Used Heller Horizontal/Vertical Machining for sale (67,108)

Condition: used, Spinner MICROTURN 52 LTBS Sub-Micron Turn Mill Center with Y / B-Axis and Twin Spindles AUTOMATION READY - MC0122 Less than 300 hours No bar feed Tools and probes included—for all 3 spindles? BMT 45 Probe would stay. No tooling Chucks etc. included Yes Coolant: used Water Based What kind of facility is it in? R and D for performance parts for injector and turbos Specifications Work Area: Swing Diameter: 23.9 in (608 mm) Turning Diameter (max): 5.9 in (150 mm) Turning Length(max): 9.8 in (250 mm) Travels: X: 23.6 in (600 mm) Z:13.8 in (350 mm) Y1 Turret: +/- 1.9 in (50 mm) Y2 Milling Spindle: +/- 1.9 in (50 mm) B Rotary: 180 degrees Feedrate: Rapid Traverse X: 944.8 ipm (24 m/min) Rapid Traverse Y: 590.6 ipm (15 m/min) Rapid Traverse Z: 944.8 ipm (24 m/min) Spindle #1 Left / #2 Right: Liquid cooled motorized spindle with C-axis servo drive and encoder for synchronous machining. Spindle Bore Capacity: 52mm (2.0 in) Speed: 5,200 rpm Performance (S6 40%): 22.1 hp (16.5 kW) Torque (S6 40%): 81.1 ft-lb (110 Nm) Spindle Nose: DIN 55026-A6 B-Axis Milling Spindle: Speed (max): 12,000 rpm Performance (S6 40%): 12 hp (9 Kw) Nedpfjyzkdcsx Acfewh Torque (S6 40%): 15.4 ft-lbs (21 Nm) Swivel Angle: +/- 180 degrees Positional Measurement: Rotary Encoder Clamping: Hydraulic Turret: Stations: 12 / BMT45 Live Tooling Speed: 8,000 rpm Performance (S3 25%): 5.8 hp (4.3 kW) Torque (S3 25%): 10 ft-lb (13.6 Nm) Tool Magazine: Station Quantity: 72 Holder Type: HSK40 Tool Length (max): 4.1 in (105 mm) Tool Diameter (max): 3.5 in (88 mm) Tool Diameter (max) - Adj Pocket Empty: 3.9 in (100 mm) Size & Electrical: Technical design according to CE standards. Machine Dimensions: 119.3 in (3030 mm) x 111.8 in (2840 mm) x 113.8 in (2890 mm) Machine Weight: 16,976 lbs (7,700 kg) Operating Voltage: 3 x 400V (+/-10%) Main Frequency: 60 Hz (+/- 2%) Electrical connection: TN network (5-wire) Standard Equipment • 72-station tool magazine mounted on top of the machine • Hydraulic spindle brake on spindle 1 • Hydraulic spindle brake on spindle 2 • Spindle rinsing on spindle 1 (switchable between coolant or compressed air) • Spindle rinsing on spindle 2 (switchable between coolant or compressed air) • CNC Clamping Force Setting on Spindle 1 - recommended for convenient setting of clamping force from the CNC program, or on the screen. • CNC Clamping Force Setting on Spindle 2 - recommended for convenient setting of clamping force from the CNC program, or on the screen. • Linear tool slide with coolant supply • Signal lamp • Rear exit chip conveyor - includes feed pump rated at 5 bar at 20l/min or 3.7 bar at 83l/min • High pressure coolant system with additional 61 gallon (230 liter) tank. Maximum 319 psi (22 bar) • Renishaw tool probe for measuring tools in the X/Y/Z axis • Preparation for mist collector unit • Automatic operator door that opens at the end of the program and closes with the start. Includes necessary safety technology. Suitable for manual loading or automation access. • UNIROB universal robot interface via a common plug on the machine control cabinet with the following signals: • Safety signals (emergency stop/door signals, etc.) • Standard signals via Profinet PN bus coupler on RJ45 module. Otherwise according to the Unirob-V2021 functional description CNC Control System

