Used Moving Center Point for sale (21,550)

Condition: ready for operation (used), Year of construction: 2014, travel distance X-axis: 1,626 mm, travel distance Y-axis: 1,270 mm, travel distance Z-axis: 813 mm, table width: 1,270 mm, table length: 1,400 mm, table load: 4,535 kg, overall weight: 20,800 kg, spindle speed (max.): 7,500 rpm, CNC Haas with 15-inch LCD screen Table size: 1400x1270 mm Maximum table load: 4,535 kg Spindle ISO 50, power 22.4 kW Maximum spindle speed: 7,500 rpm Itsdpsypv T Rsfx Ag Aon Travels: 1626x1270x813 mm 50-position tool changer Chip conveyor Weight: 20,800 kg

Condition: excellent (used), Year of construction: 2008, Machine Overview Makino V22, manufactured in 2008, with a 40,000 rpm spindle, HSK-E32, and 60 tool positions. This compact 3-axis machining center offers travels of 320 × 280 × 300 mm and a Makino Pro-5 control system based on Fanuc. Technical Data Manufacturer / Model: Makino V22 Year of Manufacture: 2008 Axes: 3 Travel (X / Y / Z): 320 / 280 / 300 mm Control System: Makino Pro 5 (Fanuc System) Spindle Speed: 40,000 rpm Tool Interface: HSK-E32 Cooling: External air and external cooling Table: Makino T-slot table Maximum Table Load: 100 kg Rapid Traverse: 20 m/min Tool Magazine: 60 positions Operating Hours: 20,712 hours Spindle Counter: 2,266 hours Fuse Rating: 63 A Footprint (L × W × H): 1,500 × 2,000 × 2,250 mm Connection, Weight, and Dimensions Electrical Connection: 400 V / 50 Hz Machine Weight: 4,200 kg Equipment and Scope of Delivery Length measuring device (hybrid) Measuring probe: Marposs and handwheel Ijdpfx Ajz Tc Srsg Ajtn REVEN X-CYCLONE CE17-3 Kraft-& Bauer CO₂ fire extinguishing system Hot-shot shrinking device Tool holders and other related photo accessories All accessories belonging to the machine, as shown in the offer photos, are included. Technical data subject to change without notice. Errors and prior sale are reserved. The characteristics and scope of delivery agreed upon in the purchase contract shall be binding.

Condition: like new (used), Year of construction: 2015, operating hours: 1,000 h, functionality: fully functional, Equipment: documentation/manual, DMG MORI / SAUER GmbH ULTRASONIC 20 Machine Data Control system Heidenhain Axes 5 (X / Y / Z / A / C) Travel ranges X / Y / Z 200 / 200 / 280 mm Spindle speed max. 42,000 rpm Tool holder HSK-E32 Tool magazine 24 Rotary table Ø 190 mm Table load capacity, center 10 kg A-axis -5° / +130° C-axis 360° Rapid traverse 40 m/min Footprint L × W × H 2,020 × 2,196 × 2,385 mm Fuse rating 63 A Feed drive X / Y / Z Synchronous linear motors Feed rate max. 40,000 mm/min Input resolution 0.001 mm C-axis speed max. 150 rpm Table clamping Pneumatic / mechanical Tool length max., from spindle nose 200 mm Tool diameter max., automatic tool changer 40 mm Compressed air supply 6–10 bar Air consumption without tool blowing 12 m³/h Additional consumption with continuous tool blowing 25 m³/h Connection, weight, and dimensions Electrical connection 400 V / 50–60 Hz Machine weight 3,900 kg Tool weight max., automatic tool changer 1 kg Itodpfsz Tc Tvjx Ag Aon Total weight of magazine tools max. 24 kg Compressed air connection min. Ø 12 mm Equipment and scope of supply 15 tool holders and other related accessories as shown in the offer photos are included. Technical data is subject to change without notice. Errors and prior sale are reserved. The specifications and scope of supply agreed upon in the purchase contract shall be the basis.

