year of construction: 2004, operating hours: 615 h, spindle motor power: 22,000 W, spindle speed (max.): 5,000 rpm, travel distance X-axis: 580 mm, travel distance Y-axis: 80 mm, travel distance Z-axis: 1,045 mm, total height: 2,597 mm, total width: 2,060 mm, overall weight: 9,700 kg, controller manufacturer: MAZATROL, controller model: PC FUSION CNC 640MT Pro, product length (max.): 3,820 mm, number of axes: 5, This 5-axis Mazak INTEGREX 200 III S was manufactured in 2004. It features a maximum turning diameter of 660 mm and a maximum workpiece weight of 150 kg. The machine is equipped with a tool magazine capacity of 80 slots and a rapid traverse speed of 38 m/min on the X and Z axes. If you are looking to get high-quality turning and milling capabilities, consider the Mazak INTEGREX 200 III S turn-mill centre we have for sale. Contact us for further details. - Max. Swing Diameter: 660 mm- Max. Turning Diameter: 660 mm- Max. Turning Diameter over Slide: 500 - 660 mm- Max. Bar Working Diameter: 51 mm- Max. Workpiece Weight (incl. Chuck) - Chuck Workpiece: 100 kg- Max. Workpiece Weight (incl. Chuck) - Shaft Workpiece: 150 kg- Main Spindle Speed Range (Stepless): 35 - 5,000 rpm- Main Spindle Drive Power (30 min. rating / 100% continuous operation): 22 kW / 15 kW- Main Spindle Max. Torque: 349 Nm- Main Spindle Nose: A2-6"- Main Spindle Bore: Diameter 76 mm- Main Spindle Chuck Diameter: 210 mm- Main Spindle Indexing (C-Axis): 0.0001°- Second Spindle Drive Power (30 min. rating / 100% continuous operation): 18.5 kW / 15 kW- Second Spindle Speed Range: 35 - 5,000 rpm- Second Spindle Max. Torque: 326 Nm- Second Spindle Indexing (C-Axis): 0.0001°- Second Spindle Chuck Diameter: 210 mm- Tool Turret Design: Single spindle turret for stationary or driven tools- Driven Tools (IPM Motor) Drive Power (20% ED): 15 kW- Driven Tools Max. Torque: 120 Nm- Driven Tools Speed Range: 15 - 12,000 rpm- Tool Taper: MAZAK KM 63 quick-change system (for stationary tools)- Tool Magazine Type: Drum type- Tool Magazine Capacity: 80 slots (equipped for stationary and driven tools)- Tool Weight: max. 10 kg- Tool Diameter: max. 90 mm- Tool Diameter (with free adjacent slots): max. 125 mm- Tool Length: max. 300 mm- Tool Change Time (Tool-to-Tool step 1): approx. 1.3 s- Travel Y-Axis: +/- 80 mm- Travel W-Axis: 1050 mm- B-Axis Swivel Range: -30° to +195°- Rapid Traverse Speed X-Axis: 38 m/min- Rapid Traverse Speed Y-Axis: 26 m/min- Rapid Traverse Speed Z-Axis: 38 m/min- Rapid Traverse Speed W-Axis: 30 m/min- Rapid Traverse Speed C-Axis: 400 rpm- Feed Range X-Axis: 0 - 8,000 mm/min- Feed Range Z-Axis: 0 - 8,000 mm/min- Feed Range Y-Axis: 0 - 8,000 mm/min- Coolant Tank Capacity: 220 L- Pump Delivery Rate: approx. 20 l/min- Pump Pressure: approx. 5 bar- Pump Power: 635 W- Connected Load: 61.4 kVA- Operating Voltage: 400 V / 50 Hz- Pneumatic Pressure: 5 bar, 500 l/min- Total Operating Hours: 3,520 hours (Recorded on 2026/05/04)- Automatic Process Time: 1,581 hours- Automatic Cutting Time: 1,267 hours- Pure Cutting Time: 905 hours- Operating Time: 615 hours- Standard Accessories / Additional Equipment:- B-Axis (0.0001° positioning axis)- C-Axis (0.0001°)- Y-Axis- Spindle orientation on second spindle- Synchronization of main and second spindle- Hydraulic 3-jaw chuck diameter 210 mm, Type KITAGAWA B-208, including 1 set of soft jaws (Main Spindle)- Hydraulic 3-jaw chuck diameter 210 mm, Type KITAGAWA B-208, including 1 set of soft jaws (2nd Spindle)- Dual foot switch for opening/closing the chucks for main and 2nd spindle- Feedback of chuck status (open/closed) for main and 2nd spindle- Air blow-out device on chuck (Second Spindle)- Tool Setter (Tool Eye)- Front door interlock- Complete coolant system- Coolant and chip guard via fully enclosed work area- Work area lighting- Chip Conveyor System (Mayfran ConSep unit visible) Crsdpfx Aszr U Auocmof Technical Specification Counter Spindle Yes

