Used Lazzoni Group Throughfeed Drilling Machine for sale (68,605)

Condition: ready for operation (used), Year of construction: 1965, functionality: fully functional, travel distance X-axis: 1,600 mm, travel distance Y-axis: 1,200 mm, travel distance Z-axis: 1,150 mm, spindle speed (max.): 6,000 rpm, table load: 6,000 kg, No minimum price – guaranteed sale to the highest bidder! TECHNICAL DETAILS Travel range, X-axis: 1,600 mm Travel range, Y-axis: 1,200 mm Travel range, Z-axis: 1,150 mm Spindle speed: 20–6,000 rpm Lhsdpezuzpaefx Agtek Work table: 1,200 × 1,400 mm Table load: max. 6 t Please note the following: The height and weight of the asset must be taken into account when selecting the transport vehicle. There is no loading dock on site. However, a forklift or an overhead crane is available for loading. If the asset is not collected on time, a storage fee of €20.00 per lot and per day (or part thereof) will be charged. The fee must be paid before collection. The sale is made without any warranty or guarantee. The information on the technical data is based on the original offer. No liability is accepted for typographical or measurement errors. In case of doubt, please compare the information with the provided photos or inspect the item on site before the auction ends.

Condition: used, machine/vehicle number: 008013, X axis working area: 5780 mm Y axis working area: 1650 mm Working Table: Pod and Rail Main Electrospindle power: 13.2 KW Number of controlled axes: 4 axes Maximum edge height: 60 mm Total number of drilling spindles: 16 Total number of tool changer positions: 16 Lhedpfxowuz Ekj Agtsk

Year of construction: 1994, condition: good (used), machine/vehicle number: 491P, Technical data: - Drilling capacity in steel ST 60: 28 mm Lhjdsdkx Anspfx Agtek - Drilling diameter in steel ST 60: 32 mm - Drill spindle mount: MK 3 - Right/left rotation - Drill spindle stroke: 150 mm - Drill spindle speeds, stepless: 80 - 1170 rpm - 2 feed rates: 0.1 / 0.2 mm/rev - Overhang: 290 mm - Max. distance table - drill spindle: 780 mm - Table with 2 T-slots: 480 x 400 mm - Height adjustable via rack and pinion with hand crank - Drive: 400 V / 0.9 / 1.3 kW - Space requirement, approx.: W 600 x H 2100 x D 900 mm - Weight, approx.: 420 kg - Includes: - Coolant system - Quick-change drill chuck 1-13 - Lighting

Condition: used, Year of construction: 1965, bore capacity in steel (diameter) 40 mm Lhodsv S Iqcjpfx Agtok total power requirement 4 kW

Condition: good (used), Year of construction: 2013, total length: 3,990 mm, total height: 2,500 mm, total width: 2,280 mm, overall weight: 8,500 kg, INGERSOLL CM SYSTEMS AOHD AGILE OIL HOLE DRILL Equipped with: Siemens 840D Control (2) Drill Heads 20-Tool Rack Lhodertrx Rspfx Agtok HSK 50A Taper (2) 7" 3-Jaw Chucks (2) Tailstocks (2) Steady Rests Chip Auger Chip Conveyor Mist Collector Hydraulic System Q R 2 Lube System Air Compressor Specifications: Maximum Length: 1050 mm (41.3") Minimum Length: 180.0 mm (7.1") Maximum Stroke: 250.00 mm Maximum Main Journal Diameter: 115.0 mm (4.5") Maximum Pin Journal Diameter: 100.00 mm (3.9") Maximum Swing Diameter: 250.0 mm (9.84") X-Axis Travel: 1450 mm (57.1") Y-Axis Travel: 150 mm (5.9")W/HSK 50 Z-Axis Travel: 305.0 mm (12.0") A-Axis Travel: 360 Degree B-Axis Travel: 90 Degree Feed Rate (Z): 1 m/min Maxim (40"/min max) Position Accuracy of X,Y,Z Axes: .010 mm (.00039") Position Accuracy of A & B Axes: .03 Degree Position Repeatability of X,Y,Z Axes: .005 mm (.0002") Position Repeatability of A & B Axes: .005 Degree Spindle Power: 5.5 kW (7.5 hp) Spindle Speed: 0-6,900 RPM Tool Adaption: HSK 50E or A Tool Storage (ATC): 20 Total - 10 Per Spindle W/HSK 50 Lubrication - Slides & Ball Screws: Automatic Central Lubricator Approximate Floor Space (LxWxH): 4.0 x 2.3 x 2.5 m (13.1 x 7.5 x 8.2 Ft) Approximate Machine Weight: 8,500 kg (18,740 #)