Condition: good (used), Year of construction: 2011, operating hours: 18,000 h, functionality: fully functional, turning length: 740 mm, turning diameter: 430 mm, spindle bore: 65 mm, travel distance X-axis: 280 mm, travel distance Y-axis: 100 mm, travel distance Z-axis: 750 mm, rotational speed (max.): 5,000 rpm, rotational speed (min.): 10 rpm, bar passage: 65 mm, overall weight: 8,000 kg, Equipment: documentation/manual, rotational speed infinitely variable, Turn-milling center EMCO HYPERTURN 665 MC Plus Year of manufacture: 2011 Control system: Sinumerik 840D Operating hours: 18,300h (according to hour meter) Technical data: Main spindle speed: 0 - 5,000 rpm Drive power: 21/29 kW (100/40%) Torque: 250 Nm Spindle mounting: KK6 Bar diameter: 65 mm Counter spindle speed: 0 - 7,000 rpm Drive power: 17/21 kW (40/100%) Torque: 130 Nm Spindle mounting: KK6 Milling spindle speed: Mounting: Capto C4 Number of magazine positions: 23 Travel ranges: X1/Z1: 280/750 mm X”/Z2: 205/750 mm Y-axis: +/- 50 mm Lower turret: Mounting: VDI 30 Number of positions: 12 Itsdpfx Agsz Tc Umo Aon Number of powered tools: 12 Accessories: - Emco short magazine LM 1200 - Chip conveyor - High-pressure coolant system - Parts catcher - Extensive equipment with tool holders

Condition: good (used), Year of construction: 1998, functionality: fully functional, CNC turning machine EMCOTURN 365 MC with counter spindle Year of manufacture: 1998 Control system: Sinumerik 840D Accessories: - Parts collector - Chip conveyor Further details to follow Includes a wide range of accessories. Ijdpfsz Tc Utsx Ag Astn

Condition: as good as new (ex-display), Year of construction: 2024, functionality: fully functional, travel distance X-axis: 620 mm, travel distance Y-axis: 520 mm, travel distance Z-axis: 460 mm, feed rate X-axis: 36 m/min, feed rate Y-axis: 36 m/min, feed rate Z-axis: 36 m/min, torque: 180 Nm, controller manufacturer: Siemens, controller model: One, table load: 300 kg, rotary table diameter: 600 mm, spindle speed (max.): 15,000 rpm, General Control: Siemens Model: One Spindle: Direct drive Speed: 15,000 rpm Power: 34 kW Torque: 180 Nm Tool holder: SK 40 Tool changer: 60 stations Working area Travel X: 620 mm Travel Y: 520 mm Travel Z: 460 mm Rotary/swivel table: D = 600 mm Table load: 300 kg Itsdsyg Eyhepfx Ag Aen C-axis: Resolution 0.001 degrees Other Rapid traverse X/Y/Z: 36 m/min Maximum speed B-axis: 25 rpm Maximum speed C-axis: 25 rpm Equipment Chip management: Chip conveyor Workpiece measurement: Renishaw OMP 40 Automation: Prepared

Condition: excellent (used), Year of construction: 2006, functionality: fully functional, table length: 1,120 mm, table width: 600 mm, Cincinnati Arrow 2-1000 machining center, with Siemens Acramatic 2100 CNC, automatic tool changer, 1120mm x 600mm table, maximum table load of 1000kg, travels X 1016mm, Y 510mm, Z 560mm, with electronic handwheel, BT40 taper, 11/15 hp, maximum spindle speed of 12500 rpm, oil-lubricated spindle, Heidenhain measuring scales on all three axes, automatic tool changer with 21 positions, year 2006, serial number 7049-AQA-KE1134, part number 91204519A, machine in very good condition, machine has never been used for metalworking. Iodpfx Agoz Tc Igj Ajtn

Condition: used, first registration: 10/2011, REISCH 82 m³ Walking Floor Sliding Floor Semi-Trailer with Grain Hopper FLOOR: VERY GOOD CONDITION! ● Body: Full aluminum ● Frame: Steel ● 82 m³ volume ● 3 x BPW-ECO Plus axles ● Air suspension ● Lift axle ● Lifting/lowering system ● Disc brakes ● Platform ● Grain hopper and slide gate at the rear ● Roller shutter ● Aluminum sliding wall ● Hydraulic locking ● WABCO - Smartboard ● ABS ● ALCOA - Rims ● Tires: 385/65 R 22.5 ● GVWR: 35,000 kg ● Tare weight: 7,700 kg! Itedpfxsyutyre Ag Aen ● Overall length: 14,050 mm ● Internal dimensions (including grain hopper): 12,600 x 2,470 x 2,510 mm - German semi-trailer! - 1st hand! - TÜV/MOT: new! Errors and prior sale excepted! = Further information = Year of construction: 2011 Payload: 1 kg Please contact Joannis Arpantzanis or Kai Bühler for more information.

