Used Optimum Table Drilling Machine for sale (68,492)

Condition: excellent (used), TBT T30 SERIES TABLE TYPE GUN DRILLING MACHINE Model T30-1000KTN Serial number 410.364.016 Year of manufacture, approx. 1980 Number of spindles 1 Drilling range in steel 4 - 30 mm (solid) Counter boring 40 mm Nominal drilling depth 1000 mm Slotted table size 850 long x 750 wide mm Table size overall 1100 long x 1000 wide mm Table cross movement 800 mm (approx.) Table vertical movement 400 mm (approx.) Drilling slide longitudinal travel 1450 mm Slideway width 250 mm Spindle speeds to approx. 9000 rpm Spindle motor 25 kW Total load 41 kW Supplied with: 2 off Whip guides. Ballscrew feed. 2 Axis DRO to table Cross and Vertical, DRO to drill slide. TS25-1000 Coolant tank. Drill bushes. For Sale with Jet Machinery Ltd Jet Machinery Stock No: #27033 Machine Serial Number: 410 364 016 Cost: £17,500.00 + VAT Whilst every effort has been made to ensure that the above information is accurate it is not guaranteed. We advise prospective purchasers to check any vital details. Ijdpfxozuxp Ro Aaystk Health and Safety At Work Act 1974: It is not reasonably practical for ourselves as suppliers to ensure that for your application the goods comply with requirements of the Act with respect to guarding etc. Prospective purchasers should ensure that a guarding specialist inspect the goods prior to use.

Condition: good (used), *FOR SALE: Cincinnati Milacron PTC 40 Column Drill – 1982* *Price:* €2,200 – Negotiable *Location:* Les Ponts-de-Cé, 49130, Pays de la Loire *Description:* Industrial column drill *CINCINNATI MILACRON PTC 40*, manufactured in 1982. French made. Very robust machine for drilling and tapping in mechanical and sheet metal workshops. Column with cross table mounted on slides. Remote control + foot pedal. Complete and fully operational machine. *Specifications:* - *Make / Model*: CINCINNATI MILACRON PTC 40 380V - *Year*: 1982 - Serial No. 45117 Itjdjzvgr Aepfx Aaysk - *Type*: Column drill on a base - *Table*: Cross table mounted on slides - *Feed*: Spindle descent via handwheel + lever - *Equipment*: Remote electrical cabinet, Foot pedal, Vises - *Mounting*: On a pallet for removal

Condition: good (used), functionality: fully functional, drilling depth: 600 mm, workpiece weight (max.): 2,000 kg, travel distance X-axis: 750 mm, travel distance Y-axis: 630 mm, travel distance Z-axis: 300 mm, spindle speed (max.): 3,000 rpm, drill diameter: 35 mm, drill spindle length: 600 mm, spindle mount: MK 2, spindle stroke: 600 mm, number of spindles: 1, Equipment: rotational speed infinitely variable, Driling capacity: Ø 35 mm Driling depth: 600 mm X-axis: 750 mm Y-axis: 630 mm Z-axis: 300 mm Spindle speeds: 0 - 3000 rpm Tabel size: 1100 x 650 mm Load on table: 2000 kg max Itedpfx Ajzu Sp Rsayjk Turning table: 360° Controller: Degen AE30 Including: - Cabinet + pallet with drills - Coolingunit - Machine manuals Country of origin: Germany Motor power: 11,2 kVA Machine LxWxH: 350 x 120 x 175 cm Machine weight: 1300 kg

Condition: excellent (used), Year of construction: 1994, tool diameter: 60 mm, spindle mount: MK 5, rotational speed (max.): 1,460 rpm, total width: 1,100 mm, total length: 2,300 mm, total height: 2,400 mm, table width: 580 mm, table length: 1,400 mm, overall weight: 2,700 kg, Arm length: 1200 mm Max. drilling diameter in cast iron: 60 mm Itsdpfx Aszvfn Neayok Max. tapping diameter: 40M Max. drilling diameter in steel: 50 mm Stroke of quill: 110 mm Max. distance spindle to table: 1165 mm Min. distance spindle to table: 300 mm Floor/table area: 1400 x 580 mm Speeds/ranges: 1460 rpm Spindle taper: 5ISO/BT/MK Length: 2300 mm Width: 1100 mm Height: 2400 mm Weight: 2700 kg