Condition: ready for operation (used), Year of construction: 2006, input voltage: 400 V, number of axes: 4, controller manufacturer: Masterwood, overall weight: 3,800 kg, Masterwood Projekt 415 4 axis CNC machine Working area 3200 x 1335 4 working fields ISO30 10.5 HP spindle C-axis Toolchanger 12 positions 6 supports Schmalz double channel Vacuumcups 17" screen Drillinghead 16 spindels (horizontal and vertical) Machine in working condition Pneumatic lifters Vacuümpump Becker Fence left, right and back Safety mats in the front (not checked) WIndows control Masterwork CAD-CAM system Available from 31 of August 2026 Ljdpfezv S Susx Agtjhk Price on request

Condition: ready for operation (used), Year of construction: 2000, number of spindles 25 -1500 U/min Stufenlos bore capacity in steel (diameter) 23 mm bore stroke 120 mm Lhjdsvr Hlrjpfx Agtok table clamping surface: 1250 x 340 mm taper MK MK3 total power requirement 2 kW weight of the machine ca. 0,4 t

Condition: good (used), *FOR SALE: Cincinnati Milacron PTC 40 Column Drill – 1982* Ledpfx Aozvgr Asgtshk *Price:* €2,200 – Negotiable *Location:* Les Ponts-de-Cé, 49130, Pays de la Loire *Description:* Industrial column drill *CINCINNATI MILACRON PTC 40*, manufactured in 1982. French made. Very robust machine for drilling and tapping in mechanical and sheet metal workshops. Column with cross table mounted on slides. Remote control + foot pedal. Complete and fully operational machine. *Specifications:* - *Make / Model*: CINCINNATI MILACRON PTC 40 380V - *Year*: 1982 - Serial No. 45117 - *Type*: Column drill on a base - *Table*: Cross table mounted on slides - *Feed*: Spindle descent via handwheel + lever - *Equipment*: Remote electrical cabinet, Foot pedal, Vises - *Mounting*: On a pallet for removal

Condition: used, Year of construction: 1998, total width: 1,100 mm, total length: 1,700 mm, total height: 1,150 mm, Colour: White Empty weight: 1.100 kg Ledpfx Agozvx N Hotjhk - Year: 1998 - Documentation available: No - CE marking present: Yes - CE certificate present: No - Serial number: 980223 - Table length [mm]: 245 - Table width [mm]: 735 - Number of spindles [pcs]: 8 - Spindle diameter [mm]: 16 - Max. spindle speed [rpm]: 17000 - Distance between spindles [mm]: 50 - Workpiece clamps [pcs]: 2 - Workpiece support/Guide: Table - Drills included: Yes - Voltage [V]: 415 - Fuse [A]: 16 - Power [kW]: 7.5 - Transport dimensions: 1700mm x 1100mm x 1150mm (l x w x h) - Transport weight [kg]: 1100kg - Transport packages [pcs.]: 1 Financial information VAT: The price shown is exclusive of VAT VAT/margin: VAT deductible for entrepreneurs Delivery and trade-in always possible for everything in the industrial sectors Yorick Diebels

Condition: good (used), Year of construction: 2013, Work table can be extended by an additional 700 mm on both the left and right sides Width: 1850 mm Height: 1800 mm Lhedpfxsw Sdwis Agtjk Depth: 1200 mm