Condition: used, fuel type: electric, Year of manufacture: 2017 Lifting capacity: 150 kg Ijdezfkgpspfx Ag Astn Please contact Gebrauchtgeräte Center for more information

Condition: used, Year of manufacture: 2014 Please contact Gebrauchtgeräte Center for more information Iedozfldpjpfx Ag Astn

Condition: used, Year of construction: 2010, x-travel 1.100 mm y-travel 900 mm z-travel 1.250 mm control SIN 840 D spindle turning speed - gearbox stage 1 20 - 1.333 1/min. spindle turning speed - gearbox stage 2 1.333 - 8.000 1/min. power capacity at 60% / 100 % load 50 / 37 KW tool taper SK50 B - axis 360 x 0,001 ° rotary table speeds infinitely variable 1 - 500 U/min feed X/Y/Z/-axis 1 - 60.000 mm/min rapid traverse 60 m/min feed capacity X/Y/Z 17 kN numbers of pallets 2 pallet size 800 x 800 mm Isdpfjymfzrex Ag Astn table load 1,50 t tool magacine with 120 Plätzen tool length - max. 600 mm tool diameter 135 mm wotkpiece diameter with 2 vacant positions 350 mm weight of tools max. 60 kg total power requirement 150,00 kW weight of the machine ca. 35,00 t dimensions of the machine ca. 11,50 x 7,40 x H4,25 m Machining center with control SIEMENS SIN840D, H/V-head and turning-operation; Pallett-changer with 2 palletts and hydr. chuck Forkardt 3KS1000, Coolant unit KNOLL; Coolant through spindle (30 l/min 50bar);

Condition: used, Year of construction: 2014, x-travel 1.100 mm y-travel 610 mm z-travel 610 mm Itjdpfxjy N D E No Ag Aen B - axis -30 / +120 ° C-axis 360 x 0,001 ° distance spindle /table 105-715 mm table dimensions 1100 x 610 mm tool taper SK40 spindle turning speed - stepless 14.000 U/min workpiece weight 500 kg control iTNC530 weight of the machine ca. 9 t

Condition: used, Year of construction: 2007, Milling machine Röders RXP 800 DS, year of manufacture 2007 Milling machine Röders RFM 600, year of manufacture 2000 Itodeyiln Ujpfx Ag Aon

Condition: used, Year of construction: 1993, CNC Lathe Monforts RNC 4 with KNCS 260 chuck Collet up to Ø 60 mm Bar feeder up to Ø 65 mm Year of manufacture: 1988 Lots of accessories Itedpfx Aoyq R T Ijg Aen CNC Lathe Monforts RNC 4 with 15-series control and C-axis, KNCS 260 chuck, year 1995, lots of accessories RNC 5 Chucking-only lathe Year of manufacture: 1992 Includes many jaws Monforts RNC 7 with automatic tailstock, 1500 mm Z-axis travel Driven tools with spindle indexing every 2.5° Chuck 500 mm, many tools and jaws included Year of manufacture: 1993 Very good condition The last CNC lathe, an RNC 7-1000 with automatic tailstock, steady rest, C-axis Lots of tools and jaws Ideally, everything would be sold as a package — 5 Monforts lathes with a very large amount of accessories.

