Pallet manufacturing machine

Condition: ready for operation (used), functionality: fully functional, machine/vehicle number: 2819-1160, travel distance X-axis: 300 mm, travel distance Y-axis: 300 mm, travel distance Z-axis: 400 mm, spindle speed (max.): 2,500 rpm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel range X-axis: 300 mm Travel range Y-axis: 300 mm Travel range Z-axis: 400 mm Dodpe Ah Slzjfx Acpewd Clamping area: 390 × 620 mm Spindle speed: 40–2,500 rpm Spindle taper: SK 40 Quill travel: 60 mm Rapid traverse: 4.0 m/min EQUIPMENT Chip collection tray

Condition: excellent (used), Year of construction: 2007, functionality: fully functional, working width: 1,050 mm, working height: 100 mm, working length: 3,250 mm, TECHNICAL DETAILS Working length: 3,250 mm Dwjdpfx Aj Aggu Ascped Working width: 1,050 mm Working height: 100 mm Drilling unit Vertical drilling spindles: 18 Horizontal drilling spindles, X-axis: 4 Horizontal drilling spindles, Y-axis: 2 Tool stations: 4 Position: rear MACHINE DETAILS Milling spindle power: 7.5 kW Operating voltage: 400 V Mains frequency: 50 Hz EQUIPMENT Grooving circular saw for X and Y direction, 90° Rear tool changer CE marking

Condition: excellent (used), Year of construction: 2008, operating hours: 2,483 h, functionality: fully functional, machine/vehicle number: 8015, travel distance X-axis: 1,200 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 600 mm, controller model: Heidenhain iTNC 530, spindle speed (max.): 12,000 rpm, TECHNICAL DETAILS Travel range, X-axis: 1,200 mm Travel range, Y-axis: 600 mm Travel range, Z-axis: 600 mm Rapid traverse rate X/Y: 30 m/min Rapid traverse rate Z: 24 m/min Table size: 1,300 × 600 mm Spindle speed: 50–12,000 rpm Spindle power: 21 / 15 kW Tool holder: BT40 Spindle drive: direct drive Tool positions: 40 Tool change time: approx. 4 s Tool changer: dual gripper MACHINE DETAILS Coolant pressure: 20 bar CNC control: Heidenhain iTNC 530 Screen diagonal: 15 inches Operating voltage: 400 V Connected power: 25 kVA Mains frequency: 50/60 Hz Number of phases: 3 Machine weight: approx. 7,500 kg Operating hours Spindle hours: 2,483 h Machine operating hours: 14,198 h Control operating hours: 65,193 h Dwedpj Aggibsfx Acped EQUIPMENT Automatic tool changer with dual gripper Internal cooling through the spindle (IKZ), Form A High-pressure coolant system Additional coolant tank Two switchable filter cartridges Chip conveyor parallel to the X-axis Three-color signal light (red/yellow/green) Fully enclosed work area Work area lighting Machine documentation Toolbox Alignment screws and washers CE specification

Condition: used, Year of construction: 1996, travel distance X-axis: 1,500 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,250 mm, controller model: Siemens 840 C, spindle speed (max.): 4,000 rpm, TECHNICAL DETAILS X-axis travel: 1,500 mm Y-axis travel: 1,200 mm Z-axis travel: 1,250 mm Spindle speed: 10–4,000 rpm Spindle power: 40 kW Spindle interface: HSK-A100 Pallet size: 1,000 × 1,000 mm Rotary table speed: 1–500 rpm Pallet load: max. 2,000 kg Dsdpfx Acj Agftmjpowd Magazine type: Chain magazine Number of tool positions: 161 MACHINE DETAILS CNC control: Siemens 840 C Overall dimensions: 8,500 × 4,800 × 4,800 mm EQUIPMENT Chip conveyor Paper filter Rotary table Automatic horizontal and vertical spindle

Condition: used, travel distance X-axis: 9,000 mm, table length: 2,800 mm, table width: 8,000 mm, table load: 64,000 kg, TECHNICAL DETAILS Longitudinal travel: 9,000 mm Transverse travel: 2,950 mm Vertical travel: 1,250 + 2,200 mm Dedpo Agftisfx Acpjwd Rapid traverse rates for longitudinal/transverse/vertical axes: 3 / 3 / 2 m/min Table size: 2,800 × 8,000 mm Table division: 5,000 + 3,000 mm Permissible table load: max. 64,000 kg Spindle speed: 20–600 rpm Spindle motor power: 100 kW Spindle torque: 13,000 Nm Spindle mounting: ISO 60 Distance between columns: 3,200 mm Distance from spindle nose to table: 2,806 mm MACHINE DETAILS Overall dimensions: 21,000 × 7,800 × 6,650 mm EQUIPMENT 90° head Compact 90° head Vertical extension Swiveling head 3-stage gearbox Note: The machine is in good condition. However, an overhaul may be necessary.

