Centrifugal Fan, Fan 5,5 kW

Condition: ready for operation (used), functionality: fully functional, machine/vehicle number: 160378, spindle bore: 40 mm, center height: 160 mm, center width: 750 mm, spindle speed (max.): 3,000 rpm, workpiece diameter (max.): 375 mm, No reserve price – guaranteed sale to the highest bidder! By placing a bid, you are obligated to collect the item within the specified timeframes: either between 11/05/2026 and 13/05/2026 or between 18/05/2026 and 21/05/2026. TECHNICAL DETAILS Centre height: 160 mm Centre distance: 750 mm Maximum workpiece diameter over bed: 375 mm Maximum workpiece diameter over cross slide: 180 mm Spindle speeds: 38 to 3,000 rpm Spindle taper: Morse 5 Spindle bore: 40 mm Collet capacity: 24 mm Fine feeds longitudinal and cross: 0.015 to 0.21 mm/rev Longitudinal and cross feeds: 0.025 to 0.35 mm/rev Cross slide travel on bed: 750 mm Compound slide travel: 120 mm Cross slide travel: 215 mm Centre height above tool slide: 32 mm Tool section: 20 x 20 mm Tailstock quill taper: Morse 3 Quill travel: 120 mm Lateral adjustment: +/- 10 mm MACHINE DETAILS Operating voltage: 380 V Klodeym Nkkjpfx Am Ner Dimensions & Weight Dimensions (L x W x H): 2,500 x 1,000 x 1,500 mm Weight: 2,500 kg EQUIPMENT Including documentation Matching tool cabinet with accessories included External reference: Showroom

Condition: excellent (used), Year of construction: 2001, functionality: fully functional, travel distance X-axis: 1,600 mm, travel distance Y-axis: 1,000 mm, travel distance Z-axis: 780 mm, controller model: HEIDENHAIN TNC 426, spindle speed (max.): 2,500 rpm, TECHNICAL DETAILS Travel Range X-axis: 1,600 mm Travel Range Y-axis: 1,000 mm Travel Range Z-axis: 780 mm Number of machining axes (excluding parallel axes): 5 Table Clamping surface (left-right): 1,000 mm Clamping surface (front-back): 1,000 mm Max workpiece weight: 6,000 kg Rotary axis: C > Positioning accuracy: 0.001° Milling Spindle/Head Spindle type: Swivel head > Positioning accuracy: 2.5° Speed range: up to 2,500 rpm Tool holder: ISO SK 50 Drive power: 22 kW Kjdpfx Aoyztl Nem Nolr Tool Magazine Tool positions: 60 Workpiece Automation Number of storage slots: 2 Pallet length: 1,000 mm Pallet width: 1,000 mm Number of pallets: 2 MACHINE DETAILS Control: HEIDENHAIN TNC 426 Dimensions & Weights Space requirement (left/right): 6,400 mm Space requirement (front/back): 6,900 mm Overall height: 4,000 mm Total weight: approx. 26,000 kg

Condition: ready for operation (used), Year of construction: 1994, functionality: fully functional, travel distance X-axis: 565 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 415 mm, workpiece weight (max.): 1,000 kg, table width: 600 mm, table length: 840 mm, TECHNICAL DETAILS Table size: 840 x 600 mm Dielectric fluid above table: 360 mm Maximum workpiece weight: 1,000 kg T-slots: 4 x 10 mm Distance table - quill without chuck max: 595 mm Distance table - quill without chuck min: 180 mm Travel X-axis: 565 mm Travel Y-axis: 400 mm Travel Z-axis: 415 mm Resolution X - Y - Z: 0.001 mm Resolution axis C: 0.001 Rapid traverse speed: 800 mm/min Max. electrode weight without rotation: 100 kg Max. electrode weight with rotation: 15 kg MACHINE DETAILS Dimensions & Weight Dimensions (H x W x D): 2760 x 1110 x 1840 mm Weight: 2,750 kg Dielectric supply Kedpfxoyzn Ryo Am Nelr Tank capacity: 400 liters Paper cartridge filters: 4 pcs Generator Dimensions (H x W x D): 1800 x 600 x 920 mm Weight: 300 kg Rated current: 60 - 120 A Connected load: 15 - 23 kVA