Condition: used, Year of construction: 2021, EMAG VMC 450 MT Mfd. 2021 Control: Siemens 840D SL Machine has no production hours Description CHUCK DIAMETER: 24" MAX WEIGHT: 1100 LBS. MAX SWING DIAMETER: 31" MAX TURNING DIAMETER: 23.5" X STROKE: 30" Z STROKE: 19" MAIN DRIVE: POWER: 100 HP FULL POWER AT 800 RPM MAX SPINDLE RPM: 2,000 C AXIS POSITIONIONG TO .01MM ANGULAR DEGREES FEED DRIVE: RAPIDS Z / Z: 60 / 30 M / MIN. FEED FORCE X / Z 4 / 15 kN BALL SCREW DIAMETER X / Z: 40 / 50 MM MILLING SPINDLE: POWER: 100 HP MAX SPINDLE SPEED: 7000 RPM SPINDLE TAPER: CAPTO C8 TOOL MAGAZINE: 60 EQUIPPED WITH: MINERALIT MACHINE BED SIEMENS 840 D SL FULL ENCLOSURE Nodpeyzkdvjfx Acfewh LEVEL PADS TURN MILL DRIVE EMAG WORKPIECE CORRECTION SYSTEM EMAG OPERATING AND SETTINGS MASKS EMAG REMOTE DIAGNOSIS Y AXIS B AXIS +/- 95 DEGREE 1000 PSI COOLANT THROUGH TOOL X-AXI CLAMPING FOR GEAR TOOTH FORMING SWARF CONVEYOR, CHAIN TYPE - REAR DISCHARGE LIFTING PUMP PAPER FILTER LOW PRESSURE COOLANT HIGHT PRESSURE COOLANT 1000 PSI PROGRAMMABLE COOLANT PRESSURE COOLANT MIST EXTRACTOR AIR BLAST CHIP FLUSH QUALITY CONTROL: WIRELESS GAUGING CALIBRATION BLK FOR PROBE TOOL GAUGING - BLUM LASER

Year of construction: 2012, condition: ready for operation (used), functionality: fully functional, machine/vehicle number: BCOR12150, BIESSE BREMA EKO 902 CNC and vertical dowel insertion machine for reduced cycle times Equipment Features - Clamping grippers measure the thickness to adjust drilling depth - Laser-based measuring system for detecting the front and rear panel edges - Length tolerance compensation correcting the workpiece length in X - 5-position tool changer - Drilling head with individually retractable spindles and grooving saw - Diameter: 120 mm - Gluing and dowel insertion units mounted on Y and Z axes Options - 4.5 kW electrospindle; 18,000 rpm - Special drilling unit for hinges Technical Data - Panel length: 160 - 3200 mm - Panel width: 35 - 900 mm - Panel thickness: 8 - 80 mm - X/Y/Z axis speed: 100 / 60 / 30 m/min - X axis travel: 3200 mm - Y axis travel: 900 mm - Main spindle power: 4.5 kW - Number of controlled axes: 3 axes - Number of drilling spindles: 20 Nodpfjw Nytnex Acfowh - Number of tool positions: 5

Condition: excellent (used), Year of construction: 1997, HAAS VF10 X AXIS 3048 MM Y AXIS 813 MM Nedpfey Epkmox Acfjwh Z AXIS 760 MM TABLE WEIGHT MAX 1800 KGS 3 AXIS HAAS CONTROL THIS IS ALL THE DETAILS I HAVE AT THE MOMENT MORE WILL FOLLOW CHEAP MACHINE MORE PHOTOS AND A VIDEO IS AVAILABLE

Condition: excellent (used), Year of construction: 2020, Traverses XYZ: 610 x 406 x 406mm, 400mm Diameter table, max table weight 226kg, table tilt +120°, -35°, 22.4kW, 10000rpm, Njdjzg Enqspfx Acfewh BT40, 30 station tool changer, coolant, swarf conveyor