Condition: used, Year of construction: 2009, CNC Machining Center Wagner-Eumach, Model EBM 3200, year of manufacture 2009 for sale. Condition: Fully operational Travel X-axis: 3,200 mm Travel Y-axis: 1,100 mm Travel Z-axis: 900 mm CNC control manufacturer: Sinumerik CNC control model: Sinumerik 810D Shopmill Total weight: 25,000 kg Overall length: 7,800 mm Overall width: 4,700 mm Maximum workpiece weight: 5,000 kg Feed travel X-axis: 3,200 mm Feed travel Y-axis: 1,100 mm Feed travel Z-axis: 900 mm Spindle motor power: 45,000 W Rated apparent power: 45 kVA Max. spindle speed: 6,000 rpm Min. spindle speed: 6,000 rpm Table length: 3,250 mm Itodpfxew D Slts Ag Aen Table height: 1,030 mm Table load: 5,000 kg Table width: 1,220 mm Maximum tool diameter: 125 mm Maximum tool length: 300 mm Maximum tool weight: 15,000 g Spindle operating hours: 18,000 h Equipment: Chip conveyor, NC rotary table (table size 800 x 800 mm), tool holder SK 50, through-spindle coolant (IKZ) Inspection possible by appointment.

Condition: good (used), Year of construction: 2010, Machining Centre Sugino Xion-II-5AX-CE Manufacturer: Sugino Machine Limited Japan Model: Xion II 5AX CE Year of manufacture: 2010 Number of axes: 5 Travel distance X axis: 300 mm Travel distance Y axis: 300 mm Ijdpfxox Hqwge Ag Aotn Travel distance Z axis: 200 mm A axis swiveling range: -90° to +90° C axis rotation: 360° Maximum tool diameter: 40 mm Maximum tool weight: 15 kg Spindle speed: 40,000 rpm Tool holder: HSK-E32 Positioning accuracy X, Y, and Z axes: 0.002 mm Repeatability X, Y, and Z axes: ±0.001 mm Machine weight: 2,800 kg No guarantee is given for the correctness, completeness, or currentness of the information provided.

Condition: excellent (used), Year of construction: 2008, Nakamura Super Mill WY-250 CNC Lathe Capacity: Max. turning diameter: 215 mm Standard turning diameter: 150 mm Distance between centers: max. 870 mm / min. 250 mm Ijdpey Ipp Rsfx Ag Ajtn Max. turning length: 580 mm Bar capacity left/right: L: 65 mm R: 51 mm Chuck size: left: 210 mm (8″) right: 165 mm (6″) Axis travel: Slide travel (X1 / X2): 160.5 mm / 160 mm Slide travel (Z1 / Z2): 580 / 580 mm Slide travel (Y1 / Y2): ±50 mm / -50 mm, +20 mm Slide travel (B2 axis): 620 mm Rapid traverse X1 / X2: 18 m/min Rapid traverse Z1 / Z2: 36 m/min Rapid traverse B2 axis: 36 m/min Rapid traverse Y1 / Y2: 10 m/min Main and sub spindle: Spindle speed: 4500 rpm / 5000 rpm Speed range: stepless / stepless Spindle nose: A2-6 / A2-5 Spindle bore: 80 mm / 63 mm Front bearing inner diameter: 110 mm / 90 mm Drawtube diameter: 66 mm / 52 mm C-axes: Minimum input unit: 0.001° Minimum command increment: 0.001° Max. indexing speed: 600 rpm Feed speed: 1–4800 mm/min C-axis lock: disc brake C-axis positioning time: 1.5 s Upper/lower turret: Turret type: 12-position drum turret Number of tool stations: 48 (2 x 24) Square tool size: 25 mm Round shank tool size: 32 mm Driven tools: Drive system: single drive Spindle speed: 6000 rpm / 3600 rpm Speed range: stepless Number of driven tool stations: 12 × 2 Collet size: ER32 Straight toolholder size: 2 mm – 20 mm Cross toolholder size: 2 mm – 20 mm Drive power and torque: Left spindle: 18.5 / 11 kW 225 / 185 Nm Right spindle: 15 / 11 kW 120 / 120 Nm Tool spindles: 7.5 / 3.7 kW 40 / 16 Nm General: Machine height: 2395 mm (without extraction) Footprint: 4436 mm × 2674 mm / 4905 mm × 3331 mm Machine weight: 14,000 kg Scope of supply as shown in photo gallery includes, among others: Nakamura lathe, toolholders (driven and non-driven), collets, complete operating documentation, portal loader and loading robot, Iemca Master 880 Verso bar feeder, peripheral devices (chip conveyor, transformer, oil mist separator, etc.) No guarantee is given for the correctness, completeness or currentness of the information provided.

