Used Höfler Gear Grinding Machine for sale (70,588)

Condition: good (used), Year of construction: 2001, Equipped with: Power Stock Fanuc 5-Axis CNC Control 160M 400mm Honing Wheel X Axis Pulse Generator Coolant System w/Twin Filters Magnetic Chip Separator Honing Tool Set up for Last Job is Still in Machine Internal Diameter of Honing Tool on Machine is 14" Work Light Power Door Auto Dress 5-Part Program Instruction Book for 16M Control Instruction Book for Set-Up and Operation Specifications: Maximum Outer Diameter: 250 (350) Minimum Outer Diameter: 30 Maximum Overall Length: 400mm Maximum Tooth Width: 45mm Module: 1.0-3.0 Cross Feed Device(Z Axis): 430mm Max. Travel Honing Wheel Cutting Feed Device(X Axis): 370 Max. Travel Honing Wheel Swing Device(C Axis): Swing Angle: +30 Degress Honing Wheel Rotation Drive Device(A Axis): Honing Wheel Spindle Speed R/Min: 500 Honing Wheel Outer Dia.: 300 (400) Maximum Honing Wheel Width: 50mm Crowning Device (Y Axis): Maximum Rocking Angle: 1.6 Degrees Motor Types: Z-Axis Drive Motor: 1.8Kw X-Axis Drive Motor: 1.8Kw Y-Axis Drive Motor: 0.7Kw C-Axis Drive Motor: 1.8Kw A-Axis Drive Motor: 2.2/3.7Kw Maximum Distance Between Centers: 600mm Dedjrualpspfx Ab Djck Center Height: 1,100mm Floor Space: 2,170W X 2,800D X 2,100H Mass Of Machine: 4,500Kg

Condition: good (used), workpiece diameter between centers: 2,286 mm, The No. 61 Angular Hypoid Tester is designed to test large bevel and hypoid gears up to 90" diameter and with shaft angles from 0 - 135 degrees. Spur, helical and internal gears can also be accommodated. The drive or pinion spindle can be rotated in either direction at a recommended spindle speed of 600 RPM. It is mounted in a head which is vertically adjustable on a column, so that the spindle can be offset either above or below the center line of the gear spindle for testing hypoid gears. The pinion head column is adjustable angularly in a horizontal plane to permit testing of gears of any shaft angle from 0 - 135 degrees. Specifications: Centerline of Drive Spindle to Nose of Brake Spindle (90 degrees shaft angle and without face plate): 38-1/2" Max. / 7-5/8" Min. Centerline of Brake Spindle to Nose of Drive Spindle (90 degrees shaft angle and without face plate): 60" Max. / 10" Min. Centerline of Brake Spindle to Nose of Drive Spindle (90 degrees shaft angle and with 54" face plate): 60" Max. / 28" Min. Centerline of Brake Spindle to Centerline of Drive Spindle (For Spur Gears): 56" Max. / 6" Min. Distance Between Nose of Brake Spindle and Nose of Drive Spindle (for spur gears): 36-1/2" Max. / 0" Min. Offset of Drive Spindle Either Above or Below Centerline of Brake Spindle: 10" Range of Shaft Angles: 0 - 360 Degrees Maximum Diameter of Gear: 90" Diameter of Face Plate: 54" Outboard Bearing: 3" Diameter Hole Dcsdpfx Abertrzdj Dok Spindles: RPM of Drive Spindle Pulley Set No. 1: 100 - 400 RPM of Drive Spindle Pulley Set No. 2: 250 - 600 Diameter of Taper Hole (large end): 6" Taper Per Foot: 3/4" Depth of Taper: 8" Hole Through Spindle: 5-1/2" Net Weight of Machine: 20,000# Net Weight of Machine W/Outboard Support and Bed Plate: 24,000#