Condition: excellent (used), Year of construction: 1974, travel distance X-axis: 4,600 mm, travel distance Y-axis: 3,000 mm, feed length W-axis: 2,000 mm, spindle diameter: 160 mm, table load: 25,000 kg, CNC boring and milling machine – Scharmann Manufacturer: Scharmann Model: WFT 160 (early 1970s) Control system: Bosch CC300 Ljdpfxszvw Iho Agtehk Work table: 2000 x 2500 mm Longitudinal travel of the table: 4600 mm Transverse travel of the table: 2000 mm Vertical travel of the spindle: 3000 mm Maximum table load: 25 tons

Condition: good (used), functionality: fully functional, drilling depth: 600 mm, workpiece weight (max.): 2,000 kg, travel distance X-axis: 750 mm, travel distance Y-axis: 630 mm, travel distance Z-axis: 300 mm, spindle speed (max.): 3,000 rpm, drill diameter: 35 mm, drill spindle length: 600 mm, spindle mount: MK 2, spindle stroke: 600 mm, number of spindles: 1, Equipment: rotational speed infinitely variable, Driling capacity: Ø 35 mm Driling depth: 600 mm X-axis: 750 mm Y-axis: 630 mm Z-axis: 300 mm Spindle speeds: 0 - 3000 rpm Tabel size: 1100 x 650 mm Ljdpezu Sp Rjfx Agtshk Load on table: 2000 kg max Turning table: 360° Controller: Degen AE30 Including: - Cabinet + pallet with drills - Coolingunit - Machine manuals Country of origin: Germany Motor power: 11,2 kVA Machine LxWxH: 350 x 120 x 175 cm Machine weight: 1300 kg

Condition: excellent (used), Year of construction: 1994, tool diameter: 60 mm, spindle mount: MK 5, rotational speed (max.): 1,460 rpm, total width: 1,100 mm, total length: 2,300 mm, total height: 2,400 mm, table width: 580 mm, table length: 1,400 mm, overall weight: 2,700 kg, Arm length: 1200 mm Max. drilling diameter in cast iron: 60 mm Max. tapping diameter: 40M Max. drilling diameter in steel: 50 mm Lhjdpfozvfn Nsx Agtjk Stroke of quill: 110 mm Max. distance spindle to table: 1165 mm Min. distance spindle to table: 300 mm Floor/table area: 1400 x 580 mm Speeds/ranges: 1460 rpm Spindle taper: 5ISO/BT/MK Length: 2300 mm Width: 1100 mm Height: 2400 mm Weight: 2700 kg

Condition: good (used), Year of construction: 1979, functionality: fully functional, spindle mount: MK 3, For sale is a column drill press made by Alzmetall in good, used condition, as can be seen in the pictures. Technical data: • Manufacturer: Alzmetall • Model: AB3-ES • Speed: approx. 65 - 1,750 rpm • Quill stroke: approx. 180 mm • Table size: approx. 515 x 415 mm Lhodpszvrt Sjfx Agtok • Year of manufacture: 1979 • With coolant pump • Condition: Used, functional The machine can be inspected and tested at any time! If interested, two identical machines are available! Shipping costs via freight carrier: approx. €190 Phone number: 01575 2236716 You will receive an invoice with VAT shown. Inspection/collection is possible by arrangement in 42855 Remscheid. Sale ex works 42855 Remscheid, free loading. Subject to errors in technical data and prior sale.

Condition: good (used), Year of construction: 1979, functionality: fully functional, spindle mount: MK 3, For sale is a pillar drilling machine from the brand Alzmetall in good, used condition, as can be seen in the pictures. Technical data: • Manufacturer: Alzmetall • Model: AB3-E • Speed: approx. 125 - 3,150 rpm • Spindle stroke: approx. 180 mm • Table size: approx. 520x400 mm • Year of manufacture: 1979 • Weight: approx. 360 kg • Coolant pump can be connected • Condition: Used, functional The machine can be inspected and tested at any time! Shipping costs via freight forwarder: approx. €190 Lsdpfezvrmlsx Agtohk International buyers are welcome! You will receive an invoice with VAT shown. Inspection/collection is possible by arrangement in 42855 Remscheid. Sale ex works 42855 Remscheid, free loading. Errors in technical data and prior sale reserved.