Condition: good (used), Year of construction: 2008, Traverses X Y Z: 1020 x 540 x 540mm, Table 1120 x 540mm, siemens 810 Control, 24 Station ATC, Spindle power 15Kw, 10,000rpm, Nedpfszg Enkox Acfswh BT40 Spindle, Coolant,

Condition: used, Year of construction: 2009, 2009 OKUMA MILLAC 800 VH Palletised System 5 Axis Machining Centre With OSP P200M Control Nwsdpfxozfhudo Acfeh Automatic Pallet Changer (APC) 6-Station Automatic Pallet Pool, Including 4 Additional Pallets. Tool Magazine 120-Station ATC (Automatic Tool Changer). Linear Glass Scales On 'X, Y, Z' axes (In Addition To Standard Encoders). 'A'-Axis Rotary Scale: Circular Glass Scale On Tilting Head Spindle ('A'-Axis), 0.001° Resolution, Equipped With Tilting Brake Clamping. 'C'-Axis Rotary Scale: Circular Glass Scale On Rotary Table ('C'-Axis), 0.001° Resolution, Equipped With Continuous Brake Clamping. Maximum Spindle Speed 10,000rpm (18.5/22 kW Motor), 21 Nm Torque. Spindle Taper BT 50 BIG PLUS. Pallet Dimension 800 x 800mm. Maximum Pallet Load 1,000kg. Axis Travel 'X'=1,020mm, 'Y'=1,020mm, 'Z'=1,020mm. Rapid Traverse 'X'=30m/min, 'Y'==30m/min, 'Z'=30m/min, 'A'=3,600min-1, 'C'=3,600min-1. Cutting Feed 'X, Y, Z'=1-12,000mm/min, 'A, C'=1-2,400°/min. Spindle Nose To Pallet Top (Vertical) -100 To 920mm. Spindle Centre To Pallet Centre (Vertical) -50 To 970mm. Spindle Centre To Pallet Top (Horizontal) 150-1,170mm. Spindle Nose To Pallet Centre (Horizontal) -300 To 720mm. Maximum Tool Ø125mm (Ø200mm Without Adjacent Tool), Maximum Tool Length 400mm, Maximum Tool Weight 20kg. Tool Change Time (T-T) 4.5sec. Power Capacity 60kVA. S/No.143486 (2009/03). With Workpiece Probe: Spindle-Loadable Measuring Probe (From ATC) For Workpiece Zero-Setting & Inspection, Including Macro B Software Option On The CNC. Air Blow System: Spindle Annular Air Blow For Chip Removal & Cone/Flange Cleaning (BT 50 Big Plus). Tool Sensor: BLUM Laser System For Tool Length And Ø Control, Including Pneumatic System For Laser Lens Cleaning. Coolant Through Spindle (CTS): High-Pressure CTS System At 70 BAR (13/18 L/min / 6.9 MPa) With Inline Centrifugal Filter. Spindle Air/Fluid Output: Selectable Air Blow Or Coolant Through Spindle. Shower Coolant: Overhead Shower Wash System. Wash Gun: Coolant Wash-Down Gun Including Dedicated Pump. Chip Conveyor: Drum Filter Type Chip Conveyor With 700L Tank. Oil Skimmer: Installed On The Chip Conveyor. Work Coordinate System Expansion: Expanded To 400 Tool/Workpiece Origins. Tool Offset Expansion: Expanded To 500 Tool Length And Radius Offsets. 3D Tool Radius Compensation: Three-Dimensional Tool Radius Compensation Software. SUPER NURBS Kit: Included (Features: Tool Length Compensation, Vector Control, Lateral Tool Compensation). Data Transfer: DNC-DT Ethernet Software Interface. Programming Functions: Scaling (G50/G51 codes), Mirror Imaging, And Programmable Custom Message Input. Cycle Restart: Sequence Return / Block Restart From Any Interrupted Block. MOP (Machining Operation Monitor): Self-Learning Cutting Load Control/Tool Overload Monitoring. G93 Function: Inverse Time Feed Function. Thermal Compensation: Spindle Tilt Thermal Compensation Software. Overall Dimensions L4,760 x D6,300 x H3,600mm. Weight 22,000kg.