Condition: like new (used), Year of construction: 2017, max. wheel diameter 100 mm gear width 26 mm max. module 31 min. module 0,1 Control Siemens 840 D SL Number of working hours 9598 h total power requirement 45 kW weight of the machine ca. 7,8 t dimensions of the machine ca. 4,40x3,95x3,01 m Dcodpfov Ehbbox Ab Dok Gleason 100S gear shaping machine for the production of internally and externally toothed cylindrical gears and other cylindrical workpiece circumference regularly occurring profiles and moulds as well as for the production of profiles using the single part process. Technical data: Nominal workpiece diameter 100 mm Largest circumferential diameter 150 mm Machine nominal module approx. 3 mm (Guide value depending on the respective machining task.) Shaping spindle stroke speed range 0 - 3,000 1/min Stroke position adjustment range (manual) 20 mm Largest toothing width 26 mm Smallest pitch height of the hydrostatic inclined guide 400 mm Smallest/largest distance between tool axis - 20/+ 180 mm and workpiece axis Stand inclination range (manual) - 1/+ 11° Tool holder (manual clamping) HSK-D63 (hollow shank taper according to DIN 69063) Weight of the machine approx. 7,000 kg with robot cell

Condition: good (used), Year of construction: 2007, max. wheel diameter 500 mm gear width 200-400 mm module 12 turning speeds 0-3250 U/min bracke pressure bis max. 95 Nm inner taper Konus #39 Control Fanuc 16 Dcjdpfx Abovr Hf Es Djk total power requirement 15 kW weight of the machine ca. 6 t dimensions of the machine ca. 2.350 x 2.240 x 2.500 mm HIGHLY FLEXIBLE TESTING OF HARD, FINISHED AND GREEN SPIRAL BEVEL AND HYPOID GEAR SETS The T 60 bevel gear testing machine is a CNC testing machine with three linear axes for the fully automatic hard and soft testing of spiral bevel and hypoid gear sets with a 90° axis angle. It offers versatile objective and subjective testing options with speeds up to 3,250 min and braking torques up to max. 95 Nm.

Condition: used, Year of construction: 2012, Control Siemens 840 D weight of the machine ca. 13,5 t dimensions of the machine ca. 7m x 4m x 2,75m m Accessories: Coolant tank Grinding wheels Various spare parts Operating and maintenance instructions CE conformity Dimensions: 7x4x2.75 m ( LxWxH) TECHNICAL DATA: Workpiece data: Dcsdpjxh Rqtjfx Ab Dek max. outer diameter: 250 mm with max. grinding wheels Ø 450 mm max. diameter to be machined over table: 375 mm Profile depth for dressable grinding wheels: 40 mm max. workpiece length: 3,600 mm max. distance between centers (1): 2,800 mm max. bevel angle: +/- 90° Number of teeth of the workpiece: 1 - 999 max. weight of the workpiece: 250 kg Working area: Center distance between workpiece and tool spindle: 355-170 mm Radial travel: 185 mm Axial travel: 3,000 mm Swivel angle: +/- 90°

Condition: good (used), Year of construction: 2002, Clampable cutter head type (max.) 460 mm Cutter head weight (max.) 150 kg Mounting disc diameter for cutter heads (Ø) 360 mm Mounting cone for cutter heads Nominal diameter Ø 58,227 mm travel -z axis 200 mm diagram-drawing enlargement ±10 - ± 500 µm weight of the machine ca. 2,3 t dimensions of the machine ca. 2 x 1,5 x 2,03 m In the manufacturing process for spiral-toothed bevel gears, the quality of the Dcsdpjw N S E Ajfx Ab Djk gear cutting gear cutting tools used plays a decisive role. Particularly in high gear cutting quality and a long service life can only be achieved with precisely can only be achieved with precisely adjusted cutterheads. The Oerlikon cutterhead setting and testing device CS 200 enables quick and easy setting of the individual knives and simple adjustment of the individual knives, it checks the position and documents the measurement results. The measuring sequence on the CNC-controlled testing device is partially automated: The individual actions for carrying out the actions for carrying out the sequence are displayed on the screen via the operator guidance. The positioning of the individual knives in the cutter head and the height of the knife tips is largely automatic thanks to a special sequence and is simultaneously documented by means of a run-out diagram. A subsequent measuring sequence checks the radial position of the inner and outer cutting edges of all knives in the cutterhead. If individual test parameters on the knives do not correspond to the the tolerance specifications, this can be individually repositioned. The combination of semi-automated setting sequence, operator-guided set-up actions and automatic operator-guided set-up actions and automatic measuring sequence, cutterheads can be can be set conveniently, quickly and with high precision. Operator-guided setting and test sequence - Graphic display of the cutter head design and the measurement results with tolerance check - Instructions for the operator in plain text Instructions for the operator in plain text (without coded information) - Simple assignment of the measurement results to the knives - Documentation of the setting and measurement results via printer- Setting and test sequence suitable for ARCON®, RSR, Spirapid, SPIRON®, TRI-AC® types - Interface for neutral data