Condition: ready for operation (used), Year of construction: 2014, functionality: fully functional, workpiece length (max.): 3,200 mm, workpiece width (max.): 920 mm, workpiece height (max.): 70 mm, number of slots in tool magazine: 6, actuation type: pneumatic, total height: 2,350 mm, total length: 3,675 mm, total width: 1,660 mm, overall weight: 2,500 kg, year of last overhaul: 2026, Equipment: CE marking, documentation/manual, HOLZ-HER Vertikale CNC Evolution 7405 4mat, Baujahr 2014, Lieferung ab Standort Bearbeitungslänge: 3.200 mm Werkstückabmessungen: X = 200 – 3.200 mm (bei zusätzlicher Auflage auch länger möglich) Y = 70 – 920 mm Werkstückdicke: Z = 8 – 70 mm Maximale Bearbeitungslänge auf X-Achse ohne Umspannen: X = 1.500 mm Z-Achsen-Verfahrweg = 240 mm Maximal programmierbare Geschwindigkeit: Vektorgeschwindigkeit: 68 m/min X = 25 m/min, Y = 60 m/min, Z = 20 m/min Software: CAMPUS V6 – Single Evolution Lsdpfx Ajy Ny Uyegtehk 19-Zoll TFT-Flachbildschirm Höhenverstellbarer Rollentisch zur 4-seitigen Bearbeitung. Komplette Formgebung der Werkstücke durch präzises Fräsen aller vier Seiten möglich. Druckluft-Vakuumsystem Absaugung am Werkzeugkopf 2D Barcode-Scanner Bohraggregat 7883, 15 Spindeln, 1,7 kW Leistung (9 vertikal, 6 horizontal) Performance-Paket, bestehend aus: 7830 Fräsaggregat 6,5 kW (S6) HSK F-63 Werkzeugwechsler 7887 mit 6 Werkzeugplätzen (Pick-up-Typ) Manuelle Schmierung, kombinierter Schmierversorgungspunkt

Condition: used, Year of construction: 1994, bore capacity in steel (diameter) 35 mm throat 300 mm bore stroke 180 mm turning speeds 55 - 1450 U/min taper MK 4 column diameter 145 mm total power requirement 2,2 kW weight 500 kg dimensions 800 x 1000 x 2000 mm Features: - Heavy-duty pillar drill - Infinitely variable speed control (V-belt) - Automatic spindle feed * with electromagnetic engagement - Pole-changing motor - Right/left rotation of the drill spindle - Fixed drilling depth stop - Machine table with 2 T-slots * height-adjustable via hand crank - Coolant system - Machine vise - Drill chuck Ledpfozu Tk Nsx Agtohk - Emergency stop