Condition: refurbished (used), Year of construction: 2017, machine/vehicle number: R-00639, load capacity: 200 kg, arm reach: 2,600 mm, controller manufacturer: IRC5, teach pendant manufacturer: DSQC679, ABB IRB 6700-200/2.60 manufactured in 2017.07. The robot comes with an IRC5 controller including Flexpendant DSQC679.   Our experts extensively tested the robot, after which we conducted a maintenance service according to the manufacturers’ specifications. The oil is examined for the amount of iron particles, indicating the corresponding axes' condition. Only robots in excellent mechanical condition will be completely refurbished, ensuring a long-term solution for our customers. This enables us to deliver our robots with a warranty term of 12 months as standard!   Brand: ABB Model: IRB 6700-200/2.60 Model Number: IRB Year of Manufacture Robot: 2017.07 Warranty term (months): 12   Payload (kg): 200 Reach (mm): 2600 Repeatability (mm): ±0.05 Controlled Axes: 6-axis Installation Type: Floor of Invented Weight (kg): 1250 Crodpfjzr Up Iox Acmjf   Controller: IRC5 Year of Manufacture Cabinet: 2017.07 RCC Length (m): 14   Teach Pendant: DSQC679 Teach Pendant Cable Length (m): 15

Condition: excellent (used), functionality: fully functional, power: 5 kW (6.80 HP), input voltage: 400 V, input frequency: 50 Hz, cutting width (max.): 295 mm, saw blade diameter: 520 mm, saw blade bore: 50 mm, rotational speed (max.): 2,800 rpm, overall weight: 300 kg, cutting depth: 200 mm, extraction nozzle diameter: 100 mm, Further technical data Cutting width: 90° 420 mm | swivelled at 45° 295 mm Cutting depth: tilted at 45/90 degrees 140 mm | 200 mm Credpoxtpuusfx Acmof Special equipment 1019 Machine tiltable on both sides from the front via hand crank 1002 Hydraulic feed brake 1049 HM circular saw blade for wood 520x4.0x50 mm / 60 teeth negative

Condition: like new (used), Year of construction: 2022, functionality: fully functional, machine/vehicle number: 106882-11, total length: 4,400 mm, total width: 1,700 mm, total height: 2,700 mm, overall weight: 7,000 kg, The drilling process of the deep hole drilling machine utilizes the single-lip drilling method. Drilling Unit Information: - Drilling depth: 200 mm - Min./max. drilling diameter: 1–12 mm based on ST 60 - Number of spindles: 2 - Spindle distance: 200 mm - Spindle drive: 2 x 2.4/4.2 kW - Infinitely variable spindle speed: 1,000–20,000 rpm - Infinitely variable feed rate: 10–25,000 mm/min - Rapid traverse: 25,000 mm/min - Slide travel (nominal): 650 mm - Slide width: 460 mm - X-axis slide travel: 200 mm, rapid traverse: 25,000 mm/min - Y-axis slide travel: 200 mm, rapid traverse: 25,000 mm/min Fluid Information: - Coolant supply: deep hole drilling oil - Tank capacity: 500 liters - 1x automatic filter, filter performance: 50 l/min - 1x monitoring filter - 2x ELB drilling oil supply lines - 1x flow divider - 1x air cooler with recirculation pump - 1x electrostatic oil mist extraction unit - 1x scraper belt chip conveyor - 1x hydraulic unit and pneumatic unit/equipment - 1x sump pump - 3x submersible pumps - 1x radial piston pump with remote adjustment: Delivery rate: 1–38 l/min Pump drive: 7.5 kW Spindle Unit: - Motorized spindles with frequency-controlled, infinitely variable speed regulation - Spindle head with connection for tool holder - 2 x tool holders for collet sleeves according to VDI 3208 SE10x60, permanently bolted to the spindle head of the motorized spindle Drill Bushing Carrier: - The drill bushing carrier is positionable via the NC axis - Cast iron design, mounted on linear guideways - W-axis drive via AC servomotor and ball screw with indirect, absolute position measurement system Workpiece Slide: - The workpiece slide is designed as a cross-slide for vertical