LUMAG VH500A Fully Hydraulic Mini Tracked Dumper - 1 unit

Condition: repair required (used), functionality: limited functionality, Year of construction: 2017, machine/vehicle number: 2219, laser type: fiber laser, working length: 3,000 mm, working width: 1,500 mm, travel distance Z-axis: 120 mm, No minimum price – guaranteed sale to the highest bidder! The machine will be dismantled at the end of week 42. TECHNICAL DETAILS Laser type: Fiber laser Laser source manufacturer: IPG Laser source model: YLS-4000-CUT Kdsdpez N Dutofx Ag Aou Laser source power: 4 kW Currently available cutting power: 2 kW Working area: 3,000 × 1,500 mm Z-axis travel: 120 mm Number of pallets: 2 MACHINE DETAILS Control system type: CNC control Level of automation: Automatic Type of operation: Electric Machine dimensions: approx. 4,000 × 8,000 mm EQUIPMENT 2-pallet changing table Note: Modules 1, 4, and 5 automatically lock after cutting and must be unlocked by IPG. The currently available cutting power is 2 kW.

Condition: ready for operation (used), Year of construction: 2004, functionality: fully functional, spindle speed (max.): 6,000 rpm, bar passage: 65 mm, Equipment: bar feeder, chip conveyor, TECHNICAL DETAILS Tool turret Number of turrets: 3 Tool holder: VDI 25 W-gear Main and counter spindle Main and counter spindle speed: up to 6,000 rpm Bar diameter: 65 mm MACHINE DETAILS Coolant tank: 600 l Coolant pressure: 8 / 18 bar EQUIPMENT Gantry removal device Hainbuch HS Axzug / GS Axfix Chip conveyor Coolant tank with strainer basket Kdjdpfx Agsz Ibf Ee Aou Coolant pump Coolant cooling unit FMB Turbo 10-65, 3-meter bar feeder

Condition: ready for operation (used), Year of construction: 2000, functionality: fully functional, travel distance X-axis: 1,100 mm, travel distance Y-axis: 500 mm, travel distance Z-axis: 640 mm, controller model: SIEMENS 840 D, spindle speed (max.): 10,000 rpm, TECHNICAL DETAILS Travel range, X-axis: 1,100 mm Travel range, Y-axis: 500 mm Travel range, Z-axis: 640 mm Number of pallets: 2 Table size: 2 × 1,000 × 450 mm Ksdpfxsz Ibb Tj Ag Ajdu Table load capacity: 600 kg Spindle speed range: 50–10,000 rpm Drive power: 18.5 kW Tool interface: DIN 69871 / ISO 40 Feed rate range X/Y/Z: up to 10,000 mm/min Rapid traverse rate in all axes: 30 m/min MACHINE DETAILS CNC path control: SIEMENS 840 D Number of tool positions: 30 Machine dimensions & weight Machine dimensions L × W × H: approx. 3,605 × 3,041 × 3,220 mm Machine weight: approx. 6,700 kg EQUIPMENT 2-position pallet changer 30-position tool changer Internal coolant supply (ICS) Full enclosure with electrically interlocked safety doors Linear guides with double roller recirculating bearing for even absorption of high torques in all directions Ball screws in all 3 axes Machine bed made of Meehanite cast iron for high precision, rigidity, and vibration damping Swivel chip conveyor with integrated coolant system Preparation for 4th axis CE compliant

Condition: ready for operation (used), functionality: fully functional, machine/vehicle number: 90439563, Year of construction: 2013, operating hours: 4,543 h, load capacity: 1,200 kg, lifting height: 2,600 mm, mast type: duplex, fork length: 1,150 mm, TECHNICAL DETAILS General Information Year of manufacture: 2013 Type: Pedestrian stacker Serial number: 90439563 Operating hours: 4,543 h Unladen weight: 834 kg CE marking: Yes Lifting Data Lifting capacity: 1,200 kg Lifting force: 1,200 kg Lifting height: 2,600 mm Ksdpfsz N Di Rox Ag Aedu Free lift: 0 mm Mast: Duplex Dimensions Overhead height: 1,700 mm Fork length: 1,150 mm Fork width: 560 mm Drive and Battery Drive: electric Battery voltage: 24 V Transport Data Transport dimensions: 1,850 × 800 × 1,700 mm Transport weight: 834 kg Transport packages: 1 unit EQUIPMENT Duplex mast Electric drive CE marking present

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2012, operating hours: 28,000 h, controller model: Siemens Sinumerik 840 D SL, laser power: 5,000 W, sheet thickness steel (max.): 25 mm, working length: 4,000 mm, working width: 2,000 mm, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Resonator power: 5 kW Working area (L × W): 4,000 × 2,000 mm Sheet metal thickness, steel: max. 25 mm Sheet metal thickness, stainless steel: max. 20 mm Sheet metal thickness, aluminum: max. 20 mm Speed: max. 235 m/min Accuracy: 0.001 mm Kjdjz Npdgspfx Ag Aodu MACHINE DETAILS Control system: Siemens Sinumerik 840 D SL Dimensions & Weight Dimensions (L x W x H): 12,000 x 5,300 x 2,200 mm Machine weight: 13,000 kg Operating hours: 28,000 h EQUIPMENT LiftMaster Power supply for TruDisk via the machine Work area lighting Positioning laser diode Spray device PierceLine FocusLine NitroLine PlasmaLine Automatic nozzle cleaning TRUMPF laser Solid-state laser TruDisk 5001 with one LLK outlet Light guide cable according to standard layout Laser cooling unit (water-air) Excitation via pump diodes Laser power control Laser logbook function Cutting head Universal cutting unit with fully adaptive lens system Protective glass against lens contamination Condition monitoring of the protective glass ControlLine: Height control and sheet metal edge detection 17-inch touch color display Simple workshop programming Advanced workshop programming Fast reproduction Integrated technology data Automatic shutdown FastLine FlyLine AdjustLine Remote service via internet USB interface RJ-45 network connection CE marking Light barriers Multi-camera base system Compact dust extraction system Machine enclosure with certified viewing window, door on the right Electric roll-up roof Retrofitting capability for max. 2 additional LLK outlets