Condition: excellent (used), Year of construction: 2015, functionality: fully functional, machine/vehicle number: FPS-20-RS, Schiatti Angelo FPS 20 RS 2015 Excellent condition 10 spindle glass edging machine including cerium wheel Dedpozrx Injfx Ab Dock Can dismantle and load for buyer

Condition: used, Tschudin HTG310 Universal Cylindrical Grinder Centre height: 100mm Distance between centres: 340mm (13.4") Maximum grinding diameter: 200mm Maximum grinding length: 340mm Hydraulic table traverse Table swivel: ±11° Wheelhead swivel: ±5° Workhead swivel: 360° Infinitely variable workhead spindle speed: 50–500 RPM Dcedpfx Abszrt Ips Dsk Automatic plunge and traverse grinding cycles Automatic infeed with adjustable spark-out timer Rapid wheelhead advance and retract Hydrodynamic wheelhead bearings for exceptional accuracy Grinding wheel size: 350 x 50 x 127mm (14" x 2" x 5") Fitted With Hydraulic table drive Universal workhead Tailstock Coolant system Wheel guard Machine lighting

Condition: good (used), Year of construction: 1999, functionality: fully functional, 11 cup wheels vertical glass edging machine min. glass height : 50 mm glass thikness : 3 - 30 mm machine dimensions : L x W x H : 8,1 x 1,2 x 2,3 m Dodpfoztatuex Ab Djck power : 23,8 Kw weight : 4150 kg reconditioned machine from year 2018 We look for export outside the EU . low price .

Condition: used, Year of construction: 1990, grinding diameter max. 1-150 mm regulating wheel width 100-200 mm weight 5 t Dcodpfx Aoztfz Deb Dek

Condition: used, Year of construction: 1980, drill diameter 2,4-13 mm drilling length ca 165 mm lip angle 90-140 ° Dcodpfx Aoztfzweb Djk

Condition: used, Year of construction: 2005, grinding diameter max. 500-600 mm regulating wheel width 100-200 mm weight 5 t grinding diameter 1-150 mm Dcjdpfxjztfzqe Ab Dek grinding wheel width 150–250 mm mm with water treatment

Condition: used, Year of construction: 1980, centre distance 900 mm 440 Dsdpjztfzkefx Ab Djck weight of the machine ca. 3 t

Condition: ready for operation (used), Year of construction: 2011, functionality: fully functional, CNC Spiral Bevel Gear Cutting Machine Gleason No 631 Year of manufacture: 2011 Control: SIEMENS 840d Retrofitted in 2011/2012 with new control, drives, etc. Dcodsw Tfb Sopfx Ab Dok The machine was fully overhauled in 2011. A new control system and drives were installed.

Condition: ready for operation (used), Year of construction: 2014, functionality: fully functional, Used surface grinding machine Rheinberg 2012-2014 retrofit with €80,000: new Wagner magnetic table New Siemens PLC Dsdpfx Absycgnrj Djck New filters

Condition: ready for operation (used), Used bevel gear lapping machine Manufacturer: Oerlikon Model: SL 2 The machine is available for immediate collection. Dodpfx Ajycc Rieb Djck

Condition: ready for operation (used), functionality: fully functional, The Studer S30-12 CNC is a precision cylindrical external grinding machine from Fritz Studer AG. Brand: Studer Type: S30-12CNC Serial number: 1248.74 Djdozn Nqrspfx Ab Dock Dimensions: L3250mm Dimensions: W2000mm Dimensions: H1950mm Wheel speed: 30 m/s