Condition: used, Year of construction: 1994, bore capacity in steel (diameter) 35 mm throat 300 mm bore stroke 180 mm turning speeds 55 - 1450 U/min taper MK 4 column diameter 145 mm total power requirement 2,2 kW weight 500 kg dimensions 800 x 1000 x 2000 mm Features: - Heavy-duty pillar drill - Infinitely variable speed control (V-belt) - Automatic spindle feed * with electromagnetic engagement - Pole-changing motor - Right/left rotation of the drill spindle - Fixed drilling depth stop - Machine table with 2 T-slots * height-adjustable via hand crank - Coolant system - Machine vise - Drill chuck - Emergency stop Itjdpfxezu Tk Ne Aayok

Condition: used, Year of construction: 1967, Year of Manufacture: 1967 Machine / Serial No.: 72882 Country of Manufacture: Germany Iedpfx Aozvfi Hsayjtk Manufacturer: Praehomawerk Kehren & Co., Hennef/Sieg Model: RW 6 Machine type: Rotary table surface grinding machine Grinding method: Surface grinding with rotary table Grinding spindle arrangement: Horizontal spindle Control: Conventional / manual Rotary table diameter: 600 mm Magnetic chuck: Electromagnetic rotary table Grinding height: approx. 350 mm Maximum workpiece diameter: approx. 650 mm Grinding wheel diameter: approx. 400 mm Grinding spindle speed: up to approx. 3,000 rpm Grinding spindle motor power: approx. 5.5–7.5 kW Vertical adjustment: Manual / powered vertical adjustment Table rotation: Powered rotary table Coolant system: Included Grinding wheel dressing: Manual dressing arrangement Machine operation: Conventional push-button control Operating hours shown: approx. 11,350 h Machine length: approx. 2,500–3,000 mm Machine width: approx. 2,000–2,300 mm Machine height: approx. 2,700–3,000 mm Machine weight: approx. 3,500 kg

Condition: new, 6-sided drilling machine Manufacturer: Quick Type: KQ-63E New machine Technical data: - Workpiece length: 70 - 2800 mm - Workpiece width: 50 - 1220 mm - Workpiece thickness: 9 - 60 mm - Min. workpiece to be processed: 70 x 50 mm - Feed rate in X: 135 m/min - Feed rate in Y: 90 m/min - Feed rate in Z: 25 m/min - Individually controllable spindles: Top: 2 x 12 vertical, 4 horizontal / Bottom: 1 x 7 vertical - Machine control: Higerman (German) - Milling spindle (top): 9 kW, 24000 rpm - Tool changer (top): 5-position - Milling spindle (bottom): 3.5 kW, 18000 rpm - Motors: Brushless servo motors - Positioning accuracy: 0.03/1000 - Repeatability: 0.02/1000 Itsdpfxezvgn De Aayjk Optional: - Machine with workpiece return Quickly found Offer machines Register for newsletter Unsubscribe from newsletter Contact us Overview

Condition: new, Six-sided drilling machine Manufacturer: Quick Type: KQ-62Lite New machine Technical data: - Workpiece length: 70 - 2,400 mm - Workpiece thickness: 9 - 60 mm - Workpiece width: 30 - 1,220 mm - Min. processing size: 50 x 70 mm - Transport speed in X: 138 m/min - Transport speed in Y: 90 m/min - Transport speed in Z: 28 m/min - Machine control: Higerman - Working height: 890 mm - Milling spindle: 2 x 3.5 kW, 18,000 RPM, manual tool change - Drilling unit: Top 9 vertical and 4 horizontal / Bottom 7 vertical - Positioning accuracy: 0.03/1000 - Repeatability: 0.02/1000 - Power consumption: 25.8 kW Optional - Machine including workpiece return Ijdpfx Aozvgndjaystk Other configurations available upon request.