Condition: excellent (used), Year of construction: 2018, HS Flex 20 station pallet loader. XYZ: 600 x 550 x 330mm, Maximum workpiece diameter 450mm, Nsdezghngspfx Acfjwh maximum workpiece height 355mm, Maximum table load 300Kg, A axis -/+ 115 degrees, spindle taper HSK 63, spindle speed 15,000rpm, 30 station tool changer, Heidenhain TNC 640 control, with swarf conveyor , and high pressure coolant.

Condition: excellent (used), Year of construction: 2016, functionality: fully functional, machine/vehicle number: PV10150642, MACHINE SPECIFICATION Table size 1200 x 480mm X axis traverse 1050mm Y axis traverse 540mm Z axis traverse 560mm Spindle nose to table 80 – 640mm Spindle BT 40 Spindle speeds 20 – 10,000rpm Spindle motor 15kW Rapid feed rate X/Y/Z 32/32/24m/min Toolchanger capacity 24 Tools Approximate weight 6600Kg Nsdpszguf Sefx Acfjwh MACHINE EQUIPPED WITH: - Siemens 828D CNC control Swarf auger Coolant system Lighting Guarding

Condition: like new (used), Year of construction: 2021, functionality: fully functional, Fully equipped Biesse Brema EKO 2.2, including a return system and auxiliary units. Quick delivery. Nwodpfxezhbpas Acfoh

Condition: used, Year of construction: 2008, functionality: fully functional, machine/vehicle number: 3001033048, travel distance X-axis: 1,020 mm, travel distance Y-axis: 550 mm, travel distance Z-axis: 560 mm, rapid traverse X-axis: 20 m/min, rapid traverse Y-axis: 20 m/min, rapid traverse Z-axis: 20 m/min, feed rate X-axis: 10 m/min, feed rate Y-axis: 10 m/min, feed rate Z-axis: 10 m/min, controller manufacturer: FANUC, controller model: 0i-MC, workpiece weight (max.): 1,000 kg, total height: 2,715 mm, total length: 3,260 mm, total width: 3,060 mm, table width: 660 mm, table length: 1,250 mm, table load: 1,000 kg, overall weight: 6,000 kg, spindle speed (max.): 8,000 rpm, spindle motor power: 11,000 W, number of spindles: 1, number of slots in tool magazine: 24, For sale: a DAHLIH DL-MCV1020BA CNC vertical machining center from 2008, equipped with a FANUC control system. The machine is currently still operational in our production environment and has not been dismantled. This means that, if interested, it can be inspected while powered on and, upon agreement, tested in working order. This robust vertical machining center is suitable for a wide range of milling, drilling, and tapping operations and represents an attractive solution for companies looking for a reliable CNC machining center with a large machining capacity. The machine is sold in its current condition. Any tools, fixtures, or other accessories visible in the photos are only included if explicitly agreed upon. Nwedpfozhbq Rox Acfeh Inspection and functional testing are possible in Kuurne, Belgium, by appointment only.

Condition: good (used), functionality: fully functional, Bridgeport VMC 600 22 CNC machining center with Heidenhain TNC 410 / 426 control system -Travel X-axis: 600mm -Travel Y-axis: 410mm -Travel Z-axis: 520mm -Table load capacity: 500 kg -Spindle taper: SK 40 ISO/BT -Spindle power: 8.5 kW -Speed range: 40 to 6000 RPM -Tool changer: 22 positions -Number of controlled axes: 3 -Year of manufacture: 2000 Nwedjzhg Rispfx Acfoh -Length: 2800 mm -Width: 2050 mm -Height: 2300 mm -Weight: Approx. 2500 kg

Condition: used, Year of construction: 1998, 13 spindles at 32mm centres Nwsdpfxszd Uu Ij Acfsh Approx 70mm max boring depth Spindle speed 2800mm 2.5hp motor Manual tilting of boring group from vertical to horizontal [can be locked at 45 degrees]

