Used Forkardt Dreibackenfutter - F315 for sale (141)

Condition: refurbished (used), Year of construction: 2022, functionality: fully functional, turning diameter over bed: 540 mm turning length: 1.500 mm turning diameter in the recess: 580 mm Working travel of the lower slide max. approx.: 415 mm adjustment of upper support, max. approx.: 140 mm turning speed range: 0 - 1.800 1/min diam. of main spinde: 135 mm spindle bore: 68 mm internal taper diameter: 68 mm bed width: 403 mm Bwodpfxjz Er Tzo Ahmju Equipped with: Three jaw chucks FORKARDT 250 Digital read out 3 axis fixed steady rest feed safety chip tray tool holders, 6 chisel holders, 1 holder for clamping sleeve

Condition: good (used), Year of construction: 1962, Centre lathe manufacturer VDF HEIDENREICH&HARBECK type: 24 RO, year of manufacture 1962, overhauled in 1992. Equipped with 3-axis digital readout Heidenhain, 250 mm Forkardt chuck, Multifix B toolholder. Centre height: 255 mm Swing over bed: 510 mm Swing over cross slide: 270 mm Distance between centres: 1000 mm Spindle bore: 55 mm Bedjxziuwjpfx Ahmswu Spindle speeds: 20 - 900 rpm, Motor power: 6.5 kW The machine is in good condition, electrical diagrams available. Required floor space: Length 3 m, Depth 1.2 m, Height 1.3 m, Weight approx. 1800 kg.

Condition: good (used), Key bar chuck, power chuck, three-jaw chuck, three-jaw lathe chuck Bodpowucrrefx Ahmjwu -Manufacturer: Forkardt, wedge bar chuck type F 400 without clamping jaws -Chuck size: Ø 400 mm -Bolt circle: mm -Through hole: 102 mm -Total dimensions: Ø 400 x 125 mm -Weight: 90 kg

Condition: ready for operation (used), Year of construction: 1997, operating hours: 34,000 h, travel distance X-axis: 570 mm, travel distance Z-axis: 2,000 mm, number of axes: 2, Horizontal turning machine manufactured in 1997. This BOEHRINGER DUC 560/2000 features a maximum turning diameter of 570 mm and a turning length of 2000 mm. It includes an 8-position disc turret and a three-jaw chuck with a diameter of 200 mm. If you are looking to get high-quality turning capabilities, consider the BOEHRINGER DUC 560/2000 machine we have for sale. Contact us for further details. Bjdpfx Ahozuyqcjmewu - Main Drive: 19 kW- Machine Control: NUM / Keller/Plus (IBM Monitor setup)- Maximum Torque Duty Cycle: 60% / 100%- Torque: 1800 / 1400 Nm- Max Rapid Traverse (Longitudinal/Cross): 10 / 5 m/min- Tool Turret: 8-position disc turret, Sauter VDI 30- Chuck: Forkardt three-jaw chuck installed, diameter 200 mm- Included Accessories: Steady rest- Operational Status: Out of service since mid-2023 due to operator retirement- Operating Hours: Approx. 34,000 hours (single-shift operation/power-on time) Technical Specification Counter Spindle No Driven Tools No

Condition: new, functionality: fully functional, Spare parts for Fritz Heckert milling machines F315, F400 - even for the oldest ones. We offer a full range of spare parts for milling machines – the old and new German WMW HECKERT milling machines F315, F400, FSS-350MR, FSS-400MR, FU-350MR, FU-450MR, FU-350ApUG, FU-450ApUG, FU-350MRApUG, FU-450MRApUG. In our stock one can find: milling machine head and all gears for it, dividing heads, lunette/rests, all electromagnetic clutches and brakes, shafts, bevel gears, worms and worm gears, pulleys, levers, longitudinal and cross screws, nuts, oil pumps, cooling pumps, spindles, quills, hydraulic dividers/distributors etc. All the original parts for Heckert milling machines we can offer directly from stock, ready for immediate shipment. All parts are new, executed in German quality, and meet the highest technical standards. Bwedpovtnfpefx Ahmeu

