Used Lovati Bem 31 for sale (5,505)

Condition: used, TECHNICAL DETAILS - max. diameter of tapping and threading : M6 - max. length of stroke : 20 [mm] - number of spindle revolutions with interchangeable gearboxes : 4200, 2700, 1600, 1050, 620 [rpm] - power : 0.5 [CV] Ijdpfx Aevu E Svjnmsba - number of revolutions : 1400 [rpm] - brake motor protected against overheating by 3 pilotherms

Condition: used, TECHNICAL DETAILS - max. diameter of tapping and threading : M6 Ibodpfxovu E S Ao Anmja - max. length of stroke : 20 [mm] - number of spindle revolutions with interchangeable gearboxes : 4200, 2700, 1600, 1050, 620 [rpm] - power : 0.5 [CV] - number of revolutions : 1400 [rpm] - brake motor protected against overheating by 3 pilotherms

Condition: ready for operation (used), thread length: 3,000 mm, Maximum spindle bore is Ø 80 mm. The possible diameter from the traverse path is max. Ø 250 mm and min. Ø 20 mm. Machining length: 3000 mm. Comes with accessories: change gears, steady rest. For further technical data, please refer to the PDF file. Ibodpov Huihjfx Anmea

Condition: good (used), Year of construction: 2021, operating hours: 300 h, fuel type: hybrid, color: white, Weights Ibsdpozt U Uyjfx Anmoa Empty weight: 4.200 kg Functional Mast: articulated arm Lifting capacity: 230 kg Working height: 3.020 cm Dimensions of cargo space: 695 x 89 x 204 cm CE mark: yes Condition Technical condition: good Visual appearance: good Other information Remanufactured: Yes Delivery terms: EXW Max. horizontal reach: 1450 m Max swing of arm in degrees: 180 Max swing of platform in degrees: 440 Latest inspection: 2026-08-11 Production country: IT Additional information Please contact Rothlehner Arbeitsbühnen GmbH for more information

Condition: used, 4-way combination hammer C3-31, standard equipment, 2000 mm table length, 3 knives, approx. 450 kg Iodpfx Ajvr I E Henmeba Prices subject to change, errors, printing and typesetting errors reserved

Condition: used, AD Planer Hammer A3-31, good condition Price changes reserved, subject to errors, printing and typographical mistakes. Ibedpfewzzhfex Anmoa

Condition: excellent (used), Year of construction: 2016, functionality: fully functional, Working area X: 3050 mm Working area Y: 1250 mm Working area Z: 180 mm 9.5 kW electrospindle Vertical drilling spindles: 12 Horizontal drilling spindles X: 4 Horizontal drilling spindles Y: 2 Blade for grooving in the X direction 4-position tool changer Rear 10-position tool changer Worktable with 6 rails, 6 TVN tables with suction cups 90 m³/h vacuum pump Software: Xilog Maestro Laser positioning device Control panel Approximate weight: 2750 kg No additional components included! Iedpfey Tb Ezsx Anmeba

Condition: excellent (used), Year of construction: 2023, functionality: fully functional, 3-Axis Electrospindle Vertical drilling heads: 12 Horizontal drilling heads (X-axis): 4 Horizontal drilling heads (Y-axis): 2 Grooving blade Circular tool changer with 8 positions Linear tool changer with 10 positions Worktable with 6 rows Iodpfxjzt T Avj Anmsba Software: WoodWop8 Chip conveyor belt 2 Vacuum pumps Only 2853 operating hours Available January 2027