Condition: good (used), Year of construction: 2013, Machining Center Fanuc Robodrill α-D21SiA5 TECHNICAL DATA Manufacturer: Fanuc Model: Robodrill α-D21SiA5 Serial Number: A04B-0102-B114#BDH Year of Manufacture: 2013 CNC Control: Fanuc Series 31i-MODEL B5 Spindle Speed: up to 24,000 rpm Travel X-Axis: 300 mm Travel Y-Axis: 300 + 100 mm Travel Z-Axis: 330 mm Rapid Traverse Rate: 54 m/min Tool Magazine: 21 positions Max. Tool Weight: 2 kg Total Tool Weight: 23 kg Max. Tool Diameter at 150–12,000 rpm: 80 mm Max. Tool Diameter at 12,000–15,000 rpm: 60 mm Max. Tool Diameter at 15,000–20,000 rpm: 45 mm Max. Tool Diameter at 20,000–24,000 rpm: 40 mm Permissible Table Load: 200 kg Machine Weight: 2,050 kg Power Supply: 200/220 V Itedpfxsxflq As Ag Ajn SCOPE OF DELIVERY Includes (list not exhaustive): • Fanuc Robodrill α-D21SiA5 Machining Center • 4th Axis Rotary Table • Coolant Pump and Chip Tray • Exact scope as per photo series No guarantee is given for the correctness, completeness, or up-to-dateness of the information provided.

Year of construction: 2005, condition: excellent (used), MIKRON HSM 400 U High-Speed Machining Center The exact scope of the offer can be found in the photo series. It includes, among other things: measuring probe, oil mist separator, fire extinguishing system, chip conveyor, handling device, oil cooler, band filter system, approx. 50 HSK tool holders, etc. Iedpfxjigrf Io Ag Ajtn 1. TECHNICAL DATA Working area X-axis: 400 mm Y-axis: 450 mm Z-axis: 350 mm B-axis: +-110° C-axis: 360° Spindle Speed range: 100 – 42,000 RPM Tool interface: HSK E 40 Spindle power at 40% duty cycle: 13 Spindle power at 100% duty cycle: 10 Torque at 60% duty cycle: 4.25 Torque at 100% duty cycle: 3.2 Lubrication: Oil/air Feed rate Rapid traverse speed: Max. 40 m/min B-axis: 150 RPM C-axis: 250 RPM Axis acceleration, XYZ: Max. 1g (10 m/s2) B-axis: 100 rad/s2 C-axis: 300 rad/s2 Tool changer: 68 positions Chip-to-chip time: 12.5 s Tool change time: 10.0 s Work table: 120 mm Max. workpiece diameter that can still be rotated 360°: 230 mm Max. workpiece height: 350 mm Max. workpiece weight: 25 kg Control system: Heidenhain iTNC 530 Weight: 5500 kg We do not guarantee the accuracy, completeness and up-to-dateness of the information.

Condition: excellent (used), Year of construction: 2006, FAMUP MCP 45 CNC machining center TECHNICAL DATA axes Number of axes: 3 X-axis: 450 mm Y-axis: 300 mm Z-axis: 400 mm Feed rate Work feed X,Y,Z: 10`000 mm/min Rapid feed X,Y,Z: 30`000 mm/min Working pressure force X,Y: 2000 N Working pressure force Z: 3300 N Pallet Dimensions: 400 x 300 mm Number of grooves: 2 Groove width: 14 mm Groove spacing: 80 mm Max. Table load: 100 kg Changeover time: 9 sec. Spindle Spindle motor power: 5 kW Speed: 10`000 rpm Tool changer Magazine slots: 16 Max. Tool diameter: 63 mm Max. Tool length: 150 mm Max. Tool weight: 4 kg Tool change time: 1.7 sec Itsdpfx Ajq U Rm Hjg Ajn Weight: Approx. 3000 kg No responsibility is taken for the correctness, completeness and up-to-dateness of the information.

