Shears

Condition: ready for operation (used), Year of construction: 2006, operating hours: 17,716 h, functionality: fully functional, machine/vehicle number: 0144, travel distance X-axis: 1,200 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 675 mm, controller model: Heidenhain iTNC 530, TECHNICAL DETAILS X-axis travel: 1,200 mm Y-axis travel: 600 mm Z-axis travel: 675 mm Work spindle speed: 30 - 8,000 rpm Tool holder: ISO B 40 Table size: 1,220 x 620 mm T-slots: 18 T-slots: 5 x 18 mm Ijdpfex Trpqox Ahujtb T-slot spacing: 100 mm Table load capacity: 1,700 kg Control system: Heidenhain iTNC 530 Feed rate X / Y / Z: 3,000 mm/min Rapid traverse X,Y / Z: 24 / 20 m/min MACHINE DETAILS Voltage: 3 x 400 V AC + PE, 50/60 Hz Control voltage: 24 V DC Connected load: 16 kW Weight: 8,000 kg Operating hours Control on: 44,842 h Machine on: 36,513 h Program run: 15,882 h Drives on: 31,655 h Spindle on: 17,716 h

Condition: ready for operation (used), Year of construction: 1998, functionality: fully functional, machine/vehicle number: 0-250-05-2654, travel distance X-axis: 3,950 mm, travel distance Y-axis: 1,943 mm, travel distance Z-axis: 400 mm, controller model: HOMATIC-2000 IPC, No reserve price – guaranteed sale to the highest bidder! The machine is equipped with a C-axis! TECHNICAL DETAILS Travel distances X-axis: 3,950 mm Iedpex Sqm Sofx Ahustb Y-axis: 1,943 mm Z-axis: 400 mm Vertical drilling unit X-direction Drill spindles: 16 Z-stroke: 60 mm Drilling depth: max. 38 mm Rotational direction: clockwise/counterclockwise Speed: 1,500 - 5,900 rpm Drive: 1.5 kW Drill chuck: d= 10 mm Total drill length: 70 mm Drill diameter: max. 20 mm (15 spindles), 1 spindle up to 25 mm, max. 35 mm (1 reinforced spindle) Spindle spacing: 32 mm (15 spindles) Spindle type: individually controllable Extraction: central Vertical drilling unit Y-direction Drill spindles: 15 Z-stroke: 60 mm Drive: 1.5 kW Rotational direction: clockwise/counterclockwise Speed: 1,500 - 5,900 rpm Drill chuck: d= 10 mm Drilling depth: max. 38 mm Total drill length: 70 mm Drill diameter: max. 20 mm, 1 spindle up to 25 mm Spindle spacing: 32 mm (15 spindles) Spindle type: individually controllable Arrangement: Y-direction Horizontal drilling unit X-direction Drill spindles: 4 Drilling depth: max. 38 mm Drilling height Z-direction: 38 mm Rotational direction: counterclockwise Speed: 4,800 rpm Drill chuck: d= 10 mm Total drill length: 70 mm Drill diameter: max. 20 mm Spindles: individually controllable Horizontal drilling unit Y-direction Drill spindles: 2 Drilling depth: max. 38 mm Drilling height Z-direction: 38 mm Rotational direction: clockwise Speed: 4,800 rpm Drill chuck: d= 10 mm Total drill length: 70 mm Drill diameter: max. 20 mm Spindle type: individually controllable Router motor Drive power: 7.5/10 kW (S1/S6 duty cycle) Speed range (stepless): 750 - 18,000 rpm Cooling: liquid recirculation cooling Bearings: hybrid bearings (ceramic) Extraction: central Tool changer magazine Magazine positions: 30 tool positions Tool weight: max. 5 kg Tool change time: approx. 8 - 10 seconds MACHINE DETAILS Control: HOMATIC-2000 IPC Liquid recirculation cooling: 18,000 l/min Power: 7.5 / 10 kW S1/S6 operation EQUIPMENT Integrated CNC axis (360° rotational) Torque support Main spindle (motor power 7.5 / 10 kW, HSK F63) Workpiece support system 1,500 mm Workpiece console K-table 1,500 mm Gantry extension Y-direction 120 mm Compressed air connection strip with quick couplers Extraction hood for additional router motor Router 5 kW with Hydro quick-release clamping system Left-side safety guard with door Safety tread mat 3,250 mm Control cabinet left Note: For further details regarding the machine’s equipment, please refer to the attached documents.