Condition: new, empty load weight: 6,870 kg, maximum load weight: 24,130 kg, overall weight: 31,000 kg, axle configuration: 3 axles, loading space length: 7,500 mm, loading space width: 2,550 mm, suspension: air, tire size: 235 / 75 R 17,5, color: other, gearing type: other, front tire size: 235 / 75 R 17,5, rear tire size: 235 / 75 R 17,5, driver cabin: other, emission class: none, fuel: biodiesel, Equipment: ABS, compressed air brake, Chassis: Hot-dip galvanized, wooden floor 70 mm thick, 18 lashing rings, 12 stake pockets, 2 ramps each 3,110 mm long x 760 mm wide, climbing strip on outside of ramps and rear slope, one-piece ramps with spring assist, loading height: 880 mm, incl. axle load indicators. Additional options: last axle as steering axle: €3,500, warning boards + lighting and beacon: €200, widening to 3 m with wooden inserts: €300. Also available with K80 drawbar eye! Subject to errors, misprints, and modifications. Sample images. More data at: ! Iodpfx Anszr Umgjmoba

Condition: new, empty load weight: 6,950 kg, maximum load weight: 24,050 kg, overall weight: 31,000 kg, axle configuration: 3 axles, loading space length: 7,500 mm, loading space width: 2,550 mm, suspension: air, tire size: 235 / 75 R 17,5, color: other, gearing type: other, front tire size: 235 / 75 R 17,5, rear tire size: 235 / 75 R 17,5, driver cabin: other, emission class: none, fuel: biodiesel, Equipment: ABS, compressed air brake, Chassis: hot-dip galvanized, wooden floor 70 mm thick, 18 lashing rings, 12 stake pockets, 2 ramps each 3,110 mm long x 760 mm wide, hydraulic one-piece ramps, loading height: 880 mm, incl. axle load indicators. Surcharges: last axle as steering axle: €3,500; warning signs + lighting and beacon: €200; widening to 3m with wooden planks: €300; hydraulic ramp shift: €1,000. Also available with K80 towing eye! -- Errors, omissions and changes excepted, sample images -- More data at: !, More Details: ! Iedpfszr Sgdox Anmjba

Condition: new, empty load weight: 6,950 kg, maximum load weight: 24,050 kg, overall weight: 31,000 kg, axle configuration: 3 axles, loading space length: 7,500 mm, loading space width: 2,550 mm, suspension: air, tire size: 235 / 75 R 17,5, color: other, gearing type: other, front tire size: 235 / 75 R 17,5, rear tire size: 235 / 75 R 17,5, driver cabin: other, emission class: none, fuel: biodiesel, Equipment: ABS, compressed air brake, Chassis: hot-dip galvanized, wooden floor 70 mm thick, 18 lashing rings, 12 stake pockets, 2 ramps each 3,110 mm long x 760 mm wide, hydraulic one-piece ramps, loading height: 880 mm, incl. axle load indicators. Surcharges: last axle as steering axle: €3,500; warning signs + lighting and beacon: €200; widening to 3m with wooden planks: €300; hydraulic ramp shift: €1,000. Also available with K80 towing eye! -- Errors, omissions and changes excepted, sample images -- More data at: !, More Details: ! Ibsdpfszr Sf Tsx Anmja