Condition: new, Year of construction: 2023, machine/vehicle number: 320542/B, functionality: fully functional, number of axes: 3, controller manufacturer: TPA, CNC Drilling and Milling Machine Manufacturer: Vitap Type: K3 New machine Through-feed processing, workpiece machining from below, and automatic workpiece return to the operator Develop an individual class: - With this machine, you can perform many different milling operations in addition to grooving and drilling, from simple edge milling to milling shapes and letters. - We do not limit your creativity. Easy entry into CNC technology: - TPA makes it easy for you: Whether drilling, grooving, linear milling, contour milling, or milling letters. - The CAD software clearly displays the machining operations. - Particularly clear is the programming of the work steps on the individual workpiece sides. - You can mirror machining operations with a mouse click. Itodozvduuspfx Aaysk - You can either enter the starting points precisely or determine them by clicking on the virtual workpiece. Vitap Bar Nesting - efficient and time-saving - This patented software produces entire corpus elements from a long workpiece. - You insert the long workpiece, and when you remove the first finished element, the machining of the next element continues directly. The DDT feed system (double dynamic transport) - 2 clamps enable uninterrupted workpiece transport. - The operator inserts the workpiece until it reaches the stop. - Both clamps then grip the workpiece and position it precisely. - During machining, both clamps communicate with each other, so that clamp 2 grips before clamp 1 releases. - This ensures a constant feed rate even during linear milling. 3 controlled axes: - X axis - DDT feed - Y axis - Drilling head travel - Z axis - Drilling - Double "0" reference: New laser generation for detecting the beginning and end of the workpiece. The program can readjust the drilling from below to achieve perfect alignment in vertical and horizontal workpieces. The laser consists of a transmitter and receiver to avoid errors with dark edge material. - Side stops with rollers, consisting of a fixed and a movable part, mechanical digital readout with automatic alignment to the 0 stop for removal of up to 3 mm on the 0 line - Constant side pressing device for precise positioning to the 0 line - Automatic 4-position tool changer - Adjustable zero point - No workpiece length limitation - Monitor LCD TFT 20" - Industrial PC - Operator interface WSC with Lister, parametric tool, and parametric setup - Graphical programming CAD TPA EDI32, basic version - USB port - Storage of all files - Macro programming - Import DXF files Technical data - Number of independent, vertical spindles: 12 - Number of independent, horizontal spindles on the X axis: (2+2) - Number of horizontal drilling spindles on the Y axis: (2+2) - 1 saw (100mm) - Electro spindle 5 kW with ISO30 taper (RPM [contact removed]) - Max. workpiece weight: 40 kg - Max. workpiece dimensions: X unlimited, Y 1250 mm, Z 50 mm - Min. workpiece dimensions: X 270, Y 150 (70op), Z 3 mm - Feed rate: 25 m/min - Spindle speed: 3600 RPM - Saw speed: 7000 RPM - Max. horizontal tool: 12mm - Max. drilling depth horizontally on the X and Y axis: 35mm - Max. drilling depth vertically: 43 mm - Max. vertical tool: 35mm - Motor: 1.7 kW - Adjustable zero point for 4-sided formatting - CE compliant Optional against additional charge

Condition: ready for operation (used), Year of construction: 1960, Available immediately ex-works: Bench drilling machine, Scharmann Type FB 125 b Year of manufacture 1960 Complete retrofit in 2010 Spindle 125 mm Metric 80 / SK 50 spindle mount Quill stroke 800 mm Table 1600 x 1200 mm Table traverse 2000 mm Spindle / table installation height 1400 mm Table longitudinal travel 2500 mm Spindle speeds 5 – 740 rpm, 7.5 – 1100 rpm For Wohlhaupter machining: 5 – 74 rpm Iedezu I Eujpfx Aayetk 3-axis Heidenhain digital display Vertical head Large Wohlhaupter boring head Various other accessories Weight 21 tons Price: EUR 9,500.00 plus VAT, ex-works.