Condition: ready for operation (used), Year of construction: 1996, LZ lathe, make SASTA STANKO, type: SA562M, year of manufacture 1996 Swing diameter above bed: 500 mm Swing diameter above plan support: 290 mm Tent length: 1500 mm Spindle speeds: 16 2000 rpm Spindle bore: 55 mm Chuck diameter 250 mm Forkardt tool holder Multifix size C. Machine with rapid traverse X and Z axis Good general condition. For further information see data sheets. Bwodpjvkuaujfx Ahmeu

Condition: excellent (used), Year of construction: 1974, functionality: fully functional, WE OFFER UNIVERSAL LATHE WITH BRAND NEW 3 AXIS DIGITALS COMPLETE TOOLS AND ACCESSORIESS. DESCRIPTION Description Precision lathe, turning machine -Manufacturer: VDF Heidenreich & Harbeck -Machine bed rails: hardened -Turning length: 750 mm -Turning Ø over bed: 500 -Turning Ø over recess: 355 mm -Turning Ø over support: 290 mm Bwsdpovkpkzofx Ahmju -Spindle bore: Ø 56 mm -Spindle speeds: 19 - 2000 rpm -Wedge bar chuck: Forkardt Ø 250 mm -Tailstock mount: MK4 -Drive: 7.5 kW -Accessories: 1x steady rest, 6x Multifix tool holder, -Dimensions: 1180/3050/H1345 mm -Weight: 2000 kg

Condition: used, functionality: fully functional, spindle bore: 102 mm, center height: 400 mm, turning length: 2,000 mm, Maximum height between centers: 400 mm Distance between centers: 2000 mm 26 spindle speeds from 4.5 - 1400 RPM - driven upper slide rest - rapid traverse - Forkardt 400 mm Bwodpfx Aozql D Hshmsu

Condition: good (used), Interchangeable jaws, top jaws, three-jaw chucks, segment jaws, clamping jaws, stepped block jaws, stepped top jaws, block jaws, base jaws, interchangeable jaws, wedge bar chucks, interchangeable jaws, power chucks -Top jaws: hard top jaws for wedge bar chucks, helical teeth -Jaw width: 45 mm Bwsdpfsypvlgex Ahmju -Dimensions: see photo technical drawing -Overall dimensions: 167/135/H93 mm -Weight: 10.7 kg

Condition: used, Year of construction: 2010, x-travel 1.100 mm y-travel 900 mm z-travel 1.250 mm control SIN 840 D spindle turning speed - gearbox stage 1 20 - 1.333 1/min. spindle turning speed - gearbox stage 2 1.333 - 8.000 1/min. power capacity at 60% / 100 % load 50 / 37 KW tool taper SK50 B - axis 360 x 0,001 ° rotary table speeds infinitely variable 1 - 500 U/min feed X/Y/Z/-axis 1 - 60.000 mm/min rapid traverse 60 m/min feed capacity X/Y/Z 17 kN numbers of pallets 2 pallet size 800 x 800 mm table load 1,50 t tool magacine with 120 Plätzen tool length - max. 600 mm Bsdpfx Ahoymfzremowu tool diameter 135 mm wotkpiece diameter with 2 vacant positions 350 mm weight of tools max. 60 kg total power requirement 150,00 kW weight of the machine ca. 35,00 t dimensions of the machine ca. 11,50 x 7,40 x H4,25 m Machining center with control SIEMENS SIN840D, H/V-head and turning-operation; Pallett-changer with 2 palletts and hydr. chuck Forkardt 3KS1000, Coolant unit KNOLL; Coolant through spindle (30 l/min 50bar);