Condition: used, maximum load weight: 30,620 kg, overall weight: 36,000 kg, axle configuration: 3 axles, first registration: 11/2017, next inspection (TÜV): 10/2026, loading space length: 7,400 mm, loading space width: 2,300 mm, loading space height: 1,500 mm, loading space volume: 24 m³, total width: 2,550 mm, total height: 3,200 mm, Equipment: ABS, 3-axle Langendorf SKA 24/31 aluminum box body VIN: WF67519 Chassis / Components: * Air suspension / Raise and lower function * Load level switch / Lowering during tipping * Wabco Smart Board * 3 x BPW Eco Plus axles with disc brakes * Tires: 385/65 R.22,5 * Remaining tire tread: Front ~50%, Middle ~30%, Rear ~50% * Alcoa Alcoa Dura Bright aluminum rims * Foldable underrun protection * Steel chassis Body: * Steel chassis * Aluminum box body * Front cylinder Hyva, high-pressure max. 230 bar * Volume: approx. 24 m³ * Standing platform * Rear gate with 2 hook locks * All-round rubber seal * Mud-tight * Grain slide * Body heating * Load pressure gauge Weights: * Gross vehicle weight 36,000 kg * Payload 30,620 kg * Tare weight 5,380 kg Other: * German registration * 1 previous owner * MOT valid until 10/2026 -- Inspection valid until 04/2027 Ijdpfezrit Isx Anmjba New main inspections / safety inspections or weight reductions / increases are possible upon request. We will gladly assist you in obtaining export / transit plates, and we can also arrange for the transport of your purchased vehicles within Germany. Contact us! We speak the following languages: German, English and Russian! No liability for printing and typographical errors, changes, prior sale and errors. Who are we? Leible Nutzfahrzeuge is a family-owned company based in Kehl am Rhein. Thanks to our many years of experience in the preparation and sale of commercial vehicles, we are a reliable partner for customers worldwide. The particular strength of Leible Nutzfahrzeuge lies in the sale of new and used commercial vehicles. On 11,000 m², you will find a wide variety of vehicles. Our company philosophy is characterized by fairness and integrity. As customer satisfaction is very important to us, we offer our customers an excellent all-round service package and provide them with a competent contact person who will assist them in the purchase or sale of vehicles. Convince yourself! Our services for you: Loading of vehicles We will gladly help you with loading your purchased vehicles. Organizing special transports We will gladly help you with organizing special transports. Day registration / export plates We will gladly help you obtain export / short-term plates. Handling customs formalities We will gladly help you with customs matters.

Condition: used, maximum load weight: 30,660 kg, overall weight: 36,000 kg, axle configuration: 3 axles, first registration: 03/2016, next inspection (TÜV): 04/2027, loading space length: 7,400 mm, loading space width: 2,300 mm, loading space height: 1,500 mm, loading space volume: 24 m³, total width: 2,550 mm, total height: 3,200 mm, Year of construction: 2016, Equipment: ABS, 3-axle Langendorf SKA 24/31 aluminum tipper body VIN: WF66008 Chassis / Components: * Air suspension / Raise and lower function * Load level switch / Lowering during tipping * Wabco Smart Board * 3 x BPW Eco Plus axles with disc brakes * Tires: 385/65 R.22.5 * Remaining tire tread: Front ~5%, Middle 50/40%, Rear 50% * Alcoa Alcoa Dura Bright aluminum rims * Foldable underrun protection * Steel chassis Body: Iodpfxszriufe Anmoba * Steel chassis * Aluminum tipper body * Front cylinder Hyva, high pressure max. 250 bar * Volume: approx. 24 m³ * Standing platform * Rear tailgate, resting type, with 2 hook locks * All-round rubber seal * Slurry-proof * Grain slide * Load pressure gauge * Tipper body heating Weights: * Gross vehicle weight 36,000 kg * Payload 30,660 kg * Tare weight 5,340 kg Other: * German registration * 1 previous owner * MOT valid until 10/2026 New main inspections / safety checks or weight reductions/increases are possible upon request. We will gladly assist you in obtaining export/transfer license plates. We can also arrange for the transport of your purchased vehicles within Germany. Contact us!---- We speak the following languages: German, English and Russian!---- No liability for printing and typographical errors, changes, prior sale and errors reserved!----Who are we? Leible Nutzfahrzeuge is a family-owned business based in Kehl am Rhein. Thanks to our many years of experience in the refurbishment and sale of commercial vehicles, we are a reliable partner for customers worldwide. The particular strength of Leible Nutzfahrzeuge lies in the sale of new and used commercial vehicles. A wide range of vehicles can be found on 11,000 m². Our corporate philosophy is characterized by fairness and integrity. As customer satisfaction is very important to us, we offer our customers an excellent all-round service package and provide them with a competent contact person who will assist them in buying or selling vehicles. Convince yourself! Our service for you: Loading of vehicles We will gladly help you with loading your purchased vehicles. Organization of special transports We will gladly help you in organizing special transports. Day registration / export license plates We will gladly help you in obtaining export/short-term license plates. Handling of customs formalities We will gladly help you in handling customs matters.