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2023, load capacity: 2,500 kg, throat depth: 2,500 mm, empty load weight: 713 kg, construction height: 3,350 mm, pivoting range: 360 °, Column Slewing Crane M25-2.5 TECHNICAL DETAILS Load capacity: 2,500 kg Jib outreach: 2,500 mm Height: 3,350 mm Slewing range: 360° Outreach: 2,500 mm Underside of jib: 2,980 mm Overall height: 3,350 mm Bolt circle diameter: 530 mm Flange outside diameter: 610 mm Beam flange width: 150 mm Minimum approach dimension (Aa): 420 mm Internal approach dimension (Ai): 820 mm Support column length: 1,530 mm MACHINE DETAILS Weight: 713 kg Electrical Data Operating voltage: 400 V Frequency: 50 Hz Control voltage: 48 V EQUIPMENT Electric travel trolley Electric chain hoist Lifting capacity: 2,500 kg Lifting height: 4 m Lifting speed: 4 / 0.7 m/min Crane trolley Motorized travel trolley Flange width range: 138–195 mm Flange width: 150 mm Travel speed (max.): 10 m/min Travel speed (min.): 3 m/min MACHINE DETAILS Travel motor (trolley) Power: 0.3 kW Rated current: 1.2 A Starting current: 4.2 A Hoist Hoist motor power: 3.6 kW Hoist motor rated current: 8.2 / 4.3 A Itsdpfxsx Nvtlo Ahuob Hoist motor starting current: 39 / 6.7 A Electrical Data Operating voltage: 400 V Frequency: 50 Hz Control voltage: 48 V

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2023, machine/vehicle number: 10000987990, total height: 5,300 mm, total length: 30,000 mm, total width: 8,900 mm, load capacity: 3,200 kg, lifting height: 4,450 mm, Up for auction is a Konecranes overhead crane with 2 bridges, each offering a lifting capacity of 3.2 t. TECHNICAL DETAILS Lifting capacity: 3,200 kg Span: 8,900 mm Lifting height: 4.45 m Hoisting speed: 3.9 m/min (ASR 1.2 m/min) Trolley travel speed: 20 m/min, infinitely variable Crane travel speed: 40 m/min, infinitely variable MACHINE DETAILS Itodpfxsx Nvrzo Ahuob Number of bridges: 2 Number of trolleys: 2 Dimensions & Weight Dimensions (L x W x H): 30,000 x 8,900 x 5,300 mm Trolley weight: 230 kg Crane total weight without trolley: 1,300 kg Electrical Data Operating/Control voltage: 400 V / 48 V, 50 Hz Rated power: 3.0 kW EQUIPMENT Runways Radio remote control Conductor rails Overload protection Load spectrum memory Signal horn Pre- and limit switches for trolley and crane travel (slow/stop) Guide rollers to reduce skewing forces Buffer extension to compensate for guide rollers

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2017, machine/vehicle number: 11690446, load capacity: 4,000 kg, lifting height: 6,530 mm, TECHNICAL DETAILS Span: 9.9 m Crane lifting capacity: 4,000 kg Lifting height: 6.53 m Lifting speed at full load: 3.2 m/min Lifting speed at partial load: min. 3.0 m/min up to max. 7.5 m/min Trolley travel speed: 20 m/min Crane travel speed: 40 m/min MACHINE DETAILS Weights Trolley weight: 390 kg Crane weight without trolley: 1,750 kg Classification Crane class: 3U4/Q2, EN 13001-1 Hoist mechanism group: 4.3 + 4.4 m / ISO M6 Crane girder mechanism group: 16 m / M5 Electrical data Itsdpfx Ahjx Nvpgeujb Power supply: 400 / 48 V / 50 Hz Rated output: 3.3 kW EQUIPMENT Radio control Overload protection Load spectrum memory Pre- and end-limit switches for crane and trolley travel Remote control type “Mini Joystick” Spare transmitter Storage cabinet Spare battery Charging station Signal horn Hook collision protection Hook center-of-gravity alignment Manual crane hook tracking Safety conductor line incl. main disconnect switch and power supply Clampable holding brackets Riser cable (fixed installation) to be provided by customer

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2024, machine/vehicle number: 10000987991, overall weight: 5,110 kg, load capacity: 6,300 kg, main lifting speed: 4,000 mm/min, lifting height: 5,200 mm, 6.3t S-DG Double-Girder Overhead Crane TECHNICAL DETAILS Crane rail type: 60 × 40 Load capacity: 6,300 kg Span: 17.100 m Maximum deflection of crane bridge at rated load: 22.8 mm Wire Rope Hoist Max. lifting capacity of hoist 1: 6,300 kg Hoist classification: 1.2 + 1.2 m (D_min) Lifting height: min. 4.9 m / max. 5.20 m Type of trolley: double rail trolley Iodox Nvlbopfx Ahustb Wire rope control: with hook drift Hook type/size: RSN2.5V Speeds Hoisting speed at rated load: min. 0.08 m/min to max. 4.0 m/min CSR speed at partial load: max. 6.00 m/min Trolley travel speed: max. 20 m/min Crane travel speed: max. 40 m/min MACHINE DETAILS Weight of crane including hoist: 5,110 kg Electrical Data Supply voltage: 3 Ph / 400 V / 50 Hz Control voltage: 48 V Area of application: indoors Ambient temperature: min. 5 °C to max. 40 °C Motor Power Main hoist motor: 4.5 kW Duty cycle main hoist motor: 60% ED Trolley travel motor: 1 × 0.45 kW Duty cycle trolley travel motor: 40% ED Crane travel motors: 2 × 0.65 kW Duty cycle crane travel motors: 40% ED EQUIPMENT DynADrive inverter control Control Pro Performance 4-stage hoist limit switch Hoist brake Wire rope drum Gearbox Overload protection Load spectrum recorder Slow/stop limit switches for trolley and crane travel Crane equipped with REMOX516MI radio remote control Includes signal horn (sound level 98 dB) Includes spare transmitter for radio remote control Includes storage cabinet for remote control Rope angle features Safety festoon line approx. 30 m long, along central support row Includes mains disconnect switch and power feed at any point Rising main (fixed installed cable) to be provided by customer Note: Further technical details can be found in the attached quotation.