Year of construction: 2012, condition: excellent (used), 1. SCOPE OF DELIVERY • Hasegawa PM 150 Compact – Machining center • Oil mist separator • Siemens fire extinguishing system 2. TECHNICAL DATA SPINDLE Spindle nose: HSK - E32 Speed: 100 – 30,000 rpm Itjdpfjgnkp Uox Ag Aen Motor: Spindle motor 3.0/4.5 kW TOOL CHANGER Capacity: 10 Tool change time: 1.8 sec WORKTABLE Working area: 300 x 260 mm T-slots: 12H7 x 5 Workpiece weight: 80 kg TRAVEL X-axis: 150 mm Y-axis: 225 mm Z-axis: 200 mm Rapid traverse: 30 m/min Dimensions: 630 x 1950 x 2670 mm We assume no liability for the accuracy, completeness, and up-to-dateness of the information provided.

Condition: good (used), Year of construction: 2007, functionality: fully functional, Technical details x-travel 1200 mm y-travel 600 mm z-travel 600 mm Control Heidenhain iTNC 530 spindle speed: 6000 1/min. spindle taper CAT-50 ISO spindle drive (S1) 10 kW table surface area 1300 x 600 mm table load 1200 kg feed speeds 1-10000 mm/min rapid travel x/y/z 20/20/15 m/min distance table - lower edge spindle 125-725 mm total power requirement 25 kVA weight of the machine ca. 7,5 t dimensions of machine 3600 x 2300 x 3000 mm Additional information Equipped with: * CNC control Heidenhain iTNC 530 * Electr. portable handwheel * Spindle oil cooler * Tool changer 24-pos., double arm changer - Max. tool diameter 80/150 mm - Max. tool length 250 mm - Max. tool weight 8 kg * Preparation for hydraulic machine vice * Preparation for 3-D measuring probes Ijdpfx Agoz Rplaj Ajtn * Chip conveyor * Coolant system, coolant through spindle 20 bar * Machine documentation Working hours (date 29. July 2026): - Control on: 60.822 h - Machine on: 59.602 h - Program cycle: 22.283 h - Spindel on: 19.522 h

Condition: good (used), Year of construction: 2009, CNC Machining Center Fanuc Robodrill α-T21iFa Itedexflr Hopfx Ag Aen TECHNICAL SPECIFICATIONS Manufacturer: Fanuc Model: Robodrill α-T21iFa Year of manufacture: 2009 Control: Fanuc Series 31i-MODEL A5 Spindle speed: up to 24,000 rpm Travel X-axis: 500 mm Travel Y-axis: 400 mm Travel Z-axis: 330 mm Rapid traverse X, Y, Z: 54 m/min Tool magazine: 21 positions Max. tool weight: 2 kg Total tool weight: 23 kg Max. tool diameter at 150–12,000 rpm: 80 mm Max. tool diameter at 12,000–15,000 rpm: 60 mm Max. tool diameter at 15,000–20,000 rpm: 45 mm Max. tool diameter at 20,000–24,000 rpm: 40 mm Permissible table load: 300 kg SCOPE OF DELIVERY Includes (not limited to): CNC machining center Fanuc Robodrill α-T21iFa Rotary unit for 4th and 5th axis Coolant pump and chip tray Exact scope of delivery according to photo series The Fanuc Robodrill α-T21iFa, built in 2009, is a versatile CNC machining center equipped with an additional 4th and 5th axis through the integrated rotary unit. This extension enables demanding multi-axis machining applications and significantly increases production flexibility. With a spindle speed of up to 24,000 rpm and travels of 500 x 400 x 330 mm, this machine provides ideal conditions for precise milling operations with high productivity. The 21-position tool magazine reduces setup times and allows for rapid tool changes. Thanks to its robust construction, a table load capacity of up to 300 kg, and the powerful Fanuc 31i control unit, this machine is perfectly suited for both series production and complex single parts. The integrated coolant system ensures process reliability and long tool life. No guarantee is given for the accuracy, completeness, or currency of the information provided.