Condition: ready for operation (used), functionality: fully functional, Year of construction: 2008, operating hours: 38,149 h, controller model: Bosch MTX compact, laser power: 4,000 W, punching force: 22 t, sheet thickness (max.): 8 mm, Includes SheetMaster & GripMaster! TECHNICAL DETAILS Kdjdpez Nn H Hsfx Ag Aou Laser power: approx. 4,000 W Punching force: max. 220 kN Sheet thickness: max. approx. 8 mm Working area, laser operation (X × Y): approx. 2,540 × 1,280 mm Working area, punching operation (X × Y): approx. 2,540 × 1,370 mm MACHINE DETAILS Control system: Bosch MTX compact Dimensions & Weight Footprint (L × W): approx. 7,950 × 6,700 mm Machine weight: approx. 23,000 kg Total connected load: 87 kVA Operating hours: 38,797 h Beam on-time: 38,149 h EQUIPMENT Active dies SheetMaster GripMaster

Condition: ready for operation (used), Year of construction: 2010, machine/vehicle number: 6.719, functionality: fully functional, cutting height (max.): 90 mm, saw blade diameter: 350 mm, overall weight: 500 kg, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Max. cutting depth: 120 mm Max. cutting height: 90 mm Max. saw blade diameter: 350 mm Saw blade bore diameter: 30 mm Kodpsz Ni S Rjfx Ag Aodu MACHINE DETAILS Voltage: 400 V Current consumption: 7.13 Fuse rating: 16 A Main motor power: 3.1 kW Dimensions & Weight Dimensions (L x W x H): 1,500 x 900 x 1,700 mm Weight: 500 kg Shipping packages: 1 piece

Condition: ready for operation (used), Year of construction: 2016, functionality: fully functional, operating hours: 3,625 h, cutting width (max.): 4,300 mm, overall weight: 7,200 kg, cutting length (max.): 1,600 mm, No minimum price – guaranteed sale to the highest bidder! Kdjdsz Ni S Dspfx Ag Aou TECHNICAL DETAILS Max. cutting length: 1,600 mm Max. cutting width: 4,300 mm MACHINE DETAILS Dimensions & Weight Dimensions (L x W x H): 13,600 x 2,450 x 2,450 mm Weight: 7,200 kg Transport packages: 8 pcs. Operating hours: 3,625 h

Condition: ready for operation (used), Year of construction: 2010, machine/vehicle number: 161/1-10, functionality: fully functional, total height: 2,580 mm, total length: 5,500 mm, total width: 1,500 mm, overall weight: 1,500 kg, No minimum price – guaranteed sale to the highest bidder! The machine has the following configuration: Number of units: 7 1st unit: Pre-milling unit 2nd unit: Gluing unit 3rd unit: Pressure rollers 4th unit: Edge trimming unit 5th unit: Rough milling unit 6th unit: Corner rounding unit 7th unit: Edge planing unit Kdsdsz Ni Rmepfx Ag Aeu MACHINE DETAILS Voltage: 400 V Current consumption: 38.85 A Fuse rating: 50 A Dimensions & Weight Dimensions (L x W x H): 5,500 x 1,500 x 2,580 mm Weight: 1,500 kg EQUIPMENT Tools: Pre-milling unit Gluing unit Tools: Pressure rollers Tools: Edge trimming unit Tools: Rough milling unit Tools: Corner rounding unit Tools: Edge planing unit CE marking

Condition: ready for operation (used), Year of construction: 2016, machine/vehicle number: 109/1-606, functionality: fully functional, operating hours: 12,415 h, overall weight: 4,800 kg, No minimum price – guaranteed sale to the highest bidder! The machine has the following configuration: Number of units: 11 Pre-milling unit Gluing unit Pressure rollers: Type 1914 Cutting unit: Type KA701 Rough milling unit: Type 1828 Fine milling unit: Type FR701 Edge rounding unit: Type FF701 Radius drawing unit: Type ZK501 Straight edge drawing unit: Type 1856 Brushing unit: Type ES701 Gluing system Gluing system: Glue pot TECHNICAL DETAILS Edge band thickness: 3–20 mm Panel thickness: 8–60 mm Panel width: max. 65 mm Panel length: 180–250 mm Feed speed: 10–25 m/min Feed control: stepless MACHINE DETAILS Voltage: 400 V Current consumption: 45 A Dimensions & Weight Dimensions (L x W x H): 9,050 x 1,200 x 2,200 mm Weight: 4,800 kg Transport packages: 2 units Operating hours: 12,415 h EQUIPMENT Tools for pre-milling unit available Tools for pressure rollers available Tools for cutting unit available Tools for rough milling unit available Tools for fine milling unit available Tools for edge rounding unit available Tools for radius drawing unit available Tools for straight edge drawing unit available Tools for brushing unit available CE marking Documentation Kodpfx Aoz Ni Hnjg Aedu