Condition: ready for operation (used), Year of construction: 2007, machine/vehicle number: 15507225, functionality: fully functional, operating hours: 9,980 h, travel distance X-axis: 700 mm, travel distance Y-axis: 420 mm, travel distance Z-axis: 610 mm, number of slots in tool magazine: 32, rotational speed (max.): 20,000 rpm, rotational speed (min.): 50 rpm, TECHNICAL DETAILS Travel X-axis: 700 mm Travel Y-axis: 420 mm Travel Z-axis: 610 mm Feed rates: 1 - 20 m/min Machine pallet Pallet dimensions: 1,260 x 490 mm T-slots: 9 x 12H8, 50 mm spacing Max. spindle speed: 50 - 20,000 rpm Tool system Tool holder: SK30 Number of tools in magazine: 32 MACHINE DETAILS Control: HEIDENHAIN iTNC 530M Ksdeyznvcepfx Am Njlr Dimensions & Weight Dimensions / Weight: 2,500 x 2,560 x 2,700 mm Installation dimensions: 4,300 x 2,950 x 3,012 mm Weight: 5,100 kg Connected load: 22 kVA Operating hours Spindle hours: approx. 9,980 h Control on-time: 78,165 h Machine on-time: 91,869 h Program run time: 54,682 h EQUIPMENT 3D touch probe, infrared Coolant system 3 bar / 30 l/min Oil mist extraction system Minimum quantity lubrication system with dual dispenser FEHLMANN HSC settings (Cycle 327) Note: The clamping devices and tools shown in the images are not included in the scope of delivery.

Condition: not inspected (used), Year of construction: 2012, functionality: unexamined, cutting width (max.): 4,500 mm, feed rate X-axis: 140 m/min, section length (max.): 2,200 mm, Equipment: CE marking, scorer, TECHNICAL DETAILS The machine is equipped with two saw carriages. The technical specifications apply to both: Maximum panel width: 4,500 mm Maximum panel length: 2,200 mm Maximum saw unit tool diameter: 380 mm Maximum scorer tool diameter: 200 mm Saw blade protrusion: 95 mm Number of rip saw grippers: 5 Number of cross cut saw grippers: 8+4 Maximum feed speed: 140 m/min Saw unit 1 connected load: 15 kW Saw unit 2 connected load: 15 kW Scorer unit 1 connected load: 2.2 kW Scorer unit 2 connected load: 2.2 kW Klodpfx Aoyxn Adsm Njr MACHINE DETAILS Control system: WINDOWS 10 Machine programming software: Biesse-OSI EQUIPMENT Second flexible push system Quick-change system for saw blades Label printer for barcodes CE marking The machine is sold and delivered in its actual and legal condition (“as seen and approved”), based on photographic documentation and technical/commercial documents of a descriptive nature. The buyer has the right to inspect the goods before collection and assumes responsibility for installation, safety, and operation of the machine at the place of destination. External reference: 5711

Year of construction: 2004, condition: not inspected (used), functionality: unexamined, plate length: 3,000 mm, plate width: 1,200 mm, stack height: 1,600 mm, TECHNICAL DETAILS Maximum panel width: 1,200 mm Maximum panel length: 3,000 mm Maximum stack height from floor: 1,600 mm EQUIPMENT Motion system: Suction cups Vacuum pump The machine is sold and delivered in its actual and legal condition ('as seen and approved'), based on photographic documentation and descriptive technical/commercial documents. The buyer has the right to inspect the goods prior to collection and is responsible for installation, securing, and use of the machine at the destination. Ksdsyxnquepfx Am Nolr External reference: 7684

Year of construction: 2011, condition: not inspected (used), functionality: unexamined, plate length: 2,200 mm, plate width: 1,000 mm, stack height: 1,600 mm, Equipment: CE marking, TECHNICAL DETAILS Max. panel length: 2,200 mm Max. panel width: 1,000 mm Max. stacking height of panels: 1,600 mm Number of stations: 2 MACHINE DETAILS Control system: WINDOWS EQUIPMENT CE marking Panel stacking station Station discharge System suction cups Vacuum pump Kjdpfx Amjyxnn To Njlr The machine is sold and delivered in its actual and legal condition ("as seen and approved") based on photographic documentation and technical/commercial documents of descriptive character. The buyer has the right to inspect the goods before collection and assumes responsibility for installation, securing, and use of the machine at its destination. External reference: 7997