Condition: new, functionality: fully functional, Jainnher Machine Co., Ltd. was established in 1982 and is dedicated to developing grinding machine technology, diversity and automation equipment. Jainnher is constantly offering new and improved machinery. The new JAINNHER JHP-4015 CNC Plunge Type machine with FANUC CNC Control. Hydrostatic and Hydrodynamic bearings. Capacity Max ø work swing Ø400 mm Max grinding length 1500mm Max grinding dia. Ø380 mm Max workpiece weight 150 kgs Distance between centres 1500mm Centre height 200mm Grinding wheel Grinding wheel size Ø410 x 50-100 x 203.2mm Max peripheral 33 m/sec Wheel speed 1250rpm Wheel head Feed angle 90 Swivel angle ±0 Rapid traverse speed 6m/min Max. travel 280mm Min. setting unit 0.0001mm Grinding feed rate 0.001~6000m/min Oil Pressure Hydrostatic = 20kg Hydrodynamic = 3kg Tailstock Retraction of quill 30mm Quill diameter 70mm Iedpsnzib Esfx Aaystk Centre taper MT.4 ( MT.5 option) Hydraulic cylinder pressure 20kg Work head Spindle speed (variable) 10~500rpm/min Centre taper MT.4 ( MT.5 option) Spindle type Telescopic (option Swivel angle 120 (90ºCCW;30ºCW) Work- table Min. setting unit 0.0001mm Swivel angle CCW/CW +7º/-4º Rapid traverse speed 10m/min Max. travel 1500mm Motor Grinding feed rate 0.001~6000mm/min Grinding wheel motor 7.5HP 4P(opt. 10.0HP) 4P Workhead motor 1.5KW Work table (Z axis) 1.8KW Work table (X axis) 1.8KW Hydraulic pump 1/4 HP 4P Wheel head pump Hydrostatic = 2.0HP Hydrodynamic = 1.0HP Coolant pump 1/8 HP 2P Magnetic coolant separator 1/25HP 2P Oil cooler ----- Oil tank Hyd. oil tank(slideways, screw ends & measurement) 60L Wheel head lubrication 50L Coolant tank 160L Machine N.W (Fully enclosed) 8080 kg G.W (Fully enclosed) 8480 kg Dimension (Fully enclosed) 4900 x 2100 x 2000mm Packing (Fully enclosed) 5090 x 2200 x 2200mm

Condition: like new (used), Year of construction: 2011, machine/vehicle number: MA10110002, functionality: fully functional, SPECIFICATION Drilling capacity in mild steel 18mm Motor 0.45kW 415 volt Spindle 2MT Drive Belt, stepped pulleys Spindle speeds rpm 50Hz 400-700-1200-2100-3600 Spindle travel 75mm Throat depth 185mm Column diameter 70mm Table -working surface 250 x 164mm Table – slots width & centres 13 x 125mm Base – overall 240 x 360mm Max. distance chuck to table 330mm Overall height 865mm Overall width 280mm Overall depth 600mm Approx. Nett weight 77Kg Machine equipped with Chuck guard Table adjustment by rack Ijdpozmuntefx Aayotk Drill chuck

Condition: new, functionality: fully functional, he EUROPA JAINNHER JHV-1008CNC vertical grinding machine is designed for grinding of large components used in the transport, aerospace, power generation, oil & gas, hydraulic and precision components. With a grinding internal diameter range from Ø50 to 800 mm, a maximum outside diameter of Ø1000 mm. The maximum height of the workpiece is 800mm, with a maximum worktable load of 1200 kg. EUROPA Jainnher JHV-1008 CNC Vertical Grinder Capacity Range of I.D. grinding 50 – 800mm Maximum O.D grinding 1000mm Z axis maximum grinding height (OD) 800mm Z axis maximum grinding height (ID) 50 – 250 : 325mm / 250 – 800 : 800mm Itodpfxsnzkvhj Aayjk Maximum swing diameter 1000mm Maximum installed component height 800mm Maximum work table load 1200kg Email for latest factory build availability