Condition: used, Year of construction: 2018, 1 x CNC-CONTROLLED DRILLING, GLUING AND DOWEL INSERTING MACHINE GANNOMAT "INDEX 130 PRO" (with options as Index 180 Pro) 400V, 3Ph, 50Hz complete in standard design with: - Support with linear guide consisting of: 1 x single-spindle horizontal drilling unit, 1.1 kW motor, tool speed selectable via operator software (3000/5000/8000 rpm) 1 x blow-out, gluing and dowel inserting station in reinforced design for dowels Æ 8 mm, dowel length 30 mm - fully automatic, electronically controlled central lubrication - X-axis NC controlled, with working length 1300 mm, travel speed max. 78 m/min. - Z-axis, position via support table 5-40 mm programmable with NC-controlled Z-axis option - Dowel driving overhang of 7-20 mm, programmable with NC-controlled Y-axis option, drilling depth of 0-35 mm (with drill length GL 70 mm) is automatically set with driving overhang - Closed glue system with 6 bar glue pressure via glue nozzle, for glues with a viscosity of 150 to 350 mPas - Glue quantity continuously adjustable via operator software - GL/WATER selector switch for rinsing the glue system, 1 stainless steel container each for 5 kg glue and 5 l water - Control lamp for residual glue quantity display in the glue container - 1 side stop left, 1 side stop right and 1 center stop (all removable) - 4 start buttons for individual working with 1-4 workpieces - 4 pcs. Pneumatic inclined clamping cylinder 10° for workpiece thicknesses up to max. 80 mm, workpiece length (Y) min. 70 mm - 1 pc. suction funnel, connection Æ 80 mm - 1 pc. TCT control with: built-in industrial PC, incl. Soft PLC type Beckhoff TWINCAT, operating temperature range 0-50°C, TFT industrial display 15" resistive touchscreen, resolution 1024 x 768, CPU 2 GHz, 256 MB RAM, 2x network interface adapters, IDE hard disk, 4x USB rear, 1x USB front, operating system: WINDOWS 7 - programming via menu-driven user software, drilling distances freely programmable with ABSOLUTE, RELATIVE or GRID dimensioning, automatic workpiece mirroring and work step optimization, 4 work fields can be assigned with different programs, graphic workpiece display, parametric programming, 0-point shift, programmable work lists, error diagnosis with plain text OPTIONS: 1 electronic, optical glue monitoring system G.I.C. (Glue Insert Control) for 1 glue nozzle 4 vertical inclined clamping cylinders 10° with holder, additionally, (total 8 clamping cylinders) 1 surcharge for machine bed length 1800 mm with working length 1800 mm 1 surcharge for: 1 horizontal drilling unit, motor 1.5 kW, with multi-spindle drilling head with 3 individually controllable drilling spindles, pitch 32 mm arranged in X-axis, tool speed 3000 rpm. (The standard working length is not reduced) 1 Y-axis NC-controlled, with recirculating ball screw and dynamic traversing speed of 300 mm/sec. The dowel driving overhang 7-30 mm and the drill hole depth 0-42 mm can be programmed via software. (with drill length GL 77 mm) for vertical drilling unit drilling from TOP, Y-axis position 5-42 mm 1 surcharge Y-axis NC-controlled position 5-62 mm instead of 5-42 mm 1 surcharge for: 1 vertical drilling unit drilling from TOP, motor 1.5 kW, with multi-spindle drilling head with 3 individually accessible drilling spindles, 32 mm pitch arranged in X-axis, tool speed 3000 rpm. Y-axis position 5-42 mm, workpiece length (Y) min. 130 mm, (the standard working length is not reduced) 1 Z-axis NC-controlled, with K Lhsdpfx Agsxwaz Hetjk