Condition: ready for operation (used), Year of construction: 2009, turning diameter over cross slide: 925 mm, turning length: 2,800 mm, turning diameter: 1,200 mm, spindle bore: 132 mm, spindle speed (max.): 2,000 rpm, CNC Siemens 840D 48-tool changer, Capto C8 tools chip conveyor Forkardt 400MM chuck, 2 hydraulic steady rests SMW Autoblok capacity 2800x1250MM, spindle bore 132MM weight 23,500 kg Bwsdpfx Ajwzyn Rshmsu

Condition: used, Year of construction: 1971, turning diameter over bed 297 mm turning diameter over bed slide 160 turning length 500 mm short taper holder Größe 5 spindle bore 36 mm spindle turning speed range 30-3550 U/min Bsdpfey Hxp Djx Ahmewu number of speeds 18 quill adjustment 90 mm tailstock quill taper MT 3 cross adjustment +15 tailstock adjustment - manual 500 mm weight of the machine ca. 610 kg dimensions of the machine ca. 1,4 x 0,7 x 1,2 m cessories: Forkardt V-block chuck, Ø 160 mm Collet chuck, Collets (see photo) Steel Multifix system, size A with 3 quick-change inserts rotating center point chip guard chuck guard fixed steady rest The machine comes from the training workshop of a renowned German corporation.

Condition: used, Year of construction: 1995, Machine in parts for sale spare parts ..... CNC lathe, make GILDEMEISTER Type: CTX 600, year 1995 Forkardt chuck 315 mm, tool turret Tailstock, steady rest Headstock Guide covers and sheets Motors Machine in individual parts for sale ..... Bsdjnximuepfx Ahmswu Please ask what you need and we will send you an offer.

Condition: good (used), Year of construction: 1972, LZ Lathe Manufacturer: HEIDENREICH & HERBECK Type: 21RO Year: 1972 with Parat quick-change toolholder, 10 pieces, machine documentation, thread dial indicator, live center, 250 mm Forkardt chuck. Swing over bed: 430 mm Swing over cross slide: 255 mm Center distance: 1000 mm Turning length: 750 mm Spindle speeds: 19-2000 rpm, 5.5 kW motor Spindle bore: 56 mm Further technical data available in the data sheet Required space: Length 2900 mm, Width 1100 mm, Height 1300 mm, Weight approx. 1750 kg Machine documentation available. Bwodpfot Ipi Iex Ahmsu Coolant system installed, chip guard/rear panel. The machine is in good condition and can be demonstrated under power.

Condition: good (used), Interchangeable jaws, top jaws, three-jaw chucks, segment jaws, clamping jaws, step block jaws, step top jaws, block jaws, base jaws, interchangeable jaws, wedge bar chucks, interchangeable jaws, power chucks -Top jaws: Base jaws for key bar chucks, helical toothed -Jaw width: 22 mm -Dimensions: see photo technical drawing -Number: 4 sets of base jaws available -Price: per set -Total dimensions: 90/65/H35 mm / 90/67/H35 mm/ 90/70/H45 mm with screws Bodpfxjr U Sfgo Ahmewu -Total weight: 1.1 kg/set

Condition: excellent (used), Interchangeable jaws, top jaws, three-jaw chucks, segment jaws, clamping jaws, stepped block jaws, stepped top jaws, block jaws, base jaws, interchangeable jaws, wedge bar chucks, interchangeable jaws, power chucks -Top jaws: soft top jaws for wedge bar chucks, helical teeth -Jaw width: 45 mm -Dimensions: see photo technical drawing Bwjdoypvg Depfx Ahmsu -Overall dimensions: 180/135/H125 mm -Weight: 19.5 kg

Year of construction: 1988, condition: used, tool adaptor SK 40 Bsdjipyx Eepfx Ahmswu weight 165 kg Type Uni. 0 Universal type milling head with SK 40 spindle of a milling machine Heckert FU 315.