Condition: new, functionality: fully functional, NEW Rotary table surface grinder available in the UK. With up to a 400mm grinding diameter on this rotary table, vertical spindle surface grinder from Italian manufacturer DELTA, a leading surface grinder manufacturer with over 20,000 units sold worldwide. The rotating table is controlled by asynchronous three-phase bipolar motors with 8/16 poles; thanks to these motors, the table can rotate at a speed of 40 rpm and at a rate of 30 rpm. Delta Rotary surface grinder Maximum grindable surface 400mm Ø Distance between column and wheel axis 315mm Max. distance between magnetic table and wheel 205mm Rapid feed per turn of handwheel 2mm Micrometric feed by small handle 0,01mm Size of cup wheel 200 x 80 x 78mm Ø Size of abrasive segments 50 x 20 x 90mm Motor power of the wheel (4 HP)-3 kW Itjdpfx Aasnziakeyek RPM of the wheel (50 Hz) 2840rpm/min Electropump motor power (0,08 HP)-0,06 kW Mass of the machine 680kg Rotary table surface grinder Standard Equipment Low tension electric system (24V). Cooling system with electropump Wheel-holder flange and grinding wheel. Grinding wheel guard Table guard.- Stakes key Instruction book/testing certificate Two colour painting RAL 5018-7032, bicomponent multicoat of paint CE conformity certificate with respect to the Units Directive CEE 89/392 and subsequent modifications Stock machine complete with Automatic Downfeed control

Condition: good (used), Year of construction: 1980, functionality: fully functional, Gear-driven drill press, no belt changes required Very quiet and smooth operation - Drilling capacity in steel ST 60: 30 mm Iedpfezuxxfjx Aayetk - Drill spindle mount: MK 3 - Drill spindle stroke: 160 mm - 9 drill spindle speeds: 90 - 1450 rpm - Overhang: 300 mm - Table with 2 T-slots - Table dimensions, swiveling: 500 x 450 mm - Table dimensions, base plate: 350 x 400 mm - Distance from base plate to spindle nose: 1100 mm - Max. distance table - drill spindle: 660 mm - Height adjustable via rack and pinion with hand crank - Column diameter: 120 mm - Drive: 380 V / 1.2 kW - Space requirement: approx. W 600 x H 2100 x D 670 mm - Weight: approx. 350 kg - Includes drill chuck

Condition: used, Year of construction: 2014, Used Machine Year of manufacture: 2014 Condition: The machine has been factory-overhauled by Ganner Features and Technical Specifications: Complete standard configuration including: - Support with linear guide consisting of: 1 single-spindle horizontal drilling unit, 0.65 kW motor, 70 mm stroke Tool speed selectable via operator software (3000/5000/8000 rpm) 1 blow-out, gluing, and dowel-driving station for dowels Ø 8 mm, dowel length 25–50 mm - Fully automatic, electronically controlled central lubrication - X-axis NC-controlled, with working length 1300 mm, travel speed max. 105 m/min. - Z-axis manually adjustable via mechanical digital counter, position adjustable via support table 5–40 mm - Dowel drive-in overhang adjustable from 7–20 mm via a mechanical digital counter; drilling depth from 0–35 mm (for drill bit length GL 70 mm) is automatically adjusted with the drive-in overhang - Closed glue system with 6 bar glue pressure via glue nozzle, for glues with a viscosity of 150 to 350 mPas - Glue quantity continuously adjustable via operator software - GLUE/WATER selector switch for flushing the glue system, each with: 1 stainless steel tank for 7.5 kg of glue and 7.5 l of water - Indicator light showing remaining glue levels in the glue tank - 1 left side stop, 1 right side stop, and 1 center stop (all removable) - 4 start buttons for individual processing of 1–4 workpieces - 4 pneumatic 10° angle clamping cylinders for workpiece thicknesses up to 80 mm, workpiece length (Y) min. 70 mm - 1 extraction funnel, connection Ø 80 mm - 1 TCT control unit with: Built-in industrial PC, including Beckhoff TWINCAT soft PLC, operating temperature range 0–50°C, 15-inch capacitive TFT industrial touchscreen, operating system: WINDOWS 7 Iodpfszlbrvsx Aaystk - Programming via menu-driven user software, drilling distances freely programmable with ABSOLUTE, RELATIVE, or GRID dimensions, automatic workpiece mirroring and operation optimization, 4 work areas assignable to different programs, graphical workpiece display, parametric programming, zero-point offset, programmable worklists, error diagnosis with plain text Optional equipment: - 1 electronic, optical glue monitoring system G.I.C. (Glue Insert Control) for 1 glue nozzle - 1 Z-axis with NC-controlled, dynamic positioning for height adjustment of the drilling and dowel-driving station (programmable from 5–40 mm), travel speed max. 30 mm/sec. - 1 single-spindle vertical drilling unit drilling from the TOP, 0.65 kW, (3000/5000/8000 rpm), position (Y) manually adjustable via a mechanical digital counter from 5–40 mm, drilling depth (Z) max. 30 mm (with drill bit length GL 57 mm), Workpiece thickness (Z) max. 50 mm, workpiece length (Y) min. 130 mm (including drilling depth compensation, e.g., for Häfele Minifix) - 4 vertical 10° angle clamping cylinders with mount - 1 keypad with mount Availability: available shortly Location: DE-63934 Röllbach