Condition: good (used), Year of construction: 1968, machine/vehicle number: 68113, Offer 24456 Technical data: Iedpezii Sfsfx Anmsba - Drilling capacity in steel ST 60 approx. 60 mm - Drilling capacity, enlarging holes approx. 80 mm - Thread cutting up to approx. M 40 - Drill spindle mount MK 5 - Drill spindle stroke 380 mm - Overhang min. / max. approx. 420 / 2000 mm - Column diameter approx. 500 mm - Stroke of the arm approx. 1350 mm - Min. / max. distance: - Spindle – base plate approx. 370 - 1700 mm - Work area on base plate approx. 1100 - 2300 mm - 12 spindle speeds 19 - 1900 rpm - 9 feed rates 0.09 - 0.75 m/rev - Drill spindle drive 400 V / 10 kW - E - central clamping system - Coolant system - Space required approx. W 1400 x H 3400 x D 3600 mm - Weight approx. 7500 kg

Condition: used, Year of construction: 2012, GENERAL FEATURES: CNC machining center with a fixed machine table and a moving tool carrier in a portal design for drilling and milling operations on panels made of various materials (chipboard, MDF, solid wood, plastic, etc.). MACHINE STRUCTURE: The base structure is a monolithic design made of thick-walled material, reinforced by welded-in parts across the entire machine bed, making it extremely stable. The table design, with a large base, ensures long-lasting precision and stability. The machine layout allows the user an optimal workflow despite a minimum of space. The mobile portal carrier is made from a solid monoblock. It is positioned in the X-direction on prismatic, ground guides using ball screw slides. On this mobile tool carrier, the working unit is in turn attached to prismatic, ground guides and the ball screw slide. Axis movement is achieved using "brushless" motors in the X/Y/Z axes. The drive system operates in the X-axis via a pre-tensioned precision rack and pinion drive, and in the Y/Z axes via ground ball screws of the highest precision class. AXIS MOVEMENT: The movement of all axes takes place on prism linear guides with a large cross-section and ball screw shoes with a large contact surface, which ensure optimal sliding even at the highest speeds and accelerations. The precise and rapid positioning of the moving portal (X-axis) is achieved by a pinion and rack with helical teeth. Ball screws with a large cross-section ensure the accurate positioning of the working unit along the moving portal (Y and Z axes). The perfect mechanical dynamics and maximum positioning accuracy are controlled by high-quality drives and brushless motors. STANDARD MACHINE DESIGN: Milling spindle with 5-axis positioning, 11kW (15HP), HSK63, 1200-20000 RPM. The machining unit consists of a powerful 11 kW (15 HP) motor, which is liquid-cooled and capable of 5-axis positioning. This feature enables machining operations to be performed with a tool that can be oriented in any direction; therefore, fewer angular movements are required. The base structure of the milling unit is based on a design with two non-orthogonal axes that intersect next to the tool. This feature guarantees a robust carrier for heavy-duty milling applications. Thanks to the non-orthogonal axes, it is possible to perform numerous repositionings without using too much space. This allows the machining of complex geometries without the risk of collision with the workpiece and achieves an angle of -10° in relation to the machine table. All machining operations are facilitated by the small dimensions of the group in relation to the rotation axis of the spindle: when the group is in a horizontal position, the dimension is only 35mm. WORK TABLE TV: The work table is designed to guarantee the operator maximum "freedom of movement." The vacuum quick-change clamping system provides maximum flexibility with precise positioning and optimal work piece holding. The table consists of moving consoles that are adjusted in the X-axis on ground guides with ball screw shoes and a special profile to ensure Isdpfx Aozrvvvonmeba