Condition: good (used), Year of construction: 1997, Used Hedelius machining center Type BC 80 X-axis: 2500 mm Y-axis: 800 mm Z-axis: 550 mm SK 50 spindle Heidenhain CNC control with Siemens motors/servos Includes tool/clamping system on the table Year of manufacture: 1999 Nsdpfezhat Dex Acfswh Excluding chip conveyor

Condition: excellent (used), Year of construction: 2019, machine/vehicle number: 960540, GIC 3100 bagging machine direct from closed salad factory. In nearly new condition but has had it's electronic components removed (we will replace these with new direct from GIC). Large choice of tooling available. Nwjdpfx Acsyx Na Rsfeh

Condition: excellent (used), GIC VFB4000 in immaculate condition. Was only used for a few weeks prior to the contract not going ahead. Can be supplied as a line with Multipond weigher (also only used for a few weeks) Njdjvtcqgepfx Acfjwh

Condition: good (used), Very high spec bagging machine. Large choice of forming sets including block bottom. Nsdpfjywpblsx Acfjwh

Condition: good (used), GEA Aquarius CX360 bagging machine direct from salad packing line. Nice condition. Nwsdpfxowztmtj Acfjh

Condition: used, machine/vehicle number: 007734, X axis working area: 3050 mm Y axis working area: 850 mm Main Electrospindle power: 5 KW Nwedpfxow Idb Hj Acfjh Total number of drilling spindles: 19

Condition: excellent (used), Year of construction: 2016, functionality: fully functional, Technical details grinding length 800 mm grinding width 400 mm workpiece height 375 mm weight of the machine ca. 3,5 t Additional information CNC Precision Surface and Profile Grinding Machine This machine is ideally suited for precision applications in tool and mold making. Technical Details: Grinding surface: 800 x 450 mm Grinding area: 800 x 400 x 375 mm Table load (max.): 700 kg X-axis = Longitudinal movement of worktable Table longitudinal stroke: 20 - 850 mm Table drive: Electromechanical with toothed belt drive Table speed: 5 - 35,000 mm/min Table setup: Electric handwheel and direction push button Y-axis = Vertical movement Distance from table to spindle center: 140 - 525 mm Vertical drive: Electromechanical with ball screw Vertical speed: 50 - 2,000 mm/min Vertical adjustment via electric handwheel and direction pushbuttons Minimum infeed 0.001 mm Measuring system: glass scale Z-axis = Transverse movement Maximum transverse travel 400 mm Drive type: electromechanical with ball screw Nsdpfx Acezg Udhjfowh Transverse speed 50 - 2000 mm/min Transverse travel adjustment via electric handwheel and direction pushbuttons Measuring system: glass scale C-axis = Grinding spindle Grinding spindle motor 7 kW Grinding spindle speed 1400 rpm Grinding wheel standard 300 x 50 x 76.2 mm Spindle bearing: Precision roller bearing Lubrication: Lifetime lubrication Connected load: approx. 19 kVA Total weight: 3500 kg Equipment: - Electro-permanent magnetic chuck Clamping surface 800 x 400 mm, Pole spacing 18 mm, with 16-stage holding force control and automatic Magnetic pole reversal for demagnetization - Leveling blocks For setting up and leveling the machine - Grinding wheels and two flanges - Partial enclosure Open at the top for loading with a sliding door - Dressing system Consisting of a holder for a prism arm or fork dresser Practicle arm for single-point diamond (MK O) or shaped diamond - Grinding spindle speed control Peripheral speed 10-32 m/s The peripheral speed of the grinding wheel is kept constant (V-constant control) with a 7 kW grinding spindle motor - Universal paper belt filter unit UPF 100 Tank capacity approx. 280 liters, Pump capacity 20 liters/minute at 1.5 bar - Air purifier Flow rate approx. 1000 m³/h - Compressed air ports For easier removal of large workpieces with a manual compressed air valve in the machine's work area. - Mobile balancing unit With optical operator guidance for dynamic balancing of the grinding wheel directly in the machine. Imbalance size and position are calculated automatically. With transport case. - Cleaning set Hand-held impulse nozzle for cleaning the work area - Documentation/Manual For sale is our reliably operating grinding machine from mold making. The machine was purchased new in 2016 and is in good technical condition, having been used for a maximum of 20 hours per week. It runs perfectly and is being sold solely due to an investment in a larger model.