Condition: used, Year of construction: 1972, Technical details: bore capacity in steel (diameter): 25 mm throat: 300 mm bore stroke: 630 mm spindle turning speed - continuous: 150 - 2860 U/min spindle taper MT: MK 4 Distance spindle/table max.: 630 mm Itedpfx Ajzfltdoayok table-size: 300 x 400 mm total power requirement: 1,65 kW weight of the machine ca.: 700 kg dimension machine approx.LxWxH: 0,6 x 0,8 x 2,10 m

Condition: used, Year of construction: 2011, Technical details: bore capacity in steel (diameter): 35 mm throat: 350 mm bore stroke: 180 mm threading: ST M 24 mm spindle taper MT: MK4 spindle speed:: 50 - 1450 U/min Distance spindle/table max.: 780 mm table clamping surface:: 560 x 560 mm weight of the machine ca.: 500 kg Iodpfx Aajyli Sfjyetk dimension machine approx.LxWxH: 0,73 x 0,56 x 0,22 m · Heavy, solid cast construction · Automatic gear lubrication via oil pump · Smooth running due to ground gearbox gears operating in an oil bath · High concentricity thanks to hardened and ground main spindle · Thread cutting device · Lockable main switch and motor protection switch · Optidrill B 40GSM additionally with automatic quill feed · Electric · 2 feed rates: 0.1 / 0.2 mm/rev · Coolant system · Drilling depth stop · 18 speeds: 50 – 1,450 rpm · 9 selectable speeds via gearbox lever on the front of the drill head *

Condition: good (used), WMW HECKERT BR 40/2 x 1250 radial drilling machine - Arm length: 1250mm - Maximum drilling diameter: 40mm - Morse taper: MK5 - Minimum speed: 20 RPM - Maximum speed: 1200 RPM - 3-speed gearbox with variable speed control - Dimensions of drilling head: (L x W x H) 710 x 710 x 500mm - Weight: 3000KG Isdezury Njpfx Aaystk - Automatic feed - Dimensions (L x W x H): 2100 x 1000 x 2900mm

Condition: used, Year of construction: 2019, - Magazine loading system - Clamping table for frame parts - 3 horizontal, longitudinal drilling units from the rear - 4 vertical drilling units from above 1 Drilling machine Manufacturer: KOCH Type: BL 2500 NC select line - used - Year of manufacture: 2019 Workpiece dimensions Workpiece length 150 - 2500 mm Workpiece width 20 - 300 mm Workpiece thickness 10 - 50 mm Material: Solid wood Magazine loading system 1 with workpiece return. Workpiece insertion via 2 parallel-controlled servomotors. The number of workpieces in the magazine depends on the workpiece weight. Manual workpiece insertion Clamping table for frame parts 1 By inserting 3 support segments into the longitudinal drilling units, workpieces can be inserted manually and clamped with clamping cylinders and templates. This also allows for special workpiece dimensions. Work cycle triggering via 2 manual controls on the swappable control panel. 3 horizontal, longitudinal drilling units from the rear Construction width 160 mm Drilling motor 2 kW Longitudinal adjustment (X) with LCD display Vertical adjustment (Z) With dust extraction 4 vertical drilling units from above (supported on one side in a linear guide) Adjustable over the entire working width (X), reading LCD display. Adjustable in working depth (Y), reading LCD display One vertical clamping cylinder mounted directly on the unit Counterpieces for through-holes are available as an option. Drilling motor 1.5 kW at 50 Hz Drilling stroke 50 mm Speed 2,800 rpm Total drill length 70 mm With 4 rotary indexing heads with quick adjustment (for vertical drilling units) with fixed stops at 0 and 90 degrees Positioning control KOCH NUMERIC Basic 1 Positioning control with Beckhoff C6920 industrial PC Intel Celeron 2.2GHz CPU 2.5 320GB HDD 1x RS232, 2x USB, 1x Ethernet available 15-inch touch panel Operating system Windows 7: English User interface in English Input of all machine commands via the touch panel Software is prepared for an online connection. The configuration of the online connection (network) and commissioning are carried out by the customer or their software company. USB port on the PC 4 x Dynamic NC axis (with bearing control) for Z axes Connection data 1 Electrical connection 400 V, 50 Hz, 3 phases Itjdszuynhepfx Aayjk Voltage fluctuations max. + 6 % to - 10 % If protected by an RCD (residual current device) on the customer's side, an all-current sensitive (R CCB, Type B) RCD with a rated residual current of /= 300 mA must be used. Air connection 7 bar Dust extraction air velocity min. 30 m/s Note: The technical data and descriptions are a transcript of the original order confirmation. The data is for informational purposes only and is not binding.