and horizontal positioning of the workpiece, for mounting clamping plates or special fixtures - Base unit in cast iron design with linear roller guideways - X and Y axes driven by AC servomotors and ball screws - Direct, absolute position measurement systems. Table plate with clamping or alignment grooves Clamping Table with NC rotary indexing device for positioning: - With rotary and swivel axes - Hydraulic clamping in rotary and swivel axes Technical Data: - Swivel range: 270º - Rotary range: 360º - Center height: 25 ± 0.02 - Spindle distance: 200 ± 0.005 - Indexing accuracy: rotary axis ± 15" / swivel axis ± 30" Electrical Equipment Information: - 1x drilling process monitoring - 1x CNC control 840D (Solution Line) Connection Data: - Operating voltage: 3AC 400V ± 10% - Frequency: 50 Hz - Control voltage: 24 V DC - Total rated power: 25 kW Crodpewh Rp Esfx Acmsf Additional Machine Equipment: - 2 x holders for resilient drill bushing holders, arranged on the drill bushing carrier - For max. drilling Ø18 mm.

Condition: used, functionality: fully functional, machine/vehicle number: 106341-11, Year of construction: 2005, overall weight: 8,000 kg, total height: 2,700 mm, total length: 5,660 mm, total width: 3,956 mm, The drilling method of the deep hole drilling machine is single-lip drill deep hole drilling. Drilling Unit Information: - Number of spindles: 1 - Infinitely variable spindle speed: 300 – 8000 rpm - Spindle drive power: 7.5 kW - Max. drilling depth: 800 mm - Drilling diameter min/max: 3 – 25 mm based on ST 60 - Max. twist drilling: 25 mm - Max. thread tapping: M24x3 - Milling material removal rate: 150 cm³/min Travel Paths: - X-axis travel: 800 mm - Y-axis travel: 400 mm - Z-axis travel: 630 mm - W-axis travel: 800 mm Travel Speed: - X-axis speed: 15,000 mm/min - Y-axis speed: 15,000 mm/min - Z-axis speed: 15,000 mm/min - W-axis speed: 15,000 mm/min Fluid Information: - Coolant supply: deep hole drilling oil - Tank capacity: 800 liters - 1x scraper belt chip conveyor - 1x hydraulic unit and pneumatic system/equipment - 1x submersible pump: Pumping capacity: 200 l/min - 1x low pressure pump: Pumping capacity: 100 l/min Pump drive: 1.7 kW - 1x compact belt filter: Filtration capacity: 120 l/min Codpfxsw E H E Re Acmorf for processing steel/non-ferrous metals - 1x radial piston pump with remote adjustment: Pumping capacity: 2 – 94 l/min Pump drive: 7.5 kW Spindle Unit: - Cartridge spindle design with drive housing and spindle drive with gearbox. Spindle bearing with precision angular contact ball bearings and lifetime grease lubrication. Milling and Drilling Spindle Unit: - For conventional machining - Spindle head with HSK 50 tool holder Drill Bush Holder: - Design as 2-position turret with electric swivel mechanism - Locating position via Hirth coupling - Turret head with fixtures for: Guide bushes for deep hole drilling Milling and drilling spindle unit for conventional machining Pickup Tool Changer: - For conventional tools and drill bushings - Disc magazine design with 20 stations including feed stroke Automatic Tool Changer for Deep Hole Drilling Tools: - Fixed ELB column magazine for at least 5 tools including automatic tool clamping for HSK holders Clamping Table with W-Axis and NC Rotary Table: - Length/width: 800 x 600 mm - Positioning accuracy: B-axis +/- 30" - Centric payload: 1,500 daN Workpiece Clamping Device: - 1x tailstock with manual clamping movement - 1x NC dividing unit (A-axis) with manually operated two-jaw chuck for workpiece clamping - 1x base plate for mounting and clamping drill bushings + supporting prisms Electrical Equipment Information: - 1x CNC control Sinumerik 840D (digital complete system), including PLC S7-300 Connection Data: - Operating voltage: 3AC 400V ±10% – Frequency: 50 Hz - Control voltage: 24 V DC - Total connected load: 25 kW