Condition: used, Year of construction: 2024, DOWEL HOLE DRILLING MACHINE GANNOMAT "DB 21400V, 3Ph, 50Hz / 1.5 kW, complete in standard design with: - Fully automatic electronic control with pulse operation via foot valve for clamping-drilling-releasing, electric intermittent operation. - Automatic retraction of the drilling unit after reaching the set drilling depth. - Automatic extension of the drilling hole depth when drilling on the end face. This eliminates the need to adjust the drilling hole depth from flat-face to end-face drilling (+10 mm, e.g. for a dowel length of 35 mm, drilling depth on the flat face 14 mm and drilling depth on the end face 24 mm). - 1 drilling bar with 21 spindles, pitch 32 mm, motor 1.5 kW (drilling feed 0-70 mm), incl. 21 quick-change chucks (Ganner system) for easy changing of the drill bits. - Easy pivoting of the drilling unit from 0° to 90°, supported by gas cylinders. - 1 clamping support movable in the Y-axis with 3 pneumatic clamping cylinders, for workpiece height up to max. 80 mm. Ideal stop system consisting of: - 1 stop rail 1800 mm for drilling shelves (aluminum profile 40x40 mm) with 3 stop blocks, with quick-change system, easily interchangeable from right to left stop side for drilling shelves in carcass structures in mirrored fashion, also suitable for row drilling in the 32 system. - Side stops and position settings, as well as the position of the drilling height above the support table, are adjusted by means of mechanical digital counters. - Side stops can be easily pivoted away, for the shortest possible conversion from carcass to frame and row drilling. - Clamping arms for the clamping support designed for row drilling positions up to max. 300 mm. - Ideal three-stage tool system. - 1 set of drill bits for dowels: - 5 carbide dowel drill bits, Ø 8x77 mm, right-hand - 4 carbide dowel drill bits, Ø 8x77 mm, left-hand Basic machine DOWEL HOLE DRILLING MACHINE GANNOMAT "DB 21400V, 3Ph, 50Hz / 1.5 kW, complete in standard design with: - Fully automatic electronic control with pulse operation via foot valve for clamping-drilling-releasing, electric intermittent operation. - Automatic retraction of the drilling unit after reaching the set drilling depth. - Automatic extension of the drilling hole depth when drilling on the end face. This eliminates the need to adjust the drilling hole depth from flat-face to end-face drilling (+10 mm, e.g. for a dowel length of 35 mm, drilling depth on the flat face 14 mm and drilling depth on the end face 24 mm). - 1 drilling bar with 21 spindles, pitch 32 mm, motor 1.5 kW (drilling feed 0-70 mm), incl. 21 quick-change chucks (Ganner system) for easy changing of the drill bits. - Easy pivoting of the drilling unit from 0° to 90°, supported by gas cylinders. - 1 clamping support movable in the Y-axis with 3 pneumatic clamping cylinders, for workpiece height up to max. 80 mm. - Ideal stop system consisting of: - 1 stop rail 1800 mm for drilling shelves (aluminum profile 40x40 mm) with 3 stop blocks, with quick-change system, easily interchangeable from right to left stop side for drilling shelves in carcass structures in mirrored fashion, also suitable for row drilling in the 32 system. - Side stops and position settings, as well as the position of the drilling height above the support table, are adjusted by means of mechanical digital counters. - Side stops can be easily pivoted away, for the shortest possible conversion from carcass to frame and row drilling. - Clamping arms for the clamping support des Lhodpfsxnlfljx Agtek

Condition: good (used), Year of construction: 1985, spindle turning speed - stepless 26 - 1650 U/min voltage 380 V 0 50 Hz rated current 15 A connected load 6,5 kW tool taper MK 4 weight of the machine ca. 2,3 t dimensions of the machine ca. 1500 x 1200 x 2500 mm Operating voltage: 380 V Frequency: 50 Hz Control voltage: 220 V Rated current: 15 A Connection: 6.5 kW Automatic feed: 0.05 - 0.45 mm/rev Column lifting speed: 40 mm/s Lhodpfx Aevylh Usgtek Column stroke: 450 mm Drilling spindle stroke: 200 mm Drilling zone: 430 - 1150 mm Height adjustment of the drilling spindle: 330 - 780 mm Tool holder: MK 4 Table dimensions: 1525 x 560 mm Table height: 800 mm

Condition: ready for operation (used), Year of construction: 2010, Equipment: CE marking, SCM Cyflex 900 Year 2010 No routing unit Ljdozka Awopfx Agtjhk Machine in perfect condition Direct available

Condition: excellent (used), Year of construction: 2022, functionality: fully functional, Urban ESB 500 corner and scissor drilling unit with drill heads for Siegenia fittings Lsdpfx Agjyza Dfetshk

Condition: new, 6-sided drilling machine Manufacturer: Quick Type: KQ-63E New machine Ledpjzvgn Djfx Agtshk Technical data: - Workpiece length: 70 - 2800 mm - Workpiece width: 50 - 1220 mm - Workpiece thickness: 9 - 60 mm - Min. workpiece to be processed: 70 x 50 mm - Feed rate in X: 135 m/min - Feed rate in Y: 90 m/min - Feed rate in Z: 25 m/min - Individually controllable spindles: Top: 2 x 12 vertical, 4 horizontal / Bottom: 1 x 7 vertical - Machine control: Higerman (German) - Milling spindle (top): 9 kW, 24000 rpm - Tool changer (top): 5-position - Milling spindle (bottom): 3.5 kW, 18000 rpm - Motors: Brushless servo motors - Positioning accuracy: 0.03/1000 - Repeatability: 0.02/1000 Optional: - Machine with workpiece return Quickly found Offer machines Register for newsletter Unsubscribe from newsletter Contact us Overview