Condition: used, Year of construction: 2018, operating hours: 500 h, Throughfeed machining, workpiece machining from below, and automatic workpiece return to the operator. 3 controlled axes: X axis - uninterrupted workpiece transport via DDT (double dynamic transport system) with a brushless motor Y axis - drilling head travel Z axis - drilling - Double "0" reference: new laser generation for detecting the start and end of the workpiece. The program can adjust the drilling from below to achieve perfect alignment in vertical and horizontal workpieces. The laser consists of a transmitter and receiver to avoid errors with dark edge materials. - Side stops with rollers consisting of a fixed and a movable part, mechanical digital readout with automatic alignment to the 0 stop for removal of up to 3 mm on the 0 line - Constant side pressing device for precise positioning on the 0 line. - Rear workpiece outlet - Automatic 4-position tool changer - No workpiece length limitation - Monitor LCD TFT 19" 5/4 - Industrial PC - Operator interface WSC with Lister, parametric tool, and parametric setup - Graphical programming CAD TPA EDI32, basic version - USB port - Storage of all files - Macro programming - Import DXF files Itjdpjzuxdbjfx Aayjk Technical data Number of independent, vertical spindles: 12 Number of independent, horizontal spindles on the X axis: (2+2) Number of horizontal drilling spindles on the Y axis: (2+2) 1 saw (Ø 100mm) Electric spindle 5 kW with ISO30 taper (RPM 12000-24000) Max. workpiece weight: 80 kg Max. workpiece dimensions: X unlimited, Y 1200 mm, Z 50 mm Min. workpiece dimensions: X 270, Y 185 (70op), Z 4 mm Feed rate: 25m/min Spindle speed: 3500 RPM Max. horizontal tool Ø 12mm Max. drilling depth horizontal on the X and Y axis 30mm Max. drilling depth vertical: 45 mm Max. vertical tool Ø 35mm Air consumption 2000 m3/h Extraction speed 30 m/s Extraction nozzle 2xØ. 100mm + 1xØ.50 mm Motor: 1.7 kw Compressed air: 7 bar Max. air consumption: 60 nlt/min CE STANDARDS - Office software - license - Adjustable zero point for 4-sided formatting - CE compliant - Status: 05/28/2026: approx. 500 operating hours and a new PC has been installed.