Condition: used, machine/vehicle number: 007289, X axis working area: 3200 mm Y axis working area: 900 mm Main Electrospindle power: 4.5 KW Nwsdpfowukyqex Acfsh Number of controlled axes: 3 axes Total number of drilling spindles: 16

Condition: excellent (used), Year of construction: 2013, FEELER VB-1650 CNC Vertical Machining Centre Control FANUC 31i-TB Year 2013 Table size 800 x 1900 mm Travels XYZ 1650 x 800 x 700 mm Spindle nose to table 145-845mm Spindle centre to column 850mm Spindle speeds to 8000 rpm Nodpfxezd Dfis Acfowh Spindle taper BT 40 Spindle motor 26 kW Number of tools 30 ATC Rapid traverse X & Y 20 m/min, Z 18 m/min Weight 13000 kg Supplied wtith: Part probing, BLUM tool probe, Swarf Augers, Swarf conveyor, Spindle chiller, Filtermist FX7002. Tooling Package. For sale with *Jet Machinery Ltd* Jet Machinery Stock No: #27002 Machine Serial Number: VHE133 Cost: £39,950.00 + VAT Whilst every effort has been made to ensure that the above information is accurate it is not guaranteed. We advise prospective purchasers to check any vital details. Health and Safety At Work Act 1974: It is not reasonably practical for ourselves as suppliers to ensure that for your application the goods comply with requirements of the Act with respect to guarding etc. Prospective purchasers should ensure that a guarding specialist inspect the goods prior to use.

Condition: used, Year of construction: 1995, Fanuc MSC 516 2 pallets, 500x500mm BT40 spindle Spindle speed: 12,000 RPM 20-tool changer Coolant pressure: 20 bar Nodpfszgrzkex Acfjwh Renishaw

Condition: used, Year of construction: 2009, x-travel 635 mm y-travel 510 mm z-travel 460 mm control Siemens ergoline table surface area 2x 790 x 560 mm number of pallets 2 rapid traverse 30 m/min turning speed range 18000 U/min power capacity - milling spindle 13 kW no. of tools in the magazine 30 Stück tool taper SK 40 | | weight 5,2 t Nwsdpjtxctvefx Acfsh dimensions 3,1 x 2,1 x 2,7 m vertical machining centre wit 2x palettchanger, Equipment: - 2x palettchanger - chipconveyor - internal coolant - filter system - ext. hand wheel - laser tool setter - cableless 3D probe - oil dust collector - Siemens ShopMill dialog programming - Roto Clean - signal lamp - spindle oil cooler

Condition: ready for operation (used), Year of construction: 2013, operating hours: 23,831 h, functionality: fully functional, machine/vehicle number: 15465588584, travel distance X-axis: 400 mm, travel distance Y-axis: 400 mm, travel distance Z-axis: 375 mm, controller model: Heidenhain iTNC 530 HSCI, rotational speed (max.): 18,000 rpm, TECHNICAL DETAILS Travel range, X-axis: 400 mm Njdezgt U Eopfx Acfewh Travel range, Y-axis: 400 mm Travel range, Z-axis: 375 mm B-axis: -5 to +110 degrees C-axis: 360 degrees Table dimensions: 450 x 400 mm Maximum workpiece weight: 250 kg Spindle speed: 18,000 rpm Tool interface: HSK-A63 Number of tool positions: 60 Rapid traverse rate: 80 m/min MACHINE DETAILS Control system: Heidenhain iTNC 530 HSCI Machine weight (approx.): 7,150 kg Operating hours Spindle hours: 23,831 h Power-on hours: 57,330 h EQUIPMENT Band filter system NC rotary table Handwheel FS Coolant gun Tool measurement system Chip conveyor Rotoclear viewing window Temperature monitoring