Condition: used, empty load weight: 12,640 kg, maximum load weight: 28,360 kg, overall weight: 41,000 kg, first registration: 06/2023, next inspection (TÜV): 01/2027, loading space length: 9,900 mm, loading space width: 2,550 mm, loading space height: 910 mm, loading space volume: 22 m³, suspension: air, tire size: 235/75 R 17.5, color: other, mileage: 86,347 km, gearing type: other, front tire size: 235/75 R 17.5, driver cabin: other, emission class: none, Available for rent from 4 weeks onwards – immediate availability – contact O. Schinke. Rent – please contact Mr. Schinke. Platform length 3,800 mm, loading length 9,400 mm, loading width 2,550 mm, access ramp 1,300 mm, Rear loading ramps 2950 x 1,700 x 900 mm, access angle approx. 11 degrees, hydraulic ramp lift, ramp hydraulically adjustable, Lubrication aid, Smart Board, loading platform extension, Spare wheel holder, including spare wheel, storage box, 1 front support: telescopic support, aluminum alloy, for coupling, 2 foldable rear support legs with spring holder, to operate the hydraulic components, a suitable truck hydraulic system with forward and return lines is required (not included in the scope of supply). Also available for long-term rental! Contact us – we will provide you with our individual offer. * ABS Ibsdpszhknrjfx Anmja * Axle steering on the 2nd and 3rd axles * Lateral impact protection * Rubber-metal pads on the loading ramps * Plastic toolbox * Single lift axle * Platform side panels * Hydraulic ramp lift * Ramp hydraulically adjustable * Spare wheel holder * Rotating beacon * SAF axles * Smart Board * Supports * Warning package * Central lubrication system We explicitly reserve the right to sell the item in the meantime, as we also offer this item on other platforms. Information on accessories is without guarantee; subject to changes, prior sale, or errors. We strongly recommend and offer an inspection and examination so that no false impressions arise about the condition and suitability with the buyer. Inspections and examinations are possible at any time by appointment and are expressly desired. We will take care of all formalities and hand over the vehicle with the desired transport license plates for an extra charge. The images have been partially edited and are only for initial viewing; if you are interested, please contact us and request current images.

Condition: like new (used), Year of construction: 2015, functionality: fully functional, It also has a milling and sawing unit. It is in excellent condition. Ijdpfoztwv Tex Anmeba

Condition: new, empty load weight: 7,300 kg, maximum load weight: 23,700 kg, overall weight: 31,000 kg, axle configuration: 3 axles, loading space length: 8,000 mm, loading space width: 2,550 mm, suspension: air, tire size: 235 / 75 R 17,5, color: other, gearing type: other, front tire size: 235 / 75 R 17,5, rear tire size: 235 / 75 R 17,5, driver cabin: other, emission class: none, fuel: biodiesel, Equipment: ABS, compressed air brake, Chassis: Hot-dip galvanized, wooden floor 70 mm thick, 18 lashing rings, 12 stake pockets, 2 ramps each 3,110 mm long x 760 mm wide, climbing strips on the outside of the ramps and rear slope, one-piece hydraulic ramps, loading height: 880 mm, incl. axle load indicators. Surcharges for: last axle as steering axle: €3,500, warning panels + lighting and rotating beacon: €200, widening to 3 m with wooden inserts: €300, hydraulic ramp shifting: €1,000. Also available with K80 towing eye! -- Errors, mistakes and changes excepted, sample pictures -- More details at: ! Ibodpfx Anezrhpnomoa

Condition: new, overall weight: 31,000 kg, axle configuration: 3 axles, loading space length: 7,500 mm, loading space width: 2,550 mm, suspension: other, tire size: 235 / 75 R 17,5, color: other, gearing type: other, front tire size: 235 / 75 R 17,5, rear tire size: 235 / 75 R 17,5, driver cabin: other, emission class: none, fuel: biodiesel, Equipment: ABS, compressed air brake, Wooden floor 70 mm thick, 18 x lashing eyes, 2 x ramps each 3,000 mm long x 750 mm wide, hydraulic 1-part ramps, loading height: 900 mm, , --  Subject to printing errors, errors and changes, sample images --, More data at: !, More details: ! Ijdpfx Anjzrhpzjmjba