Condition: refurbished (used), Year of construction: 1997, travel distance X-axis: 1,500 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,250 mm, controller model: Siemens 840 C, spindle speed (max.): 4,000 rpm, The machine has been completely overhauled! TECHNICAL DETAILS Travel range, X-axis: 1,500 mm Travel range, Y-axis: 1,200 mm Travel range, Z-axis: 1,250 mm Speed range: 10–4,000 rpm Spindle power: 40 kW Spindle interface: HSK-A 100 Pallet size: 1,000 × 1,000 mm Dodpfe Agftbsx Acpjwd Pallet speed: 1–500 rpm Pallet load: max. 2,000 kg Tool magazine: Chain magazine Tool positions: 161 MACHINE DETAILS Control system: Siemens 840 C Overall dimensions: 8,500 × 4,800 × 4,800 mm EQUIPMENT Pallet changer Horizontal and vertical automatic head Rotary table Chip conveyor Paper filter

Condition: used, Year of construction: 2000, travel distance X-axis: 1,250 mm, travel distance Y-axis: 700 mm, travel distance Z-axis: 750 mm, controller model: Fanuc 16i-M, spindle speed (max.): 4,000 rpm, TECHNICAL DETAILS Dwodpj Agfr Eefx Acpod X-axis travel: 1,250 mm Y-axis travel: 700 mm Z-axis travel: 750 mm Distance from spindle nose to table: 100–850 mm Rapid traverse rate X/Y/Z: 15 m/min Spindle speed: 4,000 rpm Spindle power: 26 kW Spindle interface: ISO 50 / DIN Number of pallets: 2 Table size: 650 × 1,400 mm Table load: max. 1,500 kg Magazine type: Chain magazine Number of tool positions: 41 Tool diameter: max. 120 mm Tool diameter with free adjacent positions: max. 200 mm Tool length: max. 400 mm Tool weight: max. 20 kg MACHINE DETAILS High-pressure coolant pressure: 30 bar CNC control: Fanuc 16i-M Dimensions & Weight Machine weight: 16,750 kg Overall dimensions: 7,135 × 5,300 × 3,426 mm EQUIPMENT Gear change Chip conveyor

Condition: used, Year of construction: 1998, travel distance X-axis: 2,000 mm, travel distance Y-axis: 1,300 mm, travel distance Z-axis: 1,200 mm, controller model: MSC 502, spindle speed (max.): 6,000 rpm, TECHNICAL DETAILS X-axis travel: 2,000 mm Y-axis travel: 1,300 mm Djds Agfrzjpfx Acpjwd Z-axis travel: 1,200 mm Number of axes: 4 Spindle speed: 60–6,000 rpm Spindle power: 30–37 kW Spindle mounting: ISO 50 / BT Number of pallets: 2 Pallet size: 1,000 × 1,000 mm Pallet load: max. 3,000 kg Workpiece diameter: max. 2,000 mm Workpiece height: max. 1,550 mm Workpiece weight: max. 3,000 kg Magazine type: Chain magazine Tool positions: 120 MACHINE DETAILS Control system: MSC 502 Dimensions & Weight Machine weight: 35,200 kg Overall dimensions: 5,330 × 7,720 × 3,810 mm EQUIPMENT Pallet changer High-pressure coolant system Chip conveyor RS-232 interface Tool pre-setter

Condition: used, Year of construction: 2011, travel distance X-axis: 520 mm, travel distance Y-axis: 360 mm, travel distance Z-axis: 360 mm, controller model: FANUC 31i-A5, spindle speed (max.): 10,500 rpm, TECHNICAL DETAILS X-axis travel: 520 mm Y-axis travel: 360 mm Z-axis travel: 360 mm Distance from spindle nose to table: 200–560 mm Rapid traverse rate X/Y/Z: 60 m/min Spindle speed range: 36–10,500 rpm Spindle power: 30–35 kW Tool holder: HSK-A63 Number of pallets: 2 Dwsdpfx Aco Agfrwepjd Pallet load: max. 450 kg Magazine capacity: 2 × 21 Tool diameter: max. 88 mm Tool diameter with free neighboring positions: max. 125 mm Tool length: max. 250 mm MACHINE DETAILS CNC control: FANUC 31i-A5 Dimensions & Weight Machine weight: 5,300 kg Overall dimensions: 3,200 × 3,250 × 3,245 mm EQUIPMENT Chip conveyor Paper filter High-pressure coolant pump Tool setting 4-axis table, 1 piece

Condition: good (used), Year of construction: 2000, functionality: fully functional, travel distance X-axis: 2,200 mm, travel distance Y-axis: 600 mm, travel distance Z-axis: 600 mm, spindle speed (max.): 8,000 rpm, TECHNICAL DETAILS Travel range X-axis: 2,200 mm Travel range Y-axis: 600 mm Travel range Z-axis: 600 mm Number of T-slots: 5 T-slot width: 18 mm T-slot spacing: 125 mm Distance from spindle nose to table: min. 200 mm Tool holder: SK 40 DIN 69871 Pull stud: DIN 69872 Tool clamping force: 12,000 N Inner bearing diameter: 80 mm Spindle speed: max. 8,000 rpm Main spindle motor at 100% duty cycle: 29 kW Main spindle motor (intermittent): 38.5 kW Speed range with constant power from: 1,500 rpm Feed force X, Y and Z axes at 100% duty cycle: 13,000 N Feed force X, Y and Z axes (intermittent): 16,000 N Rapid traverse rate X, Y and Z axes: 30 m/min Working feed rate X, Y and Z axes: max. 10 m/min Milling performance in steel St 60: 650 cm³/min Drilling diameter in steel St 60: 60 mm Threading performance in steel St 60: M36 Tool places: 24 Tool length: max. 300 mm Tool weight: max. 10 kg Tool diameter with full magazine: max. 85 mm Tool diameter with free adjacent positions: max. 125 mm Tool change time: 3.5 s Tool change time chip-to-chip: 7 s MACHINE DETAILS Electrical connection: 55 kW Operating voltage: 400 V / 50 Hz Compressed air connection: 6 bar Coolant pump capacity: 0.75 kW EQUIPMENT Tool magazine with random tool management Dsdpfxe Afx Hhs Acpjwd Coolant pump