Condition: used, Year of construction: 2012, - Work area: X: 9000 mm / Y: 2700 mm - Gantry 1: 5-axis milling spindle 20/26 kW - 32-position tool changer - Gantry 2: 2x13 spindle drilling unit Technical data - Heavy-duty gantry system with 2 gantries - Gantries with drives on both sides (gantry drive) - CNC control SIEMENS 840D sl / PCU 50 with NCU 730 Itodpszuw Ixofx Aayek - Operator panel OP 15 with 15" display, mounted on a guide rail along the longitudinal axis Work area / machinable cube size with tool length/diameter of 160 mm - X-axis: 9000 mm with both gantries - Y-axis: 2700 mm - Z-axis: (Standard cube size 420 mm) - Customer-specific design for workpiece thicknesses up to 60 mm - 5-axis head Equipment, Gantry 1 - 1 universal head for 5-axis milling - Milling spindle power: 20/26 kW (S1/S6) - Speed adjustable up to 24,000 rpm - Water-cooled - Tool interface HSK F63 for automatic tool changes - Thread cutting is possible! - 1 chain-type tool magazine with 32 positions - With rotary gripper for fast tool changes - Magazine fixed on the operator side Equipment, Gantry 2 - 2 head mounting brackets - Equipped with 2 heavy-duty multi-spindle drilling units each - With common dust extraction hood - Each drilling unit with 13 drilling spindles (total of 26 drilling spindles) - Individually selectable vertically - Arrangement in an L-shape - 2 angled drilling spindles adjustable from 0 - 25° - 1 right, 1 left, each approx. 2.2 kW, n= 2800 rpm - Drill chuck collet Rego Fix ER 25 M Machine table - Base frame with linear guide - 12 table traverses on a linear guide for positioning in the X-direction, individually driven and positionable via NC drives - Vacuum supply integrated into the table traverse - Each traverse is individually vacuum-monitored and linked to the machine control system Workpiece infeed function - 1 belt conveyor consisting of 4 belt strands - Width 40 mm, each traverse with lifting devices - Lifting device NC-controlled - Stroke 110 mm (+10 mm, -100 mm) - The machine should be installed in a foundation pit of approx. 300 mm - Vacuum pump Bush type: Mink MM 1322 - Suction capacity 250 m³/h - With intermediate tank 500 l for rapid vacuum generation - 2 chip transport belts under the machining area for the removal of chips and/or small swarf up to a size of max. 100 x 100 x 100 mm - Automatic central lubrication Work safety - Moving protective cabin on both gantries - Protective cabin with safety bumpers and safety light curtain system on the operator and rear sides (due to automatic table adjustment)

Condition: used, Year of construction: 1991, Eye-level control panel, Aigner integral stop including feed with sliding carriage (without stop ruler), milling stop with digital display and swivel mechanism Isdpeyi A Tdjfx Aayotk Storage location: Nattheim

Year of construction: 1985, condition: used, Drilling process: single-lip gundrilling, operating method: rotating tool, number of working spindles: 1, nominal drilling depth: approx. 750mm, drilling range for solid drilling in steel: approx. 30mm, drilling range for counterboring in steel: approx. 40mm, spindle drive: 11kW, max. spindle speed range I: 1800rpm, max. spindle speed range II: 5700rpm, max. feed rate range I: 320mm/min, max. feed rate range II: 160mm/min, rapid traverse: 3.5m/min, clamping table X/Y: 420mm/1280mm, cross-slide table manually operated, max. transverse travel: 400mm, table clamping surface X/Y: 600mm/600mm, high-pressure coolant system for deep-hole drilling oil with 1000l coolant tank, flow rate: approx. 2-94l/min, max. pressure at max. flow rate: 45bar, pump power: 11kW, separate control cabinet. The machine underwent an extensive partial overhaul in 2018, during which the machine was disassembled and cleaned, all guideways and support surfaces were ground and partially scraped, motors were inspected and fitted with new bearings, the drilling spindle was fitted with new bearings, the ball screw incl. nut was replaced, the pump motor was overhauled, the wiper set was replaced, and the machine was repainted and all functions were checked and rectified. Including extensive accessories. Documentation available. Inspection possible by arrangement. Itodpfxozu Szyo Aayjk

Condition: good (used), Please refer to the images for all technical specifications. Transport and loading can be arranged throughout Europe for an additional charge upon request. Prices are subject to VAT. Itedpfxszvnnfe Aaysk Viewing is possible by appointment. Contact us—our team looks forward to assisting you. Machinery purchase / sale PURCHASE / SALE OF PRODUCTION & METALWORKING MACHINES, MACHINE TOOLS, AND MUCH MORE. Do you need a high-quality yet affordable machine for your production? Or are you looking to sell yours? For further information or contact options, please reach us via the contact form.