Condition: ready for operation (used), thread length: 3,000 mm, Maximum spindle bore is Ø 80 mm. The possible diameter from the traverse path is max. Ø 250 mm and min. Ø 20 mm. Machining length: 3000 mm. Comes with accessories: change gears, steady rest. For further technical data, please refer to the PDF file. Dcodpfx Abjv Huiho Dok

Condition: used, Year of construction: 1989, band width 150 mm band length 3500 mm band speed 30 m/sec Scheiben-Ø 400 mm grinding feed 0 - 5 m/min work piece revolutions 0 - 140 U/min power capacity - workpiece power 2,2 kW grinding diameter 100 - 600 mm clamping length 6000 mm bed length ca. 8000 mm voltage 380 V / 50 Hz Dcodpfxjyw Tkkj Ab Djk motor speeds: 1450 U/min power capacity 15 kW weight of the machine ca. 9,5 t dimensions of the machine ca. 8,6 x 2,6 x 2,5 m

Condition: used, Used Matra valve grinding machine with double-cone collets as shown, 380 Volt electric motor fully functional. Please do not send email enquiries! If you have any questions, we are happy to assist you by phone. Viewing and collection only possible by prior telephone appointment! Dodpjzti Uzofx Ab Dsck Subject to alterations, prior sale, and errors.

Condition: refurbished (used), Year of construction: 2004, functionality: fully functional, Fully reconditioned milling head from a Gleason Pfauter P210L – manufactured in 2004. Dedpfx Abjzr Hd Re Dsck

Condition: excellent (used), Year of construction: 1999, functionality: fully functional, Turning diameter: 3,000 mm Turning height: 500 mm Z-axis travel, left support: 551 mm Z-axis travel, right support: 350 mm X-axis travel: 1,100 mm Spindle speed, left/right: 2,000 rpm Dcjdpfx Abjztc Uhj Djk Max. table load: 6,000 kg 2x grinding supports – swiveling 2x diamond dressing tools Magnetic clamping plate by SAV Control system updated in 2004 Control system: R&D

Condition: refurbished (used), Year of construction: 2001, functionality: fully functional, Working diameter: 4,000 mm Working height: 730 mm X-axis: 1,110 mm Dcsdpoztc T Dofx Ab Djk Control system: SIMATIC S7-300 Tool holder: Grinding segments Integrated dressing unit on the grinding head In 2010, the machine underwent a comprehensive mechanical and electrical overhaul. As part of this modernization, the entire automation and drive technology was converted to Siemens technology. The machine is equipped with a MARPOSS P7 in-process measuring system. The measuring system is fully integrated into the Siemens SIMATIC S7-300 PLC control system via PROFIBUS.

Year of construction: 1976, condition: ready for operation (used), functionality: fully functional, center height: 125 mm, center width: 600 mm, year of last overhaul: 2026, The machine underwent a comprehensive retrofit in 2026! New centering point with carbide insert on the workpiece spindle stock Tailstock with MK-3 mount and air lift Adjuster on the tailstock New centering point with carbide insert on the tailstock 2 grinding wheel flanges 1 new grinding wheel 1 internal grinding spindle Completely renewed paper band filter with new filter fleece and circuit Dodezr Ep Eopfx Ab Dock Completely overhauled, steplessly adjustable grinding spindle motor Automatic grinding cycle with dwell time and shut-off Machine geometrically completely overhauled Guides ground and scraped Hydraulic cylinder overhauled New piston rod and seals Machine body and assemblies blasted, primed and completely painted TECHNICAL DETAILS Center height: 125 mm Center distance: 600 mm Grinding wheel flange dimensions: 400 × 50 × 127 mm Speed of internal grinding spindle: 14,000 rpm EQUIPMENT Workpiece spindle stock standard with MK-5 mount, swiveling Stepless speed control via potentiometer

Condition: excellent (used), functionality: fully functional, Working diameter: 2–40 mm. Minimum and maximum point angles: 40–180°. For right- and left-side cutting tools, 1–12 cutting edges. For sharpening twist drills, step drills and tap drills. Djdpfszr N Raox Ab Dock A wide range of accessories and a user manual for the machine are included. Clean and good condition