Condition: ready for operation (used), Year of construction: 1986, functionality: fully functional, machine/vehicle number: 8531, Auction of a Famot MEXPOL TUM 35! Iedpfxex Ngnms Ahuotb

Condition: ready for operation (used), Year of construction: 2007, functionality: fully functional, travel distance X-axis: 762 mm, travel distance Y-axis: 460 mm, travel distance Z-axis: 460 mm, controller model: OSP-P200M, rotational speed (max.): 15,000 rpm, TECHNICAL DETAILS Travel X-axis: 762 mm Travel Y-axis: 460 mm Travel Z-axis: 460 mm Spindle speed range: 50 - 15,000 rpm Rapid traverse X-axis: 40 m/min Rapid traverse Y-axis: 40 m/min Rapid traverse Z-axis: 32 m/min Tool magazine: 32 positions MACHINE DETAILS Control: OSP-P200M Main drive motor: 22 kW Dimensions & Weight Required space (L x W x H): 2,850 x 2,810 x 2,750 mm Machine weight: 7,200 kg EQUIPMENT Chip conveyor Internal coolant supply Isdjx I Ecyspfx Ahuetb Standard filtration unit

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2002, controller model: Cybelec DNC 1200, bending force (max.): 250 t, working width: 3,550 mm, distance between stands: 3,000 mm, overall weight: 18,500 kg, TECHNICAL DETAILS Press force: 250 t Bending length: 3,550 mm Distance between uprights: 3,000 mm MACHINE DETAILS Controlled axes: y1, y2, x, r, z1, z2, back gauge tilt Control unit: Cybelec DNC 1200 Dimensions & weight Footprint (L x W x H): approx. 4,300 x 2,750 x 3,750 mm Machine weight: approx. 18,500 kg EQUIPMENT Itsdpfsx I Ebiox Ahuob Two-hand foot switch Lasersafe Fisseler Hydraulic tool clamping top and bottom Die shifting Hydraulic crowning Support arms 1 set of upper and lower tools Safety guard

Condition: ready for operation (used), Year of construction: 2013, functionality: fully functional, spindle speed (max.): 6,000 rpm, travel distance X-axis: 607 mm, travel distance Z-axis: 286 mm, controller model: Fanuc 32i A, grinding spindle speed: 30,000 rpm, The offer includes a CNC hard turning lathe with FMB automation! The machine is from year of manufacture 2013, but it was only commissioned in 2017 (showroom machine)! HARDINGE GT27SP GG-134HS TECHNICAL DETAILS X-axis travel: 607 mm Z-axis travel: 286 mm Max. spindle speed: 6,000 rpm Number of axes: 2 MACHINE DETAILS Control: Fanuc 32i A Dimensions & Weight Machine dimensions with robot cell (L x W x H): 4,600 x 1,600 x 2,700 mm Weight: approx. 2,100 kg Operating hours: 34,536 h EQUIPMENT MARPOSS measuring system MicroCentric 4-410-3-QC chuck Jäger HF spindle (spindle speed: 30,000 rpm) Oil mist filter S400 Spindle cooling possible Itedpox I A Hpefx Ahuob FMB Unirobot LR Mate (Serial number: E-83200 (robot) / E15X36204 (controller), year of manufacture: 2015) Robot model: FANUC LR MATE 200iD7L-P2TB Controller: FANUC R30iB Max. part feed: 70 mm Axes: 6 Robot cell weight: approx. 1,000 kg GENERAL EQUIPMENT Knoll filter system KF110/500 (capacity: 500 l) Grinding spindle holder Grinding wheel arbor RINECK Reversing station in robot cell Feed conveyor for raw/finished parts 2,900 mm 2x MAS-MEX20-GT27-1-S385H adapters 2x MAS-MEX20 turn sleeves 2x MAS-turn rings 2x Hydro-expansion holders for internal turning tools Holder for turning tool + turning tool MARPOSS probe with holder