Condition: good (used), Interchangeable jaws, top jaws, three-jaw chucks, segment jaws, clamping jaws, stepped block jaws, stepped top jaws, block jaws, base jaws, interchangeable jaws, wedge bar chucks, interchangeable jaws, power chucks -Top jaws: soft top jaws for wedge bar chucks, helical teeth -Jaw width: 45 mm -Dimensions: see photo technical drawing Bwjdpeypvlaefx Ahmju -Overall dimensions: 162/174/H175 mm -Weight: 18.8 kg

Condition: excellent (used), KELLENBERGER PRECISION UNIVERSAL CYLINDRICAL GRINDING MACHINE TYPE: 600 U YEAR OF MANUFACTURE: 2003 PARTIAL OVERHAUL: 2026 (Technical data see attached documents) Center height: 175 mm (without height adjustment) Grinding length: 600 mm Equipment: - Standard accessories - Internal grinding device for D: 80 mm max. incl. coolant supply through the workpiece spindle - Grinding wheel equipment left for D: 400 x 50 x 127 mm (standard) - Grinding wheel equipment right for D: 300 x 40 x 127 - Grinding wheel flange for wheels D: 400 x 50 x 127 mm (left) and D: 300 x 40 x 127 (right), balancing weights outside (3 pieces left, 2 pieces right) - Variable spindle drive with Danfoss frequency converter - Balancing device for dynamic balancing, type ELASO MANOBALANCE 750/EB 2000 - RENAUD internal grinding spindle type REN 828 (grease-lubricated with compressed air lock) - Various internal grinding mandrels for REN 828 – 1235, 1645, 2060, 2575 (4 pieces) - Various chucks HJNZ 28 for HJN 828 with 2 collets D: 3 mm and D: 6 mm - Tailstock standard MK 5 with adapter flange DIN 55027 size 5” Bore D: 38.2 mm (standard) - Sine bar on the tailstock - Tailstock with manual retraction for quill travel - Micrometer adjustment on the tailstock - Pneumatic relief of the tailstock - FORKARDT planetary three-jaw chuck D: 200 mm - REISHAUER wedge-bar three-jaw chuck D: 160 mm - Permanent magnet chuck D: 200 mm - Collet chuck for Schaublin B32 - Set of 59 collets Schaublin B32, D: 1.0 – 30.0 mm, graduation 0.5 mm - Set of 8 workpiece supports incl. holder - Three-jaw steady rest, 175 mm, foldable, D: 3-120 mm - Swiveling dressing tool for dressing during external, surface or internal grinding - Side and angled dressing tool for side and angled dressing of the grinding wheels - Dial indicator stop for table swiveling with dial indicator 1/100 mm - Dial indicator stop for table longitudinal movement with dial indicator 1/100 mm - Dressing stop for internal grinding Bedpszhma Defx Ahmjwu - HEIDENHAIN Digital length measuring system for the X and Z axes - STREULI paper band filter SPB 3, 90 l/min at 0.26 bar, tank volume 240 l - WALDMANN machine lamp - Set of vibration-damping pads - Three-color paint finish (light gray RAL 7035/blue RAL 5012/dark gray RAL 7016) - New acceptance test report according to KELLENBERGER standard - CE conformity - Documentation Condition: very good, machine geometrically and mechanically overhauled (see geometry report)

Condition: ready for operation (used), functionality: fully functional, Accessories: Multifix, Forkardt chuck Condition: The machine runs well; the longitudinal guide is no longer in good condition. The machine is attractively priced and only suitable for simpler tasks. Swing diameter over bed: 430 mm Centre distance: 750 mm Spindle bore: 42 mm Bedeyw Nc Njpfx Ahmswu 24 speeds: 14 – 1400 rpm Drive power: 5.5 HP Weight approx.: 2 t