Condition: new, empty load weight: 6,950 kg, maximum load weight: 24,050 kg, overall weight: 31,000 kg, axle configuration: 3 axles, loading space length: 7,500 mm, loading space width: 2,550 mm, suspension: air, tire size: 235 / 75 R 17,5, color: other, gearing type: other, front tire size: 235 / 75 R 17,5, rear tire size: 235 / 75 R 17,5, driver cabin: other, emission class: none, fuel: biodiesel, Equipment: ABS, compressed air brake, Chassis: hot-dip galvanized, wooden floor 70 mm thick, 18 lashing rings, 12 stake pockets, 2 ramps each 3,110 mm long x 760 mm wide, hydraulic one-piece ramps, loading height: 880 mm, incl. axle load indicators. Surcharge for last axle as steering axle: €3,500; warning panels + lighting and beacon: €200; widening to 3 m with timber: €300; hydraulic ramp shift: €1,000; side and front walls: €3,500. Also available with K80 drawbar eye! -- Subject to printing errors, mistakes and changes, sample images -- More data at: !, More Details: ! Ibsdpfxozrhpus Anmea

Condition: new, empty load weight: 7,480 kg, maximum load weight: 23,520 kg, overall weight: 31,000 kg, axle configuration: 3 axles, loading space length: 7,500 mm, loading space width: 2,550 mm, suspension: air, tire size: 235 / 75 R 17,5, color: other, gearing type: other, front tire size: 235 / 75 R 17,5, rear tire size: 235 / 75 R 17,5, driver cabin: other, emission class: none, fuel: biodiesel, Equipment: ABS, compressed air brake, Chassis: hot-dip galvanized, wooden floor 70 mm thick, 18 lashing rings, 12 stake pockets, 2 ramps each 3,110 mm long x 760 mm wide, hydraulic one-piece ramps, loading height: 880 mm, incl. axle load indicators. Surcharges: last axle as steering axle: €3,500; warning signs + lighting and beacon: €200; widening to 3m with wooden planks: €300; hydraulic ramp shift: €1,000. Also available with K80 towing eye! -- Errors, omissions and changes excepted, sample images -- More data at: !, More Details: ! Iodezrdx Ejpfx Anmsba

Condition: new, empty load weight: 6,950 kg, maximum load weight: 24,050 kg, overall weight: 31,000 kg, axle configuration: 3 axles, loading space length: 7,500 mm, loading space width: 2,550 mm, suspension: air, tire size: 235 / 75 R 17,5, color: other, gearing type: other, front tire size: 235 / 75 R 17,5, rear tire size: 235 / 75 R 17,5, driver cabin: other, emission class: none, fuel: biodiesel, Equipment: ABS, compressed air brake, Chassis: hot-dip galvanized, wooden floor 70 mm thick, 18 lashing rings, 12 stake pockets, 2 ramps each 3,110 mm long x 760 mm wide, hydraulic one-piece ramps, loading height: 880 mm, incl. axle load indicators. Surcharges: last axle as steering axle: €3,500; warning signs + lighting and beacon: €200; widening to 3m with wooden planks: €300; hydraulic ramp shift: €1,000. Also available with K80 towing eye! -- Errors, omissions and changes excepted, sample images -- More data at: !, More Details: ! Iodpfx Anezrdx Semoba

Condition: new, overall weight: 31,000 kg, axle configuration: 3 axles, loading space length: 7,500 mm, loading space width: 2,550 mm, suspension: air, tire size: 235 / 75 R 17,5, color: other, gearing type: other, front tire size: 235 / 75 R 17,5, rear tire size: 235 / 75 R 17,5, driver cabin: other, emission class: none, fuel: biodiesel, Equipment: ABS, compressed air brake, Chassis: hot-dip galvanized, wooden floor 70 mm thick, 18 lashing rings, 12 stake pockets, 2 ramps each 3,110 mm long x 760 mm wide, hydraulic one-piece ramps, loading height: 880 mm, incl. axle load indicators. Surcharges: last axle as steering axle: €3,500; warning signs + lighting and beacon: €200; widening to 3m with wooden planks: €300; hydraulic ramp shift: €1,000. Also available with K80 towing eye! -- Errors, omissions and changes excepted, sample images -- More data at: !, More Details: ! Ibjdjzrdp Ropfx Anmea