Condition: new, Six-sided drilling machine Manufacturer: Quick Type: KQ-62Lite New machine Technical data: - Workpiece length: 70 - 2,400 mm - Workpiece thickness: 9 - 60 mm - Workpiece width: 30 - 1,220 mm - Min. processing size: 50 x 70 mm - Transport speed in X: 138 m/min - Transport speed in Y: 90 m/min - Transport speed in Z: 28 m/min - Machine control: Higerman - Working height: 890 mm Lhsdpfx Agjzvgndotek - Milling spindle: 2 x 3.5 kW, 18,000 RPM, manual tool change - Drilling unit: Top 9 vertical and 4 horizontal / Bottom 7 vertical - Positioning accuracy: 0.03/1000 - Repeatability: 0.02/1000 - Power consumption: 25.8 kW Optional - Machine including workpiece return Other configurations available upon request.

Condition: new, Year of construction: 2023, machine/vehicle number: 320542/B, functionality: fully functional, number of axes: 3, controller manufacturer: TPA, CNC Drilling and Milling Machine Manufacturer: Vitap Type: K3 New machine Through-feed processing, workpiece machining from below, and automatic workpiece return to the operator Develop an individual class: - With this machine, you can perform many different milling operations in addition to grooving and drilling, from simple edge milling to milling shapes and letters. - We do not limit your creativity. Easy entry into CNC technology: - TPA makes it easy for you: Whether drilling, grooving, linear milling, contour milling, or milling letters. - The CAD software clearly displays the machining operations. - Particularly clear is the programming of the work steps on the individual workpiece sides. - You can mirror machining operations with a mouse click. - You can either enter the starting points precisely or determine them by clicking on the virtual workpiece. Vitap Bar Nesting - efficient and time-saving - This patented software produces entire corpus elements from a long workpiece. - You insert the long workpiece, and when you remove the first finished element, the machining of the next element continues directly. The DDT feed system (double dynamic transport) - 2 clamps enable uninterrupted workpiece transport. - The operator inserts the workpiece until it reaches the stop. - Both clamps then grip the workpiece and position it precisely. - During machining, both clamps communicate with each other, so that clamp 2 grips before clamp 1 releases. - This ensures a constant feed rate even during linear milling. 3 controlled axes: - X axis - DDT feed - Y axis - Drilling head travel - Z axis - Drilling - Double "0" reference: New laser generation for detecting the beginning and end of the workpiece. The program can readjust the drilling from below to achieve perfect alignment in vertical and horizontal workpieces. The laser consists of a transmitter and receiver to avoid errors with dark edge material. - Side stops with rollers, consisting of a fixed and a movable part, mechanical digital readout with automatic alignment to the 0 stop for removal of up to 3 mm on the 0 line - Constant side pressing device for precise positioning to the 0 line - Automatic 4-position tool changer - Adjustable zero point - No workpiece length limitation - Monitor LCD TFT 20" - Industrial PC - Operator interface WSC with Lister, parametric tool, and parametric setup - Graphical programming CAD TPA EDI32, basic version - USB port - Storage of all files - Macro programming - Import DXF files Technical data - Number of independent, vertical spindles: 12 - Number of independent, horizontal spindles on the X axis: (2+2) - Number of horizontal drilling spindles on the Y axis: (2+2) - 1 saw (100mm) - Electro spindle 5 kW with ISO30 taper (RPM [contact removed]) - Max. workpiece weight: 40 kg - Max. workpiece dimensions: X unlimited, Y 1250 mm, Z 50 mm - Min. workpiece dimensions: X 270, Y 150 (70op), Z 3 mm - Feed rate: 25 m/min - Spindle speed: 3600 RPM - Saw speed: 7000 RPM - Max. horizontal tool: 12mm - Max. drilling depth horizontally on the X and Y axis: 35mm Ljdpfxezvduuj Agtjhk - Max. drilling depth vertically: 43 mm - Max. vertical tool: 35mm - Motor: 1.7 kW - Adjustable zero point for 4-sided formatting - CE compliant Optional against additional charge