Condition: ready for operation (used), Year of construction: 1970, LZ lathe, manufacturer: KERN, type: DS 20 AL, year of manufacture: approx. 1970 with 3-jaw chuck, Forkardt 250mm, tool quick-change holder Multifix size C with holders, coolant system. Turning diameter over cross slide: 500mm Turning diameter over carriage: 250mm Distance between centers: 1000mm Spindle speeds: 12 - 1200 rpm Machine can be demonstrated in working condition. Good condition of guides. Bedpfxjgqxcij Ahmowu

Condition: good (used), Year of construction: 1993, CNC cycle-controlled lathe, manufactured by VDF BOEHRINGER, type: DUC 560, year of manufacture: 1993, with SIEMENS SINUMERIK 805T control. Turning length: 1000 mm Turning diameter over cross slide: 365 mm Turning diameter over bed: 570 mm Spindle speeds: 3-2500 rpm, spindle motor: 19 kW Spindle bore: 62 mm Chuck diameter: 315 mm, Forkardt Bwedpfx Ahjd Ewaaomeu Turret with 8 positions, VDI 30 Includes accessories and machine documentation.

Condition: used, Year of construction: 1957, turning diameter over bed 800 mm turning diameter over slide rest 540 mm turning length 4000 mm centre height 400 mm centre distance 4000 mm spindle turning speed range 9 - 1140 U/min spindle passage 96 mm weight of the machine ca. 8,5 t dimensions of machine L x W x H 7,0 x 1,70 x 1,70 m - with gap with insert - Accessories: 3-jaw chuck FORKARDT 400 mmø, 4-jaw chuck 500 mmø, faceplate 800 mmø, DRO on X-and Z-axis ACU-RITE, Bodsxwp Ehspfx Ahmowu MULTIFIX-head with various inserts, 2 solid steadies, 1 running steady, running center, coolant

Condition: used, Year of construction: 1988, Manufacturer: Haacke type: UW II A-CNC year of construction: 1988

 Bedpjg Tvmbsfx Ahmewu only for step drills up to max. Ø 30mm cross adjustment: 250mm height adjustment: 250mm grinding length: 400mm weight: 1,4t footprint: 2,5 x 1,2 x 1,9mm Application: for grinding steps on step drills Accessories:

 Paper belt filter make LKK Foreground flap collet chuck Forkardt Overz /BR 50/ LH-Z 24394

Condition: used, Year of construction: 1993, Control Sinumerik 805 turning speeds 45 - 6000 U/min Solid drill diameter / 0 weight of the machine ca. 20 t Type of machine: deep hole drilling machine Model / Type: TB 2 15 30001KT Year of construction: 1993 Manufacturer: hole Machine number: 221-3000-2093 Machine weight: approx. 20,000 kg Machine footprint: Width = approx. 3800mm Length = approx. 13500mm Height = approx. 3100mm Drilling length: approx. 3500mm Drilling capacity: drill 45mm / drill out 80mm Spindle speed range: 45 - 6000 rpm Control: Siemens Sinumerik 805 Hamül – coordinate table Type: KT 8.5 – 10.10 Clamping surface: approx. 1100 mm x 980 mm Travel: Y - axis: approx. 800mm Traverse path X - axis: approx. 500mm 7 pieces clamping - T - grooves: 18 mm Special equipment: 1 piece Fibroplan NC - rotary indexing table Type: NC 1.05 Permissible transport load in horizontal use 2500 kg With manual chuck Forkardt F 630 The NC rotary indexing table can be adjusted manually in the longitudinal and transverse directions relative to the clamping table and is clamped hydraulically. 1 piece chips - centrifuge Type: VZ5A from CEPA Drum capacity: 80 liters Loading weight max. 100 kg Drum - Ø: 600 mm Bwedpfx Ahjvvx Hiomsu Speed: 1000 rpm 1 additional pump for large drill Ø 1 piece Bosch radial piston pump no.: Suitable for lip drills (internal cooling, chips run outwards) Suitable for BTA drills with screw-on heads (internal cooling, chips run inwards)