Condition: not inspected (used), Year of construction: 2016, functionality: unexamined, edge thickness (max.): 22 mm, rotational speed (max.): 12,000 rpm, Equipment: CE marking, The machine has the following configuration: Pre-milling unit Automatic, timer-controlled intervention and positioning via NC Edge preheating lamps Edge band magazine Glue pot for EVA hot-melt adhesive Premelter for EVA hot-melt adhesive QM-705 End trimming unit IN-801 Number of motors: 2 Top and bottom flush trimming unit RS-100 Number of motors: 2 Motor power: 2 kW Speed: 12,000 rpm Fine finishing and contour trimming unit RF-100 Number of motors: 2 Motor power: 2 kW Speed: 12,000 rpm Corner rounding unit AR30 Number of motors: 2 Motor power: 0.8 kW Speed: 12,000 rpm Automatic, timer-controlled intervention End cutting unit RB02 Positioning by NC Glue scraping unit RCC-701 Polishing unit SP-501 Number of motors: 2 Motor power: 0.25 kW Spraying unit LPT-700 Klsdpfx Amjyxndbj Njr TECHNICAL DETAILS Panel height min: 10 mm Panel height max.: 60 mm Edge thickness min.: 0.4 mm Edge thickness max.: 22 mm MACHINE DETAILS Total connected load: 22 kW EQUIPMENT Feed pressure with rubber belt Panel support guides with NC positioning CE marking The machine is sold and delivered as is (“as seen and approved”) based on photographic documentation and technical/commercial documents of a descriptive nature. The buyer has the right to inspect the goods prior to collection and assumes responsibility for installation, securing, and use of the machine at the place of destination. External reference: 7673

Condition: not inspected (used), Year of construction: 2004, functionality: unexamined, workpiece length (max.): 2,500 mm, TECHNICAL DETAILS Panel length min.: 300 mm Panel length max.: 2,500 mm Panel return system for edge banding machine: Left Panel ejection: via air nozzle table Kjdpeyxnapsfx Am Nolr The machine is sold and delivered in its actual and legal condition ("as seen and approved") based on photographic documentation and technical/commercial documents of a descriptive nature. The buyer has the right to inspect the goods prior to collection and assumes responsibility for the installation, securing, and use of the machine at the destination. External reference: 7877

Condition: not inspected (used), Year of construction: 2000, functionality: unexamined, travel distance X-axis: 5,900 mm, travel distance Y-axis: 1,560 mm, feed rate X-axis: 80 m/min, feed rate Y-axis: 60 m/min, rotational speed (max.): 20,000 rpm, No reserve price – guaranteed sale to the highest bidder! TECHNICAL DETAILS X-axis working area: 5,900 mm Y-axis working area: 1,560 mm X-axis travel speed: 80 m/min Y-axis travel speed: 60 m/min Z-axis travel speed: 25 m/min Drilling spindles Vertical drilling spindles: 20 Horizontal drilling spindles in X-direction: 6 Horizontal drilling spindles in Y-direction: 2 Total number of vertical and horizontal spindles: 28 Milling spindles Number of controlled axes: 4 Motor power: 10 kW Spindle speed: 20,000 rpm Tool changer Number of positions: 10 Tool: head-mounted MACHINE DETAILS Total installed power: 24 kW Control system: WINDOWS Machine programming software: WRT EQUIPMENT Work table with suction cups Number of suction bar rows: 10 Suction cups for securing the workpiece Vacuum pump The machine is sold and delivered in its actual and legal condition ('as seen and approved') on the basis of photographic documentation and descriptive technical/commercial documents. The buyer is entitled to inspect the item before collection and is responsible for installation, securing and use of the machine at the final destination. Kedpfx Amsyxm Sws Nelr External reference: 8173