Condition: used, Year of construction: 2019, Used machine Year of manufacture: 2019 Video available at: Base machine - Dynestic 7535-R Automatic 12.7 Dynestic table For classic nesting machining with wear plate Machining length: 3700 mm Working direction: from right to left Machine frame in welded construction with ground and hardened prism guides for the traversing carriage, aggregate head and consoles Traversing carriage in gantry design Rack and pinion drive, helical, in X and Y direction, Ball screw spindles Z-axis for precise positioning Technical data: Machining dimensions: Max. load on nesting table X = 3700 mm Y = 2200 mm Max. travel distances X = 5295 mm Y = 2935 mm Z = 565 mm Max. clearance height DYNESTIC table Z = 250 mm from the top of the table (without wear plate) Maximum programmable speed Vector speed: 128.0 m/min X = 80 m/min, Y = 100 m/min, Z = 25 m/min 4-stage extraction hood with pneumatic height adjustment and viewing window Voltage 400 V, 50/60 Hz CONTROL: Dual-core processor Operating system: Windows XP 80 GB hard drive / 1 GB RAM RJ45 network connection 10/100 Base-T Fast Ethernet US keyboard and Microsoft IntelliEye mouse (optical) CD-ROM / CD-RW drive (CD burner) Remote maintenance Integrated network card for data transmission of control and program data. Itedszt Twyepfx Ag Aon Data transmission via high-speed internet connection Requirement: High-speed internet connection to the machine. DYNESTIC table Solid, continuous machining table with grid spacing, continuous grooves in X and Y direction, Groove spacing: 50 mm with 25 meters of sealing cord for securing the wear plate 1 machining field with stop strips / stop Height: 30 mm, pneumatically lowerable 2 stop strips in Y direction and 1 stop in X direction on the right (when viewed from the front of the machine) Vacuum fields 1-circuit vacuum system Drilling unit 7881-R, 24 spindles Drive power 3.0 kW, incl. saw unit 18 vertical spindles individually selectable Arrangement in L-shape, 11+2 in X and 6 in Y direction 32 mm grid Max. drill diameter: 35 mm Total drill length: 70 mm from the mounting end (depending on plate thickness) Spindle extension stroke: 70 mm Rotation direction: alternating clockwise / counterclockwise n(max.) 1000 - 5710 min-1, infinitely variable Mount: M 10 thread - clearance fit 11 mm without tool, without mount 6 horizontal spindles 2 twin drill spindles in X direction (distance 32 mm between 1st and 2nd horizontal drill spindle) 1 twin drill spindle in Y direction Mount: M 10 thread, clearance fit 11 mm Total drill length max. 70 mm from the mounting end without tool, without mount Pressure booster, increases the standard pressure from 6 to 8 bar 5-axis milling unit 7844, Power: 10.0 kW (S6) cardanic, C-axis rotatable +/- 360°, A-axis rotatable +/- 180° n(max.) = 0 - 24000 min-1, infinitely variable, max. power at 12000 min-1 to 24000 min-1 Liquid cooling (cooling unit included) with HSK-F 63 tool holder with right-hand thread (for right-hand cutting tools) with collet chuck with HSK shank Ceramic ball bearings (hybrid bearings) Tool weight max. 6 kg (incl. holder) Tools:

Condition: used, TECHNICAL DETAILS - Number of axes : 5 - Number of spindles : 3 Itodpfxey I Dixj Ag Aen MAIN SPINDLE - Spindle power : 11 [kW] - Spindle speeds : 6000 [rpm] - Max. bar diameter : 52 [mm] - C axis indexing precision : 0.0001 [°] COUNTER-SPINDLE - Spindle power : 7.5 [kW] - Spindle speeds : 6000 [rpm] - Max. bar diameter : 38 [mm] - C axis indexing precision : 0.0001 [°] TURNING-MILLING SPINDLE - X/Z stroke : 455/800 [mm] - Y stroke : 105 [mm] - B Axis stroke : 120 [°] - B axis indexing precision : 0.0001 [°] - Tool type : HSK50 - Spindle speeds : 30000 [rpm] - Spindle power : 9 [kW] TOOL CHANGER - Tool magazine capacity : 76 LOWER TURRET - Number of positions : 10 - Number of motorized positions : 10 - Live tools speed : 6000 [rpm] POWER SUPPLY - Supply voltage : 380 [V] - Total installed power : 48 [kVA] MACHINE HOURS - Number of working hours : 18186 [h] EQUIPMENT - CNC : FANUC 31i MAPPSIV - Linear scales - Tailstock option with counterspindle - Tool probe - Workpiece probe : Renishaw - Bar loader : IEMCA KID 80 - Electric transformer