Condition: excellent (used), Year of construction: 2022, functionality: fully functional, BEM 200 Case Former We offer for sale the BEM 200 Case Former. The BEM200 model is an automatic machine designed and manufactured for folding cardboard boxes and sealing their bottoms with tape. This model belongs to the mid-range/high-end category of machines and, due to its applications, covers almost all industries that use cardboard packaging. Iedpfjzr Ixisx Anmsba

Condition: used, Year of construction: 2011, AXES Working area X-Y-Z axes * mm 3050-1300-180 Workpiece length in swivel machining mm 1390 Ijdpfsyymz Usx Anmoba Stroke X-Y-Z axes mm 3460-1735-250 Max. travel speed of the X-Y axes m/min 60 WORKING TABLE Number of workpiece supports and vacuum cups 6 / 2 Standard type Standard End stops / Position 1 / rear Vacuum pump m3/h 90/108 DRILLING UNIT Vertical spindles Std/Number/Speed 1/min 12 (8X-5Y) / 4000 Horizontal spindles Std/Number/Speed 1/min 6 (4X-2Y) / 4000 Integrated slotting/sawing unit in X Ømm/1/min 120 / 6000 Motor power kW (HP) 2.2(3) ELECTROSPINDLE Motor power Std. / Opt. (S6) kW (HP) 7.5(10) / 11(15) Max. speed 1/min 24000 Tool changer mounted on the unit carrier in X 4 positions, pneumatic INSTALLATION Installed power KVA 23÷28.5 Compressed air requirement Nl/min 450 Extraction air requirement m3/h 1900+1900 (3400) Required extraction air velocity m/sec 30 Extraction nozzle diameter mm 150+150 (200) Machine weight Kg 3000 * X Distance between the stops - Y Milling center as reference point; Z Workpiece passage GENERAL FEATURES CNC-controlled boring and milling center, in C-frame design and working table with adjustable workpiece supports and vacuum cups, for performing: - Vertical drilling on the surface of the panel - Horizontal drilling on all four sides of the workpiece - Slot milling with disc cutter in "X" direction - General milling operations Self-supporting structure and working table Structure made of a steel welded construction with the control cabinet integrated into the machine frame. Available in two different lengths and with standard workpiece supports or TV supports. Movable unit carrier Box construction made of cold-rolled steel with internal reinforcing ribs, protective devices with bumpers. Working unit Consisting of a drilling head with vertical spindles, horizontal spindles, an integrated slotting and sawing unit and an SCM electrospindle with tool quick-change system type HSK 63 F. Travel paths of the portal and the unit carrier Movement in the X, Y and Z axis takes place on linear prismatic ball-bearing guides with the aid of pre-tensioned linear guides. The power transmission of the X-axis (movable stand) takes place via a pre-tensioned, backlash-free rack and pinion drive with diagonal movement. The movement of the unit carrier in Y and Z direction takes place via pre-tensioned linear guides. The positioning of the working units and the control of the machine functions takes place via "Brushless" three-phase servomotors and digital drives. CNC CONTROL The control unit consists of a numerical control for the milling and drilling machines and a pre-connected personal computer with a graphical user interface "XILOG PLUS". PC -Office- operating system Windows XP - LCD color screen 17 - Qwerty keyboard - Swiveling control panel - Machine interface software Xilog Plus Xilog Plus features Programming - parametric, graphical and ISO programming - Import of DXF and ASCII files - Linear or circular interpolation in three axes, linear in space, spiral in the chosen plane - Supported programming with graphic and syntax aids for drilling and milling operations - Automatic optimization of drilling operations and tool changes - cycles - Possibility of plate zero-point shift for performing drilling on inclined or curved plate sides - Complete compatibility with CAD/CAM Routocam (SCM) - AlphaCam Integrated additional functions - Calculator for direct transfer of the calculated data.
